Chamberlain Security+ 974CB User manual

The Light Control is for indoor use only.
Exposure to moisture can cause electric shock
or fire.
Unplug receiver before opening cover to
set/change code.
WARNING
RATING
Resistive Load ......................................1200 Watts
Motor Load...................................................1/3 HP
Incandescent Lamp.................................600 Watts
The Plug-In Light Control is designed to operate
lights according to the rating chart shown. Please
read the instructions and power limitations carefully to
ensure proper use and maximum safety. NOT
recommended for use with toasters, coffee pots,
or halogen lighting systems.
This Light Control can be operated by Models 900
Series portable remote controls and Keyless Entries.
The Plug-In Light Control receiver needs to learn
the remote control code. Follow the instructions
below:
• Select a remote control push button to operate the
light control.
• Pry up the lower edge of the actuator with a coin or
screwdriver as shown.
• Plug the light control into a 120 Vac polarized
outlet. The plug contacts are designed for
polarized outlets only. The power indicator light will
turn on if there is power to the outlet.
• Press and hold the remote control push button you
chose to activate the light control.
• Then press and release the “Smart” (learn) button
on the receiver with a pen or pencil tip. The
adjacent yellow indicator light will FLASH once.
• Release the remote control push button. Code
setting is now complete. Snap actuator back on
light control.
The remote control push button must be held down
until the receiver indicator light flashes for the light
control to learn the remote control's code .
If the receiver SMART button is pressed and held
until the yellow indicator light alongside goes out (in
about 6 seconds), all memorized codes will be
erased.
Actuator
OPERATING INSTRUCTIONS
If two or more light products are installed, the
receivers must be located at least 10 feet apart to
prevent electronic interference.
• First, plug the lamp into a wall outlet and turn it ON.
• With the lamp still in the ON position, plug it into
polarized outlet on the light control. The bulb will
not light.
• TO TEST: Press and release the light control
actuator. The light should turn ON. Press the
remote control push button. The light should turn
OFF.
If the remote control does not activate the light, check
to be sure:
• You are pressing the remote control push button
selected to operate the light control.
• The remote control battery has power. Refer to the
remote control instructions for battery changing
information.
© 1997 The Chamberlain Group, Inc.
114A2240 All Rights Reserved Printed in Mexico
120VAC
Polarized
Wall Outlet
Smart
(Learn)
Button
Smart
Indicator
Light
Power Indicator
Light
Select a
push button
Model 974CB
Plug-In Light Control
OWNER’S INSTRUCTIONS
To comply with FCC rules, adjustment or modification of receiver and/or
transmitter is prohibited, except for changing the code setting and replacing
the battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.
®
