CHD Elektroservis MXC-56 User manual

7
Model 8-462
ver. 1.0
USER´S GUIDE
© 2008 CHD Elektroserv is

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
2
Contents
page
1. Device description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1. DMX communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2. Control elements, indicators and connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3. Device functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Device setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1. Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2. MIDI system connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3. DMX system connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4. External footswitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3. Device operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1. Reset sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.2. Operating modes indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2.1. Normal mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2.2. DMX output activity indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2.3. MIDI input activity indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2.4. External switch activity indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3. Memory reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4. Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1. Global system parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1.1. System parameters adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.1.2. "DMX Shift" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.1.3. "MIDI Channel" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1.4. "MIDI Mode" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1.5. "MIDI Shift" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1.6. "MIDI Master CC Nr." parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.1.7. "MIDI Blackout CC Nr." parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.1.8. "Foot Switch Function" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.1.9. "Memory Protection" utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.1.10. "Bulk Dump" utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
4.2. Outputs parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
4.2.1. Output parameters settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
4.2.2. "Default Value" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
4.2.3. "Preheat" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
4.2.4. "Limit" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4.2.5. "Curve" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4.2.6. "Accept Master" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4.2.7. "Accept Blackout" parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
5. MIDI implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
5.1. Channel commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
5.2. System commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
5.3. System Exclusive communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6. Technical specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
7. Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Appendices
A. MIDI implementation chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
B. Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
C. Hardware tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Manufacture
r
:
CHD Elektroservis
Nad kundratkou 27, 19000 Praha 9
Czech Republic
[e-mail]
www.chd-el.cz

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
3
1. DEVICE DESCRIPTION
MXC-56 converter is a device that enables MIDI control of the lighting apparatus components controlled by
DMX-512 standard.
This allows to control lights from e.g. built-in sequencers of electronic keyboard instruments or
manually directly from the keyboard instruments without the need of special DMX-512 compatible control panel . The
converter is designed to control any DMX devices (dimmers, LED lights, moving heads, fog machines etc.).
Standard channel commands either Note On / Off or Control Changes or System Exclusive Messages can be
used for MIDI communication (MIDI channel is selectable). MXC-56 converter allows the control of up to 56 DMX
channels with independent adjustable parameters. The converter works one way, data from DMX-512 can not be
transmitted back to the MIDI messages.
An external switch (e.g. Foot Switch) can be connected to The MXC-56 with user definable function. All MXC-
56 activities are controlled by a user-programmable parameters. Various combinations of parameter settings can be
stored in internal memory.
1.1. DMX COMMUNICATION
DMX-512 standard is designed specifically to control stage lighting. It was created in the eighties in the United
States Institute for Theater Technology, Inc.. (USITT), the standard has been revised several times later .
Standard DMX-512 uses a very simple communication protocol (defined in the document USITT Engineering
Commission) DMX512/1990 Digital Data Transmission Standard. Hardware solutions for communication circuits
DMX-512 was taken from an industrial communication interface RS-485 (Electronic Industries Association standard
EIA-422A and EIA-485).
MXC-56 comply to the above standards and is fully compatible with any DMX devices thus.
1.2. CONTROL ELEMENTS, INDICATORS AND CONNECTORS
Fig.1 – Converter panels
Control and indication elements of the
MXC-56 converter are located on the front
panel, all connectors are on the rear panel of
the device as shown in Figure 1:
[1] Display
[2] SYSTÉM edit button
[3] OUTPUT edit button
[4] ENTER button
[5] PREVIOUS button
[6] NEXT button
[7] EXIT / RESET button
[8] DATA x10 button
[9] LED DATA x10
[10] DATA dial
[11] MIDI OUT
[12] MIDI IN
[13] External foot switch connector
[14] DMX-512 output
[15] Power supply connector
1.3. DEVICE FUNCTIONS
Functional block diagram of the MXC-56 is shown in figure 2 The signal from the bus coming in the MIDI input
MIDI-IN [12] is supplied to the CPU and through it back to the output MIDI-THRU/OUT [11] - "Thru" fiction of the
output.
The received data for MXC-56 are filtered and then converted according to the setting system parameters and
output parameters and the resulting data is transferred to the DMX signals, which are transmitted to Output DMX-
OUT [14].
MIDI SysEx data generated by the CPU are fed to the sum circuit and the output MIDI-THRU/OUT [11] - the
"Out" function.
Status of external Foot Switch plugged into the jack FOOT-SWITCH [13] is continuously monitored and its
activation triggers the programmed functions.

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
4
Fig. 2 - Functional block diagram
2. DEVICE SETUP
MXC-56 connection to the MIDI system and DMX system is shown in Figure 3
Fig. 3 – System connection
2.1. POWER SUPPLY
Fig. 4 – Power supply
Power supply for MXC-56 is provided from an external adapter connected
to connector DC [15]. The connector is standard 6 / 2.1 mm. External DC adapter
must be able to supply min. 250 mA in the range of 8 to 15 volts, the voltage may
not be stabilized (the recommended type of power adapter - MW0903GS,
MW1203GS).
The adapter connector must have negative outside and positive inside -
see Figure 4 Polarity of the power connector is also graphically displayed on the
rear panel. MXC-56 has a built-in protection against reverse polarity supply
voltage.

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
5
2.2. MIDI SYSTEM CONNECTION
MXC-56 is connected to the MIDI system using standard MIDI cables with DIN 41524 (5-pin 180) connectors.
Data from the master system (sequencer, keyboard control, PC, etc.) are comming to the input MIDI-IN [12], thru-
going data mixed with its own MIDI data generated by the converter is available at the output MIDI-THRU/OUT [11].
2.3. DMX SYSTEM CONNECTION
To connect the MXC-56 converter to the DMX system is used DMX-OUT [14]. In accordance with the standard
USITT (United States Institute for Theater Technology, Inc..) Should be used XLR-type connector - 5 pin. However,
since the vast majority of producers of the DMX equipment does not comply the standard and uses only 3-pin XLR
connectors, the 3-pin connector is used. The DMX connection cable must be wired according the Figure 5. If the
cable is 4-line the auxiliary data line (i.e., signals "Spare +/-") from the XLR-5 connector is not used – converter does
not use it. For quick orientation is the wiring of the connector pins DMX-OUT [14] also listed on the rear panel next to
the MXC-56 connector DMX-OUT [14].
Fig. 5 - DMX-512 cable wiring variants
2.4. EXTERNAL FOOTSWITCH
An external switch can be connected in the FOOT SW [13] type Jack 1/4"(mono) (such as Foot Switch), its
function is defined by the system parameter "Foot Switch Function” settings (see chapter 4.1 .8.). The external switch
may have the switching type (type NO – disconnected when not used) and normally closed (NC type – connected
when not used) contact. MXC-56 recognizes the type of switches automatically during the reset sequence.
Fig. 6 – External switch wiring
3. DEVICE OPERATION
All control and indicating elements are located on the front panel of the MXC-56. The device has no power
switch, it starts to work immediately after connecting the power adapter to DC [15]. In normal operating mode MXC-
56 works automatically according to received commands through MIDI bus and the values of the parameters
programmed by the user.
3.1. RESET SEQUENCE
The reset sequence starts automatically after power on, ie. after connecting the converter to the AC adapter.
The setting of all parameters is read from the internal memory during the reset sequence and all circuits are then
MXC-56 set to the required state. During the reset sequence the device name and the operating system version
number is displayed. After the execution of the reset sequence MXC-56 turns into normal working mode.
In normal operating mode can be reset sequence run manually by pressing the EXIT / RESET [7] or MIDI
command "System Reset".

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
6
3.2. OPERATING MODES INDICATORS
Current status of MXC-56 is in all its operating modes displayed on the display [1] on the front panel.
3.2.1. NORMAL MODE
In the normal operating mode the right side of the display shows the symbols as
explained in Table 1. The left of the display indicates the status of DMX output, MIDI bus
and an external switch (see below).
Table 1 – Normal mode indicators
Symbol Description Time
Idle state - the normal function of the converter permanently
Active function " Master Full " (activated by external switch) throughout activity
Active Function "Blackout On" (activated by an external
switch or MIDI CC) throughout activity
Valid System Exclusive Message from MIDI bus received approx. 2 seconds
Unknown (invalid) System Exclusive Message from MIDI bus
received approx. 2 seconds
Trying to edit parameters or to write data into memory when
memory protection enabled approx. 2 seconds
3.2.2. DMX OUTPUT ACTIVITY INDICATION
DMX output Activity indicates the "DMX" segment of the display . If all DMX channels
transmit only the basic minimum value (see parameter description "Preheat"), the segment
is off. But, if at least one DMX channel value is greater than the minimum, the segment is
on.
3.2.3. MIDI INPUT ACTIVITY INDICATION
The activity of MIDI input indicates "MIDI" segment of the display. The data on MIDI
input is indicated by a flash of a segment of about 0.3 seconds. In the case of thicker
stream individual pulses can melt and the segment lights continuously.
3.2.4. EXTERNAL SWITCH ACTIVITY INDICATION
Status of external switch is displayed by the "F-SW" segment of the display. If the
switch is inactive, the segment is off. When active the segment lights throughout its
activities.

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
7
3.3. MEMORY RESET
Parameters of MXC-56, are stored in user memory. This memory can be initialized - delete the value stored in
and replace with the default values (so-called "Factory Reset"). "Factory Reset" parameter values are shown in Table
2. To perform a complete memory initialization press the button SYS [2] and ENTER [4], keep it pressed and then
connect the converter to the power supply (adapter).
After connecting the adapter the display shows the information
about the readiness for the initialization ( "Init?") - Now you can release both buttons. After releasing the buttons the
initialization is started. After that the device automatically switches to normal working mode.
Table 2 – "Factory Reset" values
System parameters
Name Value Description
DMX Shift 1 DMX channels 1 – 56 used
MIDI Channel 16 MIDI at MIDI channel 16
MIDI Mode CTR Output kontrol by MIDI Control Changes
MIDI Shift 36 Control Changes 36 - 91 used for outputs
MIDI Master CC Nr. 7 "Master" controller is MIDI Control Changes 7
MIDI Blackout CC Nr. 16 "Blackout" function controlled by MIDI Control Changes 16
Foot Switch Function BLK External switch activates "Blackout " function
Output parameters (same for all 56 outputs !)
Name Vakue Description
Default Value 0 Zero default value of the output after reset
Curve LIN Linear curve
Preheat 0 No preheat
Limit 255 No limit
Accept Master YES "Master" controller allowed
Accept Blackout YES "Blackout" function allowed
4. PARAMETERS
All parameters are fully user programmable. Programmed values are stored in internal memory.
"MIDI Bulk Dump" utility can backup the contents of internal memory in MIDI sequencer (see below).
Parameters can be set in the editing modes by using the controls on the front panel of the MXC-56 or any time during
operation via MIDI System Exclusive communication. Parameters are divided into two groups - the global system
parameters and individual parameters of individual outputs.
4.1. GLOBAL SYSTEM PARAMETERS
Global system parameters define the basic configuration of hardware circuits of the converter.
Allowed range of values of parameters and values stored in memory "Factory Reset" (see chapter 3.3.) Stated
clearly in Table 3 and 2
Menu for editing of the global system parameters contains also two utilities ( "Memory Protect" and "Bulk
Dump") that do not set the values of parameters. They are used to protect the data or to send the values of
parameters stored in memory..

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
8
Table 3 – Global system parameters
Parameter Values
Parameter name Description Symbol Range Symbol Values
DMX Shift
DMX channel shift, e.g. select
the number of the lowest used
DMX channel 1 ~ 457
1 Æ channels 1 ~ 56
457 Æ channels 457 ~
512
MIDI Channel MIDI channel (and "Device
ID") for MIDI communication 1 ~ 457
1 Æ MIDI chn1
16 Æ MIDI chn16
MIDI Mode Selects the MIDI command
type for the converter control
Notes
Controllers
not Æ Notes
ctr Æ Control Changes
MIDI Shift
Adjusts the MIDI command
shift povelů, e.g. select the
number of the lowest used
MIDI note or MIDI CC 1 ~ 457
0 Æ notes / CC 0 ~ 55
72 Æ notes / CC 72 ~
127
MIDI Master CC
Nr.
Selects the number of
"Master" controller 0 ~ 127
0 Æ CC 0
127 Æ CC 127
MIDI Blackout
CC Nr.
Selects the number of
"Blackout" controller 0 ~ 127
0 Æ CC 0
127 Æ CC 127
Foot Switch
Function
External footswitch function
select
Blackout
Master
blk Æ “Blackout” function
MSt Æ“Master” function
Memory
Protection
Utilita – memory write
protection
Off
On
OFF Æ protection off
On Æ protection on
MIDI Bulk Dump Utility sends the MIDI SysEx
Msg Bulk dump Start the bulk dump with ENTER button
4.1.1. SYSTEM PARAMETERS ADJUSTMENTS
To enter the system parameters edit mode press the SYS [2] button. Left side of the display [1] shows the
parameter symbol, the right side its current value.
For browsing through system parameters use PREV buttons [5] (jump to the previous parameter) and NEXT
[6] (jump to the next parameter). For editing of the system parameters the memory protection must be set off.
Parameter value can be set by rotary encoder DATA [10]. Rotating the encoder to the left decrements the
number, turning right increments the output.If the button x10-DATA [8] is simultaneously pressed during the rotation
of the encoder the number of output is decremented or incremented by ten. This is possible only if the LED x10 DATA
[9] lights - for some of the parameters the ± 10 change function is not available. If the newly set value is different from
the current value (the current parameter value under which converter actually works), an indication flashes. Setting of
the new value must be confirmed by pressing the ENTER button [4].
After setting the new values of all required parameters pressing the EXIT [7] button to exit the edit mode.
It is also possible to switch to edit output parameters of by pressing the OUT [3] at any time.
4.1.2. "DMX SHIFT" PARAMETER
MXC-56 uses block of fifty-six consecutive DMX channels. Parameter "DMX Shift" can choose which of the
512 possible DMX channels will be used. Parameter directly determines the number used by the lowest DMX channel
(i.e. shift of DMX channels). Graphical representation of the DMX block is shown in Fig. 7.

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
9
Fig. 7 - DMX SHIFT parameter
4.1.3. "MIDI CHANNEL" PARAMETER
Parameter specifies the MIDI channel on which the MXC-56 receives MIDI commands. It may be chosen from
any of MIDI channels 1 to 16. Selected number of MIDI channels simultaneously serves as an device identification
number (Device ID) for SysEx communication (00h to 0Fh).
4.1.4. "MIDI MODE" PARAMETER
MXC-56 can use MIDI commands Note On / Off + Key Aftertouch and Control Changes (MIDI controllers) to
control outputs. This parameter determines which of these types of MIDI commands is used.
If the "Note" mode is selected a block of fifty-six consecutive MIDI notes is used to kontrol the outputs. In
"Note" mode converter accepts MIDI commands Note-On, Note-Off and Key Aftertouch-for note numbers chosen by
"MIDI Shift" parameter (see below).
If the "Controller" mode is selected a block of fifty-six consecutive MIDI controllers is used to control the
outputs. In "Controllers" mode converter accepts MIDI Control Change commands for controllers numbers chosen by
"MIDI Shift" parameter (see below).
4.1.5. "MIDI SHIFT" PARAMETER
Obr. 8 - MIDI SHIFT Parameter

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
10
MXC-56 converter can process a block of fifty-six consecutive MIDI not / controllers of the total potential range
of 128 notes / controllers. The parameter "MIDI Shift" set the number from which MIDI note / controller MXC-56 start
to respond - the parameter value determines the number of the lowest MIDI note / controller in the block, which will be
used to control the MXC-56. Graphic representation of valid control block of MIDI notes / controllers is shown in fig. 8.
4.1.6. "MIDI MASTER CC Nr." PARAMETER
In order to use a simultaneous dimming or lighting off all required reflectors with a single controller, the
operating system of MXC-56 has implemented the "Master Controller". As the main regulator of simultaneous
controlling of all the selected outputs may be used any MIDI controller (Control Changes).(see the output "Accept
Master")
If any of these is selected by "MIDI Master Controller" parameter, the transmitted values of DMX channels is
directly proportional to the value of selected MIDI controller. When the value of the selected controller is equal to
zero, in all used DMX channels is transmitted a minimum value, for the value equal 127 are then transmitted values
given by control MIDI commands forindividual channels to the used DMX channels.
Parameter can take values from 0 to 127, parameter directly defines the number of MIDI controller to be used
as a "Master" controller.
Attention! If the Control Changes is selected by parameter "MIDI Mode" and the number of "MIDI Master
Controller" is included in the block of controllers used to control outputs, the controller will be used primarily as a"
master "controller and not to control the output thus!
4.1.7. "MIDI BLACKOUT CC Nr." PARAMETER
The "Blackout" allows the simultaneous turn-off of all selected outputs (see the output "Accept Blackout"). If
the function is activated, the selected outputs are immediately disabled and remain so until the "Blackout" function is
cancelled.
As a controller of the "Blackout" function for the selected outputs can be used any MIDI controller (Control
Changes) - parameter can take values from 0 to 127 and the value of the parameter directly determines the number
of MIDI controller that will be used as a "Blackout" controller.
Attention! If the parameter "MIDI Mode" is selected by Control Changes and the number of "MIDI CC Nr
Blackout" is included in the block of controllers used to control outputs, the controller will be used primarily as a
"Blackout" controller and will not control the corresponding output thus!Similarly, the "Blackout" controller has higher
priority than the "Master" controller - if the "Master" and the "Blackout" has assigned the same MIDI controller, this
controller will control only the "Blackout" function!
Note: The "Blackout" may also be activated by an external switch accordigly to the system configuration
parameter "Foot Switch Function.
4.1.8. "FOOT SWITCH FUNCTION" PARAMETER
Parameter selects function of an external switch connected to the connector-FOOT SW [13]. You can
choose one of two functions:
In the "Blackout" function pressing of an external switch turn off the outputs that have with the parameter
"Accept Blackout" (see chapter 4.2.7.) response to "Blackout" controller enabled. Function is the same and fully
equivalent
In the "Master" function pressing of the external switch simulates controller settings "Master" to the
maximum value. External switch has a higher priority, so that, changes of the controller "Master" by using MIDI
commands are ignored when external switch is pressed.
4.1.9. "MEMORY PROTECTION" UTILITY
This utility allows to enable or disable the memory protection of user parameters against overwriting of
stored data. When the protection is active (value On) it is not possible to edit the parameters and received System
Exclusive message for change of parameter values are also ignored. During the reset (turn-on) of MXC-56 memory
protection is always activated.

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
11
4.1.10. "BULK DUMP" UTILITY
The last item in the system parameters menu is an utility "MIDI Bulk Dump. This utility allows to backup the
entire contents of user memory in MIDI sequencer in the form of MIDI System Exclusive messages.
After selecting the utility in the parameters menu the display request "Dump?". By pressing the ENTER button
start the transmit of the data to the output MIDI-OUT [11]. All the outputs data and the global system data are
transmitted. The actual transfer progress is shown on the display.
4.2. OUTPUTS PARAMETERS
Output parameters are valid for one output only. Each output may therefore have individual settings of all
parameters. Before adjusting the output parameters the memory protection must be disabled (see the system
parameter "Memory Protection"). When you try to edit the outputs parameters with memory protection enabled, the
converter does not respond to any changes and the display shows warning message (symbol "Prt" = Protected).
Table 4 – Parameters of the outputs
Parameter Values Parameter
name Description Symbol Range Symbol Description
Default Value
Set the default value of the
output after the device is
switched on (reset) 0 ~ 127
0 Æ output off
127 Æ max. value
Curve Output curve (see pic.9)
Lin
0-1
Lg1 ~ Lg6
Ex1 ~ Ex6
S1 ~ S5
Z1 ~ Z5
0 Æ output off
Preheat Minimal value of the output
(preheat) 0 ~ 127
0 Æ no preheat
127 Æ max. preheat
Limit Maximum output limiter (limiter) 255 ~ 128
255 Æ no limit
128 Æ max. limit
Accept Master Enable /disable "Master"
control of the output
No
Yes
No Æ Disabled
Yes Æ Enabled
Accept Blackout Enable /disable „Blackout“
function of the output
No
Yes
No Æ Disabled
Yes Æ Enabled
4.2.1. OUTPUT PARAMETERS SETTINGS
To enter edit mode, pressing the OUT [3] button. Left part of the display [1] shows
"OUT" symbol and the right part the number of output. First select by the rotary encoder
DATA [10] the number of output whose parameters will be edited. Rotating the encoder to
the left decrements the number of units, turning right increments the number of output unit.
If there is simultaneously pressed the button DATA x10 [8] while rotating encoder, the
number of output is decremented or incremented by multiple of ten. To confirm the selected output press the ENTER
button [4] or exit the diting mode by pressing the EXIT [7] button.
When the output is selected the left side of the display shows the symbol of the edited parameter the right part
shows its current value. Parameter value can be set by rotary encoder DATA [10]. Rotating the encoder, while
pressing the button DATA x10 [8], changes the value by ± 10 - this feature is indicated by LED DATA x10 [9]. If the
newly set value is different from the current parameter value, the displayed value is flashing. Setting of new value
must be confirmed by pressing the ENTER button [4].
To browse system parameters press PREV [5] (jump to the previous parameter) and NEXT [6] (jump to the
next parameter) buttons according to table 4.
By pressing EXIT [7] and OUT [3], after setting the new values of all parameters of the output, return to the
selection of the output for editing. Now you can continue adjust the parameters of another output.

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
12
After setting all the parameters of the outputs editing mode should be stopped. This is done by pressing the
EXIT [7] button repeatedly.
4.2.2. "DEFAULT VALUE" PARAMETER
Parameter "Default Value" choses default value of the output, i.e. the value at which the output is set during
the reset sequence.
Parameter can take values from 0 to 127, parameter directly corresponds to the input value for the
corresponding MIDI output. At the level 0 is the output parameter off, at the parameter value 127 has output a
maximum possible value.
4.2.3. "CURVE" PARAMETER
Fig. 9 – Curve shapes

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
13
To convert the input MIDI data to the output DMX data is possible to select one of the twenty-two predefined
transfer curves, linear, or double state transfer (on / off switch).
Conversion dependencies are shown in the graph in Figure 9. Appropriate conversion curve should be
selected by the type of used light bulbs and the conversion features of the dimmer, to enable brightness changes of
light bulbs as evenly as possible across the range of values of input MIDI control data . Choice of binary output (on /
off switch) is suitable for DMX devices that are not controlled continuously, but are only switched on and off (eg. fog
machines, fireworks, etc.). "S" type curves have a reduced sensitivity in the central position of control and "Z" type
curves have a reduced sensitivity in the extreme positions of the control.They can be used eg. for general
management of moving lights.
Obr. 10 - "Preheat" and "Limit" parameters impact on transmitted DMX values

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
14
4.2.4. "PREHEAT" PARAMETER
By the "Preheat" parameter you can specify a minimum value below which must never fall the value
transmitted to the DMX channel. This allows for example permanent bulb preheat and thus extend its life several
times during blinking.
Parameter can have values from 0 to 127, value of parameter directly corresponds to the minimum permitted
value for the DMX channel. At 0 level the preheat parameter is off, value 127 is for maximum preheat. For the
graphical description of the "Preheat" parameter impact on transmitted data see Fig 10.
4.2.5. "LIMIT"PARAMETR
'Limit' parameter sets the maximum value transmitted to the corresponding DMX channel, ie. it is possible to
limit the maximum brightness of the reflectors.
Parameter can have values of 0 to 127. The value indicates the amount of the limitation of the maximum
transmitted to DMX. The value 0 sets no limitation, while 127 is for the maximum limitation (maximum value
trasmitted to DMX is given by the following formula: DMX = 255 - Limit, ie. 255 to 128 ). Graphically, the impact of the
"Limit" parameter is shown in Fig 10.
4.2.6. "ACCEPT MASTER" PARAMETER
Parameter enables (the symbol "Yes") or disables (symbol "No") the "Master" controller changes for to the
DMX channel. To enable "Master" controller is suitable for outputs (DMX channels) used to control dimmers. For
outputs (DMX channels) controlling the movement of lights or speed of stroboscopes, is suitable to disable the
"Master" controller.
4.2.7. "ACCEPT BLACKOUT" PARAMETER
Parameter enables or disables the effect of the value transmitted to the DMX channel by the "Blackout"
function. Enable "Blackout" is suitable for outputs (DMX channels) controlling dimmers. For outputs (DMX channels)
controlling the movement of lights or speed of stroboscopes, is suitable to disable the "Blackout" controller.
5. MIDI IMPLEMENTATION
MXC-56 recognizes the channel commands, the common system commands and System Exclusive MIDI
messages. Channel commands are accepted only on MIDI channel selected by the system parameter "MIDI
Channel".
5.1. CHANNEL COMMANDS
MXC-56 recognizes MIDI channel commands "Note Off", "Note On", "Key Aftertouch" and "Control Changes"
respecting the status byte (Running Status).
Note On
Enabling Note-On command is subject to setting up a system parameter "MIDI Mode" to "Note". There are
accepted two values when receiving the command "Note On". The note number (Note Nr) and speed sensitivity
(Velocity). From the total range of note numbers (0 to 127) is always accepted only 56 consecutive notes. Note
number of the first accepted note determines the parameter "MIDI Shift" (see also Figure 8). Speed sensitivity
(Velocity) gives a value that will be sent to the corresponding output.
Note Off
Enabling of Incomming Note-Off command is the same as the Note-On command, subject to setting up a
system parameter "MIDI Mode" to "Note". Again, it is accepted only 56 consecutive notes accordingly to the setting of
the system parameter "MIDI Shift. Always when received a valid command, the corresponding output is switched off.
Key Aftertouch
Enabling Note-Off command, like the previous commands, is enabled by setting up a system parameter "MIDI
Mode" to "Note". Again, it is accepted only 56 consecutive notes accordingly to the system parameter "MIDI Shift.

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
15
Always when received a valid command, the corresponding output is set to the value of Key Aftertouch command
(second databyte command).
Valid command "Key Aftertouch is always accepted - regardless of whether the note had forerun the Note-On
command.
Control Changes
MXC-56 accepts normalized controllers Nr. 120, 121 and 123:
Control Changes Nr. 120 - All Sound Off
Controller is accepted only in MIDI mode "Note" (see the system parameter "MIDI Mode"). Always when this
controller is received (his second databyte must have value 0) all outputs are set to default values.
Control Changes Nr. 121 - Reset All Controllers
If this MIDI controller is received (the second databyte must have value 0) the "Master" controller is
immediately set to the highest value and the "Blackout" controller is disabled. If the converter works in
"Controller" mode (see the system parameter "MIDI Mode"), all outputs are set to default values (depending on
the parameter "Defult Value" of each output).
Control Changes Nr. 123 - All Notes Off
Controller is accepted only in the "Note" MIDI mode (see the system parameter "MIDI Mode"). When receiving
the controller (his second databyte must have value 0) all outputs are set to default values.
Control Changes Nr. @ Master CC Nr.
Controller selected by the system parameter "Master CC Nr" works as the main regulator for all enabled
outputs (see the output "Accept Master"). The value of the controller (second databyte MIDI Msg) may be in
full range of 0 to 127
Control Changes Nr. @ Blackout CC Nr.
Controller selected by system parameter "Blackout CC Nr" controls the "Blackout" function. For the values of 0
to 63 the function is disabled, the values of 64 to 127 activate the "Blackout" function.
Control Changes Nr. @ MIDI Shift ~ @ MIDI Shift + 55
If the converter operates in "Controller" mode (see the system parameter "MIDI Mode"), in addition to the
above-described MIDI controllers is accepted block of additional 56 consecutive MIDI controllers. Number of
the first controller in the block is defined by the system parameter "MIDI Shift" (see also Figure 8), these
controllers will control individual outputs of the converter.
5.2. SYSTEM COMMANDS
MXC-56 recognizes only the command "System Reset" (status byte FFh) of the common system commands
(Common System Messages). Always when receiving "System Reset" MIDI command the reset sequence is
launched (as well as after switching MXC-56 - see chapter 3.1) and then the device returns to normal working mode.
5.3. SYSTEM EXCLUSIVE COMMUNICATION
MXC-56 has a MIDI System Exclusive communication implemented, which allows remote set up and storing in
memory of all the parameters (Load Data) and can also request the actual list of parameter values (Data Request /
Data Save).
Detailed description of the System Exclusive communication is in a separate document.
For the simple creation of custom SysEx Messages for setting MXC-56 please use the software generator
supplied on the accompanying CD-ROM by which you can generate any SysEx messages for MXC-56.

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
16
6. TECHNICAL SPECIFICATION
Supply voltage : external power supply unit - DC 8 V to 15 V
Consumption : 250 mA max
Protection : protected against reversal of supply voltage polarity
Connector of supply adapter : standard, diameter 6 / 2.1 mm
MIDI bus : according to MIDI Manufacturer Association standards
MIDI connectors : 2x DIN 41524 (5 pins / 180°)
DMX bus : according to USITT and EIA-485 standards
DMX connector : XLR female, 3 pins
Number of DMX channels : 56 independently controlled
Transit data delay : MIDI IN Æ OUT : max. 1 ms, typ. 0,4 ms
MIDI IN
Æ DMX : max. 1 ms, typ. 0,6 ms
Dimensions : 140 mm (width) x 35 mm (height) x 105 mm (depth)
Weight : approx. 250 g
Electrical design : under the regulations of the ČSN EN 60335-1+A55,
ČSN EN 60335-2-45
EMC : under the regulations of the ČSN EN 55014
Operating environment : standard
Range of operating temperature : +10 to +35 °C
Relative environmental humidity : up to 85 %
7. WARRANTY CONDITIONS
Equipment comes with thirty-month warranty starting from the date of equipment take-over by the customer.
This date must be specified on warranty list together with dealer's confirmation.
During this period of time, all defects of equipment or its accessories, caused by defective material or faulty
manufacturing, will be removed free of charge.
Warranty repair is asserted by the customer against the dealer.
Warranty period is to be extended for the time period, during which the product was under the warranty repair.
Relevant legal regulations take effect in case of cancellation of purchase contract.
Customer will lose the right for free warranty repair, if he will not be able to submit properly filled out warranty
list or if the defects of the product had been caused by:
- unavoidable event (natural disaster),
- connecting the device to incorrect supply voltage,
- inputs or outputs overloading by connecting the signals source or load source with not-corresponding
characteristics etc.,
- faulty equipment operation, which is in conflict with instructions referred-to in the operating manual,
- mechanical damage caused by customer during transportation or usage of equipment,
- unprofessional interference with the equipment or by equipment modification without manufacturer’s approval.

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
17
APPENDICES
A. MIDI IMPLEMENTATION CHART
MIDI IMPLEMENTATION CHART
Device : MXC-56 Date : 10 / 2008
Model : 8-462 Version : 1.0
Function Transmission Reception Remarks
Basic
Channel
Default
Changed
X
X
1~16
1~16
1
)
1
)
Mode Default
Messages
X
X
Mode 3
X Not Altered
Note Number X 0~127
2
)
Velocity Note ON
Note OFF
X
X
O
X
After
Touch
Key's
Channel's
X
X
O
X
Pitch Bender X X
Control
Changes
@…
@Master CC
@Blackout CC
120
121
X
X
X
X
X
O
O
O
O
O
56x
2
)
3
)
3
)
All Sound Off
2
)
Reset All Controllers
Program Change X X
System Exclusive O O See description
System
Common
Song Position
Song Select
Tune
X
X
X
X
X
X
System
Real Time
Clock
Command
X
X
X
X
Others Local ON/OFF
All Notes Off
Active Sensing
Reset
X
X
X
X
X
O
X
O
2
)
Notes :
1
) Can be changed by user
2
) Depend on “MIDI Mode“ and “MIDI Shift“ setting
3
) CC Nr. depend on system parametrers setting
Mode 1 : OMNI ON, POLY
Mode 3 : OMNI OFF, POLY
Mode 2 : OMNI ON, MONO
Mode 4 : OMNI OFF, MONO
O : Yes
X : No

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
18
B. ERROR MESSAGES
If the operation of MXC-56 fails to work, the program is stopped and the operator is informed of this situation
on the display by "Err symbol. The number after the symbol determines the type of error occurred (see Table 5).
Table 5 – Error messages
Error
Display
indication Message Description
Err. 1 EEPROM-MALFUNCTION Damaged (not working) parameter memory
Err. 2 EEPROM-BUSY-TIMEOUT Slow parameter memory
Err. 4 EEPROM-FAIL-CELL Damaged memory cell of the parameter memory
Err. 16 MIDI-IN-FIFO-OWERFLOW MIDI communication buffer owerflow
Err. 32 DMX-UNIT-BUSY-TIMEOUT Transmitting DMX unit busy (too much data)
Err. 64 DMX-UNIT-MALFUNCTION DMX unit does not communicate with the CPU
Always when the system errors occur the device is permanently blocked. Re-entry into operation is possible by
switching the device off and on again (disconnecting the power adapter).
C. HARDWARE TESTS
The device has implemented test utilities for its hardware circuits. Before the start of the test utilities plug the
external foot switch in jack-FOOT SW [13]. To activate the test function press the buttons PREVIOUS [5] and NEXT
[6] and power on the device - plug the power adapter connector in. The display [1] will light the various segments - it
is possible to release both buttons at this moment.
a) Display test
At all positions of the display [1] sequentially light up each segment. Along with the dots the LED x10 [9] will
light up. The test is finished by pressing any key.
b) Button test
If you press any button, the display [1] lit segment corresponding to approximate position of the button on the
panel, which confirms the functionality of a button. After verifying the functionality of all seven buttons the device
automatically proceed to the next test.
c) Rotary coder test
The display [1] shows the number "00" in the middle and the LED x10 [9] lights. Rotating the rotary encoder to
the right the indicated number of unit increments, turning the encoder to the left decrements the number of units. If
there is simultaneously pressed the button x10-DATA [8], the indicated number is incremented or decremented by
multiples of ten. After reaching the limit (30 to the right respectively -30 to the left) the brackets symbol will be
displayed left resp. right on the display [1] and remains permanently visible. After reaching both limits (i.e., two
brackets are displayed) the device will automatically proceed to the next test.
d) Foot switch test
The display [1] shows the symbol "Sv". Press and release the external switch. Correct contact is indicated by
the symbol "On" on the display, the release is indicated by the !Off" symbol. If the foot switch works correctly the
display [1] after a while shows symbol "OK" and automatically proceed to the next test.
e) MIDI interface test
The display [1] displays the symbol "Mid-Er" (i.e., MIDI - Error). Connect MIDI connectors MIDI-IN [12] and
MIDI-OUT/THRU [11] with MIDI cable. If there is a correct connection the display show "Mid-ok". The test is finished
by pressing EXIT [7].

MXC-56 MIDI to DMX-512 Converter Model 8-462 ver. 1.0
Copyri ght © 2008 CHD Elektroservis. Všechna práva vyhrazena.
Tato publi kace ani žádná její část nesmí být reprodukována v jakékoliv formě bez písemného souhlas u výrobce zařízení.
19
f) DMX interface test
The display [1] shows the symbol "DMX" in its left part and numbers 0 to 127 in the right part, which indicates
the zero and the maximum possible value for DMX output [14], to DMX channels 1 to 56. The transmitted value can
be changed by rotary encoder DATA [10] on the unit or by the multiples of ten, with simultaneously pressed x10-
DATA [8] button. The test is finished by pressing EXIT [7].
g) CPU memory test
During the testing of RAM CPU the display [1] shows the symbol "CPU" on the left. After completing the test,
the right side of the display shows the result: If the CPU memory is correct - "ok" and it automatically proceed to the
next test. If there is a CPU memory error the displays shows flashing symbol "-er" (Error). Proceeding to the next test
is only possible by pressing the confirmation button EXIT [7].
h) EEPROM parameter memory test
During testing of the EEPROM the left prt of the display [1] shows the symbol "MEM". After completing the
test, the right part of the display shows the result. If the memory is correct, display the symbol "ok" and automatically
continues. If there is an error in the memory a flashing symbol "Er" (Error) appears and it is necessary to press the
confirmation button UP [5] to proceed.
After the execution of all tests, the display prompts "Init?". You can now press the ENTER button [4] to perform
a complete initialization of the device (Factory Reset all parameters), after which the device enters a normal working
mode, or you can press the EXIT button [7] to skip the inicialization procedures and continue the normal operating
mode. In this case, the internal memory save the user´s preset parameters.

7
