Champion TMM5 Plus Operation manual

OWNER'S OPERATING AND MAINTENANCE MANUAL
1-800-237-3377
CHAMPIONCHAIR.COM
PROCEDURE-CHAIR SERIES
TMM5 Plus & TMM5 Plus-X
Document No. OM-TMM-2228-13 Rev W
W Wide
T Tall
L Low
F Folding Footrest
B Battery
A AC Power
TMM5 Plus
TMM5 Plus-X

Page 2 of 35
manual
Document No.: OM-TMM-2228-13 - Revision: W
FOLLOW INSTRUCTIONS GENERAL WARNING/DANGER
IMPORTANT
READ AND FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BEFORE
USING THIS PRODUCT!
Do NOT install, maintain or operate this equipment without reading and following this manual,
otherwise injury and/or damage may result.
IF YOU HAVE ANY QUESTIONS OR CONCERNS, PLEASE CONTACT CHAMPION MANUFACTURING,
INC.
Champion assumes no responsibility for damage or injury caused by improper assembly,
installation, use, or maintenance of these products.
No part of this manual may be duplicated in any form without the prior consent of Champion
Manufacturing, Inc. Unauthorized duplication/distribution of these materials may result in civil
prosecution to the maximum extent allowed by law.
The information contained in this manual is subject to change without notice.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
These instructions are available online at no charge.
Visit ChampionChair.com to download.
SYMBOLS
PINCH-POINT WARNING

Page 3 of 35
manual
Document No.: OM-TMM-2228-13 - Revision: W
TABLE OF CONTENTS
Important Notes about this Manual .......................................................................................... 2
Intended Use Statement.............................................................................................................. 4
Transportation, Storage, Handling & Disposal ........................................................................ 4
Preparation: Before You Begin.................................................................................................... 4
Power Cable Requirements........................................................................................................ 5
Safety Precautions ........................................................................................................................ 5
Labeling Diagrams (TMM5 Plus-B Shown) ............................................................................... 11
Options ...................................................................................................................................... 12
Operating Instructions.................................................................................................................. 13
Back Section Quick Release .................................................................................................. 13
Caster Brake Operation........................................................................................................... 14
Side Rail Operation.................................................................................................................. 15
Adjusting Side Rail Angle........................................................................................................ 16
Pendant (Controller) ............................................................................................................... 17
Patient Ingress/Egress ............................................................................................................ 19
Patient Transfer ........................................................................................................................ 20
Push Bar Operation ................................................................................................................. 20
Headrest Operation................................................................................................................. 21
Options............................................................................................................................................ 22
“W” Option: Wide Width ........................................................................................................ 22
“T” Option: Tall Height ........................................................................................................... 22
“L” Option: Low Height........................................................................................................... 22
“F” Option: Folding Footrest................................................................................................. 23
“B” Option: Battery Pack........................................................................................................ 24
“A” Option: Ac Power (For On-Board Batteries & Charger).............................................. 25
Support Leg Operation ........................................................................................................... 26
Cleaning Instructions.................................................................................................................... 28
Pad Removal Instructions............................................................................................................ 30
Preventive Maintenance .............................................................................................................. 30
Battery Safety & Charging Information ..................................................................................... 31
Specifications................................................................................................................................. 33
Service & Contact Information.................................................................................................... 34

Page 4 of 35
manual
Document No.: OM-TMM-2228-13 - Revision: W
INTENDED USE STATEMENT
TMM5 Procedure-Chairs are intended for use in patient treatment, transport and/or recovery within a hospital,
clinic, same-day/ambulatory surgery center, or similar environment.
The pendant control is NOT INTENDED FOR PATIENT USE.
A surgeon and/or clinician must always rely on his or her own clinical knowledge when deciding whether to use a
TMM5 Procedure-Chair when treating a patient.
TRANSPORTATION, STORAGE, HANDLING & DISPOSAL
• The product should be transported in factory packaging, inside an appropriate medium for the
destination, i.e., air/sea cargo containers.
• The product should be stored in an environment that will inhibit rust/mold formation.
• Champion Manufacturing, Inc. recommends not leaving the product in the factory packing in excess of
three (3) months.
• The product should always be handled in a manner consistent with the user instructions and in a
manner to prevent contamination after each use.
• The product has many recyclable components and to the extent practical, all effort should be used to
recycle responsibly. Otherwise the product components shall be disposed of in accordance with local
statutes.
PREPARATION: BEFORE YOU BEGIN
1. Carefully examine your product for any damage. Be sure to inspect all components.
IF DAMAGE IS EVIDENT, CONTACT FREIGHT CARRIER OR CHAMPION IMMEDIATELY.
2. Remove all packaging material and any hardware that was secured for shipping.
3. Carefully remove all components and any included tools and/or parts from the carton.
4. You may need to cut packaging materials with a box cutter or scissors to access the product. Use CAUTION
to avoid personal injury or damage to the product.
5. Save all boxes and packaging material until AFTER you have assembled your product and have verified that
all components are functioning properly. These materials are required if it becomes necessary to return the
product.
6. DO NOT install, maintain or operate this equipment without reading and following this manual otherwise
injury and/or damage may result. IF YOU HAVE QUESTIONS OR CONCERNS PLEASE CONTACT CHAMPION
MANUFACTURING, INC .
CHAMPION ASSUMES NO RESPONSIBILITY FOR DAMAGE OR INJURY CAUSED BY IMPROPER ASSEMBLY,
INSTALLATION, USE, OR MAINTENANCE OF THESE PRODUCTS.

Page 5 of 35
manual
Document No.: OM-TMM-2228-13 - Revision: W
POWER/CABLE REQUIREMENTS
Only use the power/charging cord that came with your product.
See also sections for options A & B for additional details regarding powering this product.
SAFETY PRECAUTIONS
IMPORTANT: PLEASE READ
WARNINGS
CHAIR OPERATION BY QUALIFIED, TRAINED MEDICAL PERSONNEL ONLY
The chair is intended to be operated only by qualified, trained medical sta. Operation of chair by unauthorized,
untrained and/or lay people must be avoided.
USE CAUTION ON RAMPS
Control chair when traversing ramps. If a collision occurs, serious injury to patient, bystanders, or medical
personnel and damage to chair or medical facility could occur.
LOCK CASTERS BEFORE PATIENT EGRESS/INGRESS
Prior to patient egress / ingress, casters must be locked by depressing red tab completely down on either le- or
right-side brake pedal.
AVOID PINCH POINTS AND OTHER INJURIES
To prevent serious injury, ensure extremities of patient and bystanders are clear of all mechanical systems when
operating motors for li and positioning functions.
To prevent pinch/crush injury, ensure extremities of patient and bystanders are clear of locking mechanism
when raising and lowering side rails.
To prevent patient strangulation, use approved hand pendant storage location when not in use. See PENDANT
section for additional information.
BATTERY CAN EXPLODE DUE TO OFF-GASSING WHEN CHARGING
At end of charging process (or with overcharge conditions), battery can produce mixture of explosive gases
(Including hydrogen and oxygen). Avoid exposing battery to open flames, cigarettes, sparks, and Incandescent
materials.
Never charge battery in enclosed, unventilated spaces.
Do NOT store battery in sealed container. Store in fresh, well-ventilated area protected from direct sunlight and
heat sources.
Do NOT use water to extinguish battery fire. Use dry powder, foam CO2 extinguisher.
WARNING

Page 6 of 35
manual
Document No.: OM-TMM-2228-13 - Revision: W
SAFETY PRECAUTIONS – CONTINUED
IMPORTANT: PLEASE READ
USE CAUTION WHEN STORING OXYGEN CYLINDER UNDER CHAIR
To prevent severe gas leakage or rupture of compressed gas cylinder, when placing cylinder under chair, ensure
adequate clearance between cylinder and its attached gas equipment (i.e. regulator, gauges, fittings, knobs) and
all adjustable chair sections and/or features (i.e. seat, back, leg, rails, actuators).
To prevent fire and/or explosive hazard, do not leave chair (and stowed oxygen equipment) near heat source.
To prevent gas equipment damage during transport, ensure cylinder sets in cradle properly and strap
mechanisms are secured tightly. Chair is intended to accommodate up to an E-size cylinder (4 3/8” outer
diameter x 25” length).
DO NOT PLACE EXCESSIVE WEIGHT ON ENDS
Position patient’s body weight uniformly over the patient surface. Use caution when shiing patient’s body
weight towards either end of the Procedure-Chair. Excessive weight on either end of the device could cause the
Procedure-Chair to become unstable.
Do not sit or stand on the ends of the Procedure-Chair. Instruct patients to not stand on footrest during egress or
ingress.
Due to the unique nature of each patient’s body shape, caregiver should exercise sound judgment when
positioning patient on the device.
WARNING

Page 7 of 35
manual
Document No.: OM-TMM-2228-13 - Revision: W
SAFETY PRECAUTIONS – CONTINUED
IMPORTANT: PLEASE READ
ACCESSORY WARNINGS
• To prevent serious injury and property damage, review Operating Manuals for all medical equipment and
accessories that may be used with, or attached to, this chair.
• Using the supplied accessories in the incorrect manner may cause patient, bystander, or facility harm.
• If chair is equipped with accessory belts, refer to the appropriate Field Installation and Usage Instructions
(provided with belts) for proper installation, use, and care.
• To prevent fire hazards, follow all precautions and operating procedures prescribed by suppliers of
oxygen administering equipment (i.e. oxygen gas regulators, tents, masks, cannulas, etc.)
• To prevent injury and property damage, total weight of items placed on “IV” pole must be less than 25
pounds.
• If mounting accessories to back surgical rails, ensure accessory is properly installed and securely
engaged prior to transporting patient or chair and prior to use. Only equipment approved by Champion
is to be mounted on surgical rails. Champion Manufacturing, Inc. is not responsible for damage and
assumes no liability caused by the use of unapproved equipment or accessories. Approved medical
equipment Includes tools, instruments, or scopes that are compatible with a 0.365” thick by 1.125” wide
surgical rail.
WARNING

Page 8 of 35
manual
Document No.: OM-TMM-2228-13 - Revision: W
SAFETY PRECAUTIONS – CONTINUED
IMPORTANT: PLEASE READ
CAUTIONS
DO NOT MODIFY CHAIR
Modifying chair can cause unpredictable operation resulting in injury to patient, medical personnel, or
bystander. Modifying chair will void warranty and may cause unsafe operating conditions.
USE SAFE OPERATING PROCEDURES
Prior to operating chair, ensure patient clearance by moving any overhanging equipment or moving chair from
under a table to prevent patient injury.
For TMM5 PLUS, chair must be at least 24 inches from nearest wall or obstruction to allow for full range of
activation.
Leave chair in lowest position whenever possible. This practice will decrease potential injury during an
unsupervised patient egress from chair.
Prior to patient transport in chair, raise side rails and ensure latching mechanism is in locked position. Medical
personnel must determine degree of restraint needed to ensure patient’s safety during transport.
For “F” Option Only: Since footrest is foldable (not locked in position), ensure protection of patient’s feet while
moving chair in close quarters (i.e. elevators, crowded hallways, procedure rooms).
INSPECT AND CLEAN CHAIR REGULARLY
Inspect cushions aer each use. Discontinue use if upholstery is ripped, cut, or torn, which could allow fluids
to enter cushion. This practice will prevent infection of patients and medical personnel and contamination of
medical equipment.
Do NOT use machine/pressure/power wash procedures on chair. Aer each use in a clinical setting, hand wash
all patient-contact surfaces (i.e. cushions, rails) and plastic base cover with warm water and mild detergent.
For “A” Option Only: For large fluid spills on chair, immediately unplug chair from AC wall outlet.
PLUG CHAIR INTO PROPERLY GROUNDED WALL OUTLET MARKED “HOSPITAL ONLY” OR “HOSPITAL
GRADE”
For “A” Option Only: Chair is equipped with hospital-grade three-prong plug for protection against electric shock
and must be plugged into properly grounded hospital-grade wall outlet.
MAXIMUM WEIGHT OF BACK SURGICAL BAR
The maximum weight capacity of each back surgical bar is 50 pounds. To prevent personal injury to patient, do
not mount equipment weighing more than 50 pounds to device. Weight of patient plus weight of equipment
should not exceed 500 pound weight capacity of the Procedure-Chair.
WARNING

Page 9 of 35
manual
Document No.: OM-TMM-2228-13 - Revision: W
SAFETY PRECAUTIONS – CONTINUED
IMPORTANT: PLEASE READ
EMI CAUTIONS
EMI MAY AFFECT CHAIR FUNCTIONALITY
Chair may be susceptible to EMI (Electromagnetic Interference) caused by electromagnetic energy emitted
from various sources, such as, radio and television stations, amateur radio (HAM) transmitters, citizen band (CB)
radios, hand-held “walkie-talkies”, security/police/fire transceivers and other communication devices. EMI can
cause chair to move by itself, or in an unintended fashion and can damage control system(s).
Intensity of interfering energy is measured in V/m (volts per meter). Chair can resist EMI up to a certain intensity,
called its “immunity level”. When the immunity level is higher, the less likely EMI will interfere with chair
operation. The chair has been certified to IEC 60601-1-2 Ed 4.1 Electromagnetic Disturbances – Requirements
And Tests.
In clinical environments devices can emit electromagnetic energy which becomes more intense as one moves
closer to energy source. To reduce chance of unintended movement or operation of chair, observe the following:
• Be aware of nearby high-power transmitters (radio and TV stations), MRI (magnetic resonance imaging)
systems, and NMR (nuclear magnetic resonance) imaging systems. Keep chair away from these areas.
• Do not operate hand-held transmitters near chair.
• Do not operate chair near others using hand-held transmitters.
• If unintended chair movement occurs, disconnect battery and move chair away from location.
WARNING

Page 10 of 35
manual
Document No.: OM-TMM-2228-13 - Revision: W
SAFETY PRECAUTIONS – CONTINUED
IMPORTANT: PLEASE READ
IMPORTANT
MAXIMUM PATIENT WEIGHT IS 500 lbs (227 kg)
Maximum patient weight capacity of chair is 500 pounds. If exceeded, damage to chair could occur.
CHAIR IS INTENDED FOR INDOOR USE ONLY
To ensure proper operation and extend chair life, only use chair in specified environment.
USE CDC’S UNIVERSAL PRECAUTIONS
When maintaining chair aer clinical use, service personnel must use UNIVERSAL PRECAUTIONS as defined by
CDC (Centers for Disease Control and Prevention).
MAINTAIN CHAIR REGULARLY
To ensure proper operation and extend chair life, inspect, maintain, and service chair on a regular basis.
Inspection, maintenance, and service details are located later in this manual.
REMOVE BATTERY DURING CHAIR STORAGE
For “B” Option Only: If chair is to be stored or not in use for four (4) days or more, remove battery pack from
chair. Refer to Battery Charger Installation and Usage Instructions (IM TMA57-15), under the “Cautionary Usage
Instructions” section, for more information.
For “A” Option Only: If chair is to be stored or not in use for four (4) days or more, leave chair plugged into an AC
wall outlet or unplug battery from control box. For more information, refer to “A” Option section below.
USE ONLY FACTORY APPROVED BATTERIES
Use of unapproved batteries will void warranty.
WARNING
