Childcare TWO UP TANDEM User manual

TWO UP TANDEM
Stroller Model # 019170
IMPORTANT:
RETAIN FOR FUTURE REFERENCE, READ CAREFULLY

Check that all safety locks are engaged before placing a child in the stroller.
Ensure your child is secured with a correctly adjusted safety harness.
Do not allow children to stand on the seat.
Do not hang bags or goods from the handle as this could cause the stroller to tip over.
Do not place more than 3kgs in the basket or 1kgs in the hood pocket (if supplied).
The weight of the child using the product should not exceed 15kgs in each seat.
The height of the child using the product should not exceed 96cm.
Use original accessories and manufacturer approved parts only.
Never ride with more than two children in the stroller.
Always use safety locks.
Promptly replace worn out or broken parts.
Remove the child from the stroller before going up or down stairs and escalators.
To prevent the risk of the stroller catching re, do not park it near an open re, heater or barbeque.
Do not make any changes or alterations to this product, unless through an approved service agent.
To avoid the risk of suffocation, keep all plastic packaging materials out of reach of children.
Never leave safety harness connected when not tted to a child in the stroller as this may create
loops that could cause a strangulation hazard.
Read all instructions before assembly and use of the stroller. Keep
instructions for future use.
Safety Precautions
TO AVOID INJURY OR DEATH:
FOLLOW THE MANUFACTURER’S INSTRUCTIONS.
ALWAYS APPLY THE BRAKES WHENEVER THE STROLLER
IS STATIONARY.
USE THE TETHER STRAP AT ALL TIMES TO PREVENT THE
STROLLER ROLLING AWAY.
DO NOT LEAVE CHILD UNATTENDED.
SECURE THE CHILD IN THE HARNESS AT ALL TIMES.
DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS
STROLLER.
MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING
PARTS IF YOU ADJUST THE STROLLER, OTHERWISE THEY
MAY BE INJURED.
WARNING

3
Due to variations in the style and design of our products, the photographs and illustrations
shown in this instruction manual are generic, therefore product fabrics, colour and
design may vary from images shown. CNP Brands reserves the right to alter product
specications without notice as a result of our ongoing policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Childcare Stroller
Congratulations on your purchase of the
Childcare Two Up Tandem Stroller.
This product has been designed and developed with
safety, comfort and functionality in mind. Please take
the time to read this manual carefully before using
this product and keep it in a safe place for future
reference.

4
x2
x1
x1
x1
x1
Assembly Contents
Check what you have received...
You have received 1 box. Please check the contents of the box against the list below.
If anything is missing, please contact Customer Service. In Australia, contact CNP
Brands on 1300 667 137, in New Zealand contact Wainhouse Distribution on 0800
567 5000.
Supplied loose in box:
Front swivel wheel assemblies
Rear axle and wheel assembly
Front Hood
Footrest
Front tray
Stroller frame

5
Assembly / Operating Instructions
Unfolding the stroller
1. Release the folding lock as highlighted.
2. Lift handle and seat apart until the frame clicks and locks on
both sides
3. Ensure the stroller is locked on both sides before using.
To assemble front wheels
1. Place each swivel wheel assembly onto the front leg until it
clicks into position. Ensure swivel housing is to the top as
shown.
To assemble rear wheel
Assemble rear wheels / axle assembly onto the frame as shown.
2. To remove the wheel, press the clip on the underside of the
wheel and remove

6
Assembly / Operating Instructions
To attach front hood
Slide the front hood into the frame until it clicks into place.
To attach front tray
1. Fit each side of the tray onto the frame.
To attach basket
Insert basket tubes into corresponding basket slots and make sure
they are secure.
2. Close locking clips.

7
Assembly / Operating Instructions
To use brakes
1. To lock the brakes, push down on each red lever with foot.
2. To release the brakes, lift each brake lever up with foot.
WARNING: Always apply both brakes when parking the stroller.
To attach / detach footrest
1. Attach the footrest onto the front legs.
Use of rear seat enclosure
In order to prevent child from slipping through the gap in between
the two seats; a rear seat foot enclosure is supplied. When the foot
closure is not in use, it can be rolled and folded inside the pocket in
the back of the front seat. Attach/detach to the underside of the seat
fabric by six press studs.
2. Make sure it attaches onto the locking pin on the bar under the
footrest.

8
To fold stroller
1. Before folding the stroller, lock brakes and front swivel
wheels, adjust both seats into the upright position, fold
backwards the front hood.
2. Press both buttons on the handle simultaneously.
Assembly / Operating Instructions
Swivel wheels
1. To lock the swivels, lift the locking clip up. The swivel wheels
can only be locked when the wheels are in the trailing position
(wheels under frame).
2. Push the locking clip down to allow wheels to swivel.
3. Whilst pressing down handle buttons, press on the secondary
lock on the right hand side above the rear wheels and lower
until folding lock and be engaged.
4. Engage folding lock.

9
Restraints - Harness
1. To secure the child in the harness, place left
hand buckle prong (b) on top of (a).
2. Hold both left hand buckle prongs (a) and (b)
together and insert it into buckle housing (e)
until it snaps into position.
3. Repeat previous steps for right hand buckle
prongs (c) and (d).
4. Once all attached, carefully adjust the harness
straps by pulling each slider (f) until the desired
 t is achieved in the lap, shoulder and crotch
straps.
5. To release the buckles, squeeze the top and
bottom prongs (a) and (b), (c) and (d) together
until harness disengages.
CAUTION: Always adjust the harness when
changing the seating position of the child.
f
f f
f
f
a
b
c
d
e
(a), (b): Left hand buckle prongs
(c), (d): Right hand buckle prongs
(e): Buckle housing
(f): Strap adjustment sliders
Assembly / Operating Instructions
To adjust backrest
1. To lower the front seat backrest, lift backrest adjusting lever by
using thumb and fore nger, lower to desired position. To raise,
simply push backrest up.
2. To lower the rear seat, press button on buckle and pull down
to desired position. To raise the seat upwards, hold the strap in
one hand and pull buckle up.

10
How to care for your Childcare stroller
Cleaning
To ensure the long-lasting use of your stroller, dry it with a soft absorbent cloth after use in
rainy weather. Use a damp cloth to clean the frame. Do not use abrasive cleaners. After using
your stroller on the beach, clean the frame and wheels thoroughly with water to remove the
sand and salt. Allow it to dry thoroughly. Removable and non-removable fabric covers and
trims may be cleaned using a damp cloth with soap or mild detergent. Allow it dry completely
before folding or storing it away. Do not dry clean, or use bleach on fabrics or trims. Do not
machine wash, tumble or spin dry, unless the care labelling on the product permits these
methods.
Maintenance
Check stroller regularly to ensure that locking devices and components are secure and
working properly. Always check parts regularly for tightness of screws, nuts and other
fasteners – tighten or replace if required. To maintain the safety of your stroller, seek prompt
repairs for bent, torn, worn or broken parts. Use only those parts and accessories approved by
CNP Brands. If the wheels squeak, use silicone based spray or light oil ensuring it penetrates
the wheel and axle assembly. To prevent mould or mildew, do not fold or store the product if
it is damp or wet. Allow it to dry thoroughly. Always store the product in a well ventilated area
and away from direct sunlight.
If you have any difculties in assembling the stroller, please contact our Service Department.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand contact Wainhouse
Distribution on 0800 567 5000.

11
Currently, CNP Brands boasts one of the most diverse
brand portfolios with a combination of company
owned brands and distribution agreements. These
include distribution lines for Maclaren, Fisher Price,
Natures Purest, Bambino Mio, Motorola and Brica
among others.
Our own brands, including Childcare, have gone
from strength to strength in recent years. Childcare,
and our premium brand Bebe Care, demonstrate our
commitment to quality and continuing investment in
product development.
About CNP Brands

12
Distributed in Australia by CNP Brands, 20 Calarco Drive, VIC, 3030
Customer Service 1300 667 137 www.cnpbrands.com.au
Distributed in New Zealand by Wainhouse Distribution, 2-6 Argyle St,
Morningside, PO Box 41-014, St Lukes, Auckland, New Zealand
Customer Service: 0800 567 5000 [email protected]
