Chattanooga Hydrocollator SS-2 User manual

User Manual
®
Hydrocollator
MOBILE HEATING UNITS
SS-2 M-2 M-4
ISO 13485 CERTIFIED
120 - 220/240 Volt Units

Foreword. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Precautionary Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Nomenclature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-13
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Hydrocollator®is a registered trademark of Chattanooga Group.
HotPac™is a trademark of Chattanooga Group.
©2006 Encore Medical Corporation or its affiliates, Austin, Texas, USA.
Any use of editorial, pictorial or layout composition of this publication
without express written consent from Chattanooga Group of Encore
Medical, L.P. is strictly prohibited.This publication was written, illustrated
and prepared for print by Chattanooga Group of Encore Medical, L.P.
TABLE OF CONTENTS
1
ISO 13485 CERTIFIED
Hydrocollator®Mobile Heating Units

2
This manual contains general instructions for operation, precautionary instructions, and
maintenance recommendations for the owners and operators of the Hydrocollator SS-2,
M-2, and M-4 Heating Units. In order to obtain maximum life and efficiency of the
Hydrocollator Heating Units, please read this manual thoroughly and follow all instructions
prior to operating the unit.
Specifications put forth in this manual were in effect at the time of publication. However,
owing to Chattanooga Group's policy of continual improvement, changes
to these specifications may be made at any time without obligation on the part of
Chattanooga Group.
FOREWORD
PRECAUTIONARY DEFINITIONS
The precautionary instructions found in this section and throughout this manual are indicated by specific
symbols. Understand these symbols and their definitions before operating this equipment. The definitions of
these symbols are as follows:
= CAUTIONS - Text with a “CAUTION” indicator explains possible safety infractions that could have the
potential to cause minor to moderate injury or damage to equipment.
= WARNINGS - Text with a “WARNING” indicator explains possible safety infractions that will
potentially cause serious injury and equipment damage.
= DANGERS - Text with a “DANGER” indicator explains possible safety infractions that are imminently
hazardous situations that would result in death or serious injury.
NOTE: Throughout this manual, “NOTE” may be found. These notes are helpful information to aid in the
particular area or function being described.
•Read, understand and practice the precautionary and operating instructions. Know the limitations associated
with the Hydrocollator SS-2, M-2, M-4 Heating Units. Observe the cautionary and operational decals installed
on the unit.
•The thermostat is extremely sensitive and the slightest adjustment will alter the temperature several
degrees. The recommended operating temperature is 160° F to 166° F (71° to 74°C). The temperature of the
water should be checked with a thermometer after every adjustment, before using the HotPacs. Always
allow sufficient time for the water temperature to stabilize.
•Always keep the water level over the top of the HotPacs to avoid burning or scorching of the packs.
•Never allow the HotPacs to dry after use.
•Check water level daily as it has a natural loss due to evaporation.
CAUTION
Hydrocollator®Mobile Heating Units
Hydrocollator®Mobile Heating Units

3
•Never adjust the thermostat too high. The thermostat is extremely sensitive to the slightest adjustment.
•Clean the tank periodically as described in the maintenance portion of this manual.
•Always replace Hydrocollator HotPacs as soon as they show signs of wear.
•If the unit is to be left unattended for a period of time, unplug the unit, remove the packs, empty the water,
and clean the tank.
•Do not move the Hydrocollator while filled with water. Tipping over could result in burns to the user or
others.
•Always unplug the Hydrocollator from the power source before attempting to empty water from unit.
•Always use factory authorized replacement parts.
•Always destroy and replace HotPacs which are exposed to contamination: hazardous or cleaning materials,
bodily fluids, mold, etc.
CAUTION
•Grounding the Hydrocollator SS-2, M-2, and M-4 Mobile Heating Unit: Make certain the unit is electrically
grounded by plugging into a hospital grade electrical outlet with a ground terminal receptacle (U-ground
outlet), 120 VAC only. Follow the National Electrical Code.
•The water temperature in the Hydrocollator is approximately 160° F (71° C), and the water scalding
temperature is approximately 120° F (49° C).
WARNING
PRECAUTIONARY INSTRUCTIONS
ATTENTION: Consult accompanying documents.
Type B equipment. Denotes the degree of protection against electric shock,
particularly regarding allowable leakage currents and the reliability of the
protective earth connection.
Explanation of Symbols
Hydrocollator®Mobile Heating Units
Risk of explosion if used in the presence of flammable anesthetics.

4
NOMENCLATURE
WHITE LAMP (where applicable), when illuminated, indicates that main power is connected,
the switch is on and unit is operating.
RED LAMP (where applicable), when illuminated, warns of an overheat/low water condition.
Action is necessary to correct the condition.
GREEN LAMP (220/240 volt units), when illuminated, indicates that main power is connected,
the switch is on and unit is operating.
IMPORTANT: Some models are fitted with a thermal cut-out thermostat which acts as a
“Non self-resetting” thermal cut-out. In the unlikely event of a fault condition, this device
is designed to open the power circuit between190°F ± 14°F (88°C ± 8°C). It is not possible
to alter its operating range. The operation of the unit may be restored by depressing the
red button after the water/element temperatures have been allowed to cool. If the fault
condition persists, please contact Chattanooga Group or an authorized agent.
White Lamp
Hydrocollator®Mobile Heating Units

NOMENCLATURE
Diagram
1. Heating Element 9. Junction Box (J-Box) Cover
2. Drain 10. IEC connector
3. Overtemp Thermostat 11. Power Cord
4. Thermostat, Hydraulic 12. Drain Valve (Not Shown)
5. Bracket (Brkt. & Bulb Themo A/B Assembly) 13. Reset Overtemp Button*
6. Lid 14. Fuses
7. 3 inch Caster 15. Pilot Lamp, Red
8. Overtemp Light 16. Pilot Lamp, Clear
5
View Inside
2
34
1
NOTE: M-4 model shown; models will vary.
* All 220-240 Volt and M-4 120 Volt have this button
5
6
7
Rear View Close-Up
(Lower Left Section)
16
Hydrocollator®Mobile Heating Units
Rear View 220/240 Volt
810
14 14
13
Rear View 120 Volt
9
11

NOMENCLATURE
Rear Close-Up View
(Lower Right Section)
17. Hot Pac 23. Side Handle
18. Neck Pac Insert 24. Thermostat, Hydraulic
19. Drain, Copper Tube 25. Thermostat Control Knob
20. Lid Hinge nuts 26. On/Off Switch
21. Lid Knob/Handle 27. Internal Wiring Harness
22. Lid Hinge
6
17
18
19
22
Diagram (continued)
20
Not illustrated:
28. Stainless Steel Wire Rack
29. DrainValve, Ball - 1/2 in Replacement
30 Drain, Hose, Bib
31. Replacement Tank
32. Outer Jacket
33. Fuse 10A
34. Lid Kit Handle
35. Water Thief
36. Bracket, Element Support (2 each) [M-4 only]
37. Plastic Feet
21
23
Hydrocollator®Mobile Heating Units
Rear View (Upside Down)
(J-Box Open)
26 25
24
27
Right Side Up
(Back View)

7
TECHNICAL SPECIFICATIONS
SS-2 Model
Power Supply 110-120V~ 220-240V~
Rated Frequency 50/60Hz
Power Consumption 1000 W
Tank Capacity 49.32 Liters
Temperature Range 160°F - 165°F (71°C - 74°C)
Thermal Cut-out Temp 190°F ± 14°F (88°C ± 8°C)
Accuracy +/- 10%
Heating Up Time Time to 160°F (70°C) - 4 Hours
Cool Down Time Time from 160°F (70°C) - 2 Hours
Safety Class Type B
Safety Tests UL 544
Dimensions 33 in H x 21 in L x 16 in W (85 cm H x 52 cm L x 39 cm W)
Weight 30 lbs (13.6 kg)
Standard Accessories: Includes eight Standard size HotPacs.
M-2 Model
Power Supply 110-120V~ 220-240V~
Rated Frequency 50/60Hz
Power Consumption 1000 W
Tank Capacity 68.81 Liters
Temperature Range 160°F - 165°F (71°C - 74°C)
Thermal Cut-Out Temp 190°F ± 14°F (88°C ± 8°C)
Accuracy +/- 10%
Heat Up Time Time to 160°F (70°C) - 6 Hours
Cool Down Time Time from 160°F (70°C) - 3 Hours
Safety Class Type B
Safety Tests UL 544
Dimensions 33 in H x 27 in L x 16 in W (85 cm H x 67 cm L x 40 cm W)
Weight 37 lbs (16.8 kg)
Standard Accessories: Includes twelve Standard size HotPacs.
Hydrocollator®Mobile Heating Units

TECHNICAL SPECIFICATIONS
M-4 Model
Power Supply 110-120V~ 220-240V~
Rated Frequency 50/60Hz
Power Consumption 1500 W
Tank Capacity 135.76 Liters
Temperature Range 160°F - 165°F (71°C - 74°C)
Thermal Cut-out Temp 190°F ± 14°F (88°C ± 8°C)
Accuracy +/- 10%
Heating Up Time Time to 160°F (70°C) - 8 Hours
Cool Down Time Time from 160°F (70°C) - 4 Hours
Safety Class Type B
Safety Tests UL 544
Dimensions 33 in H x 35 in L x 20 in W (85 cm H x 89 cm L x 50 cm W)
Weight 55 lbs (25 kg)
Standard Accessories: Includes twenty-four Standard size HotPacs.
8
Hydrocollator®Mobile Heating Units

9
SETUP
Remove all of the contents inside the Hydrocollator and then replace the wire rack. Make
certain the drain valve is closed before filling the tank with water. The tank should be
approximately 3/4 full with packs removed. The tank may be filled from any standard type
faucet.
Check the voltage rating on the serial decal plate which is located on the back of the unit.
To turn the unit on, simply plug the unit into a 120 Volt~, 60 Hz or 220/240 Volt~, 50-60
HZ outlet as indicated on the decal plate. To turn the unit off, simply unplug from mains
power supply. Do not attempt to use direct current. Follow the procedures indicated in the
Precautionary Instructions. Do not attempt to use the unit if it is not properly grounded.
OPERATION Hydrocollator®Mobile Heating Units
The Hydrocollator is simple and easy to operate. The controls are located in the rear, near
the bottom of the unit. The thermostat controls the temperature of the water. It is located
near the bottom of the unit on the control panel. It has been tested and preset at the
factory to normal operating temperature. If further adjustment is necessary, it can be easily
accomplished by turning the adjusting screw located on the thermostat. Turning the outer
screw counterclockwise lowers the temperature, while turning it clockwise raises it.
NOTE: Do not turn the inner stem.
The Hydrocollator units operate through the use of a hydraulic capillary-type thermostat and
can be left plugged in and turned on to provide a ready supply of heated HotPacs.
The HotPac rack is adjustable and accommodates different sizes and types of packs.
SS-2 Unit – The unit comes complete with eight standard HotPacs.
M-2 and M-4 Units - The M-2 unit comes complete with 12 standard HotPacs. The M-4 comes
complete with 24 standard HotPacs.
Hydrocollator®Mobile Heating Units

10
Packs Too Cool
Unit Boils 1. Thermostat failure. 1. Replace thermostat.
The following are solutions to minor performance problems. Only qualified personnel should service equipment
problems.
Unit Plugged In,
Water Doesn’t Get Hot
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
1. Breaker for electric circuit off.
2. Thermostat not functioning.
3. Heating element burned out.
1. Turn breaker ON.
2. Replace thermostat.
3. Replace element.
Cloudiness of Water
1. Filler from packs is seeping.
2. Too long a period between
cleanings.
1. Replace packs.
2. Drain and clean.
Packs Too Hot 1. Thermostat set too high.
2. Thermostat failure.
1. Adjust thermostat.
2. Replace thermostat.
1. Thermostat set too low.
2. Thermostat failure.
1. Adjust thermostat.
2. Replace thermostat.
TROUBLESHOOTING
Rust 1. Contact with ferrous metal.
2. Deposits on inside of tank.
3. Too much chlorine in water.
1. Remove the ferrous metal
item from the unit - usually
a staple, paper clip, safety
pin, etc., and clean
thoroughly.
2. Thoroughly clean tank and
remove all deposits.
3. Clean tank and rinse
thoroughly. Add de-
chlorinator if local water
has high chlorine content.
Hydrocollator®Mobile Heating Units

11
REPLACEMENT PARTS
Model M-2 – Standard
Cat. No. – 2402 w/packs
Key* Part Description Part No.
1 Element, Heating 120 Volt, 1000 Watt 10630
4 Hydraulic Thermostat 10631
5 Brkt. & Bulb Thermostat A/B Assembly (2 each)** 21023
6 Lid 22297
7 Caster 3 in 21259
9 Cover, Junction Box 22087
11 Power Cord 20568
Hose, Drain 21882
15 Pilot Lamp, Red 22149
16 Pilot Lamp, Clear 22148
19 Drain, Copper Tube Part A 21286
20 Lid Hinge Rod Nuts (2 each) 21737
21 Lid Knob/Handle 21025
22 Lid Hinge Rod 22303
23 Handle, Side 20237
Thermo Low Water Kit*** 20548
27 Wiring (Internal) Harness 61579
28 Stainless, Wire Rack 22304
29 Drain Valve, Ball - 1/2 in Replacement 21085
30 Drain, Hose, Bib 23392
31 Replacement Tank M-2 56314
32 M-2 Outer Jacket 22421
34 Handle, Lid Kit 22171
26 On/Off Switch 23406
* Key numbers refer to Nomenclature section (pages 5 and 6)
** Used to hold the Hydraulic Thermostat and Overtemp Thermostat to the Heating element.
*** Includes Gasket Thermostat, Nut 1/2-20 Brass, and Overtemp Thermostat (#26)
Hydrocollator®Mobile Heating Units

12
Model SS-2 – Standard
Cat. No. – 2302 w/packs
Key* Part Description Part No.
1 Element, Heating 120 Volt, 1000 Watt 10630
4 Hydraulic Thermostat 10631
5 Brkt. & Bulb Thermostat A/B Assembly (2 each)** 21023
6 Lid SS-2 22219
7 Caster 3 inch (4) 21259
9 Cover, Junction Box 22087
11 Power Cord 20568
Hose, Drain 21635
15 Pilot Lamp, Red 22149
16 Pilot Lamp, Clear 22148
19 Drain, Copper Tube Part A 21286
20 Lid Hinge Rod Nuts (2 each) 21737
21 Lid Knob/Handle 21025
22 Lid Rod Hinge 22231
23 Handle, Side (2) 20237
Thermo Low Water Kit*** 20548
27 Wiring (Internal) Harness 61579
28 Stainless, Wire Rack 22259
29 DrainValve, Ball - 1/2 in Replacement 21085
30 Drain, Hose, Bib 23392
31 Replacement Tank SS-2 23385
32 SS-2 Outer Jacket 22425
34 Handle, Lid Kit 22171
35 Water Thief 21882
26 On/Off Switch 23406
* Key numbers refer to Nomenclature section (pages 5 and 6)
** Used to hold the Hydraulic Thermostat and Overtemp Thermostat to the Heating element.
*** Includes Gasket Thermostat, Nut 1/2-20 Brass, and Overtemp Thermostat (#26)
REPLACEMENT PARTS Hydrocollator®Mobile Heating Units

REPLACEMENT PARTS
Model M-4 – Standard
Cat. No. – 2502 w/packs
Key* Part Description Part No.
1 Heating Element M-4, 120 Volt, 1000 Watt 20570
4 Hydraulic Thermostat 10631
5 Brkt. & Bulb Thermostat A/B Assembly (2 each)** 21023
6 Lid 22348
7 Caster 3 in 21260
9 Junction Box Cover 22360
11 Power Cord 20568
14 Hose, Drain 21635
15 Pilot Lamp, Red 22149
16 Pilot Lamp, Clear 22148
19 Drain, Copper Tube Part A 21286
20 Lid Hinge Rod Nuts (2 required) 21737
21 Lid Knob/Handle 21025
22 Lid Hinge Rod 22361
23 Side Handle (Serial # Above 5149) 20237
Thermo Low Water Kit*** 20548
27 Wiring (Internal) Harness 61579
28 Rack, Stainless Steel 22374
29 Drain Valve, Ball - 1/2 in Replacement 21085
30 Drain, Hose, Bib 23392
31 Replacement Tank M-4 22343
32 M-4 Outer Jacket 23384
34 Handle, Lid Kit 22171
35 Water Thief 21882
36 Bracket, Element Support (2 each) 22356
26 On/Off Switch 23406
* Key numbers refer to Nomenclature section (pages 5 and 6)
** Used to hold the Hydraulic Thermostat and Overtemp Thermostat to the Heating element.
*** Includes Gasket Thermostat, Nut 1/2-20 Brass, and Overtemp Thermostat (#26)
13
Hydrocollator®Mobile Heating Units

14
REPLACEMENT PARTS Hydrocollator®Mobile Heating Units
Model SS-2 220-240 VOLT – (Low Water)
Cat. No. – 2307 w/packs
Cat. No. – 2309 w/o packs
Key* Part Description Part No.
1 Element, Heating, 240V~ CE 22245
4 Thermostat, Hydraulic 10631
3 Lamp, Pilot, Green 22146
11 Cord Set (Country Specific)
26 Switch 23406
28 Rack 22259
Hose, Nylon 5/8 x 4' Coupled M-F 21635
7 Caster, 3 in (4) 21259
Handle, M/SS, Lid, Finished 20513
23 Handle, Side, Common (2) 20237
34 Lid, Assembly With Handle 22219
9 Cover, Junction Box, M-2, 220-240 Volt~ 22087
29 Drain, Copper M-2 Part A #25010 21286
5 Bracket, Bulb Thermostat, H20, S/A (Lo-Water) (2) 21023
35 Water Thief 21882
Spacer, Thermostat (Lo-Water) (2) 72393
Thermostat, (Lo-Water) 20548
15 Lamp, Red, Indicator (Lo-Water) 22147
14 Fuse, 6.3 Amp. (2) 71772
Fuse Holder (2) 72734
Receptacle, Power 8843-FSG-W-40-60 74723
27 Harness Wiring 61579
31 Tank, Replacement with Drain 23372
Insert, For neck Contour Packs 21053
Thermostat, LM5-2505 23393
20 Lid, Rod Nuts (2) 21737
22 Lid, Rod 22231
29 Valve, Ball 21085
Fit Bib, SS2, M2, M4 23392

15
REPLACEMENT PARTS Hydrocollator®Mobile Heating Units
Model M-2 220-240 VOLT – (Low Water)
Cat. No. – 2407 w/packs
Cat. No. – 2409 w/o packs
Key* Part Description Part No.
1 Element, Heating, 220 Volt~, 1000 Watt 22245
4 Thermostat, Hydraulic 10631
3 Lamp, Pilot, Green 22146
11 Cord Set (Country Specific)
26 Switch 23406
28 Rack 22304
Hose, Nylon 5/8 x 4' Coupled M-F 21635
7 Caster, 3 in (4) 21259
Handle, M/SS, Lid, Finished 20513
23 Handle, Side, Common (2) 20237
34 Lid, Assembly With Handle 22297
9 Cover, Junction Box, M-2, 220-240 Volt~ 22087
29 Drain, Copper M-2 Part A #25010 21286
5 Bracket, Bulb Thermostat, H20, S/A (Lo-Water) (2) 21023
35 Water Thief 21882
Spacer, Thermostat (Lo-Water) (2) 72393
Thermostat, (Lo-Water) 20548
15 Lamp, Red, Indicator (Lo-Water) 22147
14 Fuse, 6.3 Amp. (2) 71772
Fuse Holder (2) 72734
Receptacle, Power 8843-FSG-W-40-60 74723
27 Harness Wiring 61579
31 Tank, Replacement with Drain 23373
Insert, For neck Contour Packs 21053
20 Lid, Rod Nuts (2) 21737
22 Lid, Rod 22303
29 Valve, Ball 21085
Fit Bib, SS2, M2, M4 23392

16
REPLACEMENT PARTS Hydrocollator®Mobile Heating Units
Model M-4 220-240 VOLT – (Low Water)
Cat. No. – 2506 w/packs
Cat. No. – 2508 w/o packs
Key* Part Description Part No.
1 Element, Heating, 240 Volt~, 1500 Watt 22246
4 Thermostat, Hydraulic 10631
3 Lamp, Green, 1607-5107, 220-240 Volt~ 22146
11 Cord Set (Country Specific)
26 Switch 23406
28 Rack, Wire M-4 22374
Hose, Nylon 5/8 x 4' Coupled M-F 21635
7 Caster, 3 in (4) 21260
Handle, M/SS, Lid, Finished 20513
34 Lid, Sub-Assembly M-4, With Handle 22348
9 Cover, Junction Box, 18.25x19.125, M-4 22360
29 Drain, Copper M-2 Part A #25010 21286
5 Bracket, Element Support 22356
35 Water Thief 21882
Breaker, Heinemann (2) 22173
Thermostat, (Lo-Water) 20548
15 Lamp, Red, Indicator (Lo-Water) 22147
Receptacle, Power 8843-FSG-W-40-60 74723
31 Tank, M-4, Replacement with Drain 23384
20 Lid, Rod Nuts (2) 21737
22 Lid, Rod 22361
29 Valve, Ball 21085
Fit Bib, SS2, M2, M4 23392
5 Bracket, Bulb Thermostat, H20, S/A (Lo-Water) (2) 21023

MAINTENANCE
Care and Cleaning
The Hydrocollator is equipped with an immersion type heating element and a hydraulic capillary type
thermostat which evenly maintains the HotPac temperature in the water and provides a ready supply of heated
packs. It is critical to maintain the water level over the top of the HotPac to avoid damage to the heating
element, the stainless steel, or the HotPac. Water is constantly lost during operation due to evaporation.
Therefore, it is essential that water be added daily. The tank should also be drained and cleaned systematically,
at minimum intervals of every two weeks.
Always unplug the unit from the power source when emptying or cleaning the unit. Drain the unit by the drain
valve located at the bottom rear of the unit. Either move the unit to a floor drain or attach the extension hose to
it when draining.
Your Hydrocollator Heating Unit is made of high quality stainless steel that should last a lifetime. You must
properly care for your Hydrocollator Heating Unit if you wish for it to last a lifetime.
Follow these simple steps to ensure that your Hydrocollator Heating Unit lasts.
1. Chlorine means rust to stainless steel. No bleach or any cleaner with high chlorine content should be used.
2. Clean regularly for optimal service and operation.
NOTE: Failure to maintain your equipment (including regular cleaning) will void your warranty.
3. Fill daily with water. Water is constantly lost during operation due to evaporation.
4. Chlorine in regular tap water may be present in high enough concentrations to damage your unit. If
you suspect high levels of chlorine in your Hydrocollator Heating Unit, we recommend the addition of a
dechlorinator.
5. Certain additives (such as herbal teas, essential oils, etc.) will damage the components of the heating unit
including the stainless steel. The Hydrocollator Heating Unit was designed to heat water and HotPacs only.
To avoid potential for rusting:
1. Do not use bleach or cleaners with high chlorine content.
2. Do not use paper clips, safety pins, staples, coat hangers, etc., in or on the unit.
3. Do not clean the unit with steel wool or a carbon steel brush.
4. Do not use abrasive cleaners which tend to disturb the grain in the finish.
5. Water level is critical: Add water daily and keep it full.
6. Regularly clean and drain the tank (every two weeks).
7. Remove all deposits from interior surfaces and parts (including heating element). The deposits are
concentrations of chlorine that allow rusting to begin. If allowed to accumulate on the heating element,
these deposits will lower the efficiency of the element and increase the power consumption of the unit.
8. If you suspect that you have “hard water”, you may need to change your water more frequently. Salt deposits
are an indication of hard water that will eventually cause rust.
17
•Do not move the Hydrocollator while filled with water. Tipping over could result in a burn to the user or
others.
•Always unplug the Hydrocollator from the power source before attempting to empty water from
unit.
WARNING
Hydrocollator®Mobile Heating Units

Cleaning Tips
1. The interior of the unit should be cleaned, usually every two weeks, using a low abrasive bathroom cleaner.
Check for low or no chlorine content in your cleaner and make sure that the residue is thoroughly rinsed
away with water.
2. A strong solution of vinegar and water will usually dissolve away deposits, which then must be thoroughly
rinsed away.
Care of HotPacs
Always return the Hydrocollator HotPac to the hot water of the heating unit after each treatment. There it
is heated, kept clean and ready for immediate use. The HotPac may be boiled; however, this hastens the
deterioration of the pack. The pack may also be cleaned by scrubbing the pack with soap and water. The
simplified method of keeping the pack clean is to keep it immersed in water.
The Hydrocollator HotPac, under constant daily use, should have a useful life of at least one year. When the pack
begins to wear out, the filler oozes and leaks through the fabric of the cloth and sections of the pack appear to
be loose and empty and will not retain heat properly. The pack should be replaced when it reaches this state.
Original replacement Hydrocollator HotPacs may be ordered from an authorized Chattanooga Group dealer.
NOTE: If HotPacs are to be stored for extended periods, they may be placed - while wet - in plastic bags and
stored in a freezer.
MAINTENANCE
18
Hydrocollator®Mobile Heating Units

Chattanooga Group ("Company") warrants that the Hydrocollator Models SS-2, M-2, and M-4 Heating
Units ("Products") are free of defects in material and workmanship. This warranty shall remain in effect
for one year from the date of original consumer purchase. If these Products fail to function during the
one year warranty period due to a defect in material or workmanship, Company or the selling dealer
will repair or replace this Product without charge within a period of thirty days from the date on
which the Product is returned to the Company or the dealer.
All repairs to the Product must be performed by a service center authorized by the Company. Any
modifications or repairs performed by unauthorized centers or groups will void this warranty.
To participate in warranty coverage, this Product's warranty registration card (included with Product)
must be filled out and returned to the Company by the original owner within ten (10) business days
of purchase.
This Warranty Does Not Cover:
Replacement parts or labor furnished by anyone other than the Company, the selling dealer or a
certified Company service agent.
Defects or damage caused by labor furnished by someone other than Company, the selling dealer or
a certified Company service agent.
Any malfunction or failure in the Product caused by product misuse, including, but not limited to,
the failure to provide reasonable and necessary maintenance or any use that is inconsistent with the
Product User's Manual.
COMPANY SHALL NOT BE LIABLE IN ANY EVENT FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
To obtain service from Company or the selling dealer under this warranty:
1. A written claim must be made within the warranty period to the Company or the selling dealer.
Written claims made to the Company should be sent to:
4717 Adams Road
P.O. Box 489
Hixson, TN 37343 USA
Telephone: [phone] USA
Telephone: [phone] Canada
Outside USA: [phone]
Facsimile: [phone]
2. The Product must be returned to the Company or the selling dealer by the owner.
This warranty gives you specific legal rights and you may also have other rights which vary from state
to state.
The Company does not authorize any person or representative to create for it any other obligation or
liability in connection with the sale of the Product. Any representation or agreement not contained in
the warranty shall be void and of no effect.
THE FOREGOING WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTY OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
WARRANTY
19
Hydrocollator®Mobile Heating Units
