Central Pneumatic 60328 Original instruction manual

Page 2 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
Table of Contents
Safety .................................................2
Specifications .....................................8
Setup ..................................................9
Operation...........................................11
Maintenance......................................13
Parts List and Diagram......................18
Warranty ............................................20
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INSTRUCTIONS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS
The warnings and precautions discussed in this manual cannot cover all possible conditions
and situations that may occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be supplied by the operator.
WARNING – When using tools, basic precautions should always be followed, including the following:

Page 3For technical questions, please call 1-800-444-3353.Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETYOPERATIONMAINTENANCE SETUP
Work Area
a. Keep the work area clean and well lighted.
Cluttered benches and dark areas
increase the risks of electric shock,
fire, and injury to persons.
b. Do not operate the Compressor in
explosive atmospheres, such as in the
presence of flammable liquids, gases or
dust. Compressor motors produce sparks
which may ignite the dust or fumes.
c. Keep bystanders, children, and
visitors away while operating the tool.
Distractions are able to result in
the loss of control of the tool.
Electrical Safety
a. Compressor plugs must match
the outlet. Never modify the plug
in any way. Do not use any adapter
plugs with grounded Compressors.
Standard plugs and matching outlets
will reduce risk of electric shock.
b. Do not expose Compressor to rain or wet
conditions. Water entering a Compressor
will increase the risk of electric shock.
c. Do not abuse the cord. Never
use the cord for unplugging the
Compressor. Keep cord away from
heat, oil, sharp edges or moving
parts. Damaged or entangled cords
increase the risk of electric shock.
Personal Safety
a. Stay alert. Watch what you are
doing and use common sense when
operating the tool. Do not use the
tool while tired or under the influence
of drugs, alcohol, or medication.
A moment of inattention while operating the
tool increases the risk of injury to persons.
b. Do not overreach. Keep proper
footing and balance at all times.
Proper footing and balance enables better
control of the tool in unexpected situations.
c. Prevent unintentional starting.
Ensure the switch is in the off-position
before connecting to power source
or moving the Compressor.
d. Use safety equipment. Wear a
NIOSH-approved respirator
during use.
e.
Always wear eye protection.
Wear ANSI-approved
safety goggles.
Compressor Use and Care
a. Do not use the Compressor if the
switch does not turn it on and
off. Any Compressor that cannot
be controlled with the switch is
dangerous and must be repaired.
b. Disconnect the Compressor from
the power source before making any
adjustments, changing accessories,
or storing. Such preventive safety
measures reduce the risk of starting
the Compressor accidentally.

Page 4 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
c. Store an idle Compressor out of the reach
of children and do not allow persons
unfamiliar with the Compressor or these
instructions to operate it. A Compressor is
dangerous in the hands of untrained users.
d. Maintain the Compressor. Keep the
Compressor clean for better and safer
performance. Follow instructions for
lubricating. Keep dry, clean and free
from oil and grease. Many accidents are
caused by a poorly maintained Compressor.
e. Check for misalignment or binding of
moving parts, breakage of parts and
any other condition that may affect the
Compressor’s operation. If damaged,
have the Compressor repaired before
use. If damaged, have the tool serviced
before using. Many accidents are caused
by poorly maintained tools. There is a risk
of bursting if the tool is damaged.
f. Use the Compressor in accordance with
these instructions, taking into account
the working conditions and the work to
be performed. Use of the Compressor for
operations different from those intended
could result in a hazardous situation.
Service
Have your tool serviced by a qualified repair person using only identical replacement parts.
This will ensure that the safety of the tools are maintained.
Specific Safety Instructions
Air Compressor
1. Risk of injury - do not direct air
stream at people or animals.
2. Do not use to supply breathing air.
3. Keep Compressor well-ventilated.
Do not cover Compressor during use.
4. Do not leave Compressor unattended
for an extended period while plugged in.
Unplug Compressor after working.
5. Compressor head gets hot during operation.
Do not touch it or allow children nearby
during or immediately following operation.
6. Do not use the air hose to
move the Compressor.
7. The use of accessories or attachments
not recommended by the manufacturer
may result in a risk of injury to persons.
8. All air line components, including hoses,
pipe, connectors, filters, etc., must be
rated for a minimum working pressure
of 150 PSI, or 150% of the maximum
system pressure, whichever is greater.
9. Air hose fittings may get hot during use.
Allow fittings to cool before disconnecting.
10. Industrial applications must
follow OSHA guidelines.
11. This product is not a toy.
Keep it out of reach of children.
12. Operate unit on level surface.
Airbrush
1. Do not direct spray at people or animals.
2. Do not spray near open flames, pilot lights,
stoves, heaters, the air Compressor, or
any other heat source. Most solvents
and coatings are highly flammable,
particularly when sprayed. Maintain
a distance of at least 25 feet from the
air Compressor. If possible, locate the
air Compressor in a separate room.

Page 5For technical questions, please call 1-800-444-3353.Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETYOPERATIONMAINTENANCE SETUP
3. Read all of the information concerning
coating products and cleaning solvents.
Do not use chlorinated solvents
(e.g. 1-1-1 trichloroethylene and
dichloromethane, also known as
methylene chloride) to clean Airbrushes.
Many Airbrushes contain aluminum,
which reacts strongly to chlorinated
solvents. Contact the solvent or coating
manufacturer as needed regarding
potential chemical reactions.
4. Industrial applications must
follow OSHA requirements
5. Spraying hazardous materials may
result in serious injury or death.
Do not spray pesticide, acid, corrosive
material, fertilizer, or toxic chemicals.
6. Paints and solvents may be harmful or fatal if
swallowed or inhaled. Avoid prolonged skin
contact with solvents or paints as they will
irritate skin. After any contact, immediately
wash off exposed area with hot, soapy water.
7. Attach all accessories properly to the
tool before connecting the air supply.
A loose accessory may detach
or break during operation.
8. Install an in-line shutoff valve
to allow immediate control over
the air supply in an emergency,
even if a hose is ruptured.
9. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
10. People with pacemakers should
consult their physician(s) before use.
Electromagnetic fields in close proximity to
heart pacemaker could cause pacemaker
interference or pacemaker failure.
11. WARNING: The brass components of
this product contain lead, a chemical
known to the State of California to cause
birth defects (or other reproductive harm).
(California Health & Safety Code
§ 25249.5, et seq.)
12. WARNING: Handling the cord on this product
will expose you to lead, a chemical known
to the State of California to cause cancer,
and birth defects or other reproductive harm.
Wash hands after handling. (California
Health & Safety Code § 25249.5, et seq.)
SAVE THESE INSTRUCTIONS.

Page 6 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
Symbol Definitions
Symbol Property or Statement
PSI Pounds per square
inch of pressure
CFM Cubic Feet per Minute flow
SCFM Cubic Feet per Minute flow
at standard conditions
NPT National pipe thread, tapered
Symbol Property or Statement
NPS National pipe thread, straight
WARNING marking concerning
Risk of Eye Injury.
Wear ANSI-approved
eye protection.
WARNING marking concerning
Risk of Respiratory Injury.
Wear NIOSH-approved respirator.
WARNING marking concerning
Risk of Explosion.

Page 7For technical questions, please call 1-800-444-3353.Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETYOPERATIONMAINTENANCE SETUP
Grounding
TO PREVENT ELECTRIC SHOCK AND DEATH
FROM INCORRECT GROUNDING WIRE CONNECTION:
Check with a qualified electrician if you are in doubt as to whether the outlet is
properly grounded. Do not modify the power cord plug provided with the
Compressor. Never remove the grounding prong from the plug. Do not use the
Compressor if the power cord or plug is damaged. If damaged, have it repaired by a service
facility before use. If the plug will not fit the outlet, have a proper outlet installed by a
qualified electrician.
Grounded Compressors: Compressors
with Three Prong Plugs
3-Prong Plug and Outlet
1. Tools marked with “Grounding Required”
have a three wire cord and three prong
grounding plug. The plug must be
connected to a properly grounded outlet.
If the tool should electrically malfunction
or break down, grounding provides a low
resistance path to carry electricity away
from the user, reducing the risk of electric
shock. (See 3-Prong Plug and Outlet.)
2. The grounding prong in the plug is connected
through the green wire inside the cord to the
grounding system in the tool. The green wire
in the cord must be the only wire connected
to the tool’s grounding system and must
never be attached to an electrically “live”
terminal. (See 3-Prong Plug and Outlet.)
3. The tool must be plugged into an appropriate
outlet, properly installed and grounded in
accordance with all codes and ordinances.
The plug and outlet should look like those in
the preceding illustration.
(See 3-Prong Plug and Outlet.)
Extension Cords
1. Grounded tools require a three
wire extension cord.
2. As the distance from the supply outlet
increases, you must use a heavier gauge
extension cord. Using extension cords with
inadequately sized wire causes a serious
drop in voltage, resulting in loss of power
and possible tool damage. (See Table A.)
3. The smaller the gauge number of the wire,
the greater the capacity of the cord. For
example, a 14 gauge cord can carry a higher
current than a 16 gauge cord. (See Table A.)
4. When using more than one extension cord
to make up the total length, make sure
each cord contains at least the minimum
wire size required. (See Table A.)

Page 8 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
5. If you are using one extension cord for more
than one tool, add the nameplate amperes
and use the sum to determine the required
minimum cord size. (See Table A.)
6. If you are using an extension cord
outdoors, make sure it is marked with the
suffix “W-A” (“W” in Canada) to indicate
it is acceptable for outdoor use.
7. Make sure the extension cord is
properly wired and in good electrical
condition. Always replace a damaged
extension cord or have it repaired by a
qualified electrician before using it.
8. Protect the extension cords from sharp
objects, excessive heat, and damp or wet
areas.
TABLE A: RECOMMENDED MINIMUM WIRE GAUGE
FOR EXTENSION CORDS* (120/240 VOLT)
NAMEPLATE AMPERES
(at full load)
EXTENSION CORD LENGTH
25´ 50´ 75´ 100´ 150´
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
* Based on limiting the line voltage drop to five volts at 150% of the
rated amperes.
Specifications
Compressor
Electrical Rating 120V~ / 1.1A
Motor Speed 1,750 RPM
Power Cord 6'
Maximum Air Pressure 58 PSI
Air Outlet 1/8" - 27 NPT
Air Output 0.7 CFM @ 40 PSI
Airbrush
Working Air Pressure 25 - 60 PSI
Air Inlet 1/8" - 27 NPS
Nozzle Size .35mm
Spray Pattern Hairline to 1-1/2" Wide
Glass Jar Capacity 3/4 oz. (22cc)
Air Consumption 0.7 CFM @ 40 PSI

Page 9For technical questions, please call 1-800-444-3353.Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETYOPERATIONMAINTENANCE SETUP
Setup: Before Use
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of
this manual including all text under subheadings therein before set up or use of
this product.
Note: For additional information regarding the parts listed in the following
pages, refer to the Assembly Diagram near the end of this manual.
Functions
Power
Switch
Drain
Valve
Handle
Pressure
Gauge
Air
Outlet
Air
Hose
Water
Trap
Needle
Chucking
Nut
Air
Inlet
Lid
Fitting
Color
Stem
Lid
Adjustment
Screw
Trigger
Air Cap
& Nozzle
(Under
Protective
Cap)
Glass
Jar
Figure A

Page 10 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch “OFF” and unplug the Compressor from its electrical
outlet before assembling or making any adjustments to the Compressor.
Initial Airbrush Setup
1. The Airbrush may be shipped with a
protective plug covering the Air Inlet.
Remove this plug before set up.
2. Thread Lid onto empty Glass Jar. Gently
push Lid Fitting into Color Stem on Airbrush.
3. Metal Cup (28) may be used for excess
correctly thinned paint, and also for
solvent for cleaning Airbrush.
4. Metal Hanger (30) can be attached to a
secure surface and used to hang Airbrush
for drying, or when it is not being used.
Initial Compressor Setup
1. Designate an area that is clean and
well-lit. The work area must not
allow access by children or pets to
prevent distraction and injury.
2. Before operating, make sure Compressor
is set up in a well-ventilated area, on a
flat, level, solid surface well away from
any flammable objects, such as drapes.
3. Keep at least 12″ of space around
Compressor to allow for air circulation.
4. Route Power Cord from Compressor to
grounded wall outlet, along a safe path,
without creating a tripping hazard or exposing
the power cord to possible damage.
5. Insert power cord into grounded outlet.
6. Connect one end of Air Hose to
Air Outlet of Compressor.
7. Connect other end of Air Hose
to Air Inlet of Airbrush.
8. Turn on Power Switch and inspect
air connections for leaks.
9. Turn off and unplug Compressor,
then repair any leaks found.

Page 11For technical questions, please call 1-800-444-3353.Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETYOPERATIONMAINTENANCE SETUP
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of
this manual including all text under subheadings therein before set up or use of
this product.
TO PREVENT SERIOUS INJURY:
Do not adjust or tamper with any control or component in a way not specifically explained
within this manual. Improper adjustment can result in tool failure or other serious hazards.
Workpiece and Work Area Setup
1. Before spraying, mask nearby
objects not being sprayed and lay
cloths (not included) on floors.
2. Prepare workpiece according to
paint manufacturer’s directions.
Compressor Setup
1. Insert Power Cord plug into grounded outlet.
2. Connect one end of Air Hose to
Air Outlet of Compressor.
Note: Use this Compressor only with
Airbrushes; do not use this Compressor with
any other type of painting equipment.
Airbrush Setup
IMPORTANT: Only use paints
designed for use with an Airbrush.
Note: Proper paint mixture is essential.
Follow manufacturer’s directions. Most paints
will spray easily if they are thinned properly.
1. Thin paint according to manufacturer’s
directions and mix thoroughly.
2. Carefully strain paint through a paint strainer.
3. Fill Jar to no more than 3/4 full.
4. Thread Lid onto Jar.
5. Gently push Lid Fitting into
Color Stem on Airbrush.
Note: The Jar is held in place
with friction, not threading.
6. Connect Air Hose to Air Inlet.
7. Test the consistency by spraying
on a piece of scrap material.

Page 12 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
General Operation
Note: This Compressor will automatically
shut off on overload or under excessive heat.
Should this occur, turn Power Switch off. Wait
until the Compressor cools. Then, turn Power
Switch on to resume work.
Note: Drain Water Trap as needed:
With Compressor running, drain
moisture collected in Water Trap
by loosening nut at bottom of Drain
Valve. Moisture will be forced out.
IMPORTANT: Proper spraying technique
is ESSENTIAL to achieve good results.
1. Turn on Compressor’s Power Switch.
2. Press down on Airbrush Trigger to release air
from Nozzle. Slowly and gently draw back on
Trigger to release paint from Needle. The air
will atomize the paint and create a fine spray.
3. Continue to move Trigger back slowly
to achieve the consistency you
need for your spray technique.
4. Once you have achieved desired
consistency, you may fix the position
using Adjustment Screw.
Note: If Air Cap becomes clogged, move
Needle Chucking Guide back and forth.
5. Keep the distance from workpiece at about 3″
to 5″, depending on air flow and paint type.
6. For very fine detail work, you may decrease
the distance up to 1" from workpiece.
Note: The size of your spray pattern
will differ based on distance between
workpiece and Airbrush. The closer the
Airbrush is, the finer the pattern will be.
7. To avoid paint buildup, start moving Airbrush
before pressing Trigger.
When finished with the stroke, release
Trigger while still moving Airbrush. Doing this
will produce a smoother finish. Do not stop
moving Airbrush while spraying. If Airbrush
stops even briefly while spraying, paint can
build up and run down the workpiece.
CAUTION! Air hose fittings may get hot.
Allow fittings to cool before disconnecting,
or wear gloves to prevent burns.
8. When finished using the Compressor,
turn its Power Switch off. Release any
remaining air, then disconnect the Airbrush.
9. Perform maintenance on the
Compressor according to the
instructions on the following pages.
10. Clean Airbrush and Jar thoroughly
IMMEDIATELY after EVERY use, according
to instructions on the following pages.

Page 13For technical questions, please call 1-800-444-3353.Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETYOPERATIONMAINTENANCE SETUP
Maintenance Instructions
Procedures not specifically explained in this manual
must be performed only by a qualified technician.
Compressor Maintenance
TO PREVENT SERIOUS INJURY FROM COMPRESSOR FAILURE:
Do not use damaged equipment. If abnormal noise, vibration, or
leaking air occurs, have the problem corrected before further use.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch “OFF” and unplug the Compressor from its electrical outlet
before performing any inspection, maintenance, or cleaning procedures.
Inspection and Maintenance
Note: These procedures are in addition
to the regular checks and maintenance
explained as part of the regular operation
of the Compressor and air-operated tool.
1. BEFORE EACH USE, inspect the general
condition of the Compressor. Check for:
• loose screws,
• misalignment or binding of moving parts,
• damaged air supply hose,
• cracked or broken parts, and
• any other condition that may
affect its safe operation.
2. AFTER EACH USE:
a. Drain Water Trap:
• With Compressor running, drain moisture
by loosening nut at bottom of Drain
Valve. Moisture will be forced out.
• Turn off and disconnect Compressor
from its power source.
• Close Drain Valve.
b. Wipe Compressor with clean cloth.
3. EVERY THREE MONTHS:
Clean the Water Trap filter by
blowing with compressed air.
4. WARNING! If the supply cord
of this Compressor is damaged,
it must be replaced only by a
qualified service technician.
Storage
Store Compressor in a dry, secure area out of reach of children.

Page 14 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
Airbrush Maintenance
TO PREVENT SERIOUS INJURY:
Detach the air supply and safely discharge any residual air pressure in the airbrush before
performing any inspection, maintenance, or cleaning procedures, unless otherwise noted.
TO PREVENT INJURY:
Needles are very sharp. Use extreme caution when handling needles.
Inspection and Maintenance
Note: These procedures are in addition to the regular checks and maintenance
explained as part of the regular operation of the Compressor and air-operated tool.
1. BEFORE EACH USE, inspect the general
condition of the tool. Check for:
• bent needle,
• loose screws,
• misalignment or binding of moving parts,
• clogged nozzle,
• cracked or broken parts, and
• any other condition that may
affect its safe operation.
2. AFTER EACH USE, Clean Airbrush and
Jar according to following instructions.
Solvent Selection
Follow paint manufacturer’s
recommendations for cleaning, solvent type,
and disposing of used solvent.
WARNING! TO PREVENT FIRE,
IF A FLAMMABLE SOLVENT
NEEDS TO BE USED,
ADHERE TO THE FOLLOWING:
1. Follow solvent manufacturer’s clean up
instructions and safety precautions.
2. Flush Airbrush a full hose
length from Compressor.
3. If collecting flushed solvents in
metal container, transfer to nonmetal
container, and flush metal container.
4. Work far away from any ignition
sources in a vapor free area.
5. Keep class ABC fire extinguisher nearby.

Page 15For technical questions, please call 1-800-444-3353.Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETYOPERATIONMAINTENANCE SETUP
Cleaning and Lubrication
1. Empty Jar and clean it with solvent.
2. Turn on Compressor and
connect the Airbrush.
3. Fill Jar with solvent and spray it through
the Airbrush into a container. Once
Jar is empty, repeat the process until
the solvent comes out clean.
4. Disconnect Airbrush from Compressor.
5. Point Airbrush into spent solvent
container and depress Trigger again
to make sure no air remains.
6. Remove Nozzle and Needle and soak them
in solvent until clean. Use old toothbrush
and toothpicks to remove any paint.
CAUTION: Do not immerse Airbrush.
Note: Do not use metal objects to
clean Nozzle to prevent damage to
passages. If Needle becomes bent, have
it replaced by a qualified technician.
7. Use solvent to wipe down Airbrush body.
8. Lubricate Airbrush after cleaning.
A non-silicon oil or a light lubricant may be
used on threaded connections before storing.
Solvent Disposal
After cleaning, dispose of cleaning solvent according to solvent
manufacturer’s directions and local hazardous waste standards.
Storage
Store Airbrush in a dry, secure area out of reach of children.

Page 16 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
Airbrush Troubleshooting
Problem Possible Causes Likely Solutions
Poor Paint
Atomization
1. Low paint level.
2. Paint not properly thinned.
3. Clogged Nozzle.
4. Loose/damaged Needle.
1. Refill.
2. Thin paint.
3. Clean Nozzle.
4. Adjust or replace Needle.
Will Not Spray No pressure at Airbrush. Check air hoses.
Overspray
(Paint drifting
to unintended
objects.)
1. Improper application speed.
2. Improper distance from workpiece.
1. Move moderately and parallel.
2. Adjust distance.
Nozzle Leakage 1. Dirty Nozzle.
2. Worn or damaged Nozzle.
1. Clean Nozzle.
2. Replace Nozzle and/or Needle.
Air Leaking
from Nozzle
1. Dirty air valve/seat.
2. Sticking air valve.
3. Damaged air valve spring.
4. Worn/damaged air valve/seat.
1. Clean air valve/seat.
2. Lubricate air valve/seat.
3. Replace air valve spring.
4. Replace air valve.
Follow all safety precautions whenever diagnosing or servicing the tool.
Disconnect air supply before service.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND
ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE
MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF
ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO
THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE
PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES
THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED
AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR
REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF
REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.

Page 17For technical questions, please call 1-800-444-3353.Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETYOPERATIONMAINTENANCE SETUP
Compressor Troubleshooting
Problem Possible Causes Likely Solutions
The motor does
not work.
1. No electrical power.
2. Damaged power cord.
3. Electrical wiring within
the unit is defective.
4. Power switch is defective.
1. Plug power cord into a working,
120V~, grounded, electrical outlet.
2. Have a qualified service
technician replace power cord.
3. Have a qualified service technician
replace electrical wiring.
4. Have a qualified service technician
replace power switch.
The motor runs,
but it makes
irregular noises or
a knocking noise.
1. Bearing is loose or damaged.
2. Screws in the connection
rod are loose.
1. Have a qualified service
technician replace bearing.
2. Tighten screws, or replace
them if necessary.
Not enough pressure
when painting
or spraying.
1. Loose air connection(s).
2. Air hose is damaged.
3. Screws on cylinder
cover are loose.
1. Check all air connections, and
tighten them if necessary.
2. Replace air hose.
3. Tighten screws.
Poor spray pattern. 1. Loose air connections(s).
2. The paint is too thick.
3. The Airbrush nozzle
is plugged or dirty.
1. Check all air connections, and
tighten them if necessary.
2. Add paint thinner and mix thoroughly.
3. Clean or change the nozzle.
Motor runs properly,
but no air pressure or
lack of air delivery.
1. Valve plate is loose or out of
place.
2. Retainer ring is damaged
after excessive use
at high pressure.
1. Open the front cover and make
sure the valve plate is in the proper
position. Tighten screws if necessary.
2. Have a qualified service technician
replace the retainer ring.
Follow all safety precautions whenever diagnosing or servicing
the Compressor.
Disconnect power supply before service.

Page 18 For technical questions, please call 1-800-444-3353. Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
Airbrush Parts List and Assembly Diagram
Part Description Qty
1 Protective Cap 1
2 Air Cap 1
3 Nozzle 1
4 Air Cap Body 1
5 O-Ring 1
6 Packing 1
7 Packing Nut 1
8 Body 1
9 Adjustment Screw 1
10 Trigger 1
11 Rocker 1
12 Needle Adjusting Sleeve 1
13 Needle Chucking Guide 1
14 Valve Screw 1
15 Needle Chucking Nut 1
16 Needle Cover (Handle) 1
Part Description Qty
17 Needle Spring 1
18 Needle 1
19 O-Ring 1
20 Valve Rod 1
21 O-Ring 1
22 Spring 1
23 Valve Screw 1
24 Valve Body 1
25 Hose Connector Nut 1
26 O-Ring for Hose Connector 1
27 Hose Connector 1
28 Metal Cup 1
29 7mm Wrench 1
30 Metal Hanger 1
31 Glass Jar Assembly 1
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
43 6
2
1
19 7
910
811 13 17
15
12 14
16
21
20
22
23
18
31
28
29
30
5
24
25
26
27
25.
27.
26.

Page 19For technical questions, please call 1-800-444-3353.Item 60328
NOTICE
Clean the Airbrush IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Airbrush.
SAFETYOPERATIONMAINTENANCE SETUP
Compressor Parts List and Assembly Diagram
Part Description Qty
1A Power Switch 1
2A Front Cover 1
3A Power Cord 1
4A Capacitor 1
5A Rear Housing 1
6A Screw 4
7A Stator 1
8A Bearing 1
9A Rotor 1
10A Bearing 1
11A Foot 4
12A Front Housing 1
13A O-Ring 1
14A Cylinder Block 1
15A O-Ring 1
16A O-Ring 1
17A Pressure Switch 1
Part Description Qty
18A Handle 1
19A Screw 4
20A Cylinder Head 1
21A Connector 1
22A Water Trap/Air Pressure Gauge 1
23A Connector 1
24A Counterweight 1
25A Bearing 1
26A Connecting Rod 1
27A Snap Ring 1
28A Compression Ring 1
29A Piston 1
30A Valve Plate 1
31A Screw 1
32A Sleeve 1
33A Back Cover 1
Note: When ordering parts from
this diagram, add an -a suffix.

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with
transportation charges prepaid. Proof of purchase date and an explanation of the complaint
must accompany the merchandise. If our inspection verifies the defect, we will either repair or
replace the product at our election or we may elect to refund the purchase price if we cannot
readily and quickly provide you with a replacement. We will return repaired products at our
expense, but if we determine there is no defect, or that the defect resulted from causes not
within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]
