Chicago Electric 66433 Installation manual

500 WATT HALOGEN FLOOR
SHOP LIGHT
66433
SET UP AND OPERATING INSTRUCTIONS
Distributed exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2008 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.

Page 2SKU 66433 For technical questions, please call 1-800-444-3353.
SAVE THIS MANUAL
Keep this manual for the safety warn-
ings and precautions, assembly, operat-
ing, inspection, maintenance and cleaning
procedures. Write the product’s serial
number in the back of the manual near the
assembly diagram (or month and year of
purchase if product has no number). Keep
this manual and the receipt in a safe and
dry place for future reference.
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling,
and all other information
provided with this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that
follow this symbol to avoid
possible injury or death.
DANGER indicates
a hazardous
situation which, if not
avoided, will result in death or
serious injury.
WARNING
indicates a
hazardous situation which, if
not avoided, could result in
death or serious injury.
CAUTION, used
with the safety
alert symbol, indicates a
hazardous situation which, if
not avoided, could result in
minor or moderate injury.
NOTICE is used to
address practices
not related to personal injury.
CAUTION, without
the safety alert
symbol, is used to address
practices not related to
personal injury.
GENERAL SAFETY RULES
WARNING! Read all instructions
Failure to follow all instructions
listed below may result in
electric shock, re, and/or
serious injury.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY RULES
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, ELECTRIC SHOCK,
EXPOSURE TO EXCESSIVE UV RADIA-
TION, OR INJURY TO PERSONS.
Turn off/unplug and allow to cool be-1. fore replacing bulb.
Bulb gets HOT quickly! Only contact2. switch/plug when turning on.
Do not touch hot lens (22), guard3. (25), or enclosure (16). (See assem-
bly diagram.)
Do not remain in light if skin feels4. warm.
Do not look directly at lighted lamp.5.
Keep lamp away from materials that6. may burn.
Use only with a 500 watt or smaller7. bulb.
DANGER
WARNING
CAUTION
NOTICE
CAUTION

Page 3SKU 66433 For technical questions, please call 1-800-444-3353.
Do not touch the bulb at any time.8. Use a soft cloth. Oil from skin may
damage bulb.
Do not operate the Light with a miss-9. ing or damaged housing (16), lens
(22), or grid (25). (See assembly
diagram.)
Risk of electric shock. Do not use10. with extension cord near water or
where water may accumulate. Keep
lamp at least 16 feet (5m) from pools
and spas. Keep plugs and recep-
tacles dry. For use only on GFCI-
protected circuits. Suitable for wet
location use.
Maintain labels and nameplates on11. the Light. These carry important
safety information. If unreadable or
missing, contact Harbor Freight Tools
for a replacement.
Avoid unintentional starting. Prepare12. to begin work before turning on the
Light.
Allow the unit to cool down before13. changing bulbs or storing it.
This product is not intended for use14. in a residence or to be mounted in a
cabinet. This product is not suitable
for recessed installation in ceilings or
on buildings. This product can cause
a re.
Do not leave the Light unattended15. when it is plugged into an electrical
outlet. Turn off the Light, and unplug
it from its electrical outlet before leav-
ing.
This product is not a toy. Keep it out16. of reach of children.
People with pacemakers should17. consult their physician(s) before use.
Electromagnetic elds in close prox-
imity to heart pacemaker could cause
pacemaker interference or pacemak-
er failure. In addition, people with
pacemakers should:
Avoid operating alone.•
Properly maintain and inspect to• avoid electrical shock.
Any power cord must be properly• grounded. Ground Fault Circuit
Interrupter (GFCI) should also be
implemented – it prevents sustained
electrical shock.
WARNING: Handling the cord on18. this product will expose you to lead,
a chemical known to the State of
California to cause cancer, and birth
defects or other reproductive harm.
Wash hands after handling.
(California Health & Safety Code §
25249.5, et seq.)
The warnings, precautions, and in-19. structions discussed in this instruction
manual cannot cover all possible con-
ditions and situations that may occur.
It must be understood by the operator
that common sense and caution are
factors which cannot be built into this
product, but must be supplied by the
operator.
General Safety Rules
Work area safety1.
Keep work area clean and well lit.a. Cluttered or dark areas invite acci-
dents.
Do not operate Lights in explosiveb. atmospheres, such as in the pres-
ence of ammable liquids, gases or

Page 4SKU 66433 For technical questions, please call 1-800-444-3353.
dust. Halogen Lights create heat
which may ignite the dust or fumes.
Keep children and bystandersc. away while operating. Distrac-
tions can cause you to lose con-
trol.
Electrical safety2.
Light plugs must match the outlet.a. Never modify the plug in any way.
Do not use any adapter plugs with
grounded Lights. Unmodied plugs
and matching outlets will reduce risk
of electric shock.
Avoid body contact with groundedb. surfaces such as pipes, radiators,
ranges and refrigerators. There is
an increased risk of electric shock if
your body is grounded.
Do not abuse the cord. Never usec. the cord for carrying, pulling or
unplugging the Light. Keep cord
away from heat, oil, sharp edges
or moving parts. Damaged or
entangled cords increase the risk
of electric shock.
When operating a Light outdoors,d. use an extension cord suitable for
outdoor use. Use of a cord suitable
for outdoor use reduces the risk of
electric shock.
Personal safety3.
Stay alert, watch what you are doinga. and use common sense when op-
erating a Light. Do not use a Light
while you are tired or under the inu-
ence of drugs, alcohol or medication.
A moment of inattention while op-
erating Lights may result in serious
personal injury.
Use safety equipment. Alwaysb. wear eye protection. Safety
equipment such as dust mask,
non-skid safety shoes, hard hat,
or hearing protection used for ap-
propriate conditions will reduce
personal injuries.
Avoid accidental starting. Ensurec. the switch is in the off-position be-
fore plugging in. Plugging in Lights
that have the switch on invites ac-
cidents.
Do not overreach. Keep proper foot-d. ing and balance at all times. This
enables better control of the Light in
unexpected situations.
Dress properly. Do not wear loosee. clothing or jewelry. Keep your hair,
clothing and gloves away from mov-
ing parts. Loose clothes, jewelry or
long hair can be caught in moving
parts.
Light use and care4.
Do not use the Light if the switcha. does not turn it on and off. Any Light
that cannot be controlled with the
switch is dangerous and must be
repaired.
Disconnect the plug from theb. power source before making any
adjustments or storing Lights.
Such preventive safety measures
reduce the risk of starting the
Light accidentally.
Maintain Lights. Check for breakagec. of parts and any other condition that
may affect the Light’s operation. If
damaged, have the Light repaired
before use.
Use the Light, in accordance withd. these instructions and in the man-
ner intended for the particular type
of Light, taking into account the
working conditions and the work

Page 5SKU 66433 For technical questions, please call 1-800-444-3353.
to be performed. Use of the Light
for operations different from those
intended could result in a hazardous
situation.
Service5.
Have your Light serviced by a quali-a.
ed repair person using only iden-
tical replacement parts. This will
ensure that the safety of the Light is
maintained.
SAVE THESE
INSTRUCTIONS.
GROUNDING
TO PREVENT
ELECTRIC SHOCK
AND DEATH FROM
INCORRECT GROUNDING
WIRE CONNECTION:
Check with a qualied
electrician if you are in doubt
as to whether the outlet is
properly grounded. Do not
modify the power cord plug
provided with the tool. Never
remove the grounding prong
from the plug. Do not use the
tool if the power cord or plug
is damaged. If damaged, have
it repaired by a service facility
before use. If the plug will not
t the outlet, have a proper
outlet installed by a qualied
electrician.
Grounded Tools: Tools with Three
Prong Plugs
3-Prong Plug and Outlet
1. Tools marked with “Grounding Re-
quired” have a three wire cord and
three prong grounding plug. The
plug must be connected to a properly
grounded outlet. If the tool should
electrically malfunction or break
down, grounding provides a low
resistance path to carry electricity
away from the user, reducing the risk
of electric shock. (See 3-Prong Plug
and Outlet.)
The grounding prong in the plug is2. connected through the green wire in-
side the cord to the grounding system
in the tool. The green wire in the cord
must be the only wire connected to
the tool’s grounding system and must
never be attached to an electrically
“live” terminal. (See 3-Prong Plug
and Outlet.)
The tool must be plugged into an3. appropriate outlet, properly installed
and grounded in accordance with all
codes and ordinances. The plug and
outlet should look like those in the
preceding illustration. (See 3-Prong
Plug and Outlet.)
WARNING

Page 6SKU 66433 For technical questions, please call 1-800-444-3353.
Extension Cords
Grounded1. tools require a three wire
extension cord. Double Insulated
tools can use either a two or three
wire extension cord.
As the distance from the supply outlet2. increases, you must use a heavier
gauge extension cord. Using exten-
sion cords with inadequately sized
wire causes a serious drop in voltage,
resulting in loss of power and pos-
sible tool damage.
(See Table A.)
The smaller the gauge number of the3. wire, the greater the capacity of the
cord. For example, a 14 gauge cord
can carry a higher current than a 16
gauge cord. (See Table A.)
When using more than one exten-4. sion cord to make up the total length,
make sure each cord contains at
least the minimum wire size required.
(See Table A.)
If you are using one extension cord5. for more than one tool, add the
nameplate amperes and use the sum
to determine the required minimum
cord size. (See Table A.)
If you are using an extension cord6. outdoors, make sure it is marked with
the sufx “W-A” (“W” in Canada) to
indicate it is acceptable for outdoor
use.
Make sure the extension cord is prop-7. erly wired and in good electrical con-
dition. Always replace a damaged
extension cord or have it repaired by
a qualied electrician before using it.
Protect the extension cords from8. sharp objects, excessive heat, and
damp or wet areas.
RECOMMENDED MINIMUM WIRE
GAUGE FOR EXTENSION CORDS*
(120/240 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25’ 50’ 75’
100’ 150’
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
TABLE A * Based on limiting the line
voltage drop to ve volts at
150% of the rated amperes.
Symbology
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc.
V~ Volts Alternating Current
AAmperes
n0xxxx/min. No Load Revolutions per Minute
(RPM)

Page 7SKU 66433 For technical questions, please call 1-800-444-3353.
SPECIFICATIONS
Electrical Requirements 120 V~ / 60 Hz / 3.9 A
Bulb 500W / 120 V~
Halogen (included)
E229796
UNPACKING
When unpacking, check to make sure
that the item is intact and undamaged. If
any parts are missing or broken, please
call Harbor Freight Tools at the number
shown on the cover of this manual as soon
as possible.
SET UP INSTRUCTIONS
Read the ENTIRE IMPORTANT
SAFETY INFORMATION section
at the beginning of this manual
including all text under
subheadings therein before set
up or use of this product.
Risk of accidental
starting; resulting
in serious personal injury.
Turn the Power Switch of the
Light OFF and unplug it from
the electrical outlet before
assembling or making any
adjustments.
Note: For additional information regarding
the parts listed in the following pages,
refer to the Assembly Diagram near
the end of this manual.
Deviation from the
assembly
instructions may result in a
risk of re or electric shock.
Slide the Bracket (13) over the Lower1. Grip (14), lining the hole in the Brack-
et up with the bolt hole in the Grip.
Insert the Knob (20) through the Con-2. cave Washer (34) and into the hole.
Remove the Bolt (38) at the top of the3. housing and open the Lamp Cover
(24).
Insert the Bulb (27) into the Bulb4. Socket (18). Do not touch the Bulb
with your bare hands; oil from skin
will drastically shorten the life span
of the bulb if not cleaned with rub-
bing alcohol and allowed to dry
before use. Handle the bulb with a
soft, clean cloth or clean work gloves
instead.
Close the Lamp Cover (24) and se-5. cure with the Bolt (38).
FIGURE A
6. Gently squeeze the Wire Cover (25)
while placing its four tabs into the
Lamp Cover (24). Secure the tab on
the Wire Cover to the Lamp Cover
using the Screw (39). (See Figure A.)
WARNING
WARNING

Page 8SKU 66433 For technical questions, please call 1-800-444-3353.
OPERATING INSTRUCTIONS
Read the ENTIRE IMPORTANT
SAFETY INFORMATION section
at the beginning of this manual
including all text under
subheadings therein before set
up or use of this product.
Plug the Light into a standard,1. grounded 120V electrical outlet.
Press the Switch on the back of the2. unit to turn the Light on.
WARNING! Keep the Light away3. from combustible objects. The
light and housing will get hot
enough to start a re.
To prevent accidents, turn off the3. Light and disconnect its power supply
after use. Clean, then store the Light
indoors out of children’s reach.
MAINTENANCE AND
SERVICING
Risk of serious
personal injury
from accidental starting or
electric shock. Turn the
Power Switch of the Light to
its “OFF” position and unplug
the Light from its electrical
outlet before performing any
inspection, maintenance, or
cleaning procedures.
Cleaning, maintenance, and
lubrication
BEFORE EACH USE,1. inspect the
general condition of the Light. Check
for loose screws, misalignment or
binding of moving parts, cracked or
broken parts, damaged electrical wir-
ing, and any other condition that may
affect its safe operation.
AFTER USE,2. clean external surfaces
of the Light with clean, moist cloth.
WARNING! If the supply cord of3. this Light is damaged, it must be
replaced only by a qualied ser-
vice technician.
WARNING

Page 9SKU 66433 For technical questions, please call 1-800-444-3353.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/
OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE
BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER
INSTALLATION OF REPLACEMENT PARTS THERETO.
PARTS LIST
Part Description Qty
1 Power Cord 1
2 Screw M4*16 4
3 Junction Box Cover 1
4 Pad For Junction Box Cover 1
5 Junction Box Base 1
6 Junction Box Hex Sleeve 1
7 Sleeve 2
8 Bolt M4*6 1
9 Fasten Bracket 1
10 Bolt M6*14 2
11 Washer 2
12 Hex Nut 4
13 Bracket 1
14 Lower Grip 1
15 Upper Grip 1
16 Shell 1
17 Soft Sleeve 1
18 Bulb Socket 1
19 Bolt M4*6 3
20 Knob M6*16 1
Part Description Qty
21 Reector 1
22 Glass 1
23 Seal Ring 1
24 Lamp Cover 2
25 Wire Cover 1
26 Plastic Long Plug 1
27 Bulb 1
28 Switch Cover 1
29 Switch 1
30 Wire Nut 1
31 Wire Press Board 1
32 Screw M4*12 2
33 Plastic Short Plug 3
34 Concave Washer 1
35 Large Washer 1
36 Gear Washer 1
37 Spring Washer 1
38 Bolt 1
39 Screw 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.

Page 10SKU 66433 For technical questions, please call 1-800-444-3353.
ASSEMBLY DIAGRAM

Page 11SKU 66433 For technical questions, please call 1-800-444-3353.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
LIMITED 90 DAY WARRANTY
Harbor Freight Tools Co. makes every effort to assure that its products meet high
quality and durability standards, and warrants to the original purchaser that this prod-
uct is free from defects in materials and workmanship for the period of 90 days from
the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities,
criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental,
contingent, special or consequential damages arising from the use of our product. Some
states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESS-
LY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with
transportation charges prepaid. Proof of purchase date and an explanation of the com-
plaint must accompany the merchandise. If our inspection veries the defect, we will ei-
ther repair or replace the product at our election or we may elect to refund the purchase
price if we cannot readily and quickly provide you with a replacement. We will return re-
paired products at our expense, but if we determine there is no defect, or that the defect
resulted from causes not within the scope of our warranty, then you must bear the cost
of returning the product.
This warranty gives you specic legal rights and you may also have other rights
which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]
