Central Brass 0045-A User manual

MODEL NO. 0045-A
SINK FIXTURE
Brecksville, Ohio 44141
Phone: [phone] Fax: [phone]
www.CentralBrass.com
Central Brass
C O M P A N Y
06-20-2008
Installation Drawing
The sink faucet body is a solid brass casting designed for
ledge mounting. The body is polished and copper, nickel,
and chrome plated. The inlet supply connections are xed
at 8-inch centers. The inlets are 1-1/2 inch NPS female
pipe connections. The stems are all brass with a double
O-Ring seal and rubber seat washer. The canopy handles
are zinc die cast with a chrome plated nish. The 6-inch
swivel spout is brass with a chrome plated nish and is
tted with a water saving aerator that limits the ow rate.
The O-Rings and seals are rubber.
Flow Rate: 2.0 GPM @ 60 psi
ADA Compliant and Meets ASME A112.18.1M
ANSI/NSF 61/Section 9 Certied
O-Ring Compression 1/4-Turn Compression
0045-A 0045-A-Q
Certified to
ANSI/NSF 61 Section9

MODEL NO. 0045-A
SINK FIXTURE
Brecksville, Ohio 44141
Phone: [phone] Fax: [phone]
www.CentralBrass.com
Central Brass
C O M P A N Y
06-20-2008
Handle variations available
G-4147 (4-inch)
G-4149 (6-inch)
ELS - Sufx
Wrist 4-inch
EL - Sufx
Elbow 6-inch
Spout variations available
SU-363-MA
14-inch
A1 - Sufx
8-inch Brass Tube Spout
A2 - Sufx
10-inch Brass Tube Spout
A3 - Sufx
12-inch Brass Tube Spout
A4 - Sufx
14-inch Brass Tube Spout
H - Sufx replaces A for hose end
A6 - Sufx
8-inch Brass D-Spout
H - Sufx replaces A for hose end
SU-365-CA
8-inch
(Available in 5-inch)
Cast Brass Spout
Extension
Accessory
SU-2775-R-02
7-inch
SU-157-GSA
4 3/32 -inch Swivel
Availavle in Rigid
A9 - Sufx
5-inch Cast Brass Spout
H - Sufx replaces A for hose end
GSA - Sufx
4 3/32 Swivel Gooseneck Spout
GRA - Sufx
4 3/32 Rigid Gooseneck Spout
H - Sufx replaces A for hose end
SU-157-KSA
5 1/2 -inch Swivel
Availavle in Rigid
KSA - Sufx
5 1/2 Swivel Gooseneck Spout
KRA - Sufx
5 1/2 Rigid Gooseneck Spout
H - Sufx replaces A for hose end
Faucets with lever, wrist or el-
bow handles with compression
or ceramic stem cartridges are
ADA compliant.
Drinking water products tested and certied by
NSF International to ANSI/NSF Standard 61,
Section 9. Each product required to meet the
standard proudly exhibits the NSF logo.
Sufx Options
& Accessories
SU-2923-A
5-inch
5-1/16"
8.19"
3-61/64"
5"
1/64"
1-3/4"
7"
2-1/2"
5-5/8"
4-1/16"
9-13/16"
9O
9-15/16"
5-9/16"
5-3/4"
2
O

MODEL NO. 0045-A
SINK FIXTURE
Brecksville, Ohio 44141
Phone: [phone] Fax: [phone]
www.CentralBrass.com
Central Brass
C O M P A N Y
06-20-2008
Parts Breakdown
The parts listed in the parts breakdown above may not be
offered separately as replacement parts. Please review the
Replacement Parts page for the authorized replacement parts
that are available for this item.
#Part# Description
1 2831-CP Brass Faucet Body
2 263-BC Bronze Seat
3 1028-Y Nylon Gasket
4 104 Brass Seat Washer Screw
5 901-WN Seat Washer
6 453-FL Brass Left Thread O-Ring Stem
6 453-FR Brass Right Thread O-Ring Stem
7 1038-453 O-Ring
8 453-EWC Brass Left Thread O-Ring Bonnet
8 453-EWH Brass Right Thread O-Ring Bonnet
#Part# Description
9 523-C Handle Indexed “C”
9 523-H Handle Indexed “H”
10 107-F Brass Phillips Head Screw
11 1038-KN O-Ring
12 166-FN Stainless Steel Snap Ring
13 PF-782-D Brass Spout Nut
14 PF-2924 Brass Swivel Spout
15 30-M Female Aerator
16 2821-49 Brass Flange
17 2883-49 Brass Elbow
18 PF-2843-49 Brass Hex Spout Nut
19 PF-256-L Brass Spud
20 940-TRN Washer
21 SU-453-EL Left Thread O-Ring Stem Assembly
21 SU-453-ER Right Thread O-Ring Stem Assembly
22 SU-2883 Brass Flange Assembly
