CEL POWERminidriver User manual

User Manual
Innovation from
C Enterprise Ltd
Lithium Ion Screwdriver
LI1
POWERmini
driver

THANK YOU
domestic use
www.cel-global.com
Thank you for investing in a CEL product. The Li-Ion POWERmini driver
has been engineered and made to demanding high quality standards;
ease of operation and
Proper care of your product will give you years of trouble-free use.
Normal wear and tear, including accessory wear, is not covered under
guarantee. The product is guaranteed for against
manufacturing faults for a period of 12 months (for additional guarantee
period please refer to the store or agent from which you
purchased the product or contact the nearest authorized dealer). This
product is not guaranteed for HIRE purposes.
If you have any questions, please
ownload updated user manuals, view demonstration
videos and find information about new products at:
contact us at:
[email protected]
It is possible to d
: User must read and understand the user manual before using
the product to reduce the risk of injury. Failure to follow all instructions
may result in electric shock, fire and/or serious personal injury. The
product must be used only for its prescribed purpose. Any use other than
those mentioned in this manual will be considered a case of misuse. The
manufacturer shall NOT be liable for any damage or injury resulting from
such cases of misuse, use of force, partially or completely dismantled
appliances.
Warning
safety have taken a major role in development.
(if any)
3061583

GETTING STARTED
Manual Version: 2009-0A
Designed and edited in the UK
Printed in China
Contents
1.0 Important Safety Notes
2.0 Unpacking
3.0 Description of Parts
4.0
5.0 Li-Ion
Charging
Battery
USE
CARE
10.0 Storage
11.0 Environment
12.0 Frequently Asked Questions F.A.Q
13.0 Technical Specifications
6.0 Fitting a Driver Bit
7.0 Select Mode - Pistol or Driver
8.0 Change Drive Direction
9.0 Using the 2 Speed Trigger

Important Safety Notes
1.0
1. Work Area
2. Electrical Safety
3. Personal Safety
4. Tool Use and Care
5. Service
SPECIFIC SAFETY RULES
(1) Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
(2) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools
create sparks which may ignite the dust of fumes.
(3) Keep bystanders, children and visitors away while operating a power tool.
(1) A battery operated tool with integral batteries or a separate battery pack must be recharged only with the supplied charger for the
battery. A charger that may be suitable for one type of battery may create a risk of fire when used with another battery.
(2) Do not abuse the cord. Never use the cord to carry the tools or pull the plug from an outlet. Keep cord away from heat, oil, sharp
edges or moving parts. Replace damaged cords immediately. Damaged cords increase the risk of electric shock.
(3) Lithium-ion batteries can rupture, ignite, or explode when exposed to high temperature environments e.g. in an area that is prone to
prolonged direct sunlight. Short-circuiting a Li-ion battery can cause it to ignite or explode and any attempt to open or modify the casing
or circuitry is dangerous.
(1) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use tool while tired or under the
influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury.
(2) Dress properly. Do not wear loose clothing or jewellery. Contain long hair. Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery, or long hair can be caught in moving parts.
(3) Avoid accidental starting. Carrying tools with your finger on the switch invites accidents.
(4) Attach or remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left attached to a rotating part of
the tool may result in personal injury.
(5) Do not over-reach. Keep proper footing and balance at all times.
(6) Use safety equipment. Always wear eye protection. Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used
for appropriate conditions.
(1) Use clamps or other practical way to secure and support the workpiece to a stable platform.
(2) Do not force tool. Use the correct tool for your application.
(3) Do not use tool if switch does not turn it on or off.
(4) Place the switch in the locked or off position before making any adjustments, changing accessories, or storing the tools.
(5) Switch the tool off before making any adjustments, changing accessories, or storing the tool.
(6) Store idle tools out of reach of children and other untrained persons.
(7) When the tool is not in use, keep it away from other metal objects like: paper clips, coins, keys, nails, screws, or other small metal
objects that can make a connection from one terminal to another.
(8) Maintain tools with care. Keep cutting tools sharp and clean.
(9) Check for misalignment or binding of moving parts, breakage of parts, and any other condition that may affect the tools operation. If
damaged, have the tool serviced before using.
(10) Use only accessories that are recommended by the manufacturer for your model.
(1) This product is only serviceable by the original manufacturer. Any attempt to service the product yourself will void any warranty and
may cause the product to malfunction.
• Hold tools by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring.
• ALWAYS wear ear protection when using the tool for extended periods
• NEVER place hands or other body parts near the drill bit or chuck during operation.
• NEVER touch or place your hands, fingers or other body parts near the tool's moving parts.
• Use correct tool. Don't force small tool or attachment to do the job of a heavy-duty tool.
• NEVER use a power tool for applications other than those specified in the Instruction Manual.
• NEVER allow the tool to be operated by children, individuals unfamiliar with its operation or unauthorized personnel.

Important Safety Notes
1.0
• Keep all screws, bolts and covers tightly in place. Check their condition periodically.
• Do not use power tools if the plastic housing or handle is cracked. Cracks in the tool's housing or handle can lead to electric shock.
Such tools should not be used until repaired.
• Blades and accessories must be securely mounted to the tool.
• NEVER use a tool which is defective or operating abnormally. If the tool appears to be operating unusually, making strange noises, or
otherwise appears defective, stop using it immediately and arrange for repairs by a CEL authorized service centre.
• Carefully handle power tools. Should a power tool be dropped or struck against hard materials inadvertently, it may be deformed,
cracked, or damaged.
• Do not wipe plastic parts with solvent. Wipe plastic parts with a soft cloth lightly dampened with soapy water and dry thoroughly.
• ALWAYS wear eye protection that meets the requirement of the latest revision of ANSI Standard.
1. This manual contains important safety and operating instructions for supplied battery charger.
2. Before using battery charger, read all instructions and cautionary markings on (1) battery charger and (2) product using battery.
3. To reduce risk of injury, charge only the POWERmini driver. Other types of batteries or products may burst causing personal injury
and damage.
4. Do not expose battery charger to moisture.
5. Use of an attachment not recommended or sold by the battery charger manufacturer may result in a risk of fire, electric shock, or
injury to persons.
6. To reduce risk of damage to electric plug and cord, do not pull by cord when disconnecting battery charger.
7. Make sure cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress.
8. Only plug in to a safe power outlet in a safe location.
10. Do not operate battery charger if it has received a sharp blow, been dropped, or otherwise damaged in any way; take it to a
qualified service centre.
11. Do not disassemble battery charger; take it to a qualified service centre when service or repair is required. Incorrect reassembly
may result in a risk of electric shock or fire.
12. To reduce risk of electric shock, unplug charger from receptacle before attempting any maintenance or cleaning. Removing the
battery will not reduce this risk.
You must charge the battery before you can use the cordless driver. Before using the battery charger, be sure to read all instructions
and cautionary statements on it, the POWERmini driver and in this manual.
WARNING: Improper use of the battery or battery charger can lead to serious injury.
To avoid these injuries:
1. NEVER disassemble the battery.
2. NEVER incinerate the battery, even if it is damaged or is completely worn out. The battery can explode in a fire.
3. NEVER short-circuit the battery.
4. NEVER insert any objects into the battery charger's air vents. Electric shock or damage to the battery charger may result.
5. NEVER charge outdoors. Keep the battery away from direct sunlight and use only where there is low humidity and good ventilation.
6. NEVER charge when the temperature is below 50°F (10°e) or above 104°F (40°e).
7. NEVER connect two battery chargers together.
8. NEVER insert foreign objects into the hole for the battery or the battery charger.
9. NEVER use a booster transformer when charging.
10. NEVER use an engine generator or DC power to charge.
11. NEVER store the battery or battery charger in places where the temperature may reach or exceed 104°F (40°C).
12. ALWAYS operate charger on standard household electrical power. Using the charger on any other voltage may overheat and
damage the charger.
KEEP THESE INSTRUCTIONS AND MAKE THEM AVAILABLE TO OTHER USERS AND OWNERS OF THIS TOOL!
IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CHARGER AND POWERmini driver
9. Do not operate battery charger with damaged cord or plug - replace them immediately.
REMEMBER: USE THE CHARGER ONLY ON THE POWERmini driver. OTHER TYPES OF BATTERIES MAY BURST AND
CAUSE INJURY!

packed
2
3
4
5
1
Your POWERmini driver box contains:
Case
Pocket Driver
Ratchet Adaptor (optional)
Bit Ball (9 bits)
Charger Adaptor
POWERmini driver
2
3
4
5
1
Unpacking
2.0

Charger Dock
Input
Charger Dock
Contacts
Mode Change
Buttons (2)
Charge
Indicator LED
POWERmini driver
Ratchet Adaptor
(optional)
Description of parts
3.0
Case and
Charger Dock
Charger Adaptor
LED Lights (2)
Direction Switch
2 Speed Trigger
Charger Input
Charger
Dock Contacts
Magnetic Bit Holder
9 Piece
Pocket Bit Ball

If the unit is damaged in any way do not
attempt to charge it and replace
immediately.
The POWERmini driver can be charged
either in the Charger Dock or through
the socket on the handle.
To charge on the Charger Dock:
To charge the POWERmini driver
directly from the charger:
The battery is not removable or
serviceable in this product.
Keep clear of any moisture, direct sunlight
or temperature extremes.
• Fully unwind the charger cable, plug into
a suitable mains outlet and switch the
power on.
• Fit the plug securely into the socket on
the charger dock.
• Place the POWERmini driver into the
dock so the contacts on the base of the
handle meet those in the dock. Ensure
there is no obstruction and the driver is
stable and secure.
• Fully unwind the charger cable, plug into
a suitable mains outlet and switch the
power on.
• Place the POWERmini driver in a safe
and dry place and insert the charger lead
into the handle of the unit.
Charging
4.0
The LED light on the handle of the
POWERmini driver will turn red while
the battery is charging and turn off
once the battery is fully charged.
LED
Contacts
Charger
Lead
Note: The LED light
will flash when the
battery capacity is
too low and needs
charging, or when a
charging error is
encountered.

Warning: Only use the charger supplied
with this product. Do not attempt to charge
this product with any other charger nor
attempt to charge any other product with
this charger, as it can cause damage and
will invalidate your guarantee.
The battery requires 5 hours to charge
fully from flat.
To keep the battery in prime condition it
is best to charge the battery every 3
months if stored.
Never store the unit with a flat battery.
The unit should ideally be stored
between 10º C and 24º C (50º F and 75º
F).
Lithium-ion batteries can rupture,
ignite, or explode when exposed to
high temperature environments e.g. in
an area that is prone to prolonged
direct sunlight. Short-circuiting a Li-ion
battery can cause it to ignite or explode
and any attempt to open or modify the
casing or circuitry is dangerous.
The battery will not be damaged if it is
charged for longer than 5 hours, but it is
advisable not to leave it on for more than
48 hours, as this might shorten the battery
life.
ONLY THE MANUFACTURER
CAN SERVICE THIS PRODUCT
Li-Ion Battery
5.0

The POWERmini driver has a 1/4inch
magnetic bit holder.
Fit the correct driver bit by placing into the
magnetic holder on the front of the
POWERmini driver.
Fit the optional Ratchet Adaptor into the
magnetic bit holder and press the sleeve
away from the driver to tighten a
bolt/fastening or pull toward the driver to
loosen the fastening To
Tighten
Fastening
6.0
Fitting a driver bit
To
Fastening
Loosen

Select mode - Pistol or Driver
Select the screw direction by pressing the
3 way switch.
The centre position will disable the motor
allowing only the LED lights to be
illuminated.
Change drive direction
8.0
Select the mode most comfortable to you
or most appropriate to the task.
This should be a smooth and easy motion,
if there is any resistance do not force the
unit, ensure both buttons are fully
pressed in and repeat.
The locking spindle feature on the
POWERmini driver is great for small
adjustments or to further tighten a
fastening. This feature is active while the
trigger is released, just twist the
POWERmini driver in the desired
direction.
Fully depress the round buttons on
both sides of the unit and rotate the
two body parts to the desired
orientation.
Take care not to trap your fingers when
changing from driver to pistol mode.
presspress
Twisting the
driver locks
the spindle
allowing
precise control
of the driver
bit.
LED
7.0

9.0
Using the 2 speed trigger
The
POWERmini
driver has a 2 speed trigger.
Ensure the correct direction has been selected
and the bit holder contains the appropriate driver
bit (see previous sections).
Do not allow the driver bit to slip on the fastening, doing
so will damage both the fastening and the driver bit.
Use the spindle lock feature if you are unsure if damage may
be caused (see Selecting Pistol or Driver Mode section).
Press the driver bit firmly into the fastening.
Press the trigger half way for half speed and half
torque.
Press all the way in for full speed and full torque.
Take care: Damage can be caused to items by overly
tightening fixings and fastening.

When the time comes to dispose of this product please consider the environment and
take it to a recognised recycling facility instead of disposing with general household
waste.
The driver contains a Lithium Ion (Li-Ion) battery which must be disposed of properly.
Call your local council, civic amenity site, or recycling centre for information on the
recycling and disposal of electrical products and Lithium Ion (Li-Ion) batteries.
Storage
10.0
Environment
For storage ensure the battery is fully charged, return all items to the case and place in a
dry place.
Never Store the Driver With a Flat Battery.
The battery should ideally be stored between 10ºC and 24ºC (50ºF and 75ºF).
11.0

FAQ 12.0
Do I need to fully discharge the battery
before recharging it?
When I pull the trigger the motor
doesn’t run, why?
Why does my driver stop sometimes?
Where should I keep my POWERmini
driver?
The driver can’t screw the fastening all
the way in, what can I do?
No the Li-Ion system has no memory
effect so you can charge it at any time.
The charge will be retained in storage for
much longer than older technology.
a) Check the 3 way direction switch, if it is
in the middle only the LED will light.
b) The Lithium Ion battery has a protection
circuit to prevent it from completely
discharging. The battery will provide
constant power then stop rather than
slowing down. Recharge fully.
In a dry place at a stable temperature
Try using the spindle lock feature, just
release the trigger and twist the entire unit
in the required direction.
For big jobs try
www.power8workshop.com
battery
See above.
between 10ºC and 24ºC (50ºF and 75ºF).
The kitchen drawer for example.
I keep stripping screw heads and
damaging the driver bits, what can I
do?
Where can I get replacement parts,
advice or help?
www.cel-POWERmini.com
Make sure you use the correct driver bit
for the brand of fastening you have,
Phillips head screws are different to cross
head screws. Use the 8 bladed bits for
Phillips screws. Press hard even when
removing screws.
Ask at your retailer or visit
What should I do if my POWERmini
driver gets wet?
.
How can I get my POWERmini driver
repaired if it is damaged?
Where do I find my serial number?
What is your returns policy?
Dry fully for several days in a warm but not
hot place before trying to charge or use
Contact your retailer.
On the right hand side of the upper
section.
See inside cover of manual.

13.0
- Up to 100 screws
- 4Nm
- High:200rpm / Low:100rpm
- 6.3mm 1/4inch
- 3.7V DC
- Lithium Ion
- Approx. 5 hours
- 100-240vAC 50/60Hz
- 5V DC 300mA
- 140x135x55mm
- (5.5x2.25x2.13")
- 0.67Kg (0.3lbs)
- LI1
Unit operating cycle with full battery
Maximum Torque
Speed
Bit Size
Battery operating voltage
Battery makeup
Charging period for fully discharged battery
Charger Input
Charger Output
Dimensions
Weight
Product Code
©Copyright C Enterprise Limited 2009
If you experience any problems with the product please contact
email: [email protected]
www.cel-POWERmini.com
3061583
C Enterprise Limited
Technical specifications
READ INSTRUCTION MANUAL
BEWARE OF FLYING
OBJECTS AND DEBRIS
GENERAL HAZARD
SAFETY ALERT
KEEP BYSTANDERS AWAY

C Enterprise Limited www.cel-global.com [email protected]
UK HK USA China Europe Australia Japan•• • • • •
C Enterprise Ltd
