Chino IR-AH Series User manual

RX-MEAH0406-P2
IR-AH Series
IR-AH Communications
(Options)
(IR-AHS, IR-AHT, IR-AHU)
Always keep this instruction with your unit.
Please be sure to deliver this instruction manual with the unit to a final user.

RX-MEAH0406-P2
-CONTENTS-
CONTENTS
1. General ···············································································1
2. Communications specifications ····················································1
3. Communications procedures························································2
3.1 Basic communications format ················································2
1) Commands ···································································2
2) Positive answer ·······························································2
3) Negative answer ······························································2
3.2 Data expression ·································································3
3.3 Numeric data ·····································································3
3.4 Control code······································································3
4. Details of format······································································4
4.1 PV command·····································································4
4.1.1 Measured data ································································4
4.2 SV command·····································································5
4.2.1Alarm setpoint values························································5
4.2.2 Emissivity·····································································5
4.2.3 Signal modulation mode ····················································5
4.2.4 Modulation ratio······························································6
4.2.5 Measurement unit····························································6
4.3 XX command ····································································7
4.3.1 Model number································································7
4.3.2 ROM version ·································································7
4.3.3 Number of storage data······················································7
4.3.4 Stored temperature data ·····················································8
5. Error codes············································································9
■Symbols in this instruction manual
The symbols shown below are used depending on important degrees for using
the communications safely and avoiding unexpected situations.
Important
degree Symbols Contents
1Foravoidinginjuryorinphysicaldamagetothecommunications.
2Information that we suggest to read carefully.
3Information that you can use as a reference.
Reference
Caution
Remarks

RX-MEAH0406-P2
-1-
This optional communications is for reading measured data, parameters, and storage data of IR-AH
series handheld radiation thermometers by a personal computer.
By this communications, parameters cannot be programmed to your thermometer by a personal
computer.
Start-stop synchronizing system RS-232C
Half-duplex communications system
Transmission speed 9600bps
Start bit 1 bit
Data length 7 bits
Parity bit Even
Stop bit 1 bit
Character code ASCII
BCC (Block check code) None
Data transmission procedure None
1. General
2. Communications specifications
During measurement, any answer to the data being received is not executed due to
the speed of the CPU.
Caution
This communications is onlyfor "Reading" and "Answer".
Caution

RX-MEAH0406-P2
-2-
3.1 Basic communications format
1) Commands
STX Command Sub-command Data ETX（ETB）CR LF
Command(1character)
Sub-command
Type DataNo.
(2characters) (2characters)
Type: PV…Measureddata
SV…Parameter
XX…Others
Data: 0 to 99
2) Positive answer
STX A Sub-command = Data ETX（ETB）CR LF
3) Negative answer
STX A Errorcode : ErrordataNo. ETX CR LF
3. Communications procedures
R:
Reading
A: Answer
Reference
"ETX" is added when the data is one, or added to the last data when plural data are
answered to 1 command.
"ETB" is added to data before the last data when plural data are answered to
1 command.
Reference
A sub-command in the "Reading" command returns as the sub-command in the
answer.
This format is applied to the data positively transmitted from your thermometer, too.
Reference
Error data No.: First data position (the position counted from the position next to
"STX") where an error was detected
Make sure not to use "BCC code" due to the specifications of CPU and capacities of
ROM/RAM.
Caution

RX-MEAH0406-P2
-3-
3.2 Data expression
Data is expressed by the format with fixed length of character between " =", "," and "ETX (ETB)".
3.3 Numeric data
Data is characters with fixed length and right justified. (except Para. [4.3.1 Reading model number] with
left justified)
Numeric figures exist before and after a decimal point.
The following list is for treatment of positive sign, negative sign, and “0” at receiving and transmitting.
Item Condition Contents
Sign At receiving Positive sign: “ + ” or “space ( )” is acceptable. Negative sign: “ – ”.
“ + ” or “ – ” is placed just left to a numeric figure.
At transmitting Positive sign “ + ” is expressed by “space ( )”
Negative sign “ – ” is placed just left to a numeric figure.
“0” at
higher digits At receiving “0” (zero): “0” or “space ( ) ” is acceptable.
At transmitting “0” (zero): Zero-suppressed
Data length
At receiving Variable length
When no data exists, a positive answer returns assuming that no setting
is changed.
At transmitting Fixed length Refer to [4. Communications format].
ASCII commands ASCII codes
STX 02h
ETX 03h
ETB 17h
LF 0Ah
CR 0Dh
3. Communication procedures
The following data are not acceptable as numeric figures.
"12 3", "- 234", "-.123", "123 ", "123. " etc.
(" " mark means a space.)
Caution
3.4 Control code

RX-MEAH0406-P2
-4-
This followings are the descriptions of the "Command", "Sub-command" and "Data".
4.1 PV command
4.1.1 Measured data (1st data: 1 byte, 2nd data: 4 bytes, 3rd data: 5 bytes, 4th data: 5 bytes)
APV01=,,,
1st data: Data status
0: Normal
1: Overflow
2: Underflow
3: Hardware abnormal
2nd data: Emissivity
Integer: 1 digit, Decimal point: 1 digit, Decimal: 2 digits
Range : 0.01 to 1.99
3rd data :Temperature data
For less than 300ºC or 300ºF :
Integer : 3 digits, Decimal point: 1 digit, Decimal : 1 digit
For 300ºC or 300ºF or more : Integer: 4 digits
4th data : Not using
4. Details of format
Add control codes when following commands are used for communications items
(Refer to [3.1 Basic communications format].)
For numeric data, refer to [3.3 Numeric data].
Reference
PV command is not for reading. Data is transmitted from your thermometer positively.
Caution
In the standard measurement of your thermometer
, PV command is
transmitted
at the
releasing Meas key.
In the continuous measurement, PV command is transmitted at every display renewals.
Reference
If the integral includes a sign, it becomes
2digits.
Reference
Aspace is inserted in the most significant
digit.
When the data status is "1" or "2",
"99999"isinserted.
Reference
Caution
Thisisadummydata.
"99999"isinsertedasthedummydata.

RX-MEAH0406-P2
-5-
4.2 SV command
4.2.1Alarm setpoint values (1st data: 5 bytes, 2nd data: 5 bytes)
Reading
RSV02
ASV02=,
1st data: High alarm setpoint value
Integer: 4 digits
Range
IR-AHT: -49 to 1000ºC ( -57 to 1832ºF)
IR-AHS: 601 to 3000ºC (1114 to 5432ºF)
IR-AHU: 901 to 3000ºC (1654 to 5432ºF)
2nd data : Low alarm setpoint value
Integer: 4 digits
Range
IR-AHT: -50 to 999ºC ( -58 to 1832ºF)
IR-AHS: 600 to 2999ºC (1112 to 5431ºF)
IR-AHU: 900 to 2999ºC (1652 to 5431ºF)
4.2.2 Emissivity (Data: 4 bytes)
Reading
RSV51
ASV51=
Emissivity
Integer: 1 digit, Decimal point: 1 digit, Decimal: 2 digits
Range : 0.01 to 1.99
4.2.3 Signal modulation mode (Data: 1 byte)
Reading
RSV61
ASV61=
Signal modulation mode
Integer: 1 digit
Range : 0 to 3
0 : Real
1 : Peak
2 : Delay
3 : Valley
4. Details of format
Aspaceisinsertedinthemostsignificant digitof
"High alarm setpoint value" and "Low alarm
setpointvalue".
Reference
Remarks Eachsetpointvalueisof5bytes.

RX-MEAH0406-P2
-6-
4.2.4 Modulation ratio (Data: 4 bytes)
Reading
RSV62
ASV62=
Modulation ratio
Integer: 2 digits, Decimal point: 1 digit, Decimal: 1 digit
Range : -0.1 to 99.9
4.2.5 Measurement unit (Data: 1 byte)
Reading
RSV91
ASV91=
Measurement unit
Integer: 1 digit
0 : ºC
1 : ºF
4. Details of format
Caution
When "Hold" is programmed in your
thermometer,thedatabecomes"-0.1".

RX-MEAH0406-P2
-7-
4.3 XX command
4.3.1 Model number (Data: 6 bytes)
Reading
RXX01
AXX01=
Model number
IR-AHT: For IR-AHT
IR-AHS: For IR-AHS
IR-AHU: For IR-AHU
4.3.2 ROM version (Data: 5 bytes)
Reading
RXX02
AXX02=.
ROM version
Integer: 2 digits, Decimal point: 1 digit, Decimal: 2 digits
(Example) 1.00
4.3.3 Numberof storage data (Data: 4 bytes)
Reading
RXX81
AXX81=
Number of storage data
Integer: 4 digits
Range : 0 to 1000
4. Details of format
Number of temperature data stored in your
thermometerreturnsatcommunications.
Reference

RX-MEAH0406-P2
-8-
4.3.4 Stored temperature data (1st data: 1 byte, 2nd data: 4 bytes, 3rd data: 5 bytes,
4th data: 5 bytes)
By receiving the command, all data in order of storage are transmitted at intervals of 0.4 second.
Data before the last data is finished with "ETB" and the last data is finished with "ETX".
When any temperature data is not stored in your thermometer, the error command "A9999:0000" returns.
RXX82
AXX82=,,, EB
AXX82=,,, EB
·
·
·
AXX82=,,, EB
AXX82=,,, EX
1st data: Data status
0: Normal
1: Overflow
2: Underflow
4: Hardware abnormal
2nd data: Emissivity
Integer: 1 digit, Decimal point: 1 digit, Decimal: 3 digits
Range : 0.01 to 1.99
3rd data :Temperature data
For less than 300ºC or 300ºF :
Integer : 3 digits, Decimal point: 1 digit, Decimal : 1 digit
For 300ºC or 300ºF or more : Integer: 4 digits
4th data : Not using
Even when a communications error is happened, you are required to receive all data
up to the last data.
However, when “Break” is detected, the communications is cancelled.
Reference
4. Details of format
If the integral includes a sign, it becomes 2
digits.
Reference
A space is inserted in the most significant
digit.
When the data status is "1" or "2", "99999"
isinserted.
Reference
Caution
Thisisadummydata.
"99999"isinsertedasthedummydata.

RX-MEAH0406-P2
-9-
Error No. Errorcontents Error answer
Error code:Error data No.
1Framing error A0001 :0000
2Overrun error A0002 :0000
3Parity error A0003 :0000
10 Command error (Undefined numbers other than R, PV, SV、XX) A0010 :****
14 "ETX" missing A0014 :0000
15 Receiving buffer overflow A0015 :0000
31 Data not stored A0031 :0000
32 Data not stored by EEPROM error A0032 :0000
9999 Other errors A9999 :0000
0Positive answer except data reading at adjustment on shipment A0000 :0000
Reference
Asterisks "****" are filled with an error data position (the position counted from the
position next to "STX").
If CRLF as a delimiter for data is not detected, the error code “9999” returns.
5. Error codes
