Chauvet Intimidator wave irc User manual

Quick Reference Guide

Intimidator Wave IRC QRG EN
2
About This Guide
The Intimidator Wave IRC Quick Reference Guide (QRG) has basic product
information such as mounting, menu options, and DMX values. For more
information, download the User Manual from the Chauvet
website:
http://www.chauvetlighting.com/product-manuals-literature/.
Disclaimer
The information and specifications contained in this QRG are subject to change
without notice.
Safety Notes
The following Safety Notes include important information about installation, use,
and maintenance.
•Always connect the product to a grounded circuit.
•Make sure the power cord is not crimped or damaged.
•Always disconnect the product from the power source before cleaning it or
replacing the fuse.
•Never disconnect the product from the power source by pulling or tugging on
the cord.
•If mounting the product overhead, make sure there is adequate support for the
product’s weight and always secure the product using a safety cable.
•Make sure there are no flammable materials close to the product when it is
operating.
•Avoid direct eye exposure to the light source while the product is on.
•Do not touch the product’s housing when the product is operating because the
housing can be very hot.
•The product is not intended for permanent installation.
•The product is for indoor use only. It is rated at IP20.
•Do not expose the product to rain or moisture.
•Always connect the product to a power source that is within the voltage range
stated on the label or rear panel of the product.
•Never connect the product to a dimmer or rheostat.
•Make sure to replace the fuse with another of the same type and rating.
•Always install the product in a location with adequate ventilation.
•Always leave at least 20 in (50 cm) between the product and adjacent surfaces.
•Be sure that no ventilation slots on the product’s housing are blocked.
•Do not operate the product at an ambient temperature higher than
104 °F (40 °C).
•Never carry the product by the power cord or any moving part.
•Always use the hanging/mounting bracket to lift the product.
•If there is a serious operating problem, stop using the product immediately.
•Never try to repair the product. Repairs carried out by untrained people can
lead to damage or malfunction.
•To eliminate unnecessary wear and improve its lifespan, during periods of
non-use completely disconnect the product from power via breaker or by
unplugging it.
Contact
•From outside the U.S., UK, Ireland, Mexico, or Benelux, contact the
distributor of record to request support or return a product.
•From inside the U.S., UK, Ireland, Mexico, or Benelux, use the information in
Contact Us at the end of this QRG.

Intimidator Wave IRC QRG EN
3
What Is
Included
•Intimidator Wave IRC
•Hanging bracket with mounting
hardware
•Power Cord
•Warranty card
•Quick Reference Guide
To Begin
Carefully unpack the Intimidator Wave IRC and check that all the parts are in the
package, and are in good condition.
If the box, or any of the
contents, appear damaged from shipping, or show signs of
mishandling, save all packaging and file a claim with the carrier immediately, do
not notify Chauvet. Failure to report damage to the carrier immediately, or failure
to have all packaging available for inspection, could invalidate your claim.
For other issues, such as missing components or parts, damage not related to
shipping, or concealed damage, file a claim with Chauvet within 7 days of
delivery. For information on contacting Chauvet, see Contact Us
at the end of this
QRG.
Description
The Intimidator Wave IRC is a moving light array with 5 independently controlled
moving heads emitting sharp, powerful, color-
changeable beams. It operates in
Standalone, Sound, Master/Slave, Remote, and DMX modes.
Overview
Display
Head 1
Head 2
Head 3
Head 4
Head 5
Control Buttons
Front View
Back View
Power In
Power Out
Fuse
Holder
DMX In
DMX Out

Intimidator Wave IRC QRG EN
4
AC Power
Intimidator Wave IRC has an auto-ranging power supply that can work with an
input voltage range of 100–240 VAC, 50/60 Hz.
To eliminate wear and improve its lifespan, during periods of non-use
completely disconnect from power via breaker or by unplugging it.
Power Linking
Power linking describes products that are daisy chained together through their
Power In and Power Out sockets so that many products are
powered from one
outlet. For the maximum number of Intimidator
Wave IRCs that can be power
linked at 120 V or at 240 V, see the User Manual or the label on the product.
The User Manual is available at the Chauvet website:
http://www.chauvetlighting.com.
Fuse Replacement
1. Disconnect the product from power.
2. With a Phillips #2 head screwdriver, unscrew the fuse holder
cap from the housing.
3. Remove the blown fuse.
4. Replace with a fuse of the same type and rating.
5. Screw the fuse holder cap back in place and reconnect power.
Disconnect the product from power before replacing the fuse.
Mounting
Before mounting this product, read the Safety Notes. Use one or two mounting
points and one safety cable per pro
duct. Make sure the mounting clamps (such as
CLP-15 clamps from Chauvet
) are capable of supporting the weight of the
product. For the Chauvet
line of mounting clamps, go to the Chauvet website at
https://www.chauvetdj.com/products/category/accessories/.
Mounting Diagram
When using only one mounting clamp with this fixture, you must use a clamp
with a captive bolt to prevent accidental loosening.
Hanging/Mounting
Bracket
Mounting Clamps
Rubber
Feet (x4)
Safety
Cable

Intimidator Wave IRC QRG EN
5
Control Panel
Description
Button
Function
<MENU>
Exits from the current menu or function
<UP>
Navigates upwards through the menu list or increases the
numeric value when in a function
<DOWN>
Navigates downwards through the menu list or decreases the
numeric value when in a function
<ENTER>
Enables the currently displayed menu or sets the currently
selected value into the selected function
Menu Map
Main Level
Programming Levels
Description
Address
001–512
Sets DMX starting address
Run Mode
DMX
14CH
Sets DMX personality
34CH
Auto
Auto01–Auto16
Sets an auto program
Sound
Slave
S-1–S-4
Sets a Slave mode
IR
Sets Infrared mode
Setup
Mast Set
M-1–M-4
Sets a Master mode of M-1, M-2 or M-4
Tilt Reverse
ON
Sets reverse tilt operation
OFF
Tilt Angle
90
Sets tilt angle range
180
270
Display
ON
Sets display blackout
OFF
Screen Reverse
ON
Sets screen orientation
OFF
Sensitivity
1–100
Sets sound sensitivity
Reset
Resets all motor defaults
Factory Reset
Resets to factory defaults
System Info
Ver XX
Displays software version
Running Mode XXXXX
Displays current operating mode
DMX Address XXX
Displays current DMX address

Intimidator Wave IRC QRG EN
6
IRC-6 (Infrared
Remote Control)
The Intimidator Wave IRC is compatible with the IRC-6 from Chauvet.
The following IRC-6 buttons are used with the Intimidator™ Wave IRC:
•<BLACKOUT>,<A>, <UV>, <W> - Turns LED on/off
•<AUTO> , <0> thru <9> - Selects Auto program mode
•<SOUND> - Selects Sound mode
•<STROBE> - Strobing (0–20 Hz)
•<SPEED> - Auto program speed
•<SENSITIVITY>- Sets sound sensitivity
•<%> - Dimmer
•<MANUAL> - Sets white color level
•<R> - Sets red color level
•<G> - Sets green color level
•<B> - Sets blue color level
DMX Linking
The Intimidator Wave IRC works with a DMX controller. Information about
configuring the Intimidator
Wave IRC for DMX operation is in the User Manual,
which is available from the Chauvet website: http://www.chauvetlighting.com
.
Information about DMX is in the Chauvet DMX Primer, which is availab
le from
the Chauvet website: https://www.chauvetdj.com/downloads/.
Starting Address
To ensure full access to all channels in each DMX mode, the highest recommended
DMX address for this product is 479.
Master/Slave
Connection
The Intimidator Wave IRC works in Master/Slave mode. Information about
configuring this product for Master/Slave operation is in its User Manual, which is
available from the Chauvet website: http://www.chauvetlighting.com.

Intimidator Wave IRC QRG EN
7
DMX Assignments
34CH
Channel
Function
Value
Percent/Setting
1
Head 1 Tilt
000ó255
0–270°
2
Head 2 Tilt
000ó255
0–270°
3
Head 3 Tilt
000ó255
0–270°
4
Head 4 Tilt
000ó255
0–270°
5
Head 5 Tilt
000ó255
0–270°
6 Head Tilt Programs
000ó047
No function
048ó055
Program 1
056ó063
Program 2
064ó071
Program 3
072ó079
Program 4
080ó087
Program 5
088ó095
Program 6
096ó103
Program 7
104ó111
Program 8
112ó119
Program 9
120ó127
Program 10
128ó135
Program 11
136ó143
Program 12
144ó151
Program 13
152ó159
Program 14
160ó167
Program 15
168ó175
Program 16
176ó183
Program 17
184ó191
Program 18
192ó199
Program 19
200ó207
Program 20
208ó215
Program 21
216ó223
Program 22
224ó231
Program 23
232ó239
Program 24
240ó247
Program 1 all heads
248ó255
Sound program
7
Head Tilt Program
Speed
000ó255 Fast to slow
8
Head 1 Red
Dimmer
000ó255 0–100%
9
Head 1 Green
Dimmer
000ó255 0–100%

Intimidator Wave IRC QRG EN
8
DMX Assignments (Cont.)
34CH
Channel
Function
Value
Percent/Setting
10
Head 1 Blue
Dimmer
000ó255 0–100%
11
Head 1 White
Dimmer
000ó255 0–100%
12
Head 2 Red
Dimmer
000ó255 0–100%
13
Head 2 Green
Dimmer
000ó055 0–100%
14
Head 2 Blue
Dimmer
000ó255 0–100%
15
Head 2 White
Dimmer
000ó255 0–100%
16
Head 3 Red
Dimmer
000ó255 0–100%
17
Head 3 Green
Dimmer
000ó255 0–100%
18
Head 3 Blue
Dimmer
000ó255 0–100%
19
Head 3 White
Dimmer
000ó255 0–100%
20
Head 4 Red
Dimmer
000ó255 0–100%
21
Head 4 Green
Dimmer
000ó255 0–100%
22
Head 4 Blue
Dimmer
000ó255 0–100%
23
Head 4 White
Dimmer
000ó255 0–100%
24
Head 5 Red
Dimmer
000ó255 0–100%
25
Head 5 Green
Dimmer
000ó255 0–100%
26
Head 5 Blue
Dimmer
000ó255 0–100%
27
Head 5 White
Dimmer
000ó255 0–100%

Intimidator Wave IRC QRG EN
9
DMX Assignments (Cont.)
34CH
Channel
Function
Value
Percent/Setting
28 Colors
000ó007
No function
008ó015
Red
016ó023
Green
024ó031
Blue
032ó039
White
040ó047
Red+Green
048ó055
Red+Blue
056ó063
Red+White
064ó071
Green+Blue
072ó079
Green+White
080ó087
Blue+White
088ó095
Red+Green+Blue
096ó103
Red+Green+White
104ó111
Red+Blue+White
112ó119
Green+Blue+White
120ó127
Red+Green+Blue+White
128ó179
Reserved
180ó201
Fade rainbow clockwise (speed fast to slow)
202ó207
Full on of current color
208ó229
Fade rainbow counter-clockwise
(speed fast to slow)
230ó234
All colors 100%
235ó249
Snap change (speed fast to slow)
250ó255
Sound color

Intimidator Wave IRC QRG EN
10
DMX Assignments (Cont.)
34CH
Channel
Function
Value
Percent/Setting
29 Heads On/Off
000ó007
●●●●●
008ó015
●●●●○
016ó023
●●●○○
024ó031
●●○○○
032ó039
●○○○○
040ó047
○○○○○
048ó055
○○○○●
056ó063
○○○●●
064ó071
○○●●●
072ó079
○●●●●
080ó087
●●●●●
088ó095
○○○○●
096ó103
○○○●○
104ó111
○○●○○
112ó119
○●○○○
120ó127
●○○○○
128ó135
○○○●●
136ó143
○○●●○
144ó151
○●●○○
152ó159
●●○○○
160ó167
●○○○●
168ó175
○○●●●
176ó183
○●●●○
184ó191
○○●●●
192ó199
●●○○●
200ó207
●○○●●
208ó215
○●●●●
216ó223
●●●●○
224ó231
●●●○●
232ó239
●●○●●
240ó247
●○●●●
248ó255
●●●●●

Intimidator Wave IRC QRG EN
11
DMX Assignments (Cont.)
34CH
Channel
Function
Value
Percent/Setting
30 Auto Programs
000ó015
No function
016ó020
Program 1
021ó025
Program 2
026ó030
Program 3
031ó035
Program 4
036ó040
Program 5
041ó045
Program 6
046ó050
Program 7
051ó055
Program 8
056ó060
Program 9
061ó065
Program 10
066ó070
Program 11
071ó075
Program 12
076ó080
Program 13
081ó085
Program 14
086ó090
Program 15
091ó095
Program 16
096ó100
Program 17
101ó105
Program 18
106ó110
Program 19
111ó115
Program 20
116ó120
Program 21
121ó125
Program 22
126ó130
Program 23
131ó135
Program 24 (built-in for all)
136ó140
Program 25
141ó145
Program 26
146ó150
Program 27
151ó155
Program 28
156ó160
Program 29
161ó165
Program 30
166ó170
Program 31
171ó175
Program 32
176ó180
Program 33
181ó185
Program 34
186ó190
Program 35
191ó195
Program 36

Intimidator Wave IRC QRG EN
12
DMX Assignments (Cont.)
34CH
Channel
Function
Value
Percent/Setting
30 Auto Programs
(Cont.)
196ó200
Program 37
201ó205
Program 38
206ó210
Program 39
211ó215
Program 40
216ó220
Program 41
221ó225
Program 42
226ó230
Program 43
231ó235
Program 44
236ó240
Program 45
241ó245
Program 46
246ó250
Program 47
251ó255
Program 48 (built-in for all)
31
Program Speed
000ó255
Slow to fast
32
Dimmer All Heads
000ó255
0–100%
33 Shutter Programs
000ó019
Off
020ó024
On
025ó064
Shutter 1 even on/even off (fast to slow)
065ó069
On
070ó084
Shutter 2 fast on/slow off (fast to slow)
085ó089
On
090ó104
Shutter 3 slow on/fast off (fast to slow)
105ó109
On
110ó124
Shutter 4 random shutter (fast to slow)
125ó129
On
130ó144
Shutter 5 random shutter fast on/slow off
(fast to slow)
145ó149
On
150ó164
Shutter 6 random shutter slow on/fast off
(fast to slow)
165ó169
On
170ó184
Shutter 7 pulse shutter (fast to slow)
185ó189
On
190ó204
Shutter 8 random pulse shutter (fast to slow)
205ó209
On
210ó224
Shutter 9 on and off gradually (fast to slow)
225ó229
On
230ó244
Shutter 10 pulse shutter (fast to slow)
245ó255
On

Intimidator Wave IRC QRG EN
13
DMX Assignments (Cont.)
34CH
Channel
Function
Value
Percent/Setting
34
Settings
(Set these values
before setting other
DMX channels.
There is a 10 sec
delay before the
settings take effect)
000ó009
No function
010ó014
Move-in-black
015ó019
Cancel move-in-black
020ó024
Independent macros – cancels macro product
combinations below
025ó029
Macros used when linking 2 products together:
This is the value for first product
030ó034
Macros used when linking 2 products together:
This is the value for second product
035ó039
Macros used when linking 4 products together:
This is the value for first product
040ó044
Macros used when linking 4 products together:
This is the value for second product
045ó049
Macros used when linking 4 products together:
This is the value for third product
050ó054
Macros used when linking 4 products together:
This is the value for fourth product
055ó059
No function
060ó064
Reset tilt only
065ó069
No function
070ó074
Reset all
075ó089
No function
090ó094
Reverse tilt
095ó099
No function
100ó104
Cancel reverse tilt
105ó114
No function
115ó119
Controls all heads with head 1 channels
120ó124
Cancels control of all heads with
head 1 channels
125ó255
No function

Intimidator Wave IRC QRG EN
14
DMX Assignments (Cont.)
14CH
Channel
Function
Value
Percent/Setting
1
Head 1 Tilt
000ó255
0–270°
2
Head 2 Tilt
000ó255
0–270°
3
Head 3 Tilt
000ó255
0–270°
4
Head 4 Tilt
000ó255
0–270°
5
Head 5 Tilt
000ó255
0–270°
6 Head Tilt Programs
000ó047
No function
048ó055
Program 1
056ó063
Program 2
064ó071
Program 3
072ó079
Program 4
080ó087
Program 5
088ó095
Program 6
096ó103
Program 7
104ó111
Program 8
112ó119
Program 9
120ó127
Program 10
128ó135
Program 11
136ó143
Program 12
144ó151
Program 13
152ó159
Program 14
160ó167
Program 15
168ó175
Program 16
176ó183
Program 17
184ó191
Program 18
192ó199
Program 19
200ó207
Program 20
208ó215
Program 21
216ó223
Program 22
224ó231
Program 23
232ó239
Program 24
240ó247
Program 1 all heads
248ó255
Sound program
7
Head Tilt Program
Speed
000ó255 Fast to slow

Intimidator Wave IRC QRG EN
15
DMX Assignments (Cont.)
14CH
Channel
Function
Value
Percent/Setting
8 Colors
000ó007
No function
008ó015
Red
016ó023
Green
024ó031
Blue
032ó039
White
040ó047
Red+Green
048ó055
Red+Blue
056ó063
Red+White
064ó071
Green+Blue
072ó079
Green+White
080ó087
Blue+White
088ó095
Red+Green+Blue
096ó103
Red+Green+White
104ó111
Red+Blue+White
112ó119
Green+Blue+White
120ó127
Red+Green+Blue+White
128ó179
Reserved
180ó201
Fade rainbow clockwise (speed fast to slow)
202ó207
Full on of current color
208ó229
Fade rainbow counter-clockwise
(speed fast to slow)
230ó234
All colors 100%
235ó249
Snap change (speed fast to slow)
250ó255
Sound color

Intimidator Wave IRC QRG EN
16
DMX Assignments (Cont.)
14CH
Channel
Function
Value
Percent/Setting
9 Heads On/Off
000ó007
●●●●●
008ó015
●●●●○
016ó023
●●●○○
024ó031
●●○○○
032ó039
●○○○○
040ó047
○○○○○
048ó055
○○○○●
056ó063
○○○●●
064ó071
○○●●●
072ó079
○●●●●
080ó087
●●●●●
088ó095
○○○○●
096ó103
○○○●○
104ó111
○○●○○
112ó119
○●○○○
120ó127
●○○○○
128ó135
○○○●●
136ó143
○○●●○
144ó151
○●●○○
152ó159
●●○○○
160ó167
●○○○●
168ó175
○○●●●
176ó183
○●●●○
184ó191
○○●●●
192ó199
●●○○●
200ó207
●○○●●
208ó215
○●●●●
216ó223
●●●●○
224ó231
●●●○●
232ó239
●●○●●
240ó247
●○●●●
248ó255
●●●●●

Intimidator Wave IRC QRG EN
17
DMX Assignments (Cont.)
14CH
Channel
Function
Value
Percent/Setting
10 Auto Programs
000ó015
No function
016ó020
Program 1
021ó025
Program 2
026ó030
Program 3
031ó035
Program 4
036ó040
Program 5
041ó045
Program 6
046ó050
Program 7
051ó055
Program 8
056ó060
Program 9
061ó065
Program 10
066ó070
Program 11
071ó075
Program 12
076ó080
Program 13
081ó085
Program 14
086ó090
Program 15
091ó095
Program 16
096ó100
Program 17
101ó105
Program 18
106ó110
Program 19
111ó115
Program 20
116ó120
Program 21
121ó125
Program 22
126ó130
Program 23
131ó135
Program 24 (built-in for all)
136ó140
Program 25
141ó145
Program 26
146ó150
Program 27
151ó155
Program 28
156ó160
Program 29
161ó165
Program 30
166ó170
Program 31
171ó175
Program 32

Intimidator Wave IRC QRG EN
18
DMX Assignments (Cont.)
14CH
Channel
Function
Value
Percent/Setting
10 Auto Programs
(Cont.)
176ó180
Program 33
181ó185
Program 34
186ó190
Program 35
191ó195
Program 36
196ó200
Program 37
201ó205
Program 38
206ó210
Program 39
211ó215
Program 40
216ó220
Program 41
221ó225
Program 42
226ó230
Program 43
231ó235
Program 44
236ó240
Program 45
241ó245
Program 46
246ó250
Program 47
251ó255
Program 48 (built-in for all)
11
Program Speed
000ó255
Slow to fast
12
Dimmer All Heads
000ó255
0–100%

Intimidator Wave IRC QRG EN
19
DMX Assignments (Cont.)
14CH
Channel
Function
Value
Percent/Setting
13 Shutter Programs
000ó019
Off
020ó024
On
025ó064
Shutter 1 even on/even off (fast to slow)
065ó069
On
070ó084
Shutter 2 fast on/slow off (fast to slow)
085ó089
On
090ó104
Shutter 3 slow on/fast off (fast to slow)
105ó109
On
110ó124
Shutter 4 random shutter (fast to slow)
125ó129
On
130ó144
Shutter 5 random shutter fast on/slow off
(fast to slow)
145ó149
On
150ó164
Shutter 6 random shutter slow on/fast off
(fast to slow)
165ó169
On
170ó184
Shutter 7 pulse shutter (fast to slow)
185ó189
On
190ó204
Shutter 8 random pulse shutter (fast to slow)
205ó209
On
210ó224
Shutter 9 on and off gradually (fast to slow)
225ó229
On
230ó244
Shutter 10 pulse shutter (fast to slow)
245ó255
On

Intimidator Wave IRC QRG EN
20
DMX Assignments (Cont.)
14CH
Channel
Function
Value
Percent/Setting
14
Settings
(Set these values
before setting other
DMX channels.
There is a 10 sec
delay before the
settings take effect)
000ó009
No function
010ó014
Move-in-black
015ó019
Cancel move-in-black
020ó024
Independent macros – cancels macro product
combinations below
025ó029
Macros used when linking 2 products together:
This is the value for first product
030ó034
Macros used when linking 2 products together:
This is the value for second product
035ó039
Macros used when linking 4 products together:
This is the value for first product
040ó044
Macros used when linking 4 products together:
This is the value for second product
045ó049
Macros used when linking 4 products together:
This is the value for third product
050ó054
Macros used when linking 4 products together:
This is the value for fourth product
055ó059
No function
060ó064
Reset tilt only
065ó069
No function
070ó074
Reset all
075ó089
No function
090ó094
Reverse tilt
095ó099
No function
100ó104
Cancel reverse tilt
105ó114
No function
115ó119
Controls all heads with head 1 channels
120ó124
Cancels control of all heads with
head 1 channels
125ó255
No function
