Caple BUCH User manual

Built Under Extractor
Instruction Manual
BUCH
Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk

Instruction manual BUCH
2Please keep this instruction manual for future reference
CONTENTS
Safety Instructions 3
Environmental Protection 9
Product Overview 10
Ducting Options 11
Installation 12
Operation 14
Cleaning and Maintenance 14
Caple Contact Details 16

3
Please keep this instruction manual for future reference Instruction manual BUCH
IMPORTANT
Please read this instruction manual before installing and
using this cooker hood. Keep this instruction manual in a
safe place for future reference.
-Never pull the power cable as you could damage it.
If the appliance is faulty, do not attempt to repair it.
Isolate it from the mains electric supply and contact
Caple Service either by phone [phone] or email
[e-mail]
-Keep all packaging (including plastic bags, polystyrene
foam etc) out of the reach and away from children.
-Do not rest large or unstable objects on any part of the
appliance.
-Caple cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product.
-Please note that Caple reserve the right to invalidate
the guarantee supplied with this product following
incorrect installation or misuse of the appliance. Under
no circumstances should any external covers be removed
for servicing or maintenance except by suitably qualified
personnel.
INSTALLATION WARNINGS:
-Do not operate the appliance before it is fully installed.
-Only a qualified and trained service technician can
undertake the work of installation and servicing.

Instruction manual BUCH
4Please keep this instruction manual for future reference
-Two or more people are required to install or move this
appliance. Failure to do so can cause physical injuries.
-Caple is not responsible for any damage that may
be caused by defective placement and installation by
unauthorised persons.
-When unpacking the appliance, make sure that it is
not damaged during transportation. In the case of any
defect; do not use the appliance and contact your retailer
or Caple Service immediately.
-Materials used for packaging (nylon, staplers, Styrofoam
etc) may cause harmful effects to children they should be
disposed of immediately.
-Protect your appliance against atmospheric effects. Do
not expose it to effects such as sun, rain, snow etc.
-The surrounding materials of the appliance (i.e. kitchen
cabinet or furniture) must be able to withstand a
minimum temperature of 120°C.
ELECTRICAL SHOCK HAZARD
-Only plug this unit into a properly earthed outlet. If in
doubt seek advice from a suitably qualified engineer.
-Failure to follow these instructions can result in death,
fire, or electrical shock.
-To protect against fire, electrical shock and injury to
persons, do not immerse cords or plugs in water or any
other liquid.

5
Please keep this instruction manual for future reference Instruction manual BUCH
-Do not use any accessories or attachments not
recommended by Caple as this may result in fire, electric
shock or injury.
-Never touch the appliance with wet or damp hands.
-This appliance must be connected to the mains by a
competent person. We recommend that the appliance is
connected by a qualified electrician who is a member of
the N.I.C.E.I.C who will comply with the I.E.E and local
regulations. Electrical information can be found on the
rating plate.
-Check that the mains voltage corresponds to the one
indicated on the rating plate fixed inside the hood.
-WARNING: Failure to install the screws or fixing device
in accordance with these instructions may result in
electrical hazards.
SAFETY INSTRUCTIONS:
-When using a gas hob, do not leave naked flames under
the extractor.
-Before connecting this appliance check that the power
supply cord is not damaged.
-If the room where the hood is to be used contains a fuel
burning appliance such as a central heating boiler then
its flue must be of the sealed or balanced flue type. If
other types of flue or appliances are fitted ensure that
there is an adequate supply of air to the room.

Instruction manual BUCH
6Please keep this instruction manual for future reference
-The air must not be discharged into a flue that is used
for exhausting fumes from appliances burning gas or
other fuels.
-Regulations concerning the discharge of air have to be
conformed to.
-Do not flambé under the cooker hood.
-Never leave frying pans unattended during use as
overheated fats and oils may catch fire.
-Do not check the status of the filters while the cooker
hood is operating.
-Do not touch the light bulbs after appliance use.
-To ensure the best performance, we recommend
switching on the extractor 15 minutes before cooking
and leave it running 15 minutes after. This will ensure
that the air in the kitchen is being circulated before
cooking commences and the air is being cleaned after
cooking has finished.
-The performance of your extractor will vary depending
on a number of factors. These include type of extraction,
room volume, length of ducting, ventilation available and
the cleanliness of the filters.
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.

7
Please keep this instruction manual for future reference Instruction manual BUCH
-This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance.
-Never let children operate the machine.
-Children should be supervised to ensure that they do not
play with the appliance.
-Never immerse the appliance in water.
-This appliance is intended to be used in household and
similar applications such as:
› Staff kitchen areas in shops, offices and other
working environments.
› Farm Houses.
› By clients in hotels, motels and other residential type
environments.
› Bed and breakfast type environments.
-To avoid all risk, if the power cable is damaged, it must
only be replaced by a Caple appointed engineer.
-Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.

Instruction manual BUCH
8Please keep this instruction manual for future reference
-Children must not play with this appliance.
-When not in use and before cleaning, always isolate the
appliance from the electrical supply.
CLEANING AND MAINTENANCE:
-Disconnect the hood from the main supply before
carrying out any maintenance work.
-Proper maintenance of the cooker hood will ensure
proper performance of the unit.
-The cooker hood and its filter should be cleaned regularly
in order to keep in good working condition.
-Clean the cooker hood according to the instruction
manual to reduce the risk of fire.
-Clean and/or replace aluminium grease filters and
activated charcoal filters after specified period of time.
-Cleaning and user maintenance must not be made by
children without supervision.
-Clean the hood using a damp cloth and a neutral liquid
detergent.
-DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately for
special treatment is necessary.
-If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.

9
Please keep this instruction manual for future reference Instruction manual BUCH
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product
WARRANTY
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date of
purchase, model and serial number. Registration can also be completed online by visiting
www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase. If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
UKCA DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation.
TECHNICAL FICHE
This appliance conforms to all current and applicable energy regulations. To view the Technical
Fiche that supports the energy labelling data, please visit the product page on our
website www.caple.co.uk

Instruction manual BUCH
10 Please keep this instruction manual for future reference
IMPORTANT:
1. Please read the entire instructions before installing the extractor.
2. Always switch power off prior to installation.
3. Stainless steel is very easily damaged during installation if scratched or knocked by tools.
Protect the extractor with the cardboard box or plastic bag during installation.
4. All electric work must be done in accordance with the local and national electrical codes
as applicable.
5. For safety, this product must be earthed.
6. A power outlet should be within 1500mm of the power cord exit from the extractor.
7. The power socket must be accessible and enable the end user to isolate the extractor from the
power for the purpose of internal cleaning or maintenance.
8. 150mm round ducting adapters are supplied. All other ducting accessories are not supplied.
All ducting must comply with local requirements and building codes.
See Ducting options next page.
PRODUCT OVERVIEW
DIMENSIONS
∅150mm
490mm
520mm
258mm
286mm
520mm
270mm
182mm
9mm
CONTENTS OF PACKAGING:
1 x Hood body
1 x face plate
1 x packet of fasteners and wall plugs
TYPICAL EQUIPMENT REQUIRED:
1. Electric drill
2. Screwdriver
3. Tape measure
4. Spirit level
5. Duct tape (if ducting)
6. Jig saw (if ducting)
7. Ladder (if ducting)

11
Please keep this instruction manual for future reference Instruction manual BUCH
DUCTING OPTIONS
The method of ducting should be carefully considered before installing the extractor. The guide
below recommends the ducting components to use for all common ducting configuration -
through the top of the home (the roof and soffit) and through the external wall. Alternatively this
extractor can be operated in recirculation mode.
NOTE:
This product should be installed using 150mm ducting.
Extra lengths and/or bends may be required, depending on the length required and whether there
is any structural material in the run e.g. rafters.
Long duct runs, elbows, and transitions will reduce the performance of the hood. Use as few of
them as possible.
Some authorities require extractors to be vented outside. Ducted models should comply with this
requirement in every aspect.
RECIRCULATION INSTALLATION:
If you are unable to duct the extractor via an outlet to the outside, the exhaust pipe is only
required to help remove the air from the cabinet. We recommend this is done by ducting the air
out of the top of the cabinet. The charcoal filters must be installed as shown on page 14-15.
NOTE: This product should be installed using 150mm ducting
910
scratched
the external wall.
Top Ducting Through Roof Side Ducting Recirculating
(Use charcoal filtered
discs mounted either
side into the motor)

Instruction manual BUCH
12 Please keep this instruction manual for future reference
INSTALLATION
Carefully remove the plastic protective film from all exterior surfaces of the hood prior to final
installation.
NOTE:
At least two people will be required to install the hood.
When installing the extractor, the lower edge of the unit must be a minimum of 650mm
(750mm for gas cooker) above the hob.
NOTE:
If the instructions for the gas hob specify a greater distance, this has to be taken into account.
650mm
For Gas 750mm

13
Please keep this instruction manual for future reference Instruction manual BUCH
MOUNTING THE EXTRACTOR
Before fixing the hood to the unit, drill
a hole of 165mm diameter for 150mm
ducting in the wall unit.
Check the position of the power outlet
and consider where the power cable
will run; a hole might have to be made
in the wall unit to accommodate it.
Create an opening of 492mm x 263mm
in the underside of the cupboard where
the hood will be installed.
Unscrew the 2 visible screws located
on both side-ends of the hood, 8
mounting holes around the unit are
then accessible.
Lift the cooker hood and place into the
cupboard opening. Secure the unit using
the eight long screws supplied and then
fit the face plate using the two screws
located on both sides. Make sure the lights
are located at the front.
Make the electrical connection.
263mm
190mm
492mm
343mm
504mm
272mm

Instruction manual BUCH
14 Please keep this instruction manual for future reference
OPERATION
CONTROLS
LIGHT:
The light can be operated independently by sliding the light switch on/off despite the working
status of the fan. Please refer to the icon switch panel.
FAN:
The fan is operated by sliding the power switch on. It can be run at three different speeds
(Speed 1/Speed 2/Speed 3) depending on the cooking requirements. Please refer to the icon on
the switch panel.
CLEANING AND MAINTENANCE:
Switch off the extractor before cleaning or maintenance. To prevent surface damage never use
abrasive or oil based liquid cleaners. To clean the surfaces of the appliance, use mild detergent and
warm water. In areas of high humidity and coastal environments cleaning should be carried
out frequently.
WARNING:
A build up of oil may occur if the extractor is not cleaned regularly.
FILTER MAINTENANCE:
To maintain efficiency, the filters should be removed regularly (approximately monthly), and
washed using hot soapy water or the dishwasher.
Extractor On/Off
Light On/Off

15
Please keep this instruction manual for future reference Instruction manual BUCH
NOTE:
Some discolouration of the frame may occur if washed in the dishwasher.
CHARCOAL FILTERS:
Extractors fitted with charcoal filters are designed to remove grease and odours from cooking
vapours prior to the cleansed air re-entering the kitchen (when the extractor is in recirculation
mode). The charcoal filters for this appliance cannot be regenerated or washed and should be
replaced every 6 months, these can be ordered from www.caple.co.uk (code CAP73CF).
To install the charcoal filter rotate it anticlockwise until the stop click is heard. To remove the
charcoal filters, rotate it clockwise.
NOTE:
Fully saturated charcoal filters can become a barrier to air movement therefore limiting extractor
performance. In the event of fire, grease laden filters could be flammable and therefore require
replacement is recommended.
REPLACING THE BULB:
To replace a bulb, first disconnect the extractor from the power supply. Use a small blade
screwdriver to prise off the lamp cover. Care must be taken to avoid the lamp lens falling to the
hob top. The bulb is a screw fit into the lamp socket. Insert the replacement bulb into the lamp
socket and replace the lamp cover.
The LED light must be replaced by an authorised engineer or similar only. For more information,
please contact Caple service - 0117 938 7420 or [e-mail]
PARTS AND ACCESSORIES LIST:
1. Charcoal filter (replacement code CAP73CF)
2. LED 2x2W
Replacement charcoal filters can be ordered from www.caple.co.uk, order the code CAP73CF for
this extractor. You can also order by calling 0117 938 1900.

Caple Service
Fourth Way
Avonmouth
Bristol
BS11 8DW
T: 0117 938 1900
E: [e-mail]
www.caple.co.uk
