Chicago Pneumatic CP875 User manual

!Ensure that the workpiece is properly supported.
!Avoid direct contact with rotating spindle and accessory to prevent cutting of
hands or other body parts. Wear gloves to help protect hands. Tool continues to
run after the throttle lever has been released.
!Do not disable the lock off feature on the throttle lever.
!This tool and its accessories must not be modified.
!Operators and maintenance personnel must be physically able to handle the
power of the tool and capable of performing the job task.
!Always wear impact-resistant eye and face protection when involved with or near
the operation, repair or maintenance of the tool or changing accessories on the
tool. Gloves and protective clothing are recommended.
!Even small projectiles can injure eyes and cause blindness.
!Be sure all others in the area are wearing impact-resistant eye and face
protection.
!Daily measure the air tool speed with a tachometer to make sure it is not greater
than the RPM marked on the grinding accessory.
!Maximize the gripping length of the accessory, it must not be less than .390 in.
(10mm). Increased overhang of a mounted wheel reduces its permitted speed -
Refer to manufacturer's recommendations and (ANSI B7.1)
Workplace Hazards
!Slip/Trip/Fall is a major cause of serious injury or death. Be aware of excess hose
left on the walking or work surface.
!High sound levels can cause permanent hearing loss. Use hearing protection as
recommended by your employer or OSHA regulation (see 29 CFR part 1910).
!Maintain a balanced body position and secure footing.
!Repetitive work motions, awkward positions and exposure to vibration can be
harmful to hands and arms. If numbness, tingling, pain or whitening of the skin
occurs, stop using tool and consult a physician.
!Avoid inhaling dust or handling debris from the work process which can be
harmful to your health. Use dust extraction and wear respiratory protective
equipment when working with materials which produce airborne particles.
!This tool is not intended for use in explosive atmospheres and is not insulated for
contact with electric power sources.
!Potentially explosive atmospheres can be caused by dust and fumes resulting
from sanding or grinding. Use dust extraction or suppression system which are
suitable for the material being processed.
!Some dust created by power sanding, sawing, grinding, drilling and other
construction activities contains chemicals known to the State of California to
cause cancer and birth defects or other reproductive harm. Some examples of
these chemicals are:
- Lead from lead based paints
- Crystalline silica bricks and cement and other masonry products
- And Arsenic and chromium from chemically-treated rubber
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area,
and work with approved safety equipment, such as dust masks that are specially
designed to filter out microscopic particles.
!For professional use only.
For Additional Safety Information Consult:
!Your employer, union and/or trade association.
!US Department of Labor (OSHA); Council of the European Communities
europe.osha.eu.int
!“Safety Requirements for the Use, Care and Protection of Abrasive Wheels”
(ANSI B7.1) and “Safety Code for Portable Air Tools” (ANSI B186.1)
!“Safety Requirements for Hand-Held Non-Electric Power Tools” available from:
European Committee for Standardization.
Air Supply And Connection Hazards
!Never direct air at yourself or anyone else. Air under pressure can cause severe
injury.
!Always shut off air supply, drain hose of air pressure and disconnect tool from air
supply when not in use, before changing accessories or when making repairs.
!Whipping hoses can cause serious injury. Always check for damaged or loose
hoses and fittings.
!Do not use quick disconnect couplings at tool. See instructions for correct setup.
!Whenever universal twist couplings are used, lock pins must be installed.
!Do not exceed maximum air pressure of 90 psi/6.2 bar or as stated on tool
nameplate.
Entanglement Hazards
!Keep away from rotating spindle and accessory.
!Do not wear jewelry or loose clothing.
!Scalping can occur if hair is not kept away from tool and accessories.
!Choking can occur if neckwear is not kept away from tool and accessories.
Operating Hazards
!Never mount a grinding wheel, cut off wheel or router cutter on a die grinder or
tire buffer. A grinding wheel or other accessory that bursts can cause very serious
injury or death.
!Grinding accessory's rated speed must be equal to or greater than the speed of
the die grinder.
!Use only mounted wheels or tire buffing accessories with adequate speed rating
and the correct shaft diameter.
!Do not use wire brushes, drill bits, or any other accessory other than mounted
wheels, burrs and tire buffing accessories.
!Damaged, worn or incorrectly mounted accessories can cause higher vibration.
To reduce exposures to vibration ensure burring tools are sharp and this tool and
all accessories are in proper working condition.
To reduce risk of injury, everyone using, installing,
repairing, maintaining, changing accessories on, or
working near this tool must read and understand
these instructions before performing any such task.
The goal of Chicago Pneumatic is to produce tools that help you work safely and
efficiently. The most important safety device for this or any tool is YOU. Your
care and good judgment are the best protection against injury. All possible
hazards cannot be covered here, but we have tried to highlight some of the
important ones.
Air Supply Requirements
1. Supply tool with 90 psig (6.2 bar) of clean, dry air. Higher pressure drastically
reduces tool life.
2. Connect tool to air line using pipe, hose and fitting sizes shown in the diagram
on page 12.
3. Do not install a quick coupler directly into the tool handle.
Lubrication
1. Motor - Use an air line lubricator with SAE #10 oil, adjusted to two drops per
minute. If an air line lubricator cannot be used, add air motor oil to the inlet
once a day.
2. Gears - Use grease gun C098689 with Mobilux EP-2 or equal grease. Grease
fitting is on side of angle head.
Noise & Vibration Declaration*
2
Vibration value 3.0 m/s , re. ISO 8662-13.
Maintenance
1. Disassemble and inspect air motor every three months if the tool is used every
day. Replace damaged or worn parts.
2. High wear parts are underlined in the parts list.
Sound pressure level 101.3 dB(A) in accordance with EN ISO 15744. For
sound power, add 10 dB(A).
We, Chicago Pneumatic Tool Company, declare under our sole responsibility that the product to
which this declaration relates, is in conformity with the requirements of the Council Directive of
June 1998 on the approximation of the laws of the Member States relating to machinery (98/37/
EC).
Machine Name CP875 Mini-Angle Die Grinder / CP876 Die Grinder
Machine Type Power tool equipped with 1/4 in. or 6 mm collet chuck for use with various
burrs for polishing and grinding - No other use is permitted.
Serial No. Tools with No. 94001A or higher
Technical Data
1/4 in. or 6 mm collet
Free speed 22,500 RPM (CP875), Free speed 30,000 RPM (CP876)
Air pressure 90 psi (6.2 bar)
Air consumption 22 cfm (CP875), Air consumption 24 cfm (CP876)
Harmonized Standards Applied EN792-9
National Standards Applied ISO 8662-13, EN ISO 15744
CP875 Mini-Angle Die Grinder
CP876 Die Grinder
Model "A"
CA156680 Rev. G
* These declared values were obtained by laboratory type testing in compliance with the stated standards and are
not adequate for use in risk assessments. Values measured in individual work places may be higher than the
declared values. The actual exposure values and risk of harm experienced by an individual user are unique and
depend upon the way the user works, the workpiece and the workstation design, as well as upon the exposure time
and the physical condition of the user. We, Chicago Pneumatic, cannot be held liable for the consequences of
using the declared values, instead of values reflecting the actual exposure, in an individual risk assessment in a
work place situation over which we have no control.
Signature of Issuer

Index
No. Part No. Description No. Req'd.
Housing-Motor (Incl: Index No.34)
Pin-Throttle
Lever-Throttle (Incl: Lockout)
Valve-Throttle
O-Ring (P4)
Spring-Throttle Valve
O-Ring (P10)
Plug-Throttle Valve
O-Ring (P7)
Collar-Rotor
Bearing-Ball (CP875)
Bearing-Ball (CP876)
Plate-Rear End
Rotor
Blade Set-Rotor (4)
Pin-Roll
Liner
Plate-Front End (CP875)
Plate-Front End (CP876)
Bearing-Ball (CP875)
Bearing-Ball (CP876)
Regulator-Air
Pinion (CP875)
Nut-Clamp (CP875)
Nut-Clamp (CP876)
Collet (1/4 in.)
Collet (6 mm)
Nut-Collet
Cap-Housing (CP875)
Cap-Housing (CP876)
Wrench-Spanner
Head-Housing. (Incl: Grease Fitting)
Gear-Bevel (CP875)
Ring-Lock (CP875)
Key (CP875)
Spindle (CP 875)
Spindle (CP 876)
Bushing-Throttle Valve
Decal Safety Warning (not shown)
Motor Assy. (Incl: Index Nos. 13, 14,
15, 16, 17, 18, 19, 20 & 22) (CP875)
Motor Assy. (Incl: Index Nos. 13, 14,
15, 16, 17, 18, 19, 20 & 33) (CP876)
Gear Housing Assy. (Incl: Index Nos.
13, 20, 28, 30, 31, 32, & 33 ) (CP875)
Housing Assy. (Incl: Index Nos. 1, 5,
7, 8, 9, 10, 11 & 21)
(CP875, CP876)
CA144786
CA144787
CA144788
CA144789
CA144842
CA144790
CA144843
CA144791
CA144844
CA144792
CA144793
CA144793
CA144794
CA144795
CA144796
CA144797
CA144798
CA144799
CA144855
CA144800
CA144800
CA144801
CA144802
CA144803
CA144856
C138727
C139289
C138728
CA144806
CA144857
CA144807
CA144808
CA144809
CA144810
CA144811
CA144812
CA144858
CA147745
CA144813
CA145217
CA145315
CA145218
CA145219
1
2
4
5
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
30
31
32
33
34
35
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
2
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
CP875
Mini-Angle Die Grinder
CP876
Die Grinder
Air Supply Diagram 1/2" (12mm)
3/8" (10mm)
3/8" (10mm)
3/8" (10mm)
CA048361 (1/2")
CA048362 (1/2")
CA048360 (1/2")
3/8" (10mm)
3/8" (10mm)
130
90
0
1
22
20
23
30
13
9
10
27
26
21
11
8
7
5
34
31
24
25
25
24
33
26
28
32
23
17
18
42
13
17 14
33
20
19
16
15
12
