CHIEF OFB206 User manual

INSTALLATION INSTRUCTIONS
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Office Furniture Bracket
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
OFB206

Installation Instructions OFB206
3
DISCLAIMER
Milestone AV Technologies, Inc., and its affiliated corporations
and subsidiaries (collectively, "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
IMPORTANT WARNINGS AND
CAUTIONS!
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached to this accessory does not exceed
40 lbs (18.14 kg). DO NOT exceed the weight limitations of
the mount being installed.

OFB206 Installation Instructions
4
LEGEND
TOOLS REQUIRED FOR INSTALLATION AND PARTS
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Open-Ended Wrench
Llave de boca
Gabelschlüssel
Chave de bocas
Chiave a punte aperte
Steeksleutel
Clé à fourche
Hex-Head Wrench
Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleutel
Clé à tête hexagonale
3/32"
C (2)
B (1)
A (1)
8-32 x 1/2"
E (3)
10-24
D (3)
#10
3/32"
(Included)

Installation Instructions OFB206
5
Assembly And Installation
The OFB206 bracket is compatible with the Fisher Hamilton
Work Bench Station.
1. Identify desired mounting location considering display size
and mount capabilities when determining location.
2. Connect OFB206 bracket (A) to work bench station by
latching hooks onto tabs located under mounting surface.
(See Figure 1)
Figure 1
3. SecureOFB206bracket(A)toworkbenchstationusingtwo
8-32 x 1/2" button head cap screws (C). (See Figure 2)
Figure 2
4. Secure mount wall bracket (included with mount) to
OFB206 bracket (A) using three #10 flat washers (D) and
three 10-24 nylon lock nuts (E). (See Figure 3)
Figure 3
WARNING: IMPROPER INSTALLATION CAN LEAD TO
DISPLAY FALLING CAUSING SERIOUS PERSONAL
INJURY OR DAMAGE TO EQUIPMENT! DO NOT substitute
hardware! Use only hardware provided by manufacturer.
5. Continue with mount installation, following the instructions
provided with the mount.
(A)
2
3
(C) x 2
(A)
4
Mount Wall
Bracket
(E) x 3
(D) x 3

OFB206 Installation Instructions
6

OFB206 Installation Instructions
Chief Manufacturing, a division of
Milestone AV Technologies
8812-000048 Rev A
©2008 Milestone AV Technologies
www.chiefmfg.com
10/08
