Chipolino BMW User manual

This toy is produced in conformity with the requirements of
Toy Safety Directive 2009/48/EC of the European Parliament and the Council,
the Regulation on essential requirements and conformity assessment of toys,
the Regulation on conformity marking and the applicable European standards.
IMPORTANT! RETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE!
INSTRUCTION MANUAL
FOR TOY RIDE ON CAR
BMW

1
IMPORTANT! WARNINGS!
• CAUTION! NEVER LEAVE THE CHILD UNATTENDED!
• CAUTION! THIS TOY HAS NO BRAKE!
• CAUTION! THIS TOY IS NOT SUITABLE FOR CHILDREN UNDER 18 MONTHS AND WEIGHT
MORE THAN 20kg. DO NOT OVERLOAD!
• CAUTION! THIS PRODUCT IS NOT A TRANSPORT MEANS!
• CAUTION! DO NOT USE ON ROAD LANES!
• CAUTION! KEEP AWAY FROM FIRE!
• CAUTION! BEFORE USE, CHECK THE GOOD WORKING ORDER AND FIXING OF ALL PARTS.
 Donotusetheproductifyoundanydamagedormissingparts!
• CAUTION! TO AVOID THE RISK OF INJURY, REMOVE THE PUSH HANDLE WHEN THE CHILD
STARTS TO RIDE THE TOY UNAIDED.
• CAUTION! WHEN YOU DIRECT THE RIDE ON CAR BY THE PARENT PUSHBAR, ALWAYS USE
THE FOOT REST TO AVOID INJURY THE CHILD’S FEET!
• Useforachildaged18-35months!
• Nottobeusedbytwochildrensimultaneously!
• Adultassemblyonly!
• The child must wear shoes at all times when using the toy! It is advisable to use helmet and
protectors.
• Runningandskatingareforbiddenduringpushingwhilethereisachildonthecar.
• Useonlyduringthedayandinplaceswithgoodlighting.
• Donotletchildrentouchthewheelsorstandclosetothemwhiletherideoncarismoving!
• Iftherearestickersgoingo󰀨,youmuststickthembackorremovethemtoavoidchildrenswallowing
 them!
• Donotusesparepartsorothercomponents,whicharenotsuppliedbytheproducer!
 Theproducerrevokesallresponsibilityincasepartsdi󰀨erentfromtheoriginaloneshavebeenused.
• Donotmakechangesormodicationstotheconstruction!Ifnecessary,contacttheretaileroran
 authorizedservicecenterforadviceandrepair.
• Usetheproductonlyforitspurpose!
• Donotallowpresenceofchildrenunder3yearsduringassemblyoftheproductiscomplete,toavoid
 accesstosmallorlooseparts!
• Donottiestringsoraccessoriestotheproductinordertoavoidtheriskofsu󰀨ocation.
• Useonlyonevenplaygroundsandatasafedistancefromstreetsorroadlanesforvehicles!
• Donotusetheproductnearstairs,escalators,protrusions,swimmingpoolsetc.!
• Keepnylonpackagesawayfromchildrentoavoidriskofsu󰀨ocation!
TO GUARANTEE THE SAFE USE OF THIS PRODUCT FOLLOW
THE WARNINGS, GUIDELINES AND RECOMMENDATIONS IN THIS MANUAL!

2
MAIN PARTS
Pleasecheckthatthedescribedpartsareavailable.
MAIN FEATURES OF THE PRODUCT
• Alwayssecurethebatteriescompartmentwiththecoverafterbatteriesinstallation.
• Donotallowchildrentoaccessorplaywiththebatteries!
• Useonlybatteriesofthedesignatedtypeandpower.
• Donotusebatteriesofdi󰀨erenttypes.
• Donotmixnewwithusedbatteries.
• Followthedesignatedpolarityinthebatterycompartment.
• Removedamagedorwornoutbatteries.
• Removethebatterieswhentheproductwillnotbeusedforlongtime.
• Donotthrowthebatteriesinopenre.Donottakethebatteriestopieces.
CAUTION!Wastefromdepletedorunusablebatteriesmustbedisposedofseparately.Itisforbidden
tothrowthemoutincontainersforhouseholdwaste.Disposeofthebatteriesonlyatthespecied
places.
IMPORTANT! WARNINGS AND GUIDELINES FOR BATTERY USE
Name Photo Qty. Name Photo Qty.
Body 1 pc Wheel 4 pcs
Decorativecap 4 pcs Sideguards 1 set
Brakepads 4 pcs Backrest 1 pc
Steeringwheel 1 pc User’smanual 1 pc
Pushhandle 1 pc
Batteriesneeded 4pcssizeАА/1,5V
Recommendedageofthechild 18-35months
Maximumweightofchild 20 kg
Sizesoftoy 65х29х42cm(withoutpushhandle)
79,5х35,5х101,5cm(withpushhandle)

3
press
press
WARNING! FOLLOW EXACTLY THE INSTRUCTIONS AND SEQUENCES FOR ASSEMBLY AND US-
ING THE PRODUCT FROM THE BELOW FIGURES.
WARNING! CHECK THE SECURITY OF FIXING AFTER PERFORMING ANY OPERATION!
Required tools for performing some operations:screwdriver(notincluded).
Thetoyassemblyoperationsandfunctionsaredescribedbelow.
FOOTREST
BATTERIES
Pressthebuttonsandadjustthefootrestsinwards.
Beforerstusageofthetoy:
1.Liftuptheseat.
2.Untightenthescrewandremovethecoverofbatteriescompartment.
3.Install4pcssizeАА/1,5Vbatteries,obeyingthegivenpolarityatbatteriescompartment.
3.Placebackthebatteriescompartmentcoverandxitwiththescrew.
ASSEMBLY UNSTRUCTIONS AND FUNCTIONS
ASSEMBLY
Batteries: 4 pcs size AA/1.5V
1.5V battery
1.5V battery
1.5V battery
1.5V battery
cover of batteries
compartment
screw

4
ASSEMBLY OF BRAKE PADS
ASSEMBLY OF FRONT WHEELS
Placeatbothsidesoffrontandrearaxisonebrakepadandpress.
Placethewheelonfrontaxis,addthewasherandxwiththebracket.
Atlastplacethedecorativecoverwithpressureuntilyouhearaclicksoundanditxes.
Assembletheotherwheelfollowingthesameorderofactions.
pads
pads
front wheel xing bracket
washer
decorative cover

5
ASSEMBLY OF REAR WHEELS
ASSEMBLY OF STEERING WHEEL
Placethewheelonrearaxis,addthewasherandxwiththebracket.Atlastplacethedecorativecover
withpressureuntilyouhearaclicksoundanditxes.Assembletheotherwheelfollowingthesame
orderofactions.
Jointhewireconnectorsatsteeringwheelandsteeringaxisasshowninthegure.Aligntheopenings
atthesteeringwheelandsteeringaxissotheymatch.Placethescrewandxwiththenut.
decorative cover
xing bracket ATTENTION!
Correct installation
of xing bracket!
rear wheel
washer
steering wheel
steering axis
connectors

6
ASSEMBLY OF BACKREST
ASSEMBLY OF GUARDS
ASSEMBLY OF PUSH HANDLE
Placethebackresttothebodyofcarasshownin
thegure.Presstoxit.
Insert the shoulders of the guards into the
corresponding slots of the backrest. Place the
lockingaxisasshowninthegure.
Rotatetheshouldersoftheguardsandplacethem
tothesteeringwheel.Pressuntilthebuttonshows
out of the slot. This indicates that shoulders are
xed.
Placethepush handle to the slot of thebackrest.
Press the button and insert the push handle until
thebuttonshowsoutoftheslot.Thisindicatesthat
pushhandleisxed.
• STEERING WHEEL WITH MELODIES AND BEEP
Beforeyouusethefunctionsofthesteeringwheel,checkifyouhaveinstalled4pcssizeАА/1,5V,as
described in section „BATTERIES“.
• PUSH HANDLE
ATTENTION!Removethepushhandlewhenchildstartstohandlethetoybyhis/herown!
1.SettheswitchinONposition(I),
tostartthepower.
2.Presstheleftbuttontobeep.
3.Presstherightbuttontoplaymelodies.
FUNCTIONS
locking axis
push handle
beep
Switch
ON/OFF
“click“
button
melodies
guards

7
CARE AND MAINTENANCE INSTRUCTIONS
• Regularlychecktheplasticpartsoftherideoncarforanycracksordamage.
• Regularlyoilthemovingparts.
• Cleanthetoybyusingadampsofttowelorspongeandamildsoap.Donotpourwateronthetoy.
• Donotcleanwithaggressivedetergentscontainingabrasiveparticles,ammonia,bleachorspirit.
• Store the product in a clean and dry place, without moisture and at a safe distance from heat
 sources!Donotsubjecttodirectenvironmentale󰀨ect–sun,rain,moistureorharshtemperature
 changes!
• Donotusetheproductonmuddy,sandyorgravelcoveredterrains,whichcandamagethemoving
 parts.
• Incaseofproblemsrelatedtonormaloperation,contactauthorizedservicecentersforconsultation
 orrepair.
ROCBMW023xxxx/ SXZ2078

Producer:ProducedforChipolinoinPRC
Importer:CHIPOLINOLTD.,1GoliamokonarskoShosseStr,
Plovdiv,BULGARIA;tel.:+35932600889;
www.chipolino.com
