Challenge Xtreme CSD36L.1 User manual

CSD36L.1
ORIGINAL INSTRUCTIONS
3.6V LIThIUm ION
SCRewDRIVeR

HELPLINE NO 08448012949
2
ORIGINAL INSTRUCTIONS
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING: Read all safety
warnings and all instructions.
Failure to follow the warnings and
instructions may result in electric shock, re
and/or serious injury.
Save all warnings and instructions for
future reference.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in
explosive atmospheres, such as in the
presence of ammable liquids, gases
or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose
control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power tools.
Unmodied plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric
shock if your body is earthed or
grounded.
c) Do not expose power tools to rain
or wet conditions. Water entering a
power tool will increase the risk of electric
shock.
d) Do not abuse the cord. Never use
the cord for carrying, pulling or
unplugging the power tool. Keep cord
away from heat, oil, sharp edges or
moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk
of electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected
supply. Use of an RCD reduces the risk
of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired or
under the inuence of drugs, alcohol
or medication. A moment of inattention
while operating power tools may result in
serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing
protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying
the tool. Carrying power tools with your
nger on the switch or energising power
tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating
part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose
clothing or jewellery. Keep your
hair, clothing and gloves away from
moving parts. Loose clothes, jewellery
or long hair can be caught in moving
parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of

HELPLINE NO 08448012949
3
ORIGINAL INSTRUCTIONS
dust collection can reduce dust-related
hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use
the correct power tool for your
application. The correct power tool will
do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the
switch does not turn it on and off. Any
power tool that cannot be controlled with
the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories,
or storing power tools. Such preventive
safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power
tool’s operation. If damaged, have
the power tool repaired before use.
Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
g) Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger
specied by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of re
when used with another battery pack.
b) Use power tools only with specically
designated battery packs. Use of any
other battery packs may create a risk of
injury and re.
c) When battery pack is not in use, keep
it away from other metal objects,
like paper clips, coins, keys, nails,
screws or other small metal objects,
that can make a connection from one
terminal to another. Shorting the battery
terminals together may cause burns or
a re.
d) Under abusive conditions, liquid
may be ejected from the battery;
avoid contact. If contact accidentally
occurs, ush with water. If liquid
contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
6) SERVICE
a) Have your power tool serviced by a
qualied repair person using only
identical replacement parts. This will
ensure that the safety of the power tool is
maintained.
Screw driver and impact wrench safety
warning
Hold power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden
wiring. Fasteners contacting a “live”
wire may make exposed metal parts of
the power tool “live” and could give the
operator an electric shock.
Safety instructions for battery pack
a) Do not dismantle, open or shred
secondary cells or battery pack.
b) Do not expose cells or battery pack
to heat or re. Avoid storage in direct
sunlight.
c) Do not short-circuit a cell or a battery
pack. Do not store cells or battery pack
haphazardly in a box or drawer where
they may short-circuit each other or be
short-circuited by other metal objects.
d) Do not remove a cell or battery from its
original battery pack enclosure required
for use.

HELPLINE NO 08448012949
4
ORIGINAL INSTRUCTIONS
SYMBOLS
e) Do not subject cells or battery pack to
mechanical shock.
f) In the event of a cell leaking, do not allow
the liquid to come in contact with the skin
or eyes. If contact has been made, wash
the affected area with copious amounts
of water and seek medical advice.
g) Do not use any charger other than that
specically provided for use with the
equipment.
h) Observe the plus (+) and minus (–)
marks on the cell, battery and equipment
and ensure correct use.
i) Do not use any cell or battery pack
which is not designed for use with the
equipment.
j) Do not mix cells of different manufacture,
capacity, size or type within a device.
k) Keep cells and battery pack out of the
reach of children.
l) Seek medical advice immediately if a cell
or a battery pack has been swallowed.
m)Always purchase the correct cell or
battery for the equipment.
n) Keep cells and battery pack clean and
dry.
o) Wipe the cell or battery pack terminals
with a clean dry cloth if they become
dirty.
p) Secondary cells and battery pack need
to be charged before use. Always use
the correct charger and refer to the
manufacturer’s instructions or equipment
manual for proper charging instructions.
q) Do not leave a battery pack on prolonged
charge when not in use.
r) After extended periods of storage, it may
be necessary to charge and discharge
the cells or battery pack several times to
obtain maximum performance.
s) Secondary cells and battery pack give
their best performance when they are
operated at normal room temperature
(20°C ± 5°C).
t) Retain the original product literature for
future reference.
u) Use only the cell or battery pack in the
application for which it was intended.
v) When possible, remove the battery pack
from the equipment when not in use.
w) Dispose of properly.
To reduce the risk of injury, user
must read instruction manual
Wear ear protection
Wear eye protection
Wear dust mask
Warning
Indoor use only
Do not expose to rain or water
Do not burn
This product has been marked
with a symbol relating to removing
electric and electronic waste. This
means that this product shall not
be discarded with household waste
but that it shall be returned to a
collection system which conforms
to the European Directive 2002/96/
CE. It will then be recycled or
dismantled in order to reduce the
impact on the environment. Electric
and electronic equipment can be
hazardous for the environment
and for human health since they
contain hazardous substances.

HELPLINE NO 08448012949
5
ORIGINAL INSTRUCTIONS
12 3 4 5
6
7
8
9
10
11
12

HELPLINE NO 08448012949
6
ORIGINAL INSTRUCTIONS
COMPONENT LIST
1. Chuck
2. Battery capacity indicator
3. Battery capacity indicator switch
4. Charging indicator
5. Sight light switch
6. Soft handle
7. On/Off switch
8. Forward / Reverse switch
9. Sight light
10. Battery charging base
11. Bits holder
12. Bits
TECHNICAL DATA
Charger Voltage 230-240V~50Hz
Voltage 3.6V
No load speed 180/min
Battery capacity 1300mAh Li-Ion
Maximum Torque 3N.m
Machine Weight 0.3kg
Charging Time 3~5hr
NOISE INFORMATION
A weighted sound pressure 65dB(A)
A weighted sound power 76dB(A)
KPA&KWA 3.0dB(A)
Wear ear protection when sound pressure is over 80dB(A)
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined according to EN 60745:
Typical weighted vibration
Vibration emission value ah= 0.98m/s2
Uncertainty K = 1.5m/s²
WARNING: The vibration emission value during actual use of the power tool can
differ from the declared value depending on the ways in which the tool is used
dependant on the following examples and other variations on how the tool is used:
The tool being in good condition and well maintained.
The use the correct accessory for the tool and ensuring it is sharp and in good condition.
The tightness of the grip on the handles and if any anti vibration accessories are used.
And the tool is being used as intended by its design and these instructions.

HELPLINE NO 08448012949
7
ORIGINAL INSTRUCTIONS
This tool may cause hand-arm vibration syndrome if its use is not adequately
managed.
WARNING: To be accurate, an estimation of exposure level in the actual conditions
of use should also take account of all parts of the operating cycle such as the times
when the tool is switched off and when it is running idle but not actually doing the job. This
may signicantly reduce the exposure level over the total working period.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti vibration accessories.
Avoid using tools in temperatures of 100C or less.
Plan your work schedule to spread any high vibration tool use across a number of days.
ACCESSORIES
3-5hr charger 1
Screwdriver bits 9
(3 x at: 4,5,6mm 3 x cross: PZ1,PZ2.PZ3 3 x Phillips: PH1,PH2,PH3 )
We recommend that you purchase your accessories from the same store that sold you the
tool. Use good quality accessories marked with a well-known brand name. Choose the
type according to the work you intend to undertake. Refer to the accessory packaging for
further details. Store personnel can assist you and offer advice.

HELPLINE NO 08448012949
8
ORIGINAL INSTRUCTIONS
charger, the screwdriver should be ready to
use.
Fig.A1
Fig.A2
Important:
When charging, the charger and screwdriver
may become warm to the touch, this is
normal and does not indicate a problem.
OPERATING INSTRUCTIONS
Inspect the screwdriver before using to
ensure all parts are running smoothly and
there no abnormal sounds or sparks. Before
driving fasteners, check behind walls for
wire, other electrical hazards or plumbing.
Clear the work area of all parts and debris
that may cause injury by ying objects.
Securely x the object to be fastened in a
vice or otherwise clamp to avoid injury. Do
not attempt to hold work-piece by hand.
1. FITTING AND REMOVING BITS
To use any one of the short bits supplied,
insert the bit into the chuck as far as
possible. To remove the bit, simply pull it out
of the chuck. (See Fig.B)
RECHARGING BATTERIES
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
This tool is intended for the fastening
and loosening of bolts, nuts and various
threaded fasteners. This tool is not intended
for use as a drill.
A) CHARGING THE BATTERY
The battery charger supplied is matched to
the Li-ion battery installed in the machine.
Do not use another battery charger.
The Li-ion battery is protected against deep
discharging. When the battery is empty,
the machine is switched off by means of a
protective circuit: the tool holder no longer
rotates.
In a warm environment or after heavy use,
the battery pack may become too hot to
permit charging. Allow time for the battery to
cool down before recharging.
When the battery is charged for the rst
time and after prolonged storage, the
battery will only accept approximately 60%
charge. However, after several charge and
discharge cycles the battery will accept a
100% charge.
B) IMPORTANT NOTES FOR CHARGING
THE BATTERY
The battery in your new Screwdriver is not
charged when it leaves the plant. Therefore
it must be charged for 3~5 hours before
using the rst time!
C) CHARGING for CSD36L.1 (See Fig.
A1, A2)
Plug charger plug into a suitable power
outlet and afterwards place the screwdriver
onto the battery charger, the charging
indicator (Orange) (4) will illuminate at this
time.
Let the battery charge for 3~5hours. This
will give the battery a full charge, the
charger indicator (orange) will go out when
charging is complete. Then unplug the
charging plug from the wall socket and
remove the screwdriver from the battery

HELPLINE NO 08448012949
9
ORIGINAL INSTRUCTIONS
Fig.B
2. FITTING AND REMOVING SOCKETS
(SOLD SEPARATELY)
To use the socket, you can simply refer part
of ” tting and removing Bits”.
Just insert the socket into adaptor and
then put them together into bit holder. (See
Fig.C)
Fig.C
3. FORWARD / REVERSE SWITCH (See
Fig.D)
For drilling and screw driving use forward
rotation marked “►” (lever is moved to
the left). Only use reverse rotation marked
“◄” (lever is moved to the right) to remove
screws or release a jammed drill bit.
WARNING: Never change the
direction of rotation when the
chuck is rotating, wait until it has
stopped!
Fig.D
4. BATTERY CAPACITY INDICATOR (See
Fig.E)
You can press the battery capacity indicator
switch (3) to show the battery capacity.
When the battery capacity indicator (2)
lights up red the battery has less than 30%
of its capacity and should be charged.
Fig.E
a
b
c
a: Full power (green)
b: Full power but will require charging
shortly (yellow)
c: Needs charging (red)
5. USING THE SIGHT LIGHT (See Fig.F)
The sight light allows you to keep a clear
view under less illuminated circumstances.
To turn on the light simply press the sight
light switch. (Repeat to turn the light off
again)
NOTE: Please turn off the sight light after
using or the battery will be exhausted soon.
Fig.F
6. AUTOMATIC SPINDLE LOCK
The screwdriver chuck (1) is locked when
the On/Off switch (7) is not pressed.
This enables screws to be screwed in,
even when the battery is empty and allows
for the machine to be used as a manual
screwdriver.
Important:
When using it as a manual tool, do not
press the On/Off switch (7). Otherwise the
power tool can be damaged.

HELPLINE NO 08448012949
10
ORIGINAL INSTRUCTIONS
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Your tool requires no additional lubrication
or maintenance.
There are no user serviceable parts in your
tool. Never use water or chemical cleaners
to clean your tool. Wipe clean with a dry
cloth. Always store your tool in a dry place.
Keep the motor ventilation slots clean.
Keep all working controls free of dust.
Occasionally you may see sparks through
the ventilation slots. This is normal and will
not damage your power tool.

HELPLINE NO 08448012949
11
ORIGINAL INSTRUCTIONS
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.
If faults can not be remedied, contact the Helpline on 08448012949
GUARANTEE
This product is selected for DOMESTIC USE ONLY and not for business use.
This product is guaranteed against manufacturing defects for a period of 12 months. This
does not cover the product where the fault is due to misuse, abuse, use in contravention of
the instructions, or where the product has been the subject of unauthorised modications or
alterations, or has been the subject of commercial use. In the event of a problem with the
product within the guarantee period please return it to your nearest Argos store. If the item is
shown to have an inherent defect present at the time of sale, the store will provide you with
a replacement Your statutory rights remain unaffected.
Guarantor: Argos Ltd, MK9 2NW
Issue1 03/2012
