Champion UH-170B User manual

(2M) 9/07 Printed in U.S.A.
CH086
Undercounter High Temperature
Dishwashing Machine with
Built-in Booster Heater
UNDERCOUNTER
STANDARD FEATURES
• ENERGY STAR® Qualied
•NEW “Shear Energy” – a reduction in energy
requirements while maximizing performance!
•NEW “Multi-Phase” – allows for ineld conversion
from single to three phase electrical with ease!
• Rinse Sentry – extends the cycle time to ensure
180°F nal rinse.
• Built-in electric booster for 180°F nal rinse water
(standard 40°F or optional 70°F rise)
• Pumped drain
• Door safety switch
• Low-water tank heat protection
• Detergent and rinse aid pump
• Quiet double-wall construction
• Independent stainless steel interchangeable upper and
lower wash and rinse arms
• Fresh water rinse
• Top mounted slide-out controls
• Stainless steel top and side panels
• 90-second total cycle time
• Extended wash for dicult ware cleaning & de-liming
• Automatic drain cycle
• 1 Hp motor
• Stainless steel construction
SPECIFIER STATEMENT
Specied unit will be Champion model UH-170B
undercounter high temperature dishwashing machine
with built-in booster heater.
Features 90 second total cycle, extended wash, analog
controls, Rinse Sentry, detergent and rinse aid pump,
top and side panels. Constructed of stainless steel.
1 year parts and labor warranty.
Champion Industries, Inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: [phone] Fax: [phone]
www.championindustries.com
Project
Item No.
Quantity
NEW!
OPTIONS & ACCESSORIES
1-RDT Dish Table Durable, heavy-gauge
stainless steel dish table with sink, stand-pipe
drain, removable scrap screen holder, drain-
board, backsplash and lower storage cabinet.
Sprayhose is optional. See 1-RDT catalog sheet.
Specify right hand or left hand sink.
Additional Dish Racks
17” Stand
Stainless Steel
6” Leg Stand
3 Phase Connection
70°F Rise Booster
UH170 without Booster
Peg
Flat
UH-170 Model without Booster Heater

Undercounter High Temperature
Dishwashing Machine
with Built-in Booster Heater
UH170B
UH170B UNDERCOUNTER
Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice.
Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: [phone] • www.championindustries.com
Dimensions shown in inches and [milimeters]
Warning: Plumbing and electrical connections should be made by qualified personnel
who will observe all the applicable plumbing, sanitary and safety
codes and the National Electrical Code.
Note: Electrical supply
service must be a 3-wire
ground for connection
shown.
Field convertible to accept 3 phase power
Volume crated: 15 cu. ft.
Shipping weight crated: 215 lbs.
CHAMPION
UH170B
2" [51]
1
2
3
40-1/2"
[1029]
14-3/4"
[375]
Clearance
33-3/4"
[857]
24" [610]
15-3/4" [400]
4" [102]
25" [635]
1
2 3
CHAMPION
UH170B
2" [51]
1
2
3
40-1/2"
[1029]
14-3/4"
[375]
Clearance
33-3/4"
[857]
24" [610]
15-3/4" [400]
4" [102]
25" [635]
1
2 3
CHAMPION
UH170B
2" [51]
1
2
3
40-1/2"
[1029]
14-3/4"
[375]
Clearance
33-3/4"
[857]
24" [610]
15-3/4" [400]
4" [102]
25" [635]
1
2 3
SPECIFICATIONS
Capacities
Cycle time (seconds) 90
Racks per hr. (NSF) 30
Motor horsepower
Wash 1
Water consumption
U.S. Gal. per hr. (Max. use) 28.2
U.S. Gal. per rack .9
Temperatures °F
Wash 150
Rinse 180
Heating
Tank heat, electric, kW 2.0
Electric booster
(kW) required for 40°F rise) 6
Electric booster
(kW) required for 70°F rise) 9
Time Cycle in Seconds
Wash 70
Rinse 15
Total cycle 90
Standard 20” x 20” Rack Complement
Dish 1
Open 1
UH-170 without booster
750 watt tank heat
Elec. Rated
Specs. Amps
115/60/1 12
115V
115V208V
L1 L2 N G
Utilities
1Electrical
208-240/60/1; 3 wire plus ground, (See Box).
208-240/60/3; 4 wire plus ground, (See Box).
2Hot Water
1/2” supply; 140°F Min. hot water connection for 40°F rise booster; 110°F Min.
hot water connection for 70°F rise booster. Incoming supply pressure must
maintain a Flow pressure 20-22 PSI (Pressure reducing valve, PRV, supplied by
customer or may be purchased unmounted from Champion).
Machine equipped with 3/4” hose connector.
3Pumped Drain
5/8” I.D. flexible reinforced hose, 6 ft. long.
Max. drain flow 15 US gpm.
Max. drain height 3 ft.
UH-170B with 40°F/22°C Rise Booster
Elec. Specs.
Rated
Amps
Minimum
Supply Ckt.
Conductor
Ampacity
Maximum
Overcurrent
Protective
Device
208/60/1 32 40 40
240/60/1 36 40 40
208/60/3 22 30 30
240/60/3 24 30 30
UH-170B with 70°F/39°C Rise Booster
Elec. Specs.
Rated
Amps
Minimum
Supply Ckt.
Conductor
Ampacity
Maximum
Overcurrent
Protective
Device
208/60/1 45 60 60
240/60/1 50 60 60
208/60/3 29 35 35
240/60/3 33 40 40
Side ViewFront View Plan View
