CENTRAL BRASS MFG CO
2950East55thStreet,Cleveland,Ohio44127
Phone: [phone] Fax: [phone] Email: sales @CentralBrass.com
022503 I-0000
www.CentralBrass.com
Faucets with lever, wrist or elbow
handles and compression or ceramic
stem cartridges are ADA compliant.
Certified to
ANSI/NSF 61 Section9
0072 - A-Q Series
100072-A-Q Series
200072-A-Q Series
CONCEALED LEDGEMOUNT
KITCHEN SINK FAUCET
8-Inch Centers
Quarter-Turn Compression Stem Units

CENTRAL BRASS MFG CO
2950East55thStreet,Cleveland,Ohio44127
Phone: [phone] Fax: [phone] Email: sales @CentralBrass.com
022503 I-0000
www.CentralBrass.com
CENTRAL BRASS
INSTALLATION INSTRUCTIONS
1. Placetwolocknutsontofaucetbodyoneonhotandoneon cold side. Screw locknut down to
lowerportionofthreads,donottighten. Placegasketoneachlocknut.
2. Placelargelocknutoncenter spout portion of faucet body and screw down onto base. Place
gasketovercenterlocknut.
3. Insertfaucetbodyinsinkfromunderside.
4. Applyathincoatofplumbersputtytothebottomedgeofthecenterescutcheonand tighten
downuntilsnugwith sink.
5. Assemblespout to faucetbody. Tighten spout nutcarefully.
6. Loosencenter escutcheon untilclearancebetweenescutcheon and spoutnutis minimum.
Tightencenterlocknut on undersideofsink.
7. Applyathin coat of plumbers putty to the bottom edge ofthecornerescutcheonsandtighten
downuntilsnug. Tighten locknutsundersink.
9. Connectsupplylines to bottom inletsofvalvebody.Hottoleftside.
10.Turn on supply lines. Check allconnectionsforleakage.
11. Remove spout by looseningspoutnut,replacespout and remove aerator. Turnonhot and
coldwater for one minutetoflushout dirt and sedimentthatmighthave accumulated during
installation.
12. Reconnectspoutandreplaceaerator.
13. Checkallconnectionsforleakage.

CENTRAL BRASS MFG CO
2950East55thStreet,Cleveland,Ohio44127
Phone: [phone] Fax: [phone] Email: sales @CentralBrass.com
022503 I-0000
www.CentralBrass.com
1
2
3
4
*
*
*
56
7
8
9
*
A
B
*
12
11
10
13
C
14
15
16
17
18
REPLACEMENT
PARTS
*These items are not offered
individually and must be
purchased as a group or unit.
Please contact Central Brass
for more information.

CENTRAL BRASS MFG CO
2950East55thStreet,Cleveland,Ohio44127
Phone: [phone] Fax: [phone] Email: sales @CentralBrass.com
022503 I-0000
www.CentralBrass.com
OPTIONS & REPLACEMENT PARTS for options
REPLACEMENTPARTS
# Part Number Description
A G-523-C Lever Handle C Indexed with Screw (X107-F)
A G-523-H Lever Handle H Indexed with Screw (X107-F)
B G-454-EL Cold Quick-Pression Quarter-Turn O-Ring Stem Assembly with Gasket (X1028-Y)
B G-454-ER Hot Quick-Pression Quarter-Turn O-Ring Stem Assembly with Gasket (X1028-Y)
C SU-365-CA 8-Inch Swivel D-Spout with Aerator (30-M)
1 X107-F Handle Screw (25 pcs per pack)
2 524-B Escutcheon
3 X491-U Gasket (12 pcs per pack)
4 X53-AS Locknut (6 pcs per pack)
5 X1038-453 O-Rings (25 pcs per pack)
6 X901-WNN Stem Seat Washer (25 pcs per pack)
7 X104 Seat Washer Screw (25 pcs per pack)
8 X1028-Y Gasket (25 pcs per pack)
9 XPF-263-C Replacement Seat (2 pcs per pack)
10 30-M Aerator
11 XPF-782-D Spout Nut (2 pcs per pack)
12 X166-FN Snap Rings (6 pcs per pack)
13 X1038-KN Spout O-Ring (25 pcs per pack)
14 1012-N Spout Escutcheon
15 2985-J Centerpiece
16 X402-J Gasket (12 pcs per pack)
17 X491-S Gasket (12 pcs per pack)
18 X53-BS Locknut (6 pcs per pack)
Suffix
Number Replaces Item # Part Number Description
07 C SU-357-WSA 8 ¾ -Inch High-Rise Swivel Spout with Aerator (30-L)
7 C SU-1974-A 10-Inch Cast Spout with Aerator (30-M)
8 C SU-357-HSA 7 ¼ -Inch High-Rise Swivel Spout with Aerator (30-L)
TSA C SU-257-TSA Tri-Arc Swivel Gooseneck Spout with Aerator (30-M)
GRA C SU-157-GRA 4 3⁄32 -Inch Rigid Gooseneck Spout with Aerator (30-M)
GSA C SU-157-GSA 4 3⁄32 -Inch Swivel Gooseneck Spout with Aerator (30-M)
KRA C SU-157-KRA 5 ½ -Inch Rigid Gooseneck Spout with Aerator (30-M)
KSA C SU-157-KSA 5 ½ -Inch Swivel Gooseneck Spout with Aerator (30-M)
PF-741-DO Double O-Ring Adapter for the SU-157-KSA Spout
XPF-166-U Brass Adapter for the SU-157-KSA and SU-157-KRA Spouts
EL A G-4149-C or H 6-Inch Brass Wrist Handles – Index Blue (X107-FB) or Index Red (X107-FR)
ELS A G-4147-C or H 4-Inch Brass Wrist Handles – Index Blue (X107-FB) or Index Red (X107-FR)
X A G-1143-C or H Brass Canopy Handles – Index Blue (X107-FB) or Index Red (X107-FR)
X107-FB or FR Blue Index or Red Index (5 pcs per pack) Used for EL, ELS and X suffix’s
Prefix
Number Replaces Item # Part Number Description
10 A K-512-02 Handle Kit for Villager Collection with Chrome Lever ( one pair )
20 A K-512-15 Handle Kit for Villager Collection with White Lever ( one pair )
XSU-512-G-02 Handle Grip chrome plated (2 pcs per pack)
XSU-512-G-15 Handle Grip white (2 pcs per pack)

CENTRAL BRASS MFG CO
2950East55thStreet,Cleveland,Ohio44127
Phone: [phone] Fax: [phone] Email: sales @CentralBrass.com
022503 I-0000
www.CentralBrass.com
WRENCH
CENTRALBRASS
MAINTENANCEINSTRUCTIONS
4 Use Only Genuine
Central Replacement Parts
DISASSEMBLY REPLACEMENT
Replace Components In Reverse
Order of Disassembly
1
2
3
REMOVE STEM ASSEMBLY
1.Turnoffwater supply.
2.Removescrew.
3.Removehandle.
REMOVE HANDLE
REMOVESEAT
1. Insert 5/16" allen
wrench in seat.
2. Turn seat counter-
clockwise to remove.
1.Use adjustable
wrench.
2. Turn stem to open
position
3.Unscrew counter-
clockwise. Remove
stem unit.
Nylon
Gasket
G-454-ER Hot stem assembly 1/4 turn
G-454-EL Cold stem assembly 1/4 turn
XPF-263-C Replaceable Seat
 If faucet has round handles (G-398) or (70 or 80 suffixes) , use two Hot stem assemblies
 If faucet has lever handles, use one Hot and one Cold stem assemblies
