Channel Vision 6117 User manual

500-140 Rev B
Specifications:
Image Sensor:
Picture Elements:
Resolution:
S/N Ratio:
Min Illumination:
Electronic Shutter:
Iris Control:
Flickerless Mode:
Gain Control:
Back Light Comp.:
Gamma Characteristic:
Operating Temp:
Sony 1/3” Hi-Res Super HAD
NTSC: 768x494
550 lines
More than 48 dB
0.4 LUX @ F2.0
1/60s - 1/100,000s, ON/OFF Switch-able
Built-in DC Drive Iris Control
1/60s ON/OFF switchable
High/Low switchable
ON/OFF switchable
0.45
-10°C to 50°C (14°F to 122°F)
Specifications subject to change without notice.
Auto White Balance:
Camera Lens:
Focal Length & App. Ratio:
Angle Field of View:
Sync. System:
Power Requirements:
Power Consumption:
Video Output:
Color Temperature: 2500K-9500K
Vari-Focal with DC Drive Iris Lens
3.7mm-12mm, F1.6-3.0
Wide: 71.6°x55.8°, Tele: 23.8°x17.9°
Internal, Negative sync.
12VDC
195 mA
1 Vp-p @ 75 ohms
CHANNEL VISION
Limited Warranty
Channel Vision Technology will repair or replace any defect in material or workmanship which occurs
during normal use of this product with new or rebuilt parts, free of charge in the USA, for two years from
the date of original purchase. This is a no hassle warranty with no mail in warranty card needed. This
warranty does not cover damages in shipment, failures caused by other products not supplied by Channel
Vision Technology, or failures due to accident, misuse, abuse, or alteration of the equipment. This warranty
is extended only to the original purchaser, and a purchase receipt, invoice, or other proof of original
purchase date will be required before warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling [phone] toll free. A Return
Authorization number must be obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other rights (which vary from state to state).
If a problem with this product develops during or after the warranty period, please contact Channel Vision
Technology, your dealer or any factory-authorized service center.
6117
Vandal-Proof Color Dome Camera
8

2
Features:
High quality 1/3” Sony Hi-Res Super HAD CCD sensor
550 TV lines of resolution
Digital Signal Processor (DSP) chip-set provides image
control
High sensitivity, low smear, high anti-blooming and high
S/N ratio
Automatic Gain Control (AGC) and Auto White Balance
(AWB)
h
h
h
h
h
h3-Axis mechanism for easy rotation and adjustment
The is a vandal-proof color dome camera. Its extremely
rugged construction makes it ideal for CCTV installations
where the camera will be subjected to physical abuse.
Typical applications included factories, warehouses, and
other industrial buildings.
6117
Dome CoverDome Base & Camera
Zoom Focus
Power Supply
Hex Wrench
Screws
1. Tilt camera to
desired angle
2. Rotate camera to
desired direction
3. Rotate camera ring
so that the image
appears right side up
Adjusting the 3-Axis Mount
Rotate
Rotate
Top Top
Top
Tilt
3
Model
611
7
3. Adjust camera settings
4. Attach dome Camera Adjustments
1. Connect wiring
2. Mount base
Installation:
Using the wrench, loosen the 4 screws securing the
dome cover to the base.
Drill a hole in the wall or ceiling for wiring (see diagram).
If necessary, attach the camera’s video output to a coax
extension that is long enough to reach your monitor or
video distribution equipment.
If necessary, cut the connector off of the end of the power
supply and splice in an extension using crimp-on
connectors.
Mount the base with the provided screws.
Move the camera body to adjust the view and make
electronic adjustments using the dip switches.
Re-attach the dome cover by tightening the four screws
with the provided wrench.
h
h
h
h
h
h
h
2-Conductor power
supply extension
(not included)
Crimp-on splice
connectors
(not included)
To Monitor
or
Video distribution
Power supply
(included)
Coax extension
(not included)
BNC connector
FL: Flicker Lens ON/OFF
AGC: Auto Gain Control High/Low
AES: Auto Electronic Shutter ON/OFF
BLC: Back Light Compensation ON/OFF
VR Adjustment level for DC Drive Lens
(Switch AES OFF before adjusting)
