Checkpoint ATP3 Series User manual

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 1 of 13
Series ATP3
Electric Chemical Injection Pump
Operating Manual
CheckPoint Headquarters
CheckPoint UK
CP Pumps & Systems FZE
21356 Marion Lane
C2 Lombard Centre
Shed 2, Warehouses 7 & 8
Mandeville, Louisiana 70471
Kirkhill Place, Kirkhill Industrial Estate
RAK Technology Park | P.O. Box 54796
United States of America
Dyce, Aberdeen AB21 0GU Scotland
Ras Al Khaimah | UAE
[phone]
[phone]
[phone]

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 2 of 13
TABLE OF CONTENTS
1. MARKINGS 4
2. SPECIAL CONDITIONS OF SAFE USE: 5
3. SYSTEM REQUIREMENTS 5
3.1 Inspection............................................................................................................................................. 5
3.2 Storage.................................................................................................................................................. 5
3.3 Unpacking............................................................................................................................................. 6
3.4 Safety .................................................................................................................................................... 6
3.5 Typical Installation Schematic........................................................................................................... 6
3.6 Connect chemical and process lines. ................................................................................................ 8
4. MOTOR INSTALLATION 8
4.1 Motor Requirements........................................................................................................................... 8
5. INJECTION HEAD ASSEMBLY 9
5.1 Installing the Injection Head Assembly ............................................................................................ 9
6. STROKE LENGTH ADJUSTMENT 10
6.1 Adjusting the stroke length ............................................................................................................. 10
7. OPERATION 11
7.1 Initial Startup..................................................................................................................................... 11
8. TROUBLESHOOTING 12
8.1 Pump does not stroke....................................................................................................................... 12
8.2 Drive is excessively noisy ................................................................................................................. 12

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 3 of 13
8.3 Miscellaneous .................................................................................................................................... 12

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 4 of 13
This manual covers the installation and operation of CheckPoint Electric motor-driven ATP
CAUTION:
1. Do not operate pump without reading all of the following information.
2. Follow all local rules, regulations, and safety requirements, and ensure that you
are wearing proper PPE at all times.
3. Before troubleshooting the pump, ensure that power is disconnected from the
pump according to site protocol.
4. The electric motor must be connected so that its direction of rotation is the same
as the arrow on the gearbox. Motor polarity is important. The Pump Drive’s input
shaft must be turned counterclockwise to prevent premature failure.
1. MARKINGS
Details
ATEX
Product
ATP Pump Assembly
Model
****
Serial Number
****
Hazardous Location Marking
II 2G
Ex h IIC T3 Gb
Ambient range & Process
Temperature range:
Ta: -20°C to +60°C
Ratings
5000PSI
66RPM
Shaft” 5/8”
Max Rod Force: 200lbf/.89kN

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 5 of 13
Warnings
WARNING - DO NOT OPEN, MAINTAIN, OR SERVICE IN AN AREA
WHERE AN EXPLOSIVE ATMOSPHERE MAY BE PRESENT
WARNING – THE CLEANING OF THE EQUIPMENT SHALL BE DONE
ONLY WITH A DAMP CLOTH
REFER TO MANUAL FOR CONDITIONS OF SAFE USE
2. SPECIAL CONDITIONS OF SAFE USE:
i. The maximum surface temperature rise has been assigned as T3 (200°C). Any flammable
substances with an auto-ignition temperature of less than 200°C must not be used when the equipment is
energized.
ii. It is the responsibility of the end-user that the intended site of operation has been correctly
classified in accordance with the ATEX Directive and that the equipment placed into service is compatible
with that classification.
iii. It is the responsibility of the end-user to ensure that an appropriate inspection and maintenance
schedule is established to ensure effective operation.
iv. Only competent, trained operators should use the equipment.
v. The replaceable components must be identical and meet the same specifications as the replaced
ones as per the OEM’s recommendation. All the replacement activities shall take place only when the
equipment is de-energized AND the area is known to be NON-HAZARDOUS AREA.
3. SYSTEM REQUIREMENTS
3.1 Inspection
Before installation, please inspect the pump carefully. If the pump appears to have sustained damage in
transit, call your CheckPoint Authorized Distributor or CheckPoint Customer Service directly at +1 (504) 340-
0770 to report and confirm damage. If it is determined that damage occurred in transit, a carrier claim will be
required.
3.2 Storage
The ATP pump has been thoroughly tested at the CheckPoint factory prior to shipment. This testing may
leave residual fluids in the pump head. Although our pumps can be placed in service without environmental
protection, we suggest that they are stored indoors until being commissioned.

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 6 of 13
3.3 Unpacking
The ATP pump can be shipped as a single-head or dual-head pump. Please ensure that unpackaged pumps
are securely placed in a safe area. Refer to the CheckPoint Quick Setup Guide for installation of the ATP
pump.
3.4 Safety
The ATP can produce high rod loads. All CheckPoint pump heads used with the ATP have been designed to
eliminate pinch points
3.4.1 For safe and continuous operation, locate the pump with supplied base on a stable and level surface
with sufficient access for the operator.
3.4.2 CheckPoint ATP requires horizontal mounting. Improper mounting could result in poor drive
performance and difficulty during priming. The ATP base is provided to ensure proper orientation.
3.4.3 The pump may be mounted to a skid or other surface in a number of ways; however, clamping around
the outside of the drive is not recommended. Proper mounting techniques increase accessibility during
maintenance and troubleshooting.
3.4.4
3.5 Typical Installation Schematic
FIGURE 1: TYPICAL INSTALLATION

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 7 of 13
CheckPoint offers Series ATP pump packages, which contain all necessary components indicated within the Package Limit Line in Figure 1.
CheckPoint can also supply pump packages that contain ALL components indicated in Figure 1, including the tank, mounted on a single skid,
with or without full leak containment.
1. Suction Line Block Valve 4. CheckPoint Calibration Gauge* 7. PRV – Discharge Lline 10. Discharge Check Valve*
2. CheckPoint Chemical Filter* 5. Tank Gauge 8. CheckPoint Series ATP Chemical Pump
3. Calibration Gauge Block Valve 6. Discharge Line Block Valve 9. Discharge Pressure Gauge
All items in Figure 1 can be purchased from CheckPoint. Call today for our latest prices on pumps, gauges, packages and other components.
*CheckPoint OEM products

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 8 of 13
3.6 Connect chemical and process lines.
Always clean suction lines and check chemical containers to ensure that they are free of all foreign matter,
sand, sludge, or chemical buildup.
NOTE: Even new chemical tanks can contain debris, which may cause system damage. Removing
foreign debris from suction lines and chemical containers will substantially extend the life of
the High Pressure Seal and other pump components.
NOTE: A presuction in-line chemical filter is strongly recommended to prevent early packing failure.
Abrasive particles carried into the pump through suction plumbing is a common cause of
high pressure seal failure. CheckPoint offers a range of chemical filters suitable for use with
the ATP pump.
3.6.1 Suction Check
The attach point is a ¼” MNPT thread. Apply thread sealant, taking care to keep the sealant away from the
inlet port. Sealant entering the check could cause the pump to operate incorrectly.
3.6.2 Discharge Check
The attach point is a ¼” MNPT thread. Apply thread sealant, taking care to keep the sealant away from the
discharge port. Sealant entering the process line could cause issues downstream.
4. MOTOR INSTALLATION
The base model ATP comes with the motor already installed. Should you need to remove the motor for any
reason, install per the motor install drawing located on the CP website.
4.1 Motor Requirements
4.1.1 Connect Power
• Special attention should be paid to motor type and location hazards prior to hookup. The electric
motor must be connected in accordance with all local regulations and area classifications and
should include overload protection.
• It is recommended that the ATP installation is equipped with an easily accessible “emergency off”
switch.

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 9 of 13
5. INJECTION HEAD ASSEMBLY
The base-level ATP pump assembly comes with a single head attached to the drive assembly (shown in
Figure 2).
5.1 Installing the Injection Head Assembly
To install the injection head assembly, follow the instructions below:
1. Screw in the head bolts until the hex heads are approximately ½” from the injection head.
2. Carefully align head assembly onto plunger and corresponding bolt holes in the housing.
3. Gently push the injection head assembly until the bolt heads fully pass through the housing and the
injection head assembly is seated against the housing.
4. Turn the injection head assembly clockwise until it stops. The check valves will be vertical when
properly installed.
5. If the injection head assembly cannot be turned all the way, loosen the head bolts 1-2 turns and
repeat step 4.
6. Tighten the head bolts to 45 in-lbs. Do not over tighten.
FIGURE 2: INJECTION HEAD ASSEMBLY
*Motor and Base Removed for Clarity

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 10 of 13
6. STROKE LENGTH ADJUSTMENT
Both injection heads operate independently and have adjustable stroke lengths between 0” - 0.75”.
6.1 Adjusting the stroke length
Pump Delivery Volume is controlled by adjusting the stroke length. To change the stroke length, the
adjustment screw is rotated clockwise for shorter stroke length or counterclockwise for longer stroke
length. The adjustment scale on top has indicators for approximate percentage of stroke. Note: These
values are only approximate. Depending on plunger size the zero point may vary slightly.
Max. stroke length ( ¾”)– Line up the adjustment indicator to the 100% marking for max stroke length
Min. stroke length (0”) - Line up the adjustment indicator to the 0% marking for minimum stroke length
FIGURE 3: SHOWN AT 100% STROKE FIGURE 4: SHOWN AT 0% STROKE

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 11 of 13
7. OPERATION
The ATP drive requires no additional lubrication. The ATP drive has sufficient grease in the drive assembly
prior to shipment.
Pump Flow Rate – DC Motor
• The flow rate is adjusted by changing the motor rpm and by changing the stroke length.
NOTE: Adjusting the motor’s rpm during operation will not damage the ATP pump. Refer to your
motor manufacturer’s manual to determine the effects of adjusting RPM during operation.
Pump Flow Rate – AC Motor
• The AC motor does not include an integral speed adjustment. The flow rate can only be varied by
adjusting the stroke length.
7.1 Initial Startup
7.1.1 Ensure that no leaks are visible prior to startup.
7.1.2 Disconnect the power to the motor.
NOTE: The pump was tested in-house prior to shipping, using water with 5% water-based lubricant.
If the residual liquid remaining in the pump from testing could cause issues with the
chemical, flush the head prior to use.
7.1.3 Open the chemical supply and system pressure valves.
7.1.4 Start the motor.
7.1.5 Bleed the injection head.
7.1.6 Adjust the flow rate.

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 12 of 13
8. TROUBLESHOOTING
8.1 Pump does not stroke
8.1.1 Check the power to the motor.
8.1.2 Ensure proper motor sizing for the particular application. Contact CheckPoint or your Authorized
CheckPoint Distributor for sizing assistance.
8.1.3 Check to see if there is damage to the keyway. A key may have sheared during an overload situation.
Inspect all bores and keyways for damage or missing components.
8.2 Drive is excessively noisy
8.2.1 Drive components may be worn.
8.2.2 The motor or gear reducer may be worn. Contact your drive component manufacturer.
8.3 Miscellaneous
If you are experiencing an operating problem not listed above, or if none of the above troubleshooting actions
solve your operating problem, please contact your Authorized CheckPoint Distributor, or contact CheckPoint
directly at [phone] or [email protected]. We will work to assist you in determining the
appropriate next steps. Once CheckPoint has had the opportunity to assist you with troubleshooting your
problem, please keep in mind the following information regarding repairs.
8.3.1 CheckPoint offers exchange programs to keep you in service.
8.3.2 CheckPoint will ship you a rebuilt pump, which you will be able to install prior to sending us your existing
pump. Upon receipt of your pump, we will tear it down, rebuild it, and report to you our findings. We offer a
fixed-price exchange plan, an actual-cost plan, and a consigned exchange plan. Please contact CheckPoint to
learn more about our unique exchange services.
8.3.3 Although the Series ATP has been designed for easy operation and repair, the best way to ensure
continued reliable service is to have your pump repaired by CheckPoint’s factory. OEM repair services ensure
CheckPoint quality and reliability.
8.3.4 After your CheckPoint pump has been repaired, it should perform like new
8.3.5 If your pump is anything less than exceptional, call us to determine what can be done to restore the
pump to “like-new” performance.
8.3.6 Training sessions are available. CheckPoint strives to maintain excellence in all that we do, and we are
happy to share our knowledge with you. If you would like to train your employees regarding anything involving
CheckPoint Pumps & Systems, please contact us to discuss training options.

Series ATP Reciprocating Drive - Single or Dual Head
With External Adjustable Stroke Length
Operating Manual
CP-MAN-PRD-021 REV01 EFF. DATE 3/31/2023 Page 13 of 13
