a.When receiving the inverter, check that the packing materials are intact.
b.After unpacking, check that the deliverables are complete, intact, and consistent with your
order list.
c.Examine the PV inverter and its fittings for damage such as scraps and cracks.
Do not install the inverter in aplace where personnel are likely to
come into contact with its enclosure and heat sinks to avoid electrical
shock/burn.
Figures 4.1The deliverables: The inverter and its fittings
CAUTION
DANGER
12
Do not install the inverter on flammable building materials or in an
area where flammable or explosive materials are stored.
or
G
Items
A
B
C
D
E
F
G
H
Deliverables
The inverter
Rear panel
AC output connector
File package
DC terminal connector group
Screws
Removal tool for DC connector
Expansion screw group
H
󾙖󾙙󾙙󾙙󾙔󾙔󾙒󾙔󾙒
󾙕
