ChargePoint Home Flex J1772 User manual

ChargePoint® Home Flex
16A-50A Flexible Amperage Charger
Installation Guide for J1772 and NACS
ATTENTION: Installers, please read this guide thoroughly. Do not throw this
guide away. Return the guide to the owner after installation.

Important Safety Instructions
SAVETHESEINSTRUCTIONS
WARNING: This manual contains important instructions for Home Flex. When
using electric products, always follow basic precautions, including the
following.
1. Read and follow all warnings and instructions before installing and operating the
ChargePoint® charging station. Install and operate only as instructed. Failure to do
so may lead to death, injury, or property damage, and will void the Limited
Warranty.
2. Only use licensed professionals to install your ChargePoint charging station and
adhere to all national and local building codes and standards. Before installing the
ChargePoint charging station, consult with a licensed contractor, such as a licensed
electrician, and use a trained installation expert to ensure compliance with local
building and electrical codes and standards, climate conditions, safety standards,
and all applicable codes and ordinances. Inspect the charging station for proper
installation before use.
3. Always ground the ChargePoint charging station. Failure to ground the charging
station can lead to risk of electrocution or fire. The charging station must be
connected to a grounded, metal, permanent wiring system, or an equipment
grounding conductor shall be run with circuit conductors and connected to the
equipment grounding terminal or lead on the Electric Vehicle Supply Equipment
(EVSE). Connections to the EVSE shall comply with all applicable codes and
ordinances.
4. Install the ChargePoint charging station using a ChargePoint approved method.
Failure to install on a surface that can support the full weight of the charging
station can result in death, personal injury, or property damage. Inspect the
charging station for proper installation before use.
5. This charging station is not suitable for use in Class 1 hazardous locations, such as
near flammable, explosive, or combustible vapors or gases.
6. This device should be supervised when used around children.
7. Do not put fingers into the electric vehicle connector.
8. Do not use this product if any cable is frayed, has broken insulation, or shows any
other signs of damage. Call ChargePoint Support immediately at 1.888.758.4389
(24 hours).
9. Do not use this product if the enclosure or the EV connector is broken, cracked,
open, or shows any other signs of damage. Call ChargePoint Support immediately
at 1.888.758.4389 (24 hours).
2chargepoint.com

10. Use 90°C wire copper conductors only.
11. Do not operate the charging station in temperatures outside its operating range.
For charging stations set to 16-48 A, the range is -40˚F to 122˚F (-40˚C to 50˚C).
For charging stations set to 50 A, the range is -40˚F to 113˚F (-40˚C to 45˚C).
lOther than the charging cable, Home Flex contains no field serviceable parts. Do
not attempt to repair or service any other part of the unit yourself. If the unit
requires servicing, contact ChargePoint, Inc.
lEnsure the Home Flex charging cable is positioned so it is not stepped on, tripped
over, or subjected to damage or stress. Do not close a garage door on the charging
cable.
IMPORTANT: Under no circumstances will compliance with the information in a
ChargePoint guide such as this one relieve the user of the responsibility to
comply with all applicable codes and safety standards. This document
describes approved procedures. If it is not possible to perform the procedures
as indicated, contact ChargePoint. ChargePoint is not responsible for any
damages that may result from custom installations or procedures not
described in this document or that fail to adhere to ChargePoint
recommendations.

chargepoint.com3

Product Disposal
ChargePoint Home Flex is electronic and therefore may not be disposed of
as part of unsorted domestic waste. Inquire with local authorities
regarding proper disposal. Product materials are recyclable as marked.
Document Accuracy
The specifications and other information in this document were verified to
be accurate and complete at the time of its publication. However, due to ongoing product
improvement, this information is subject to change at any time without prior notice. For
the latest information, see our documentation online at chargepoint.com/guides.
Copyright and Trademarks
©2013-2023ChargePoint, Inc. All rights reserved. This material is protected by the
copyright laws of the United States and other countries. It may not be modified,
reproduced, or distributed without the prior, express written consent of ChargePoint,
Inc.ChargePoint and the ChargePoint logo are trademarks of ChargePoint, Inc., registered
in the United States and other countries, and cannot be used without the prior written
consent of ChargePoint.
CAN ICES-3 (A)/NMB-3 (A)
4chargepoint.com

Table of Contents
Important Safety Instructions 2
Verify Contents 6
Gather Tools 8
Plan the Location 9
Wire the Circuit 11
Mount the Charging Station 12
Install the Charging Cable 18
Complete the Installation 20
Access the Installer App 21
Questions? 24
Limited Warranty 25
chargepoint.com5

Verify Contents
CAUTION: The ChargePoint Home Flex charging station must be
installed by a licensed electrician. If you do not know where to find
one, refer to the ChargePoint Home Flex Quick Start Guide or
chargepoint.com/homeinstall for help.
Check the box (J1772 Home Flex factory configuration order) to ensure you
have the Quick Start Guide, this Installation Guide, and these parts:

(a) Charging station (if applicable, with attached input power cable)
(b) Faceplate (pre-installed on charging station)
(c) Installation template
(d) Charging cable connector (J1772) with cable clip
(e) Wire cover (pre-installed on charging station)
(f) 10 mm (3/8 in) driver bit
(g) 4 mm (3/16 in) drill bit
(h) Three 6 mm (1/4 in) x 51 mm (2 in) lag screws

Check the box (NACS Home Flex factory configuration order) to ensure you
have the Quick Reference Guide, and these parts:
6chargepoint.com

(a) Charging station with NACSholster ball insert (if applicable, with
attached input power cable)
(b) Faceplate (pre-installed on charging station)
(c) Installation template
(d) Charging cable connector (NACS) with cable clip
(e) Wire cover (pre-installed on charging station)
(f) 10 mm (3/8 in) driver bit
(g) 4 mm (3/16 in) drill bit
(h) Three 6 mm (1/4 in) x 51 mm (2 in) lag screws
Note: If you are missing any of these parts, call 1.888.758.4389
(24hours).

Note: Visit chargepoint.com/guides and find the "ChargePoint Home
Flex" section for full instructions for NACS cable installation.
chargepoint.com7

Gather Tools
You also need:
(a) One NEMA 14-50 outlet, or one NEMA 6-50 outlet, or supplies to install
a hardwired circuit
(b) Pencil
(c) Stud finder
(d) Level
(e) Drill
(f) Coin
(g) ChargePoint Installer app on your smartphone
Scan the QR code to download the app, and sign up if necessary.
(h) Needle-nose pliers
8chargepoint.com

Plan the Location
IMPORTANT: While this charger can be installed as either a plug-in
or hardwired, we recommend hardwiring for optimal performance.
Before beginning work, check the site for appropriate mounting location and
electrical capacity.
1. Ensure the homeowner has chosen an installation location that allows
the charging cable to reach the car's charging port while still providing
slack. Mount the charging station on a surface that can support the full
weight of the charging station with the cord hanging from it. Follow the
steps below to mount on a surface using the supplied screws. Ensure
Wi-Fi signal is available.
Note: Outdoor installation requires hardwiring or an outdoor-rated,
weather-resistant electrical outlet.
WARNING: In areas with frequent thunderstorms, add surge
protection at the service panel. Ensure all power and ground
connections, especially those at the breaker and bus bar, are clean
and tight. Remove all oxide from all conductors and terminals before
connecting wiring.
2. Home Flex must be set to match the rating of the circuit as determined
by the available panel capacity.
CAUTION: Home Flex is a continuous load device. The circuit must
be rated for 125% of the maximum load.
Consult all applicable codes for breaker and wire sizing requirements. The
field-wiring terminal is rated to 105 °C (221 °F) and accepts a maximum of 16
mm2 (6AWG) wire. Home Flex supports the following amperages for circuit
capacity:
chargepoint.com9

Circuit
Rating
Max
Load
Estimated Range per
Hour Plug-in Hardwire
80 A 50 A 37 miles/60 km no yes
70 A 50 A 37 miles/60 km no yes
60 A 48 A 36 miles/58 km no yes
50 A 40 A 30 miles/48 km yes yes
40 A 32 A 25 miles/40 km yes yes
30 A 24 A 18 miles/29 km no yes
20 A 16 A 12 miles/19 km no yes
Table: Home Flex supports the following amperages for circuit
capacity
IMPORTANT: In Canada, a plug-in installation is only allowed with a
50 A circuit.
3. For plug-in installation, determine the plug type
purchased by the homeowner. It is either a NEMA
14-50 or 6-50 type plug.
4. For a hardwired installation, determine if the desired
circuit rating requires a hardwired circuit.
10chargepoint.com

5. Ensure the electrical panel supports a 240 V dedicated circuit with a
new, dedicated, non-GFCI two-pole circuit breaker, in accordance with
local codes and ordinances.
Note: If local codes require a GFCI breaker for plug-in installation,
ChargePoint recommends a hardwire installation. We do not
recommend using a GFCI breaker as the Home Flex has charging circuit
interrupting device (CCID) protection. Using a GFCI breaker in the panel
can cause nuisance tripping.
6. For plug-in installations, the outlet should
be located 0.45-0.66m (20-26in) from the
ground adjacent to the stud where the
charging station will be mounted.
Note: The input power cable is 0.45 m (18
in) long (as per the National Electric Code
for EV chargers). Ensure the outlet is
installed close enough to the stud for the
input power cable to plug in.
7. Follow all applicable codes and ordinances
and pull a permit for completing the
electrical work as required.
Wire the Circuit
1. Turn off the circuit breaker to the 240 V outlet.
WARNING: RISK OF SHOCK. Do not restore power to the
outlet until installation is complete. Failure to follow these
instructions could result in shock or electrocution.
2. Install a circuit:
lFor a 40 or 50 A plug-in installation, wire the circuit with the
appropriate 6-50 or 14-50 outlet. Install the outlet with the
ground facing up.
lFor a hardwired installation, provide a listed conduit with wiring
to the bottom or rear 19 mm (3/4 in) knockout for AC input. Seal
the unused knockout with the plug provided.
3. Affix the label with the appropriate rating to the circuit in the panel.
4. Ensure power is off to the circuit at the panel before proceeding.
chargepoint.com11

Mount the Charging Station
Note: For hardwired installation, see the Hardwired Installation section below.
Plug-In Installation
1. Remove the faceplate and the wire cover from the charging station and
set them aside.
2. Mark the center of the mounting location with a vertical line at a height
between 1-1.1m (39-43in) above the floor. This must be centered on a
stud or other structurally suitable surface.
3. To find the charging station’s ideal mounting height, plug the charging
station's input power cable into the outlet.
DANGER: If the front status light turns on when the charging station
is plugged in, the circuit is not off.
STOP IMMEDIATELY. Unplug the charging station and turn off the
power to the outlet at the circuit breaker until the installation is
complete.
12chargepoint.com

4. Hold the station against the wall, centered on the mark you just made.
Note: Ensure the input power cable has a slight curve, and is not
stretched.
5. Mark the two lower mounting holes through the holes in the station,
then unplug the charging station and set aside.
6. Place the template on the wall, aligning the lower template holes with
the two marks you made.
7. Mark the top mounting hole on the wall using the top hole in the
template. All three marks should be on the vertical line you first made.
8. Remove the template from the wall.
9. Drill the three mounting holes on the marks using the included drill bit.
10. Use the driver bit to drive a screw into the top-most mounting hole,
leaving a 3 mm (1/8 in) gap to hang the charging station on.
chargepoint.com13

11. Hang the charging station on the screw using the top notch on the back.
Note: Do not plug the charging station in yet.
12. Drive the remaining two lag screws into the bottom mounting holes to
secure the charging station.
Note: Ensure the screw does not make contact with the input wire.
For more information, see the Install the Charging Cable section below.
Hardwired Installation
Note: The conduit can be connected to the station at the bottom or the rear
knockouts.
1. Remove the faceplate and the wire cover from the charging station and
set them aside.
Note: To hardwire a ChargePoint Home Flex with a pre-installed NEMA
power cord, remove the plug by lifting the three white levers on the left
of the terminal block, and lifting and pulling out the cable clip. Using a
pair of needle-nose pliers can make removing the clip easier.
2. Mark the center of the mounting location with a vertical line at a height
between 1.0-1.1 m (39-43 in) above the floor. This must be centered on a
stud or other structurally suitable surface.
14chargepoint.com

3. Hold the station against the wall, centered on the mark you just made.
The top of the station should be approximately 1.3 m (50 in) above
ground level.
4. Mark the two lower mounting holes through the holes in the station,
then set aside.
5. Place the template on the wall, aligning the lower template holes with
the two marks you made.
6. Mark the top mounting hole on the wall using the top hole in the
template. All three marks should be on the vertical line you first made.
7. Remove the template from the wall.
8. Drill the three mounting holes on the marks using the included drill bit.
chargepoint.com15

9. Use the driver bit to drive a lag screw into the top-most mounting hole,
leaving a 3 mm (1/8 in) gap to hang the charging station on. Keep the
remaining two screws for later use.
10. If bringing power through the back of the station, remove the rear
knockout plug and route the wires through before hanging the station.
Note: If mounting on an exterior wall and bringing power through the
rear knockout, apply sealant around the rear knockout to prevent water
ingress.
11. Hang the charging station on the screw using the top notch on the back.
12. Drive the remaining two lag screws into the bottom mounting holes to
secure the charging station.
13. Ensure the service wiring can easily reach the connectors on the
charging station’s input terminal block.
16chargepoint.com

14. Tighten the locknut on the conduit fitting.
15. Strip each wire 12 mm (1/2 in).
16. Lift the white levers to open the terminal block. Fully insert the wires
into the connectors on the left side of the terminal block with the
ground wire in the center. Ensure to insert the wires in the correct order,
where left terminal corresponds to Line 1 (L1), middle terminal is Ground
(GND), and right terminal is Line 2 (L2).
17. Press the levers down until they snap into place to secure the wires in
the terminal block. Pull on the wires to ensure they are properly
secured.
Note: The levers snap shut with great force. Keep fingers away from
underneath the levers.
chargepoint.com17

Install the Charging Cable
1. Turn off the circuit breaker to the 240 V outlet.
WARNING: RISK OF SHOCK. Do not restore power to the
outlet until installation is complete. Failure to follow these
instructions could result in shock or electrocution.
2. Remove the cable clip from the wire end of the cable, but do not
discard it.
3. Lift the white levers to open the terminal block.
4. Insert the wires of the charging cable through the bottom hole of the
charging station.
5. Match the green wire to the ground terminal on the left side of the
output block.
6. Insert the ends of the wires into the corresponding holes, pushing the
cables up until the silver conductors are no longer visible.
7. Press the three levers down until they snap into place.
Note: The levers snap shut with great force. Keep fingers from
underneath the levers.
18chargepoint.com

8. Insert the white plug into the connector towards the right of the
terminal block.
9. Push up on the charge cable strain relief and slide the cable clip into the
slot. This secures the cable in place.
10. Install the wire cover using a coin to lock it in place.
11. Locate the rating label on the bottom of the station. Apply the new
rating label that matches the station's circuit.
12. Snap the faceplate onto the charging station.

chargepoint.com19

Complete the Installation
1. Extend the cable to its full length to remove any twists or tension.
2. Drape the charging cable over the top of the charging station and dock
the connector in its holster.
3. Ensure labels specifying circuit amperage are applied to the bottom of
the charging station and to the circuit in the electrical panel.
4. Plug the charging station into the outlet (if applicable).
Note: The images below represent a ChargePoint charging station
integrated with two different adapters:
(a) J1772 cable
(b) NACS cable
5. Restore power to the circuit at the electrical panel.
6. Watch to ensure the front status light glows yellow, then blinks white.
Note: For more information, see the Charger Status Lights section
below.
20chargepoint.com
