3
3 Using the chip card reader
3.1 Chip cards with contact
➤Insert the chip card into the chip card slot with the chip
facing upwards and towards the read head in the chip
card shaft.
After a discernable pressure point has been passed,
contact takes place.
3.2 Non-contact chip cards/transponders
➤Position the chip card or transponder as parallel to the
chip card reader as possible. (You can also insert the card
into the chip card reader.)
Data is transmitted beginning at a distance of less than
5cm.
4Disposal
5Contact
ZF Friedrichshafen AG
Electronic Systems
Cherrystraße
91275 Auerbach
Germany
www.cherry.de
Telephone:
Sales: +49 (0) 180 5 243779* (0180 5 CHERRY*)
Technical support: +49 (0) 180 5 919108*
(*14 euro cent/min. from German landlines, prices may vary
for calls made from mobile networks.)
Please have the following information on hand when
contacting technical support:
• Item and serial no. of the product
• Name and manufacturer of your system
• Operating system and, if applicable, installed service
pack version
Dispose of the old unit via a collecting point for
electronic scrap or via your dealer.
6 General advice
CHERRY, a brand of ZF Friedrichshafen AG, continuously
optimizes its products as new technologies are developed.
For this reason we reserve the right to make technical
alterations. The evaluation of product reliability and the
definition of the product's technical performance are carried
out according to our own requirements in order to meet
internationally recognized regulations and standards.
Requirements in addition to these can be met through mutual
cooperation. Improper usage, handling, storage and external
influences could lead to faults and defects during use.
We do not accept warranty for defects caused by alterations
to our product by the user and shall not be held liable for
unauthorized modifications. All repairs must be made by us
or an officially appointed organization or person.
Possible compensation claims against ZF Friedrichshafen AG
or its nominated officers – whatever the legal justification
including physical or stress related injuries – are excluded.
Exceptions to this exist in the case of intent or gross
negligence on the part of ZF Friedrichshafen AG,
infringements of Product Liability Law or in cases of injury,
bodily harm or risk to health. These operating instructions
only apply to the accompanying product.
Full details can be obtained from your distributor or direct
from us.
