ChargePoint Express 200 User manual

ChargePoint Express 200 (CPE200)
Charging Station
ChargePoint, Inc.
254 E. Hacienda Ave.
Campbell, CA 95008-6617 USA
US toll free: [phone]
www.chargepoint.com
Installation Guide
Document P/N: 75-001150-01 Rev. 5

SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
This manual contains important instructions that must be followed during installation of a ChargePoint® Networked Charging Station.
Grounding instructions
The ChargePoint® Charging Station must be connected to a grounded, metal, permanent wiring system; or an equipment-grounding
conductor is to be run with circuit conductors and connected to the equipment grounding terminal or lead on the Electric Vehicle Supply
Equipment (EVSE). Connections to the EVSE shall comply with all applicable codes and ordinances.
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the manufacturer’s instruction manual, may cause harmful interference with radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which case, you will be required to correct the interference at your own expense.
Important: Changes or modifications to this product not authorized by ChargePoint, Inc., could affect the EMC compliance and revoke
your authority to operate this product.
Exposure to Radio Frequency Energy: The radiated power output of the 802.11 b/g/n radio and cellular modem (optional) in this device is
below the FCC radio frequency exposure limits for uncontrolled equipment. This device should be operated with a minimum distance of
at least 20 cm between the 802.11 b/g/n and cellular antennas and a person’s body and must not be co-located or operated with any
other antenna or transmitter by the manufacturer, subject to the conditions of the FCC Grant.
IC Compliance Statement - Déclaration De Conformité à la IC
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired
operation of this device.
Ce dispositif est conforme à la d'Industrie Canada (IC) exempts de licence RSS norme(s). Son fonctionnement est assujetti aux deux
conditions suivantes: (1) Ce dispositive ne doit pas provoquer de brouillage préjudiciable, et (2) il doit accepter tout brouillage reçu, y
compris le brouillage pouvant entraîner un mauvais fonctionnement.
FCC/IC Compliance Labels
Go to http://www.chargepoint.com/labels/.
Safety and compliance
This document provides instructions to install the ChargePoint® Charging Station and should not be used for any other product. Before
installing the ChargePoint® Charging Station, you should review this manual carefully and consult with a licensed contractor, licensed
electrician and trained installation expert to ensure compliance with local building practices, climate conditions, safety standards, and all
applicable codes and ordinances.
The ChargePoint® Charging Station should be installed only by a licensed contractor and a licensed electrician and in accordance with all
local and national codes and standards. The ChargePoint® Charging Station should be inspected by a qualified installer prior to the initial
use. Under no circumstances will compliance with the information in this manual relieve the user of his/her responsibility to comply with
all applicable codes or safety standards. This document describes the most commonly-used installation and mounting scenarios. If
situations arise in which it is not possible to perform an installation following the procedures provided in this document, contact
ChargePoint, Inc. ChargePoint, Inc. is not responsible for any damages that may occur resulting from custom installations that are not
described in this document.
No accuracy guarantee
Reasonable effort was made to ensure that the specifications and other information in this manual are accurate and complete at the time
of its publication. However, the specifications and other information in this manual are subject to change at any time without prior notice.
Warranty information and disclaimer
Your use of, or modification to, the ChargePoint® Charging Station in a manner in which the ChargePoint® Charging Station is not intended
to be used or modified will void the limited warranty. Other than any such limited warranty, the ChargePoint products are provided “AS
IS,” and ChargePoint, Inc. and its distributors expressly disclaim all implied warranties, including any warranty of design, merchantability,
fitness for a particular purposes and non-infringement, to the maximum extent permitted by law.
Limitation of liability
IN NO EVENT SHALL CHARGEPOINT, INC. OR ITS AUTHORIZED DISTRIBUTORS BE LIABLE FOR ANY INDIRECT, INCIDENTAL, SPECIAL,
PUNITIVE, OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION, LOST PROFITS, LOST DATA, LOSS OF USE, COST OF
COVER, OR LOSS OR DAMAGE TO THE CHARGEPOINT® CHARGING STATION, ARISING OUT OF OR RELATING TO THE USE OR
INABILITY TO USE THIS MANUAL, EVEN IF CHARGEPOINT, INC. OR ITS AUTHORIZED DISTRIBUTORS HAVE BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Copyright and trademarks
©2016–2017 ChargePoint, Inc. All rights reserved. This material is protected by the copyright laws of the United States and other
countries. It may not be modified, reproduced or distributed without the prior, express written consent of ChargePoint, Inc.
CHARGEPOINT is a U.S. and European Union registered trademark and service mark of ChargePoint, Inc. and can not be used without the
prior written consent of ChargePoint. All other products or services mentioned are the trademarks, service marks, registered trademarks
or registered service marks of their respective holders. ChargePoint, Inc. has several patents filed.

1 - 1
Contents
1Introduction
Before you begin ...............................................................................................1-1
Grounding instructions ....................................................................................1-1
Specifications .....................................................................................................1-2
Handle with care ............................................................................................... 1-3
Note on electrical power ................................................................................1-4
2Planning your installation
Charging cable proximity ...............................................................................2-1
Conduit locations ............................................................................................. 2-2
Above ground conduit ................................................................................... 2-3
Stand alone charging station .......................................................................2-4
Adjacent walls or obstacles .......................................................................... 2-5
Back-to-back charging stations ..................................................................2-6
3Installing the CPE200
Tools included ................................................................................................... 3-1
Materials included .............................................................................................3-1
Tools you will need .......................................................................................... 3-1
Materials you will need .................................................................................. 3-2
Overview of Steps ........................................................................................... 3-2
Step 1: Positioning and unpacking the shipping crate ......................... 3-3
Step 2: Positioning the CPE200 vertically ...............................................3-4
Step 3: Removing the fan .............................................................................. 3-5
Step 4: Removing the shipping baseplate ............................................... 3-7
Step 5: Securing the CPE200 to the prepared concrete pad ............3-8
Step 6: Removing the front panel ..............................................................3-9
Step 7: Removing the service covers ...................................................... 3-10
Step 8: Running conduit and service wiring ...........................................3-11
Step 9: Connecting the wiring ....................................................................3-13
Step 10: Preparing the CPE200 for operation ...................................... 3-14
Step 11: Verifying correct operation ......................................................... 3-16

ChargePoint Charging Stations
1-2
4Preparing the Station for Activation on ChargePoint
Before You Start ...............................................................................................4-1
Overview of Steps ............................................................................................4-1
Pinpoint the Station ........................................................................................4-2
Complete the Post-installation Checklist .................................................4-4
5Maintaining the CPE200
General exterior maintenance ...................................................................... 5-1
Maintenance checklist ..................................................................................... 5-1
Snowfall areas ................................................................................................... 5-1
APreparing a concrete pad for the CPE200
Before you start ............................................................................................... A-1
Overview of steps ...........................................................................................A-2
Mounting the station to a new concrete pad ..........................................A-2
Mounting to an existing concrete surface .............................................. A-4
............................................................................................................................. A-6
BUsing a transformer to derive 120V
Wiring requirement ..........................................................................................B-1
General guidelines ............................................................................................B-1
Wiring diagram ................................................................................................B-2

1 - 1
1
Introduction
This document provides important instructions that must be followed when installing the CPE200.
IMPORTANT:
• The CPE200 must be installed and serviced by ChargePoint-certified installers only. Contact ChargePoint
to find out how to become a certified installer. If the CPE200 is installed by any person other than a
ChargePoint-certified installer, the CPE200 is not covered under warranty and ChargePoint is not
responsible for any malfunctions.
• Ensure that all connections comply with local codes and ordinances.
• Observe all local and national safety regulations.
• Observe local regulations regarding wiring different circuits in the same conduit. In general, all
conductors occupying the same conduit must have an insulation rating equal to at least the maximum
circuit voltage applied to any conductor within the conduit.
• The CPE200 must be connected to a circuit provided with appropriate branch circuit over-current
protection in accordance with the National Electrical Code, ANSI/NFPA 70 or CEC for Canada.
Before you begin
•Take the online training course to become a ChargePoint Certified Installer and get a login for ChargePoint.
If you do not complete this training, you will be unable to complete the installation process.
• Ensure that the appropriate wiring, circuit protection, and metering is in place at the installation location by
reviewing the specifications, wiring diagrams, and grounding requirements described in this chapter.
• Verify that the installation site has a load capacity sufficient to support the CPE200.
• Ensure that adequate CDMA (Verizon or Sprint) or GSM (AT&T, Rogers) cellular coverage is available at the
installation location. To ensure adequate signal strength in underground garages or other enclosed parking
structures, cellular repeaters may be required.
• Review the contents of this document to familiarize yourself with the installation steps.
Grounding instructions
The CPE200 must be connected to a grounded, metal, permanent wiring system. An equipment-grounding
conductor must be run with circuit conductors and connected to equipment-grounding terminal or lead on
battery charger.
An insulated grounding conductor that is identical in size, insulation material and thickness to the grounded and
ungrounded branch-circuit supply conductors except that it is green with or without one or more yellow stripes is
to be installed as part of the branch circuit that supplies the unit or system. This grounding conductor is to be
grounded to earth at the service equipment or, when supplied by a separately derived system, at the supply
transformer.

ChargePoint Charging Stations
1-2
Specifications
Electrical Input
Electrical Output
Functional Interfaces
Safety and Connectivity Features
Input Power 52kW @ 3 phase and 250W @ 1 phase
Input Voltage, Charging 480VAC 3 phase
Input Voltage, Control & Communication 120VAC 1 phase
Input Current 63A @ 480VAC, 2A @ 120VAC
Input Frequency 50/60Hz +5%
Standard Wiring 3 phase, 4-wire (L1,L2,L3, Ground) and 1 phase (L1, N, Ground)
Maximum Output Power 50kW (@400–500V)
Output Voltage 200–500VDC
Output Current 125A max
Connector Types CHAdeMO, CCS1 (SAE J1772 DC Combo)
Cable Length 12.5’ (3.8 meters)
LCD Display 2 line OLED display
Card Reader ISO 15693, ISO 14443, NFC
Plug-in Detection No selection of plug required. Auto-detects which plug is connected.
Vehicle Safety Communications CHAdeMO - JEVS G104 over CAN
CCS1 -SAE J1772 over PLC
Plug-out Detection Power terminated per JEVS G104 (CHAdeMO) and SAE J2931 (CCS1)
specification
Power Measurement Accuracy +/- 2% from 10% to full scale
Power Report/Store Interval 15 minutes, aligned to hour
Wide Area Network 3G GSM, 3G CDMA

1 - 3
Introduction
Safety and Operational Ratings
Dimensions and Weights
NOTE: ChargePoint, Inc. reserves the right to alter product offerings and specifications at any time without notice,
and is not responsible for typographical or graphical errors that may appear in this document.
Handle with care
Always transport and store the CPE200 in its original packaging in a horizontal position. Unpack and raise
the CPE200 to its vertical position during the installation process only.
Use appropriate lifting equipment (forklift, pallet jack, lifting straps and engine hoist, crane, etc). Ensure all
lifting equipment used is rated for shipping and product weights listed above.
DANGER: Allow the CPE200 to stand in its vertical position only when secured to lifting equipment with the
lifting straps, or when the CPE200 has been bolted to its concrete pad.
Enclosure Rating Type 3R, IP 65
Safety Compliance UL Listed for USA cUL certified for Canada: complies with UL 2202,
UL 2231-1, UL 2231-2
Surge Protection 6kV @ 3,000A. In geographic areas subject to frequent thunderstorms,
supplemental surge protection at the service panel is recommended.
EMC Compliance FCC Part 15, Subpart B
Efficiency >92%
Power Factor >0.99
Cooling Liquid Cooled
Operational Altitude <6,000 feet (<1828 meters)
Operational Temperature -31 °F to 122 °F (-35 °C to 50 °C)
Storage Temperature -31 °F to 122 °F (-35 °C to 50 °C)
High Altitude Operating Temperature 6000–8000’ (1800–2400 m): -31 °F to 104 °F (-35 °C to 40 °C). Output
power derating may apply.
Operating Humidity Up to 95% @ 122 °F (+50 °C) non-condensing
Terminal Block Specifications
480V Terminal Block
120V Terminal Block
Temperature Rating: 90 °C
Tightening Torque: 31 in-lbs (3.5 Nm)
Wire Size: 4-2 AWG (21–34 mm2)
Temperature Rating: 90 °C
Tightening Torque: 14 in-lbs (1.6 Nm)
Wire Size: 14 –12 AWG (2.1–3.3 mm2)
Dimensions HxWxD: 79” x 30” x 13” (2,000mm x 750mm x 330mm)
Installation Footprint WxD: 23” x 11” (580mm x 270mm)
Weight 364 lb (165 kg)
Shipping Weight 728 lb (330 kg)

ChargePoint Charging Stations
1-4
Note on electrical power
The CPE200 requires both 480 VAC, 3 phase (L1, L2, L3, G) and 120 VAC, single phase (L, N, G). The 120 VAC can
be brought from a nearby 208/120V panel or, if allowed by the local AHJ, a low power transformer can be set at
the installation site, eliminating the need for a second conduit run and second disconnect switch. In either case,
both the 480 VAC and 120 VAC must be brought into the disconnect enclosure and run through the same 1-1/4”
conduit that feeds the CPE200.
For details on using a transformer to supply 120 VAC to the CPE200, refer to Appendix B.

2 - 1
2
Planning your installation
The CPE200 is fastened to a prepared concrete pad using four anchor bolts (not supplied). The pad must be level
and flat and be a minimum of 2,500 PSI. The concrete pad must support the size and weight of the CPE200 and
comply with all applicable codes. Consult an engineer if necessary. For details on preparing the concrete pad,
see Appendix A.
DANGER: Do not install the CPE200 in a commercial car repair facility or within 20 feet (6 meters) of an
outdoor fuel dispensing device due to risk of explosion.
Charging cable proximity
When choosing the installation location, it is important to ensure the CPE200’s charging plugs can easily reach
cars’ charging ports without effort or strain on either end. The CPE200 charging cables can reach up to 10.5 feet
(3.2 meters).
Install the CPE200 at the end of a stall type parking space or island with pull through capability.
Do not install the CPE200 curbside on a roadway.
If installed at the end of a parking space, it can either be centered at the end of the parking space or positioned up
to 12” to the left as you face the rear of the space.

ChargePoint Charging Stations
2-2
Conduit locations
The CPE200 accommodates service wiring through conduit installed either underground or above ground.
Above ground conduit is to be used only in locations such as a parking garage where it is impossible to
accommodate service wiring from underground.
Underground conduit
These are the basic steps for using underground conduit with a CPE200. See Appendix A for detailed instructions.
1Fabricate a plywood template using template pattern 75-001152-01 stapled into the canter of this guide.
Be sure template is printed 1:1 by verifying measurements on pattern.
NOTE: For your convenience you can also purchase a prefabricated plywood template directly from
ChargePoint (Part Number CPE200T-BT).
2Locate mounting studs and conduit within .05” tolerance.
3The 1-1/4” threaded female coupling must be flush with the surface of the pad and precisely located relative to
the mounting studs.
Do not pull wiring at this time. It will be pulled after the conduit run is terminated into the unit.
TEMPLATE GUIDE (NOT TO SCALE)
Conduit Coupling
Score Line

2 - 3
Planning your installation
Above ground conduit
Above ground conduit is recommended only in locations such as a parking garage where it may be impossible to
accommodate service wiring from underground.
When service wiring is supplied above the ground or down a wall, it enters the CPE200 through a cutout on the
left side of the back fan panel. Run at least three feet (one meter) of conduit and wiring from the back left fixing
point.
NOTE: Conduit and service wiring must be trimmed prior to installation.

ChargePoint Charging Stations
2-4
Stand alone charging station
When installing the CPE200 use the minimum distances shown below.
NOTES:
1CONCRETE PAD FOOTING TO BE 24” BELOW GRADE MINIMUM.
2CONCRETE TO BE 3000 PSI MINIMUM.
3TOP OF PAD TO BE 6” ABOVE ASPHALT.
4REINFORCE AND DOWEL TO SURROUNDING CONCRETE WITH REBAR.
51” RADIUS ALL EXTERNAL EDGES.
6SCORE LINE 6” IN FROM OUTER EDGE TO FORM FAUX CURB. (SEE ILLUSTRATION BELOW)
7PAD DIMENSIONS SHOWN ARE MINIMUM REQUIRED. CAN BE LARGER. CONSULT AN ENGINEER AND
LOCAL CODES TO ENSURE A COMMPLIANT INSTALLATION.
8MOUNTING HARDWARE REQUIRED (SEE ILLUSTRATION BELOW):
aBOLTS: 5/8–11 X 9” MIN. F1554 GRADE 55 HOT-DIPPED GALVANIZED THREADED BOLTS - 4 EA
bNUTS: 5/8–11 HEAVY GALVANIZED HEX NUTS (DH RATED) - 12 EA
cWASHERS: GALVANIZED WASHERS (ASTM F436) - 8 EA

2 - 5
Planning your installation
Adjacent walls or obstacles
When installing the CPE200 with its back or side against or near a wall or other obstacle, use the minimum
distances shown below.
NOTES:
1CONCRETE PAD FOOTING TO BE 24” BELOW GRADE MINIMUM.
2CONCRETE TO BE 3000 PSI MINIMUM.
3TOP OF PAD TO BE 6” ABOVE ASPHALT.
4REINFORCE AND DOWEL TO SURROUNDING CONCRETE WITH REBAR.
51” RADIUS ALL EXTERNAL EDGES.
6SCORE LINE 6” IN FROM OUTER EDGE TO FORM FAUX CURB. (SEE ILLUSTRATION BELOW)
7PAD DIMENSIONS SHOWN ARE MINIMUM REQUIRED. CAN BE LARGER. CONSULT AN ENGINEER AND
LOCAL CODES TO ENSURE A COMMPLIANT INSTALLATION.
8MOUNTING HARDWARE REQUIRED (SEE ILLUSTRATION BELOW):
aBOLTS: 5/8–11 X 9” MIN. F1554 GRADE 55 HOT-DIPPED GALVANIZED THREADED BOLTS - 4 EA
bNUTS: 5/8–11 HEAVY GALVANIZED HEX NUTS (DH RATED) - 12 EA
cWASHERS: GALVANIZED WASHERS (ASTM F436) - 8 EA

ChargePoint Charging Stations
2-6
Back-to-back charging stations
When installing two CPE200’s back-to-back, ensure a minimum distance of 12 inches (300 mm) between them. To
ensure this minimum distance, position the concrete pad using the dimensions shown below.

3 - 1
3
Installing the CPE200
After the pad is prepared and surveyed by a qualified engineer as described in the previous section, you are ready
to begin the installation process.
Important: The CPE200 has an IP65 and NEMA Type 3R electronics enclosure rating. However, because the
enclosure must be opened during installation, the installation process must be performed during dry calm
weather or under cover to prevent ingress of moisture or debris.
Important: Ensure the concrete pad is completely cured before mounting the CPE200.
Tools included
• 5 mm tamper-resistant hex driver bit
• 2.5 mm hex “L” wrench
•Liftingstraps
Materials included
• Two Conduit fittings
• Conduit cut to 11” long
• Two sealing washers
• 1-1/4” rigid conduit nipple, 6”
• 1-1/4” rigid conduit female coupling
• Black ferrite ring
• Gray ferrite ring
• CPE200T baseplate template guide
• CPE200T installation guide
• Activation label (for pinpointing the station as described in Chapter 4)
Tools you will need
• Lifting equipment sufficiently rated to lift a weight of 728lb / 330kg and dimensions of:
37” (H) x 90” (W) x 21” (D) / 940mm (H) x 2,286 (W) x 533 (D)
• Power driver
• #2 Philips screwdriver
• 1/2” drive breaker bar
•15/16”socket

ChargePoint Charging Stations
3-2
• 1/2” drive torque wrench
• Adjustable pliers
•1/4”flatbladescrewdriver
• 1/8” flat blade screwdriver
Materials you will need
• Four anchor bolts, 5/8-11 x 9” minimum - see Appendix A
• Concrete, minimum 3000 PSI - see Appendix A
• 1-1/4” conduit to concrete pad - see Appendix A
• Twelve galvanized nuts 5/8-11
• Eight heavy washers 5/8 ID
• Wire 4 AWG & 14 AWG
• Service disconnect switches as required
Overview of Steps
Important: Before installing the CPE200, contact ChargePoint to make arrangements for system
commissioning.
1Unpacking the shipping crate (see page 3-3)
2Positioning the CPE200 vertically (see page 3-4)
3Removing the fan (see page 3-5)
4Removing the shipping base plate (see page 3-7)
5Securing the CPE200 to the prepared pad (see page 3-8)
6Removing the front panel (see page 3-9)
7Removing the service covers (see page 3-10)
8Running the internal conduit and service wiring (see page 3-11)
9Connecting the wiring (see page 3-13)
10 Preparing the CPE200 for operation (see page 3-14)
11 Verifying correct operation (see page 3-16)
These steps are detailed in the remainder of this section.

3 - 3
Installing the CPE200
Step 1: Positioning and unpacking the shipping crate
1Position the crate with the bottom of the CPE200 as close to the installation pad as possible.
The CPE200T is enclosed in a wooden crate with foam packing. Using appropriate lifting equipment (forklift,
pallet jack, engine hoist, crane, etc) and be sure to loop the CPE200’s lifting straps onto the lifting equipment.
Always lift and transport the crate horizontally.
CAUTIONS:
•Transport the CPE200 in its horizontal position only.
• Ensure the lifting equipment is appropriately rated for shipping weight (728lb / 330kg) and crate
dimensions of (79” (H) x 30” (W) x 13” (D) / 2,006mm (H) x 762mm (W) x 330mm (D)).
• Check that the crate is in good condition and that the CPE200 is not damaged. If damage is evident,
make a formal complaint to the transporter and notify ChargePoint at 1-877-850-4562.
2Remove the packaging.
Unscrew all crate fasteners and remove all
panels and loose packaging. Parts shown in
orange are removed prior to positioning
the vertical position.
IMPORTANT:
Collect all screws and place in a plastic
bag or tape together for proper disposal.
Leave no screws in the parking area to
reduce the risk of puncturing tires.
Please recycle or reuse packing materials.

ChargePoint Charging Stations
3-4
Step 2: Positioning the CPE200 vertically
DANGER: Never stand the CPE200 vertically without having it attached to lifting equipment using the lifting
straps. The CPE200 must remain attached to lifting equipment until the mounting bolts have been installed
(as described on page 3-7).
1Securely attach the lifting straps at the top of the CPE200 to the lifting apparatus and gently raise the
CPE200 to a standing position on its shipping baseplate.
NOTE: The CPE200 is 6.85 ft (2,090 mm) high, including the shipping baseplate.
2When the CPE200 is vertical, set it down but keep tension on the lifting straps.
3Remove all remaining wrapping from the CPE200 with the exception of its two charging connectors. The
wrapping will protect the plugs through the installation process.
Lifting straps
Shipping baseplate

3 - 5
Installing the CPE200
Step 3: Removing the fan
1With the CPE200 in the vertical position, remove the front and rear fan covers by unfastening the two security
screws and washers from each fan cover using the supplied 5 mm Pin Hex tool. Store the fasteners in safe
place.
2Release the front fan panel by moving it to the left and down. This exposes the fan and shipping base.
3Remove the fan by unfastening its four nuts using an 8mm (5/16”) nut driver. Slide the fan off the fasteners
and place it on the base plate. Store the fasteners in safe place. Gently pull the fan about 2” forward taking
care to avoid pulling on the fan wires or coolant hoses.

ChargePoint Charging Stations
3-6
IMPORTANT: Do not pull on the power connector and cooling hoses.
4Reach behind the fan and disconnect the fan’s power connector by pressing on the release latch at the front
of the connector and pulling down.
5Release the two cooling hoses located behind the fan by pulling the quick release sleeve. A drop or two of
coolant may come out when the connectors are uncoupled. This is normal.
IMPORTANT: Store the fan in a safe and clean place to prevent damage. Be careful not to allow dirt or other
contaminants to come in contact with the coolant connectors or fan plug.
