Chicago Electric 99675 Installation manual

19.2 VOLT, 4-1/2” ANGLE
GRINDER
99675
SET UP AND OPERATING INSTRUCTIONS
Distributed exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2008 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements,
actual product may differ slightly from the product described herein.
For technical questions or replacement parts, please call 1-800-444-3353.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 2
SAVE THIS MANUAL
Keep this manual for the safety warn-
ings and precautions, assembly, operat-
ing, inspection, maintenance and cleaning
procedures. Write the product’s serial
number in the back of the manual near the
assembly diagram (or month and year of
purchase if product has no number). Keep
this manual and the receipt in a safe and
dry place for future reference.
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling,
and all other information provid-
ed with this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that
follow this symbol to avoid
possible injury or death.
DANGER indicates
a hazardous
situation which, if not
avoided, will result in death or
serious injury.
WARNING
indicates a
hazardous situation which, if
not avoided, could result in
death or serious injury.
CAUTION, used
with the safety
alert symbol, indicates a
hazardous situation which, if
not avoided, could result in
minor or moderate injury.
NOTICE is used to
address practices
not related to personal injury.
CAUTION, without
the safety alert
symbol, is used to address
practices not related to
personal injury.
General Power Tool Safety
Warnings
WARNING Read all safety
warnings and instructions.
Failure to follow the warnings and
instructions may result in electric
shock, re and/or serious injury.
Save all warnings and
instructions for future reference.
The term ″power tool″ in the
warnings refers to your battery-
operated (cordless) power tool.
Work area safety1.
Keep work area clean and well lit.a.
Cluttered or dark areas invite acci-
dents.
Do not operate power tools inb.
explosive atmospheres, such as in
the presence of ammable liquids,
gases or dust. Power tools create
sparks which may ignite the dust or
fumes.
Keep children and bystandersc.
away while operating a power tool.
Distractions can cause you to lose
control.
Electrical safety2.
Power tool plugs must match thea.
outlet. Never modify the plug in
any way. Do not use any adapter
plugs with grounded power tools.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 3
Unmodied plugs and matching out-
lets will reduce risk of electric shock.
Avoid body contact with groundedb.
surfaces such as pipes, radiators,
ranges and refrigerators. There is
an increased risk of electric shock if
your body is grounded.
Do not expose power tools to rainc.
or wet conditions. Water entering
a power tool will increase the risk of
electric shock.
Do not abuse the cord. Never used.
the cord for carrying, pulling or
unplugging the power tool. Keep
cord away from heat, oil, sharp
edges or moving parts. Damaged
or entangled cords increase the risk
of electric shock.
When operating a power tool out-e.
doors, use an extension cord suit-
able for outdoor use. Use of a cord
suitable for outdoor use reduces the
risk of electric shock.
If operating a power tool in a dampf.
location is unavoidable, use a
Ground Fault Circuit Interrupter
(GFCI) protected supply. Use of
a GFCI reduces the risk of electric
shock.
Personal safety3.
Stay alert, watch what you are do-a.
ing and use common sense when
operating a power tool. Do not use
a power tool while you are tired
or under the inuence of drugs,
alcohol or medication. A moment
of inattention while operating power
tools may result in serious personal
injury.
Use personal protective equip-b.
ment. Always wear eye protection.
Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or
hearing protection used for appropri-
ate conditions will reduce personal
injuries.
Prevent unintentional starting.c.
Ensure the switch is in the off-po-
sition before connecting to power
source and/or battery pack, pick-
ing up or carrying the tool. Carry-
ing power tools with your nger on
the switch or energizing power tools
that have the switch on invites acci-
dents.
Remove any adjusting key ord.
wrench before turning the power
tool on. A wrench or a key left at-
tached to a rotating part of the power
tool may result in personal injury.
Do not overreach. Keep propere.
footing and balance at all times.
This enables better control of the
power tool in unexpected situations.
Dress properly. Do not wear loosef.
clothing or jewelry. Keep your
hair, clothing and gloves away
from moving parts. Loose clothes,
jewelry or long hair can be caught in
moving parts.
If devices are provided for the con-g.
nection of dust extraction and col-
lection facilities, ensure these are
connected and properly used. Use
of these devices can reduce dust-
related hazards.
Only use safety equipment thath.
has been approved by an appropri-
ate standards agency. Unapproved
safety equipment may not provide
adequate protection. Eye protection
must be ANSI-approved and breath-
ing protection must be NIOSH-ap-
proved for the specic hazards in the
work area.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 4
Power tool use and care4.
Do not force the power tool. Usea.
the correct power tool for your ap-
plication. The correct power tool will
do the job better and safer at the rate
for which it was designed.
Do not use the power tool if theb.
switch does not turn it on and off.
Any power tool that cannot be con-
trolled with the switch is dangerous
and must be repaired.
Disconnect the plug from thec.
power source and/or the battery
pack from the power tool before
making any adjustments, chang-
ing accessories, or storing power
tools. Such preventive safety mea-
sures reduce the risk of starting the
power tool accidentally.
Store idle power tools out of thed.
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to oper-
ate the power tool. Power tools are
dangerous in the hands of untrained
users.
Maintain power tools. Check fore.
misalignment or binding of moving
parts, breakage of parts and any
other condition that may affect the
power tool’s operation. If dam-
aged, have the power tool repaired
before use. Many accidents are
caused by poorly maintained power
tools.
Keep cutting tools sharp andf.
clean. Properly maintained cutting
tools with sharp cutting edges are
less likely to bind and are easier to
control.
Use the power tool, accessoriesg.
and tool bits etc. in accordance
with these instructions, taking into
account the working conditions
and the work to be performed. Use
of the power tool for operations differ-
ent from those intended could result
in a hazardous situation.
Service5.
Have your power tool serviced bya.
a qualied repair person using
only identical replacement parts.
This will ensure that the safety of the
power tool is maintained.
Battery tool use and care6.
Recharge only with the chargera.
specied by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of re
when used with another battery pack.
Use power tools only with speci-b.
cally designated battery packs.
Use of any other battery packs may
create a risk of injury and re.
When battery pack is not in use,c.
keep it away from other metal ob-
jects, like paper clips, coins, keys,
nails, screws or other small metal
objects, that can make a connec-
tion from one terminal to another.
Shorting the battery terminals togeth-
er may cause burns or a re.
Under abusive conditions, liquidd.
may be ejected from the battery;
avoid contact. If contact acciden-
tally occurs, ush with water. If
liquid contacts eyes, additionally
seek medical help. Liquid ejected
from the battery may cause irritation
or burns.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 5
Angle Grinder Operation Safety
Warnings
Do not use accessories which are1.
-
mended by the tool manufacturer.
Just because the accessory can be
attached to your power tool, it does
not assure safe operation.
The rated speed of the accessory2.
must be at least equal to the maxi-
mum speed marked on the power
tool. Accessories running faster than

apart.
The outside diameter and the thick-3.
ness of your accessory must be
within the capacity rating of your
power tool. Incorrectly sized acces-
sories cannot be adequately guarded
or controlled.
4.
backing pads or any other accessory

power tool. Accessories with arbor
holes that do not match the mounting
hardware of the power tool will run
out of balance, vibrate excessively
and may cause loss of control.
Hold power tool by insulated grip-5.
ping surfaces only, when performing
an operation where the cutting ac-
cessory may contact hidden wiring.

wire may make exposed metal parts

operator.
Never lay the power tool down until6.
the accessory has come to a com-
plete stop. The spinning accessory
may grab the surface and pull the
power tool out of your control.
Regularly clean the power tool’s air7.
vents. The motor’s fan will draw the
dust inside the housing and exces-
sive accumulation of powdered metal
may cause electrical hazards.
8. The battery charger gets
hot during use. The
charger’s heat can build
up to unsafe levels and

receive adequate ventilation, due to
an electrical fault, or if it is used in a
hot environment.
-
mable surface. Do not obstruct any
vents on the charger. Especially
avoid placing the charger on car-
pets and rugs; they are not only
ammable, but they also obstruct
vents under the charger.
Place the charger on a stable, solid,

stable metal workbench or concrete



smoke detector in the area. Fre-
quently monitor the charger and
battery during use.
Maintain labels and nameplates on9.
the tool. These carry important safety
information. If unreadable or miss-
ing, contact Harbor Freight Tools for a
replacement.
Avoid unintentional starting. Prepare10.
to begin work before turning on the
tool.
Do not lay the tool down until it has11.
come to a complete stop. Moving
parts can grab the surface and pull
the tool out of your control.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 6
Do not leave the tool unattended12.
when it is plugged into an electrical
outlet. Turn off the tool, and unplug it
from its electrical outlet before leav-
ing.
This product is not a toy. Keep it out13.
of reach of children.
People with pacemakers should14.
consult their physician(s) before use.
-
imity to heart pacemaker could cause
pacemaker interference or pacemak-
er failure. In addition, people with
pacemakers should:


on.

avoid electrical shock.

grounded. Ground Fault Circuit Inter-
rupter (GFCI) should also be imple-
mented – it prevents sustained elec-
trical shock.
Some dust created by power sand-15.
ing, sawing, grinding, drilling, and
other construction activities, contains
chemicals known [to the State of Cali-
fornia] to cause cancer, birth defects
or other reproductive harm. Some
examples of these chemicals are:

-
ment or other masonry products
-
cally treated lumber
Your risk from these exposures var-
ies, depending on how often you do
this type of work. To reduce your
exposure to these chemicals: work in
a well ventilated area, and work with
approved safety equipment, such as
those dust masks that are specially

particles. (California Health & Safety
Code § 25249.5, et seq.)
WARNING: Handling the cord on16.
this product will expose you to lead,
a chemical known to the State of
California to cause cancer, and birth
defects or other reproductive harm.
Wash hands after handling. (Califor-
nia Health & Safety Code § 25249.5,
et seq.)
The warnings, precautions, and in-17.
structions discussed in this instruction
manual cannot cover all possible con-
ditions and situations that may occur.
It must be understood by the operator
that common sense and caution are
factors which cannot be built into this
product, but must be supplied by the
operator.
Vibration Safety
This tool vibrates during use. Re-
peated or long-term exposure to vibra-
tion may cause temporary or permanent

arms and shoulders. To reduce the risk of

Anyone using vibrating tools regu-1.
larly or for an extended period should

then have regular medical check-
ups to ensure medical problems are
not being caused or worsened from
use. Pregnant women or people
who have impaired blood circulation
-
vous system disorders, diabetes, or
Raynaud’s Disease should not use
this tool. If you feel any medical or
physical symptoms related to vibra-
tion (such as tingling, numbness, and

SKU 99675 For technical questions, please call 1-800-444-3353. Page 7

advice as soon as possible.
Do not smoke during use. Nico-2.
tine reduces the blood supply to the


Wear suitable gloves to reduce the3.
vibration effects on the user.
Use tools with the lowest vibration4.
when there is a choice between dif-
ferent processes.
Include vibration-free periods each5.
day of work.
Grip tool as lightly as possible (while6.

the tool do the work.
To reduce vibration, maintain the tool7.
as explained in this manual. If any
abnormal vibration occurs, stop use
immediately.
SAVE THESE
INSTRUCTIONS.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 8
SPECIFICATIONS
Electrical Requirements
for Charger 120 V~ / 60 Hz / 2.4 A
Battery Class 2,19.2 VDC
NiCd
Tool Charging Time 1 Hour
 7,000 RPM
Wheel Diameter 4-1/2”
Wheel Rotation Speed 13,200 RPM
Arbor Diameter 7/8”
Spindle Thread 5/8” x 11 TPI
UNPACKING
When unpacking, check to make sure
that the item is intact and undamaged. If
any parts are missing or broken, please
call Harbor Freight Tools at the number
shown on the cover of this manual as soon
as possible.
List of contents
Description Qty
Angle Grinder 1
Grinding Wheel 1
Battery 1
Side Handle 1
Pin Wrench 1
Tool Case 1
Owner’s Manual 1
INSTRUCTIONS FOR
PUTTING INTO USE
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set
up or use of this product.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Power Switch of the
tool to its “OFF” position and
disconnect the battery before
assembling or making any
adjustments to the tool.
Note: For additional information regarding
the parts listed in the following pages,
refer to the Assembly Diagram near
the end of this manual.
Assembly
The Grinding Wheel must be:1.
rated to at least 13,200 RPM.
4-1/2” in diameter.
have a 7/8” round arbor hole.
0.54” thick or less.
a grinding wheel suitable for surface
grinding, not edge grinding.
dry and clean.
proven undamaged by inspec-
tion and by the ring-test explained
below.
2.
Button to prevent the Spindle from
turning.
Spindle Lock
Button

SKU 99675 For technical questions, please call 1-800-444-3353. Page 9
Use the Pin Wrench to remove the3.
Clamp Nut (8)
Closely inspect the Grinding Wheel4.
before mounting. Perform a ring-test
on the wheel (unless wheel is smaller
than 4” or is an unusual shape) as
follows:
a.
through the arbor hole.
Tap
Wheel
Here
45° 45°
45° 45°
Hang
Wheel
from
Pin
V
E
R
T
I
C
A
L
C
E
N
T
E
R
b. 

screwdriver handle, at a point 45°
from the vertical center line on each
side of the wheel and 1 – 2 inches
from the edge of the wheel (see Il-
lustration).
Rotate the wheel 45 degrees andc.
repeat the test until the entire wheel
has been checked.
An undamaged wheel will give ad.
clear tone. If cracked, there will be a
dead sound and not a clear ring.
Slip the grinding wheel onto the Spin-5.
dle with a paper gasket, or blotter,

on the grinding wheel and the wheel

Inner Flange.
WARNING: To prevent serious
injury, blotters must be used for all
grinding wheels they are provided
with. Blotters help prevent grind-
ing wheel damage and wheel slip-
page, causes of wheel failure.
Thread the Clamp Nut onto the Spin-6.
dle. Wrench tighten only enough so
that the wheel is securely held on the
spindle.
WARNING: To prevent serious
injury, do not overtighten ange.
Overtightening can damage the
wheel, causing wheel failure.
Thread the Side Handle onto either7.
side of the tool.
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set
up or use of this product.
Work Piece and Work Area Set Up
Designate a work area that is clean1.
and well-lit. The work area must not
allow access by children or pets to

Secure loose work pieces using a2.
vise or clamps (not included) to pre-
vent movement while working.
There must not be hazardous ob-3.


hazard while working.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 10
GENERAL OPERATING
INSTRUCTIONS
TO PREVENT
SERIOUS INJURY:
Grip the tool rmly in both
hands.
Charge the Battery (24) before1.
rst use. Hold both buttons on the
side of the Battery down and slide
the Battery downward to detach it
from the tool. Insert the Battery into
the Charger (26) (the Battery Pack

position), and plug the Charger into
a grounded, 120V electrical outlet.
Typical charge time for the Battery is
one hour. While charging, the Bat-
tery and Charger may become warm
to the touch. This is normal and does
not indicate a problem. When the
Battery is charging both the red and
green lights on the Charger will be lit.
When the Battery is fully charged the
red light will turn off, indicating that
the Battery is ready for use. Once
the Battery is charged, unplug the
Charger from the electrical outlet and
remove the Battery from the Charger.
Push the Safety down and push the2.
Switch (20) forward to start the tool.
Power Switch
Safety
3. Allow the tool to come up to full speed
before touching the work material.
Apply the wheel to the work mate-4.
rial, allowing the tool to operate at
full speed. If the tool bogs down, use
lighter pressure.
To create a smoother surface, keep5.
the tool moving over the work sur-
face.
Pull the Switch back to stop the tool.6.
Allow the tool to come to a complete7.
stop before setting it down.
To prevent accidents, turn off the tool8.
and disconnect its power supply after
use. Clean, then store the tool in-
doors out of children’s reach.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 11
MAINTENANCE AND
SERVICING
Procedures not specically
explained in this manual
must be performed only by a
qualied technician.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Power Switch of the
tool to its “OFF” position and
disconnect the battery before
performing any inspection,
maintenance, or cleaning
procedures.
TO PREVENT SERIOUS
INJURY FROM TOOL
FAILURE:
Do not use damaged
equipment. If abnormal noise
or vibration occurs, have the
problem corrected before
further use.
Cleaning, Maintenance, and
Lubrication
BEFORE EACH USE,1. inspect the
general condition of the tool. Check
for loose screws, misalignment or
binding of moving parts, cracked or
broken parts and any other condition
that may affect its safe operation.
Periodically blow dust and grit out2.
of the motor vents using dry com-
pressed air.
AFTER USE,3. clean external surfaces
of the tool with clean cloth.
4. WARNING! If the supply cord of
this power tool is damaged, it must
be replaced only by a qualied
service technician.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 12
Troubleshooting
Problem Possible Causes Likely Solutions
Tool will not start Battery discharged.1.
Carbon brushes worn or damaged.2.
Charge battery.1.
2.
carbon brushes.
Tool operates
slowly or
erratically.
Carbon Brushes worn or damaged.1.
Excess pressure applied to2.
workpiece.
1.
carbon brushes
Decrease pressure, allow tool to do2.
the work.
Tool does not grind
effectively.
Disc accessory loose on Spindle.1.
Disc accessory damaged, worn or2.
wrong type for material.
Be sure disc is correct dimension and1.
Clamp Nut tight.
Use correct disc accessory in good2.
condition.
Follow all safety precautions whenever diagnosing or servicing the
tool. Disconnect power supply before service.
PLEASE READ THE FOLLOWING CAREFULLY


DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT








SKU 99675 For technical questions, please call 1-800-444-3353. Page 13
PARTS LIST
Part Description Qty.
1 Screw 4
2 Front Assembly 1
3 Bush 1
4 Side Handle 1
5 Guard 1
6 Flange 1
7 Abrasive Wheel 1
8 Clamp Nut 1
9 Wrench 1
10 Upper Housing 1
11 Screw 2
12 Motor Mount 1
13 Motor 1
14 Wires 1
15 Battery Connector 1
PARTS LIST
Part Description Qty.
16 Wires 1
17 Wires 1
18  1
19 Spring 1
20 Switch 1
21  1
22 Screw 6
23  1
24 Battery 1
25  2
26 Charger 1
27  1
28  1
29  1
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.

SKU 99675 For technical questions, please call 1-800-444-3353. Page 14
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
LIMITED 90 DAY WARRANTY
Harbor Freight Tools Co. makes every effort to assure that its products meet high
quality and durability standards, and warrants to the original purchaser that this prod-
uct is free from defects in materials and workmanship for the period of 90 days from
the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities,
criminal activity, improper installation, normal wear and tear, or to lack of maintenance.

contingent, special or consequential damages arising from the use of our product. Some
states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESS-


To take advantage of this warranty, the product or part must be returned to us with
transportation charges prepaid. Proof of purchase date and an explanation of the com-
-
ther repair or replace the product at our election or we may elect to refund the purchase
price if we cannot readily and quickly provide you with a replacement. We will return re-
paired products at our expense, but if we determine there is no defect, or that the defect
resulted from causes not within the scope of our warranty, then you must bear the cost
of returning the product.

which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]
