Chauvet COLORmist System Manual

Appendix
DMX Channel Values
DEFAULT VALUE FUNCTION
1
000 Ù009
010 Ù019
020 Ù029
030 Ù039
040 Ù049
050 Ù059
060 Ù069
070 Ù079
080 Ù089
090 Ù099
100 Ù109
110 Ù119
120 Ù129
130 Ù139
140 Ù149
150 Ù159
160 Ù169
170 Ù179
180 Ù189
190 Ù199
200 Ù209
210 Ù219
220 Ù255
Programs
Black
Red
Green
Blue
Yellow
Purple
Light Blue
White
Color Change
Slow Flow 1
Slow Flow 2
Roll Chase 1
Roll Chase 2
Multi Color
Fast Flow 1
Fast Flow 2
Fast Flow 3
Fast Flow 4
2 Color Chase
2 Color Flow
Any Color: Activates Red, Green & Blue Intensity controls
Color Fade
Auto Run
Run Speed
Slow > Fast, (1 step/Minute) > (100 steps/Second)
2
000 Ù255 Any Color (Active)
Red: Intensity: 0% > 100
000 Ù002
003 Ù249
250 Ù255
Flash Speed
Always On
Slow > Fast
Blackout
3
000 Ù255 Any Color (Active) Green: Intensity: 0% > 100
000 Ù012
013 Ù025
026 Ù038
039 Ù051
052 Ù064
065 Ù077
078 Ù090
091 Ù103
104 Ù116
117 Ù129
130 Ù142
143 Ù155
156 Ù168
169 Ù181
182 Ù194
195 Ù207
208 Ù220
221 Ù233
234 Ù246
247 Ù255
Color Combinations
Red & Green
Red & Yellow
Red & Blue
Red & Purple
Red & Cyan
Red & White
Green & Yellow
Green & Blue
Green & Purple
Green & Cyan
Green & White
Yellow & Blue
Yellow & Purple
Yellow & Cyan
Yellow & White
Blue & Purple
Blue & Cyan
Blue & White
Purple & Cyan
Purple & White
4
000 Ù255 Any Color (Active) Blue: Intensity: 0% > 100
Refer to the Single Actions Program Chart on page 8 to determine if a
Run Speed, Flash Speed and/or Color Combinations become
functional. Not all functions are available to all preset programs listed.
