Central Pneumatic 41209 User manual

COIL ROOFING NAILER
7/8” TO 1-3/4” FASTENER LENGTH CAPACITY
Model 41209
ASSEMBLY AND OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
Copyright 2005 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
®
©
REV 05/05

Page 2SKU 41209 For technical questions, please call 1-800-444-3353.
Specifications
Save This Manual
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep this manual and invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp
or wet locations. Do not expose to rain. Keep work area well lit. Do not use
electrically powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do not
let them handle machines, tools, extension cords, or air hoses.
4. Store idle equipment. When not in use, tools must be stored in a dry location to
inhibit rust. Always lock up tools and keep out of reach of children.
5. Use the right tool for the job. Do not attempt to force a small tool or attach-
Item Description
Operating Air Pressure 65-100 PSI
Air Consumption 11 CFM (Non-continuous)
Magazine Capacity 120 Fasteners
Fastener Lengths / Gauge Size 7/8”, 1”, 1-1/4”, 1-1/2”, 1-3/4” – 11 Gauge
Air Inlet 1/4”-18 NPT
Trigger Mechanism Type Contact Safety Trip Mechanism
Sound Level 95dB
Tool Length 10-1/4”
Tool Width 4-3/4”
Tool Height 10-1/8”
Tool Weight 5.5 Pounds

Page 3SKU 41209 For technical questions, please call 1-800-444-3353.
ment to do the work of a larger industrial tool. There are certain applications for
which this tool was designed. It will do the job better and more safely at the rate
for which it was intended. Do not modify this tool and do not use this tool for a
purpose for which it was not intended.
6. Dress properly. Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically non-conductive clothes and non-skid foot
wear are recommended when working. Wear restrictive hair covering to contain
long hair.
7. Do not overreach. Keep proper footing and balance at all times. Do not reach
over or across running machines or air hoses.
8. Use eye and ear protection. Always wear ANSI approved impact safety
goggles and appropriate hearing protection. Wear a full face shield if you
are producing metal filings or wood chips. Wear an ANSI approved dust
mask or respirator when working around metal, wood, and chemical dusts
and mists. Other people in the work area must also wear ANSI approved
impact safety goggles.
9. Maintain tools with care. Keep tools clean for better and safer performance.
Follow instructions for lubricating and changing accessories. Inspect tool cords
and air hoses periodically and, if damaged, have them repaired by an authorized
technician. The handle must be kept clean, dry, and free from oil and grease at
all times. Do not operate a tool if any portion of the tool’s operating controls are
inoperable, disconnected, altered or not working properly.
10. Disconnect Air Hose and release any built-up air pressure. Never perform
service on the Nailer, clear jams, or disassemble with the air hose attached.
Always release any built-up air even after disconnecting hose. Disconnect the
Nailer when not in use.
11. Remove adjusting keys and wrenches. Check that keys and adjusting
wrenches are removed from the tool or machine work surface before attaching to
an air source.
12. Avoid unintentional starting. Be sure the trigger is in the Off position when not
in use and before plugging in. Do not carry any tool with your finger on the
trigger, whether it is attached to an air source or not. Do not point the tool to-
wards yourself or anyone whether it contains fasteners or not.
13. Stay alert. Watch what you are doing, use common sense. Do not operate any
tool when you are tired.
14. Check for damaged parts. Before using any tool, any part that appears

Page 4SKU 41209 For technical questions, please call 1-800-444-3353.
damaged should be carefully checked to determine that it will operate properly
and perform its intended function. Check for alignment and binding of moving
parts; any broken parts or mounting fixtures; and any other condition that may
affect proper operation. Any part that is damaged should be properly repaired or
replaced by a qualified technician. Do not use the tool if the trigger does not
operate properly.
15. Guard against electric shock. Prevent body contact with grounded surfaces
such as pipes, radiators, ranges, and refrigerator enclosures.
16. Replacement parts and accessories. This product is to be repaired and ser-
viced only by a qualified technician. When this product is serviced, only identical
replacement parts should be used. Use of any other parts will void the warranty.
Only use accessories intended for use with this tool. Approved accessories are
available from Harbor Freight Tools.
17. Do not operate tool if under the influence of alcohol or drugs. Read warning
labels if taking prescription medicine to determine if your judgement or reflexes
are impaired while taking drugs. If there is any doubt, do not operate the tool.
18. Use proper size and type extension cord. If an extension cord is required, it
must be of the proper size and type to supply the correct current to the compres-
sor without heating up. Otherwise, the extension cord could melt and catch fire,
or cause electrical damage to the tool. Check your air compressor’s manual for
the appropriate size cord. It is also possible that the use of an extension cord
may cause your circuit breaker to trip or your panel fuse to break. If this hap-
pens, either use the compressor without an extension cord or find a larger am-
perage circuit to use.
19. Maintenance. The maintenance outlined in the maintenance section should be
performed regularly. For your safety, this product should be serviced or repaired
regularly only by a qualified technician.
20. Compressed air only. Never use combustible gas as a power source.
21. Do not load nails with the trigger or safety depressed. Uninten-
tional firing may occur. Do not load nails when the air hose is connected
to the tool. Always assume the tool contains fasteners.
22. Disconnect air supply before loading the Nailer. Before reloading (or making
any adjustments to) the Nailer, make sure the compressed air is disconnected.
23. Fire fasteners into an appropriate work surface only. Do not attempt to fire
fasteners into surfaces too hard to penetrate. Do not drive fasteners on top of
other fasteners, or at too steep an angle. Fasteners can ricochet causing per-

Page 5SKU 41209 For technical questions, please call 1-800-444-3353.
26. Stay within air pressure capacity. Never operate the Nailer above 100 PSI.
27. Hold tool away from head and body. During operation the Nailer may kick
back causing injury.
28. Transport Nailer safely. Always disconnect air supply when moving the tool in
the workplace. Carry the tool by the handle to avoid contact with the trigger.
29. Avoid working alone. If an accident happens, an assistant can bring help.
Note: Performance of the compressor (if powered by line voltage) may vary depending
on variations in local line voltage. Extension cord usage may also affect the tool
performance.
sonal injury. Never fire the Nailer into the air, or point it toward yourself or an-
other person. Always wear ANSI approved safety goggles during use, mainte-
nance, and reloading.
24. Do not fire fasteners too close to the edge of a workpiece. They may split
the workpiece and fly free, causing personal injury.
25. Take caution, as some woods contain preservatives such as copper chro-
mium arsenate (CCA) which can be toxic. When stapling or nailing these
materials extra care should be taken to avoid inhalation and minimize skin con-
tact.
WARNING: Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contain chemicals known (to the State of Cali-
fornia) to cause cancer, birth defects, or other reproductive harm.
Some examples of these chemicals are:
* Lead from lead-based paints
* Crystalline silica from bricks and cement and other masonry products
* Arsenic and chromium from chemically treated lumber.
(California Health & Safety Code 25249.5, et seq.)
Warning: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may occur. It
must be understood by the operator that common sense and caution are factors
which cannot be built into this product, but must be supplied by the operator.

Page 6SKU 41209 For technical questions, please call 1-800-444-3353.
Note: To connect this tool, we recommend you use the included quick connector.
For smoother operation and to extend the life-span of the tool, put 3-5 drops of
pneumatic tool oil in the attached Air Plug (17) before each use.
Unpacking
When unpacking, check to make sure all parts shown in the Parts List on page
13 are included. If any parts are missing or broken, please call Harbor Freight Tools at
the number on the cover of this manual as soon as possible.
Operation
For best service, you should incorporate an oiler, regulator, and inline filter, as
shown in the diagram below. Hoses, couplers, oilers, regulators, and filters are all
available at Harbor Freight Tools.
TO
ROOFING
NAILER
Testing the Contact Safety Trip Mechanism
Warning: Even though the nailer should be empty during this procedure,
ALWAYS point the Nailer at a piece of scrap wood and wear ANSI
approved safety goggles when testing.
1. Make sure the tool is disconnected from the air supply.
2. Completely empty the Magazine (92) of brads.
3. The Nailer should not fire if the Nose (72) is not depressed against the workpiece.
4. Make sure the Trigger (42) and Nose (72) move freely, without sticking - see the
illustration on the following page.

Page 7SKU 41209 For technical questions, please call 1-800-444-3353.
5. Connect the air supply to the tool at the Air Plug (17). Set the regulator at the
recommended 65 PSI to 100 PSI. Do not to go over the maximum 100 PSI.
6. Test the tool by depressing the nose against the workpiece without pulling the
Trigger (42). The Tool must not cycle (fire). If it cycles (fires), stop immedi-
ately and have it repaired by a qualified service technician.
7. Hold the tool away or off of the workpiece. The Nose (72) of the tool should
return to its original position. Squeeze the Trigger (42). The tool should not
cycle (fire). If the tool fires, stop immediately and have it repaired by a qualified
service technician.
8. Depress the Nose (72) against the workpiece and squeeze the Trigger (42). The
tool must cycle (fire). Release the Trigger and squeeze it again. The tool must
cycle (fire). With the Trigger held, carefully lift the Nailer and press it against the
workpiece again. The tool must cycle (fire). If it fails to perform in the manner
explained in bold, have it repaired by a qualified service technician.
Loading Coil Nails
ALWAYS WEAR ANSI APPROVED IMPACT SAFETY GOGGLES WHEN
RELOADING OR DOING ANY OTHER MAINTENANCE ON THIS TOOL.
Other people in the work area must also wear ANSI approved impact safety
goggles.
Warning! Make sure the Nailer is not attached to the air hose whenever loading
the tool.
NOSE (72)
TRIGGER (42)
AIR PLUG (17)

Page 8SKU 41209 For technical questions, please call 1-800-444-3353.
2. Check the Magazine Post (95) inside the Magazine (92). The Magazine Post can
be adjusted up and down to use various lengths of nails from 7/8” to 1-3/4”:
A. 7/8” Long Nails
(Use top setting).
B. 1”, 1-1/4”, and 1-1/2” Long Nails
(Use middle setting).
C. 1-3/4” Long Nails
(Use bottom setting).
MAGAZINE COVER
(101)
MAGAZINE COVER (101)
(TURN TO ADJUST)
MAGAZINE (92)
MAGAZINE (92)
NAILS
1. To open the Magazine (92), press down on the Cover Hinge Pin (99) and swing
the Door (80) open to open the Magazine Cover (101).
MAGAZINE POST (95)
DOOR
(80)
DOOR
(80)
DOOR HINGE PIN (74)
FEED PAWL (61)

Page 9SKU 41209 For technical questions, please call 1-800-444-3353.
3. Place a coil of nails (not included) around the Magazine Post (95) in the
Magazine (92).
4. Uncoil enough nails to reach the Feed Pawl (61). Place the
second nail on the
coil between the teeth of the Feed Pawl, making sure the nail head fits in the slot
in the upper portion of the Feed Pawl.
5. Swing the Magazine Cover (101) closed. Then, close the Door (80). Make sure
the Door closes securely. If it does not engage, the nail head is not in the slot in
the upper portion of the Feed Pawl (61).
To Adjust The Shingle Gauge:
1. The Gauge (87) controls roof shingle spacing. To adjust the Gauge to work with
a particular width of shingles, use the accessory Hex Wrench (103) to loosen the
Screw (84) on the Gauge. Slide the Gauge forward or backward to the desired
spacing. Then, retighten the Screw.
BOTTOM
VIEW
SCREW
(84)
GAUGE
(87)
SHINGLE SPACING
Operating the Nailer
1. Attach the Nailer to the air supply at the Air Plug (17). Start your compressor and
check the pressure making sure it is set at the recommended 65-100 PSI and not
to go over the maximum 100 PSI.
2. To fire, place the nose of the Nailer on the workpiece. The Nailer should not fire if
the nose is not depressed. Once depressed, gently and briefly squeeze the
Trigger (42) once. WARNING: Do not fire repeatedly. Nails could bounce off of
one another, damaging the workpiece or causing PERSONAL INJURY.

Page 10SKU 41209 For technical questions, please call 1-800-444-3353.
3. WARNING: When the Trigger (42) is depressed, the Roofing Nailer will fire if the
Nose of the tool comes in contact with anything.
4. Do not press the Nose (72) of the Roofing Nailer against the work surface with
extra force. Allow the tool to do the work. Always allow the tool to recoil off the
workpiece.
5. Caution: While working on roofs, tar and dirt may build up on the Nose of
the Roofing Nailer. This can prevent normal operation. Remove buildup with a
non-flammable solvent. NEVER use gasoline or other flammable solvents. Do
not immerse the Roofing Nailer in an approved solvent beyond the height of the
nail heads, to avoid getting the solvent into the drive cylinder of the tool. Make
sure to dry off the Roofing Nailer before use. Any oil film left after cleanup will
accelerate tar buildup.
6. When finished using the Roofing Nailer, always disconnect the tool from its
compressed air supply. Empty the Magazine (92) completely of nails. Attempt to
fire the Roofing Nailer into a piece of scrap wood to ensure it is disconnected and
is incapable of firing any nails.
7. Make sure to store the Roofing Nailer in a clean, dry, safe location out of reach of
children.
ROOFING SHINGLE
NOSE (72)
TRIGGER (42)
AIR SUPPLY HOSE
(NOT INCLUDED)

Page 11SKU 41209 For technical questions, please call 1-800-444-3353.
Clearing Jams
1. Occasionally a nail may become jammed in the firing mechanism of the Roofing
Nailer, making the tool inoperable.
2. To remove a jammed nail, disconnect the Roofing Nailer from its compressed air
supply. Empty the Magazine (92) completely of nails. Attempt to fire the Roofing
Nailer into a piece of scrap wood to ensure it is disconnected and is incapable of
firing any nails.
3. Use a pair of needle nose pliers (not included) to remove the jammed nail (usu-
ally from the Feed Pawl (61) area). Replace the coil of nails into the Roofing
Nailer. Close the Magazine Cover (101) and Door (80) securely. Then, recon-
nect the air supply hose to the tool.
Anytime any maintenance or repairs are done (including clearing jams),
FIRST:
1. Disconnect the Nailer from the air hose.
2. Empty the Magazine (92) completely.
3. Attempt to fire the Nailer into a piece of scrap wood to ensure that it is discon-
nected and is incapable of firing any nails.
Anytime any maintenance or repairs are done,FIRST:
1. Disconnect the Nailer from the air hose.
2. Empty the Magazine (92) completely.
3. Attempt to fire the Nailer into a piece of scrap wood to ensure that it is discon-
nected and is incapable of firing any nails.
Inspection, Maintenance, and Cleaning
1. Inspect the Nailer frequently and lubricate periodically with Pneumatic tool oil,
then wipe dry.
Do not use detergent oil or additives as these lubricants will cause accelerated
wear to the internal seals.

Page 12SKU 41209 For technical questions, please call 1-800-444-3353.
Please Read the Following Carefully
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST
AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEI-
THER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION
OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO
MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO
REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/
OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS RE-
PLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNI-
CIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR RE-
PLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
2. Inspect the air supply filter, if present, before each use and clean or replace as
necessary.
Dirt and water in the air supply filter are major causes of pneumatic tool wear.
Use a filter/oiler for better performance and longer tool life. The filter must have
adequate flow capacity for the specific application.
3. Store the unit in a clean and dry location.
4. All maintenance, service, or repairs not listed in this manual are only to be
attempted by a qualified technician.

Page 13SKU 41209 For technical questions, please call 1-800-444-3353.
PARTS LIST
NOTE:
Some parts are listed and shown for illustration purposes only, and are not available individually
as replacement parts.
Part
#
Description Part
#
Description Part
#
Description
1 Screw (6mmx22mm) 38 Rocker 72 Nose
2 Cap Assembly 39 Roll Pin 73 Trip Foot Assy.
3 Gasket 40 Straight Pin (161) 74 Door Hinge Pin
4 Exhaust Bumper 41 Rocker Pin 75 Holding Pawl
5 Head Valve Spring 42 Trigger 76 Compression Spring
6 O-Ring 43 Roll Pin 77 Kickback Pawl
7 O-Ring 44 Trip Lever Guide 78 Screw (6mmx35mm)
8 Head Valve 45 Nut 79 Pawl Drive Pin
9 Head Valve Seal 46 Washer (Piston, Upper) 80 Door
10 Cylinder Sleeve 47 O-Ring 81 Latch Retainer Pin
11 O-Ring 48 Piston 82 Latch Spring
12 O-Ring 49 Washer (Piston, Lower) 83 Door Latch
13 Bullhead Ring 50 Driver 84 Screw (6mmx12mm)
14 O-Ring 51 Driver Guide (Front) 85 Lock Washer
15 Frame 52 Driver Guide (Back) 86 Piston Washer
16 Filter (Optional) 53 Drive Bumper 87 Gage
17 Air Plug (1/4” NPT) 54 Trip Cover 88 Gage Nut Plate
21 O-Ring 55 Elastic Stop Nut (M6x1) 89 Post Retainer
22 Handle End Cap 56 Screw (6mmx22) 90 Receiver Spring
23 O-Ring 57 Spring (Trip Lever) 91 Spring
24 O-Ring 58 Trip Lever 92 Magazine
25 Trigger Valve Cap Assy. 59 Screw (6mmx10mm) 93 Magazine Wear Clip
26 O-Ring 60 O-Ring 94 Spacer
27 O-Ring 61 Feed Pawl 95 Magazine Post
28 Trigger Valve 62 Roll Pin 96 Magazine Bushing
29 O-Ring 63 Hinge Pin Retainer 97 Washer
30 O-Ring 64 Retaining Ring 98 Platform Assy.
31 Trigger Valve Housing 65 O-Ring Feed Piston Cap 99 Cover Hinge Pin
32 O-Ring 66 Feed Piston Cap 100 Gauge Bracket
33 Poppet Orifice Plate 67 Feed Piston Bumper 101 Magazine Cover
34 Compression Spring
(3129)
68 Feed Piston 102 Cover Retainer
35 O-Ring 69 O-Ring Piston Stem 103 Hex Wrench
36 Trigger Stem 70 Spring (Feed Pawl) 104 Tool Oil
37 Trigger Valve Cap 71 Feed Pawl Pin

Page 14SKU 41209 For technical questions, please call 1-800-444-3353.
ASSEMBLY DIAGRAM
NOTE:
Some parts are listed and shown for illustration purposes only, and are not available individually
as replacement parts.
1
2
3
4
5
6
7
8
7
9
10
11
12
13
14
15
16 21 22 17
39
42
43
39
39
44
40
24
25
26
28
29
30
31
32
33
34
35
36
37
38
27
103
101
93
90
95
19796 95
94
93
92
63
99
45
46
47
48
49
50
51
52
53
54
55
291
90
89
88
87
86
85
84
57
56
100
102
56
57
58
59
73
72
74 77 78 79
80
81
82
83
63
76
75
63
78 71
70
69
68
236766
65
64
41
104 TOOL OIL NOT SHOWN.
