Certa CTSMARTIFLA User manual

SMART CORDLESS MICRO AIR
COMPRESSOR TYRE INFLATOR
CTSMARTIFLA

Read these instructions carefully before using this product for the first time. Retain this user
guide for future reference.
• This product is suitable for the inflation of small cars tires, motorcycle tire, bicycle
tire, balls, swimming rings and other inflatables
• The product and hose can get hot during extended usage.
• To a v o i d o ve r-inflation and potential injuries, always confirm the required air
pressure of the item before inflating.
• The product has a built-in non-removable lithium battery. Do not place this product
into fire or discard it with household waste. The battery may cause spontaneous
combustion or explosion due to overheating, impact and water ingress.
• Avoid storing this product in high temperature environments.
• Do not bend or step on the hose during inflation.
• Do not leave the product unattended during operation. Always pay attention to
avoid over-inflating.
• Do not expose the product to moisture, heavy falls, water immersion and mud or
sand ingress.
• This product contains a DC motor which may generate electric sparks during
operation. Do not place it near flammable liquids or gases during operation.
• Ensure the product is stored between -10°C ~ 45°C.
• Excessive heat or cold will shorten the life of the product and damage the battery.
• It is recommended to charge the battery it at least once every 3 months.
• This product is not a toy. Do not allow children to play with it.
• Ensure children and pets are supervised and kept at a safe distance during
operation.
• Before setting the air pressure value, ensure that you have selected the correct unit
of measurement, otherwise it may lead to over-inflation and potential injury.
SAFETY & WARNINGS

1
Valve
7
Battery indicator
2
Hose
8
Mode button
3
To u c h screen
9
Light button
4
Hose storage port
10
Increase button
5
Light
11
Power button
6
Charging port
12
Decrease button
OVERVIEW

Turning On
Remove the air hose from the hose storage port. The inflator will automatically turn on. If
there is no input for 180 seconds the inflator will automatically turn itself off to converse
power. Press and hold the power button to turn the inflator back on.
Turning Off
When you have finished using the inflator, replace the hose back into the hose storage jack.
The hose will ‘click’ back into position and after 10 seconds will turn off.
Alternatively pressing and holding the power button will turn off the inflator.
Battery Indicator
The battery indicator light is always on and uses different colours to indicate the current
power level:
• Solid blue light: battery power ≥30%
• Solid red light: battery power 20% - 30%
• Flashing red light: battery power <20% needs to be charged
Charging
• The battery will need to be fully charged before first use.
• Plug the supplied charging cable into a 5V 2A adaptor
(mobile phone charger).
• Plug the charging cable into the charging port on the
bottom of the inflator
• The battery indicator uses different colours to indicate
the charging status:
o Blue light flashing: battery charging
o Green light: battery fully charged
GETTING STARTED
Indicator

Air Valves and Needle
Schrader valve:
Standard valve, suitable for mountain bikes, electric bikes,
motorcycles and small cars tires.
Presta valve:
• Suitable for road bikes and some mountain bikes.
• Connect the presta valve to the schrader valve before inflating.
Air needle:
• Suitable for basketballs, footballs and other kinds of balls.
• Connect the air needle to the schrader valve before inflating.
Checking Air Pressure
With the inflator turned on, when you connect the valve to the inflatable the current air
pressure will be displayed.

Air Pressure Guide
In order to maintain user safety and avoid over or under inflating items, always check the
recommended air pressure of the product.
Below is a guide of recommended air pressure values for common products.
Category
Product Type
Recommended
Pressure Range
Bicycle
Folding bicycle tire
12, 14, 16-inch bicycle tire
20, 22, 24-inch bicycle tires
26, 27.5, 29-inch bicycle tire
700c road bike open tire
700c highway support lower tube tire
45-50psi
30-50psi
40-50psi
45-65psi
100-130psi
120-145psi
Motorcycle
Motorcycle tire
26-43psi
Car
Small car tire
31-40psi
Ball
Basketball
Football
Volleyball
Rugby
7-9psi
8-16psi
4-5psi
12-14psi
Preset Air Pressure Modes
The portable inflator features five different preset modes for inflating common products.
Press the mode button to switch between the different presets. Press and hold the mode
button to switch the unit of measure between “bar” and “psi”.
Free Mode
Default: 35psi.
Adjustable range: 3-150psi
Bicycle
Default: 45psi
Adjustable range: 30-65psi
Motorcycle
Default: 34psi
Adjustable range: 26-43psi
Car
Default: 36psi
Adjustable range: 26-50psi
Ball
Default: 8psi
Adjustable range: 4-16psi

Fine-tuning Presets
• After selecting the desired preset mode, press "+" or "-" to slowly adjust the air
pressure value.
• Press and hold "+" or "-" buttons to quickly adjust the air pressure value.
• When adjusting the preset value the number flashing indicates the preset target
and the solid number displays the current air pressure of the product.
Multifunction Light
The portable inflator features a multifunction light. Press the light button to switch between
a bright white light, red warning light and a red SOS light.
Inflating
Select the correct preset mode and connect the inflator to the product using the appropriate
valve or needle. Press the power button to begin inflating.
• The screen will display the current air pressure value.
• During operation the inflator will generate 75-80 dB of noise.
Note: It is completely normal for the hose and the body of the inflator to become hot
during operation. If the inflator has been used for an extended period of time, avoid
contact and allow it to cool before touching it with your hands.
Stopping the Inflator
When the air pressure reaches the preset air pressure value, the pump will automatically
stop. During the inflation process, you can also stop at any time by pressing the power
button.
Note: When inflating item such as balloon, toy balls, swimming rings and other products
with a recommended air pressure lower than range of the preset, the inflator will not
automatically turn off. Always inflate these items with caution.
OPERATION

Pressure range
0.2~10.3bar/3~150psi
Dimension (without hose)
70x140mm
Working temperature
Charging
0°C~45°C
Operation
-10°C~45°C
Storage temperature
-10°C~45°C
Battery capacity
2600mAh
Working noise
less than 75dB when 1m away
Input current
5V==2A
Charging interface
USB-C
Charging time
Less than 4 hours
Air pressure gauge accuracy
35±1.5psi
Common unit conversion: 1bar = 14.5psi, 1bar = 100kPa
SPECIFICATIONS

Problem
Solution
Slow inflation
1. Check the power is sufficient
2. Check if the air hose is leaking.
3. Check whether the connection at both ends of
the air hose are tight
Cannot inflate when turning on
1. Check whether the air hose is pulled out.
2. Check whether the power is sufficient
3. Check whether the current tire pressure value is
higher than the preset value
Cannot increase or decrease
the preset pressure
1. Check whether you are in the correct preset
mode,
2. Select the free mode without any icon lit and the
preset value can be adjusted within the range of
3-150psi
Normal inflation but screen
displays 0
Balloons and other low-pressure inflatable products
are not within the measurable range of the device
The air pump has shut down
automatically after screwing
the valve adaptor
Press and hold the power button to turn on again
Air leaking when connecting the
hose
Tighten the hose
The colour of the battery
indicator during operation is
inconsistent with the standby
mode.
Sometimes the lithium battery has a significant
voltage drop during operation, which results in a
colour inconsistency of the indicator. This
phenomenon is not a malfunction.
TROUBLESHOOTING

NOTES

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com.
