Chore-Time 50576 Specifications

24" Basket Fan (50576 and 50576-230)
Installation and Operators Instruction Manual
3
1
Item Description
1 Socket Wrench
2 7/16" & 9/16" Combination Wrench
3 Safety Glasses
4 Measuring Tape
5 7/16" & 9/16" Socket
Recommended Tools for
Assembly (Not Provided)
Item Qty. Description
1 1 3/8" x 1-1/4" Hex Bolt
223/8" Flat Washer
3 1 3/8" Nylock Nut
Item Qty Description
4 1 1/4" x 1" Bolt
5 2 1/4" Flat Washer
6 1 1/4" Nylock Nut
1
2
3
4
Please read over all instructions carefully before you begin. For additional parts and information,
contact your nearest Chore-Time distributor or representative.
Find your nearest distributor at: www.choretime.com/contacts
4
5
3
2
1
5
6
Included Assembly
Hardware-Full Scale
50576
115V Fan
50576-230
230V Fan
Item Description Qty. Part No.
1 Motor, .5HP, 1PH, 60HZ, 115/230V 1 53143 53143
2 Decal, CT Round Fan 1 ST79001 ST79001
3 Capacitor 1 55337 55337
2
MV2478ADecember 2018

Limited Warranty 24" Basket Fan (50576 and 50576-230)
2MV2478A
LIMITED WARRANTY
Chore-Time Group, a division of CTB, Inc. (“Chore-Time”) warrants the new CHORE-TIME Fans manufactured by Chore-
Time to be free from defects in material or workmanship under normal usage and conditions, for One (1) year from the date
of installation by the original purchaser (“Warranty”). Chore-Time provides for an extension of the aforementioned
Warranty period (“Extended Warranty Period”) with respect to certain Product parts. If such a defect is determined by
Chore-Time to exist within the applicable period, Chore-Time will, at its option, (a) repair the Product or Component Part
free of charge, F.O.B. the factory of manufacture or (b) replace the Product or Component Part free of charge, F.O.B. the
factory of manufacture. This Warranty is not transferable, and applies only to the original purchaser of the Product.
CONDITIONS AND LIMITATIONS
THIS WARRANTY CONSTITUTES CHORE-TIME’S ENTIRE AND SOLE WARRANTY AND CHORE-TIME
EXPRESSLY DISCLAIMS ANY AND ALL OTHER WARRANTIES, INCLUDING, BUT NOT LIMITED TO,
EXPRESS AND IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES AS TO
MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSES. CHORE-TIME shall not be liable for any direct,
indirect, incidental, consequential or special damages which any purchaser may suffer or claim to suffer as a result of any
defect in the Product. Consequential or Special Damages as used herein include, but are not limited to, lost or damaged
products or goods, costs of transportation, lost sales, lost orders, lost income, increased overhead, labor and incidental costs,
and operational inefficiencies. Some jurisdictions prohibit limitations on implied warranties and/or the exclusion or
limitation of such damages, so these limitations and exclusions may not apply to you. This warranty gives the original
purchaser specific legal rights. You may also have other rights based upon your specific jurisdiction.
Compliance with federal, state and local rules which apply to the location, installation and use of the Product are the
responsibility of the original purchaser, and CHORE-TIME shall not be liable for any damages which may result from non-
compliance with such rules.
The following circumstances shall render this Warranty void:
· Modifications made to the Product not specifically delineated in the Product manual.
· Product not installed and/or operated in accordance with the instructions published by the CHORE-TIME.
· All components of the Product are not original equipment supplied by CHORE-TIME.
· Product was not purchased from and/or installed by a CHORE-TIME authorized distributor or certified
representative.
· Product experienced malfunction or failure resulting from misuse, abuse, mismanagement, negligence, alteration,
accident, or lack of proper maintenance, or from lightning strikes, electrical power surges or interruption of
electricity.
· Product experienced corrosion, material deterioration and/or equipment malfunction caused by or consistent with
the application of chemicals, minerals, sediments or other foreign elements.
· Product was used for any purpose other than for the care of poultry and livestock.
·
The Warranty and Extended Warranty may only be modified in writing by an officer of CHORE-TIME. CHORE-TIME
shall have no obligation or responsibility for any representations or warranties made by or on behalf of any distributor,
dealer, agent or certified representative.
Limited Warranty
Effective: April 2014

24" Basket Fan (50576 and 50576-230) Installation
3
MV2478A
Installation
Minimum 5’
Unrestricted Space
Required
It is important to select a proper location when mounting your
circulation fan. You must provide a minimum of 5’ unrestricted
air flow on the back side of the fan. Failure to provide the space
needed for airflow may reduce motor life and void the war-
ranty.
1
If mounting bracket to structure, verify anchor points are
strong enough for added weight of bracket and fan. Attach top
of bracket to structure with (4) washers and (4) screws or
bolts with nylock nuts (not provided) suitable for your struc-
ture. DO NOT attach bracket to or against wall as this will not
give motor enough unrestricted air flow.
2a
4a
Prep motor for use by removing the 2 drain plugs located on
the bottom (flag mount) side of the motor. Removal of these
plugs allows for drainage of any moisture that might get
inside the motor. DO NOT remove the plugs on the top
(capacitor) side of motor. Removal of these plugs will void
warranty and allow dirt and moisture into the motor, reducing
the life of the motor.
3
Attach fan to bracket. Insert bracket flag in between the motor
flags and secure using the center holes on the motor flags with
(1) 3/8” x 1-1/4” hex bolt, (2) 3/8” washers and (1) 3/8” nylock
nut as shown in step 4a. Using the crescent openings on the
motor flags, install the (1) 1/4” x 1” hex bolt, (2) 1/4” washers
and (1) 1/4” nylock nut as shown in step 4b. Adjust the fan to
the desired angle and tighten hardware to secure fan angle.
4b
4c
DO NOT
MOUNT
AGAINST
WALL!

Additional Clarifications and Warnings 24" Basket Fan (50576 and 50576-230)
4MV2478A
Additional Clarifications and Warnings
Do NOT mount fan with capacitor on the bottom. This
can cause moisture to build up in the capacitor cap and
short out the capacitor. Mounting the fan this way will
void the warranty.
Do NOT mount bracket horizontally. The included
bracket was not designed to be mounted this way and
cannot withstand the structural stress caused by the
weight and movement of the fan. Mounting the bracket
and fan this way will void the warranty.
CHORE-TIME has a wide variety of horizontal brack-
ets and additional options for mounting. Contact
CHORE-TIME for more information.
DISCONNECT POWER BEFORE
INSTALLING OR SERVICING.
ALLELECTRICALWORK SHOULD BECOMPLETEDBYQUALIFIED
PERSONNEL AND MEET NATIONAL (NEC), REGIONAL, AND
LOCAL ELECTRIC CODES
PROVIDING POWER TO FAN
Instructions for corded models
• Provide a grounded outlet that meets or exceeds the load capability for your fan.
Wiring instructions for non corded models
• Wiring should only be performed by a trained electrician to prevent injury or death.
Install manual disconnect switch inside building adjacent to fan.
• Route wire to motor with drip loop and secure.
• Drip loop will drain accumulated moisture away from the motor.
• Configure internal wires to match supply voltage and wire according to motor
nameplate. Test to verify correct rotation.
• Only permit power to unit when guard and motor’s cover plate is properly installed
to prevent injury.
MAINTENANCE INSTRUCTIONS
Part No. Fan Size Description
Side Mount Brackets
VRSBR14 12"-36"[30.5-91.4cm] 42" Extended Bracket, for Sq. or Rnd Up Post
VRSBR143 12"-36"[30.5-91.4cm] 42" Extended Bracket, for 3" Tube-Bolt On
VRSBR144 12"-36"[30.5-91.4cm] 42" Extended Bracket for 4" Tube -Bolt On
VRSBR14412 12"-36"[30.5-91.4cm] 42" Extended Bracket, 4-1/2" Tube-Bolt On
VRSB901 12"-36"[30.5-91.4cm] Wall Mount Bracket
Ceiling Mount Brackets
VRSBR2-HDG 12"-24"[30.5-70cm] 6-Way Bracket
VRSBR3-HDG 36"[91.4cm] 6 Way Bracket
Pole Mount Brackets
VRSBR12 12"-36"[30.5-91.4cm] Pole Bracket, fits 4"-4-1/2" Tube
VRSBR13 12"-36"[30.5-91.4cm] Pole Bracket, fits 3"-3-1/2" Tube
VRSBR14
VRSBR12, VRSBR13
VRSBR2-HDG
VRSBR3-HDG
VRSBR143
VRSBR144
VRSBR14414
Capacitor
• Disconnect power before cleaning or maintaining your fan in order to prevent
serious injury or death.
• Service and repair of fan should only be completed by a qualified technician.
• For maximum efficiency and fan life, keep the blades, motor and guard free from
dirt and dust.
• The totally enclosed air over motor has sealed ball bearings and does not require
additional lubrication.
