Childcare 025013-191 User manual

IMPORTANT:
RETAIN FOR FUTURE REFERENCE,
READ CAREFULLY
Drive‘N’Play 5-in-1
Activity Center
Model # 025013-191

2
Use only accessories as recommended by the supplier.
ALWAYS use the safety locks once the walker height is correctly adjusted.
Check that all safety locks are engaged before placing child in the walker.
This walker should not be used by a child who can walk unaided.
This walker should not be used by a child weighing less than 7kgs and 65cm in height.
A child should discontinue using this walker when weighing more than 11kgs and 80cm in height.The walker is not
suitable for babies under 6 months of age.
Electrical cords, heaters, replaces and other hot objects, or any other objects or substances that may be dangerous,
should be guarded or put out of reach of a child using the walker.
Promptly replace any broken parts.
The walker should not be used (whether indoors or outdoors) on surfaces that have any obstructions that could cause
the walker to tip over.
The walker should not be carried with a child in it.
Adjust the height of the walker so that both feet of a child in the walker should be able to touch the ground.
Care must be taken while folding and unfolding the walker to prevent ngers being caught.
Read all instructions before assembly and use of the walker. Keep
instructions for future use.
BEFORE ASSEMBLINGTHIS WALKER,READ AND UNDERSTANDTHE INSTRUCTIONS.
Never leave a child unattended.
Always keep child in view while in walker.
Only use on at surfaces free of objects that could cause the walker to tip over.
To avoid burns, keep the child away from hot liquids, ranges, radiators, space heaters and
replaces etc...
Do not use the walker if it is damaged or broken.
Do not use until baby can sit up by itself.
To avoid serious injury or death,block stairs/steps securely before using walker.
Clean (friction components) regularly to maintain stopping performance.
Remove packaging from walker vicinity after assembly.
KEEP INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE.
SAFETY PRECAUTIONS
WARNING
WARNING - STAIR HAZARD
AVOID SERIOUS INJURY OR DEATH:BLOCK STAIRS/STEPS SECURELY BEFORE USING WALKER.

3
Battery Safety Information
WARNING
In exceptional circumstances, batteries leak uids that can cause a chemical burn injury or ruin your product.To avoid
leakage:
• DO NOT mix old and new batteries or batteries of different types: alkaline, standard (carbon zinc) or rechargeable
(nickle-cadmium).
• Insert batteries as indicated inside the battery compartment.
• Remove batteries during long periods of non-use.
• ALWAYS remove exhausted batteries from the product.
• Dispose of batteries safely.
• DO NOT dispose of this product in a re.The batteries inside may explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same equivalent type,as recommended.
• DO NOT charge non-rechargeable batteries.
• Remove rechargeable batteries from the product before charging.
• If removable,rechargeable batteries are used,they are only to be charged under adult supervision.
SAFETY PRECAUTIONS
Keep medication,strings,elastics and small toys out of reach from any position of the walker.
ALWAYS attach the toys tightly to the walker according to the instructions.Check frequently.
This walker should be used only for short periods of time eg:20mins
FALL HAZARD
Babies can FALL from product resulting in head injuries.
• NEVER leave child unattended.ALWAYS keep child in view while in product.
• NEVER use near stairs.
• To avoid tip over,place product on a at,level surface.
STRANGULATION HAZARD
Strings can cause STRANGULATION.
• DO NOT place items with a string around child’s neck,such as hood strings or pacier cords.
• DO NOT suspend strings over product or attach strings to toys.

4
Due to variations in the style and design of our products, the photographs and illustrations shown in this
instruction manual are generic,therefore product fabrics,colour and design may vary from images shown.
CNP Brands reserves the right to alter product specications without notice as a result of our ongoing
policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Drive‘N’ Play 5-in-1 Activity Center
Congratulations on your purchase of the Drive ‘N’Play
5-in-1 Activity Center
This product has been designed and developed with safety,
comfort and functionality in mind. Please take the time to read
this manual carefully before using this product and keep it in a
safe place for future reference.
CONGRATULATIONS

5
ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the
box against the list below. If anything is missing, please contact
Customer Service.
InAustralia,contact CNP Brands on 1300 667 137,in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
Top Frame
Frame Legs
x 1
x 4
x 1
x 1
x 2
x 2
x 2
Base Frame
Toy Tray
Toy Tray
overhead Toys
Rocker
Attachments
Cars
x 1Seat Pad

6
ASSEMBLY CONTENTS
There are no accessories recommended for use with this Childcare Walker.
Supplied loose in box continued:
x 1
x 1
x 1
x 2
x 1
x 1
x 2
x 1
Trafc Signal
Flag Toy
Car Ramp
Base Track Ends
Helicopter Toy &
mounting pole
Tree Toy
Top Track Ends
Curved Base
Joiner
x 1
x 1 Horn Toy
Stickers for Toy
Tray Overhead
Toys

7
ASSEMBLY / OPERATING INSTRUCTIONS
To Assemble Frame...
1Lay the Top Frame face down.1a.
2
4
3
5
Open the Frame Legs until they lock with a
click.
With the Base Frame on the oor,join the Top
Frame by sliding the Frame Legs into the Base
Frame mountings.
Insert the Frame Legs into the Top Frame using
moderate force until they lock in.
Pushing the leg button in to secure the leg.The
3 positons are the adjustments for the height
selection for your child.
2a.
4a.
3a.
5a.

8
ASSEMBLY / OPERATING INSTRUCTIONS
To assemble Seat Pad...
1
2
Position the Seat Pad into the opening in the
Top Frame.Push down with moderate force to
secure the seat in the track.
The seat can swivel,but in walker mode use
the white locking lever under the Top Frame to
secure the Seat.
1a.
2a.
2Attach the Overhead Toys to the Toy Tray by
pressing down until they click into place.Peel
the stickers off the backing sheet and apply to
the Overhead Toys.
2a.
To assemble Toys...
1Attach the Car Ramp the Top Frame by
placing it in the groove and secure by twisting
the 2 x tabs on the underside of the Top Frame.
1a.

9
ASSEMBLY / OPERATING INSTRUCTIONS
4
5
6
The Tree,Horn, Flag,Trafc Signal,and Helicopter
Toys slot in and twist to lock in the Top Frame.
4a.
5a.
6a. Unscrew the Battery compartment lid on each
Car and insert 2 x AA batteries. Re-screw the lid.
Apply the stickers to the Trafc Signal.
To assemble Toys (continued)...
3Unscrew the battery compartment lid on the Toy Tray
and insert 2 x AA Batteries and re-screwing the lid.
Place the Toy Tray on to the Top Frame and secure
by twisting the 2 x tabs on the underside of the Top
Frame.
3a.
The walker is now ready for use.
NOTE: The Helicopter clips on and off the mounting pole.
NOTE: The toy is intended to be assembled by an adult before use.

10
ASSEMBLY / OPERATING INSTRUCTIONS
1
1
1
2
For more compact storage,press the red
button, while sliding the red lever on each
Frame Leg to allow the legs to fold inwards.
Insert the Rocking Attachments to the
underside of the Base Fame on each side of
the Base near the join.
Remove the Seat by pushing two of the black
seat ring tabs outwards and upwards on the
underside of the Top Frame.
Remove the Frame Legs from the Base
by pressing the button while lifting the leg
upwards.Repeat for all legs.
1a.
1a.
1a.
2a.
To fold the Walker...
To convert to Rocking Mode...
To convert to Play Station...

11
The play station is now ready for use.
ASSEMBLY / OPERATING INSTRUCTIONS
3
4
5
6
7
Turn the Base over and separate the ends by
pressing the lever sideways and sliding the
sections apart.Repeat for the other side.
Join the Base Frame ends together using the
Curved Base Joiner. Slide the Base Track Ends
on to each end.
Separate the Top Frame using the same
process as the Base.
Connect each end together as shown and
attach the Top Track Ends.
Hold the Top Frame above the Base and slot
the Frame Legs into the base,pushing the
buttons to slide the Leg in securely.
3a.
4a.
5a.
6a.
7a.
To convert to Play Station (continued)...

12
HOW TO CARE FOR YOUR CHILDCARE WALKER
Cleaning
Maintenance
This product has been designed and developed with safety,comfort
and functionality in mind. Please take the time to read this manual
carefully before using this product and keep it in a safe place for
future reference.
To ensure the long-lasting use of your walker, do not use abrasive
cleaners.Always store product in a clean dry place.
Seat Pad: Remove from frame.Hand wash with cold water.No bleach.
Toy and snack tray: Wipe clean with a damp cloth and mild soap.
Air dry. Do not immerse in water.
Frame: Wipe the frame with a soft, clean cloth and mild soap.
Always check parts regularly for tightness of screws, nuts and other
fasteners – tighten or replace if required. To maintain the safety of
your walker, seek prompt repairs for bent, torn, worn or broken parts.
Use only those parts and accessories approved by CNP Brands.
If you have any difculties in assembling the walker, please contact
our Service Department.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
