Chicago Welding 67102 Installation manual

80W PLASTIC WELDING KIT
WITH IRON
Model 67102
SET UP AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2008 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improve-
ments, actual product may differ slightly from the product described herein. Tools required for assembly
and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 10j

Page 2SKU 67102 For technical questions, please call 1-800-444-3353.
SAVE THIS MANUAL
Keep this manual for the safety
warnings and precautions, assembly,
operating, inspection, maintenance and
cleaning procedures. Write the product’s
serial number in the back of the manual near
the assembly diagram (or month and year of
purchase if product has no number). Keep
this manual and the receipt in a safe and dry
place for future reference.
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling,
and all other information
provided with this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that
follow this symbol to avoid
possible injury or death.
DANGER indicates
a hazardous
situation which, if not
avoided, will result in death or
serious injury.
WARNING
indicates a
hazardous situation which, if
not avoided, could result in
death or serious injury.
CAUTION, used
with the safety
alert symbol, indicates a
hazardous situation which, if
not avoided, could result in
minor or moderate injury.
NOTICE is used to
address practices
not related to personal injury.
CAUTION, without
the safety alert
symbol, is used to address
practices not related to
personal injury.
General Power Tool Safety
Warnings
WARNING Read all safety
warnings and instructions.
Failure to follow the warnings and
instructions may result in electric
shock, re and/or serious injury.
Save all warnings and
instructions for future reference.
The term ″power tool″ in the
warnings refers to your mains-
operated (corded) power tool.
Work area safety1.
Keep work area clean and wella.
lit. Cluttered or dark areas invite
accidents.
Do not operate power tools inb.
explosive atmospheres, such as in
the presence of ammable liquids,
gases or dust.
Keep children and bystandersc.
away while operating a power tool.
Distractions can cause you to lose
control.
Electrical safety2.
Power tool plugs must match thea.
outlet. Never modify the plug in
any way. Do not use any adapter
plugs with grounded power tools.
Unmodied plugs and matching
outlets will reduce risk of electric
shock.

Page 3SKU 67102 For technical questions, please call 1-800-444-3353.
Avoid body contact with groundedb.
surfaces such as pipes, radiators,
ranges and refrigerators. There is
an increased risk of electric shock if
your body is grounded.
Do not expose power tools to rainc.
or wet conditions. Water entering
a power tool will increase the risk of
electric shock.
Do not abuse the cord. Never used.
the cord for carrying, pulling or
unplugging the power tool. Keep
cord away from heat, oil, sharp
edges or moving parts. Damaged
or entangled cords increase the risk
of electric shock.
When operating a power toole.
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use reduces
the risk of electric shock.
If operating tool in a damp locationf.
is unavoidable, use a Ground Fault
Circuit Interrupter (GFCI) protected
supply. Use of a GFCI reduces the
risk of electric shock.
Personal safety3.
Stay alert, watch what you area.
doing and use common sense
when operating a power tool. Do
not use a power tool while you
are tired or under the inuence of
drugs, alcohol or medication. A
moment of inattention while operating
power tools may result in serious
personal injury.
Use safety equipment.b. Always
wear ANSI-approved safety goggles,
heavy-duty work gloves and face
shield during use.
Do not overreach. Keep properc.
footing and balance at all times.
This enables better control of the
power tool in unexpected situations.
Power tool use and care4.
Do not force tool. Use the correcta.
tool for your application. The
correct tool will do the job better
and safer at the rate for which it was
designed.
Disconnect the plug from theb.
power source and/or the battery
pack from the tool before making
any adjustments, changing
accessories, or storing power
tools. Such preventive safety
measures reduce the risk of starting
the power tool accidentally.
Store idle tools out of the reach ofc.
children and do not allow persons
unfamiliar with the tool or these
instructions to operate the power
tool. Welding tools are dangerous in
the hands of untrained users.
Maintain welding tools. Check ford.
misalignment or binding of moving
parts, breakage of parts and any
other condition that may affect
the tool’s operation. If damaged,
have the tool repaired before use.
Many accidents are caused by poorly
maintained tools.
Keep cutting tools sharp ande.
clean. Properly maintained cutting
tools with sharp cutting edges are
less likely to bind and are easier to
control.
Use the tool and accessoriesf.
in accordance with these
instructions, taking into account
the working conditions and the
work to be performed. Use of the
tool for operations different from

Page 4SKU 67102 For technical questions, please call 1-800-444-3353.
those intended could result in a
hazardous situation.
Service5.
Have your tool serviced by aa.
qualied repair person using only
identical replacement parts. This
will ensure that the safety of the tool
is maintained.
Welding Kit Safety Warnings
Do not use this Plastic Welding Kit1.

Handle hot tip with care. Do not2.
touch any metal parts on the Welder
until they have completely cooled.
Use in well-ventilated areas only.3.
Do not place the Welder in a vise to4.
change heating elements.
Always use Wire Brush (5) to clean5.
the tip on the Welder.
Avoid electrical shock. Do not use in6.
a damp or wet environment.
-7.
ble surface.
Avoid unintentional starting. Prepare8.
to begin work before plugging in tool.
Do not leave the tool unattended9.
when it is plugged into an electrical
outlet. Unplug it from its electrical
outlet and allow it to cool before
leaving.
Use clamps (not included) or other10.
practical ways to secure and support
the workpiece to a stable platform.
Holding the work by hand or against
your body is unstable and may lead
to loss of control.
This product is not a toy. Keep it out11.
of reach of children.
This product is designed for use only12.
for plastic welding. This product
is designed to be used only to weld
plastic items.
When working with plastics, varnish,13.
or similar materials, gases develop

lead to explosions. Be prepared for


Do not point Welder at people or14.
animals. The intense heat can injure
them.
Maintain labels and nameplates on15.
the tool. These carry important safety
information. If unreadable or missing,
contact Harbor Freight Tools for a
replacement.
People with pacemakers should16.
consult their physician(s) before

proximity to heart pacemaker could
cause pacemaker interference or
pacemaker failure. In addition,
people with pacemakers should:


avoid electrical shock.

grounded. Ground Fault Circuit
Interrupter (GFCI) should also be
implemented – it prevents sustained
electrical shock.
Some dust created by power17.
sanding, sawing, grinding, drilling,
and other construction activities,
contains chemicals known [to the
State of California] to cause cancer,
birth defects or other reproductive

Page 5SKU 67102 For technical questions, please call 1-800-444-3353.
harm. Some examples of these
chemicals are:


cement or other masonry products

chemically treated lumber
Your risk from these exposures
varies, depending on how often you
do this type of work. To reduce your
exposure to these chemicals: work in
a well ventilated area, and work with
approved safety equipment, such as
those dust masks that are specially

particles. (California Health & Safety
Code § 25249.5, et seq.)
The warnings, precautions,18.
and instructions discussed in
this instruction manual cannot
cover all possible conditions and
situations that may occur. It must
be understood by the operator that
common sense and caution are
factors which cannot be built into this
product, but must be supplied by the
operator.
SAVE THESE
INSTRUCTIONS.
GROUNDING
TO PREVENT
ELECTRIC SHOCK
AND DEATH FROM
INCORRECT GROUNDING
WIRE CONNECTION: Check
with a qualied electrician if
you are in doubt as to whether
the outlet is properly
grounded. Do not modify plug
provided with tool. Never
remove grounding prong from
plug. Do not use tool if power
cord or plug is damaged. If
damaged, have it repaired by
a service facility before use. If
plug will not t outlet, have a
proper outlet installed by a
qualied electrician.
Grounded Tools: Tools with Three
Prong Plugs
Tools marked with “Grounding1.
Required” have a three wire cord and
three prong grounding plug. Plug
must be connected to a properly
grounded outlet. If tool should
electrically malfunction or break
down, grounding provides a low
resistance path to carry electricity
away from user, reducing risk of
electric shock. (See 3-Prong Plug
and Outlet.)
