Challenger AD39 User manual

CHALLENGER SECURITY PRODUCTS
10 Sandersons Way,
Blackpool, FY4 4NB
Email: [e-mail]
Web: www.challenger.co.uk
Installation Guide of AD39 PIR&MW Intelligent Detector
AD39(wired)
AD39
AD39
AD39
AD39
AD39
series PIR&MW complex intrusion detector is the ideal motiondetector for
industrial,commercial, residence and so on, can be able to work in the most difficult
environment conditions and where high security is required while maintaining
unprecedented immunity to false alarms,also can be work out door because good
water-proof, will inform user automatically if it be damaged or can not work
normally. series adopt precise Fresnel lens lens technology produce 3D
protected area with high energy receiving rate and high sensitivity but no false alarm;
combining four sources anti-mask microwave head, can calculate motion's volume,
speed etc. so with high sensitivity distant range from 4m to 12m. also adopt IR
tube leading technology to make MW area and PIR area superposed. except special
detect technology, possesses protection device to avoid tampering or
damaging. in it's working state,possesses functions as below:
Due to our policy of continuous improvement we reserve the right to change specification without prior notice. Errors and omissions excepted.
These instructions have been carefully checked prior to publication. However, no responsibility can be accepted by Challenger for any
misinterpretation of these instructions.
INSTALLATION INSTRUCTION
challenger_AD39_Instructions_Rev01

4.change lens, input 4 fixed fasteners in frame, matching the hole.
5.put lens frame back to cover, and fixed lens frame using screw.
6.install out side over, and fix screw of cover.AD39
Microwave can penetrate walls and ground, it can detect moving water in
plastic pipes or movement through walls.
