Chore-Time REVOLUTION Setup guide

Adult Turkey Feeder, MODEL ATF™
Installation and Operators Manual
MF232QJuly 2023

Chore-Time Warranty Adult Turkey Feeder, MODEL ATF™
2MF232Q
CTB, Inc., (“Chore-Time”), warrants each new CHORE-TIME® product manufactured by it to be free from
defects in material or workmanship for one-year from and after the date of initial installation by or for the original
purchaser. If such a defect is found by Chore-Time to exist within the one-year period, Chore-Time will, at its
option, (a) repair or replace such product free of charge, F.O.B. the factory of manufacture, or (b) refund to the
original purchaser the original purchase price, in lieu of such repair or replacement. Labor costs associated with
the replacement or repair of the product are not covered by the Manufacturer.
Additional extended warranties for the equipment and/or systems listed below are provided to the original
purchaser as follows (for all other CHORE-TIME® products purchased, the one-year warranty period shall
apply):
1. TURBOand RLXfans, less motors - 3 years
2. TURBOfan fiberglass housings, polyethylene cones, and cast aluminum blades - for the life of the product
3. TURBOfan motors and bearings - 2 years
4. TURBOfan components (including plastic shutters) - 3 years
5. Poultry feeder pans that becomes unusable within five years from the date of installation - Warranty prorated
after three years usage
6. Rotating centerless augers, excluding applications involving high moisture feed stuffs (exceeding 18%), for
ten years from the date of installation. Note: MULTIFLO® and applications involving high moisture feed
stuffs are subject to a one-year warranty
7. Chore-Time manufactured roll-formed steel auger tubes for ten years from the date of installation
8. ULTRAFLO® Breeder Feeding System auger and feed trough are warranted for a period of five years from
the date of original installation against repeated breakage of the auger or wear-through of the feed trough
caused solely by the auger
9. ULTRAPAN® Feeding System augers are warranted for a period of five years from the date of installation againstlely
by the auger
Chore-Time Warranty

Adult Turkey Feeder, MODEL ATF™ Chore-Time Warranty
MF232Q 3
CONDITIONS AND LIMITATIONS
1. The product must be installed by and operated in accordance with the instructions published by the
Manufacturer or Warranty will be void.
2. Warranty is void if all components of the system are not original equipment supplied by the
Manufacturer.
3. This product must be purchased from and installed by an authorized distributor or certified
representative thereof or the Warranty will be void.
4. Malfunctions or failure resulting from misuse, abuse, negligence, alteration, accident, or lack of
proper maintenance shall not be considered defects under the Warranty.
5. This Warranty applies only to systems for the care of poultry and livestock. Other applications in
industry or commerce are not covered by this Warranty.
Chore-Time shall not be liable for any consequential or special damage which any purchaser may suffer or claim
to suffer as a result of any defect in the product. “Consequential” or special damages” as used herein include, but
are not limited to, lost or damaged products or goods, costs of transportation, lost sales, lost orders, lost income,
increased overhead, labor and incidental costs and operational inefficiencies.
THIS WARRANTY CONSTITUTES THE MANUFACTURER’S ENTIRE AND SOLE WARRANTY AND
THIS MANUFACTURER EXPRESSLEY DISCLAIMS ANY AND ALL OTHER WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, EXPRESS AND IMPLIED WARRANTIES AS TO
MERCHANTIBILITY, FITNESS FOR PARTICULAR PURPOSES SOLD AND DESCRIPTION OR
QUALITY OF THE PRODUCT FURNISHED HEREUNDER.
Chore-Time Distributors are not authorized to modify or extend the terms and conditions of this Warranty in any
manner or to offer or grant any other warranties for Chore-Time products in addition to those terms expressly
stated above.
An officer of CTB, Inc. must authorize any exceptions to this Warranty in writing. Chore-Time reserves the right
to change models and specifications at any time without notice or obligation to improve previous models.
Effective: July 2023
Thank You
The employees of Chore-Time would like to thank your for your recent Chore-Time purchase. If a problem should
arise, your Chore-Time distributor can supply the necessary information to help you.
*Chore-Time Poultry Feeder Pan Pro Rata Schedule
Year from date of installation during which pan becomes unusable Charge to be paid by the purchaser for replacement.
0 - 1 years NO CHARGE
1 - 2 years NO CHARGE
2 - 3 years NO CHARGE
3 - 4 years 4/10 of then current list price
4 - 5 years 5/10 of then current list price

Contents
Topic Page
MF232Q
4
Chore-Time Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CONDITIONS AND LIMITATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Follow Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Decal Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Support Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Model ATF Recommendations & Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Manufacturer’s Recommendations: Birds per Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Glossary of Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Planning the Floor Feeding System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Suspension System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Screw Hook Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Ceiling Hook Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power Winch Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Drop Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Hopper Assembly Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Suspend the Hopper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Feeder Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
MODEL ATF™ Feeding System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Adult Turkey Feeder Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Feeder Tube Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Feeder Line Assembly and Suspension. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Feeder Line Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Control Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Auger Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Auger Brazing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Winch Adjustable Feed Level Tubes (optional equipment) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Installation of the Winch Adjustable Feed Level Tube System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Intermediate Control (optional equipment) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Intermediate Control Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Anti-Roost Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Maintaining the MODEL ATF™ Feeding System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Floor Feeding System Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Gear Head Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Switch Adjustment procedure for the Control Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
SENSOR PLUS™ Sensor Switch Adjustment for Control Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
For less time — turn Time Delay Adjusting Screw counter-clockwise (Light blinks fast). . . . . . . . . . . . . . . . 36
Feeder Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Power Lift Winch Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Trouble Shooting the MODEL ATF™ Feeding System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Contents - continued
Topic Page
MF232Q 5
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
End & Intermediate Control Wiring Diagrams: Single Phase(Ø) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Single Phase(Ø) Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Single Phase(Ø) Wiring Diagram w/Motor Starter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
End & Intermediate Control Wiring Diagrams: Three Phase(Ø) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Three Phase(Ø) Wiring Diagram: 220/230 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Three Phase(Ø) Wiring Diagram: 380/415 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Sensor Plus™ Internal Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Sensor Plus™ Control Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Sensor Plus™ Three Phase(Ø) Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Intermediate Control Internal Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Parts Listing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
150# Hopper Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Hopper Mount Bracket (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Single Boot Components Part No. 6821 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Twin Boot Components Part No. 8460 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Feeder Line Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Power Unit Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Power Unit Assembly Part Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Sensor Plus™ End Control Part No. 42343. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
MODEL ATF™ Control Unit Components Part No. 49040 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Drop Tube Assembly Part No. 28072 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Intermediate Control Part No. 6039. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Feed Level Tube Winch Kit Part No. 46218 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
47687 Power Winch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Miscellaneous Suspension Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
MODEL ATF™ Pan Assemblies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Optional Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

About This Manual Adult Turkey Feeder, MODEL ATF™
6MF232Q
The intent of this manual is to help you in two ways. One is to follow step-by-step in the order of assembly of your
product. The other way is for easy reference if you have questions in a particular area.
Important: Read ALL instructions carefully before starting construction.
Important: Pay particular attention to all SAFETY information.
• Metric measurements are shown in millimeters and in brackets, unless otherwise specified. “ " ” equals inches
and “ ' ” equals feet in English measurements.
Examples:
1" [25.4]
4' [1 219]
• Optional equipment contains necessary instructions for assembly or operation.
• Very small numbers near an illustration (i.e., 1257-48) are identification of the graphic, not a part number.
Caution, Warning and Danger Decals have been placed on the equipment to warn of potentially dangerous
situations. Care should be taken to keep this information intact and easy to read at all times. Replace missing or
damaged safety decals immediately.
Using the equipment for purposes other than specified in this manual may cause personal injury and/or damage to
the equipment.
Safety–Alert Symbol
This is a safety–alert symbol. When you see this symbol on your equipment, be alert to the
potential for personal injury. This equipment is designed to be installed and operated as safely
as possible...however, hazards do exist.
Understanding Signal Words
Signal words are used in conjunction with the safety–alert symbol to identify the severity of the warning.
DANGER indicates an imminently hazardous situation which, if not avoided, WILL result in death or
serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, COULD result in death or
serious injury.
CAUTION indicates a hazardous situation which, if not avoided, MAY result in minor or moderate
injury.
About This Manual
Safety Information

Adult Turkey Feeder, MODEL ATF™ Safety Instructions
MF232Q 7
Follow Safety Instructions
Carefully read all safety messages in this manual and on your equipment safety signs. Follow recommended
precautions and safe operating practices.
Keep safety signs in good condition. Replace missing or damaged safety signs.
Decal Descriptions
DANGER: Moving Auger
This decal is placed on the Panel Weldment.
Severe personal injury will result, if the electrical power is not
disconnected, prior to servicing the equipment.
DANGER: Electrical Hazard
Disconnect electrical power before inspecting or servicing equipment
unless maintenance instructions specifically state otherwise.
Ground all electrical equipment for safety.
All electrical wiring must be done by a qualified electrician in accordance
with local and national electric codes.
Ground all non-current carrying metal parts to guard against electrical
shock.
With the exception of motor overload protection, electrical disconnects and
over current protection are not supplied with the equipment.
CAUTION:
Use caution when working with the Auger—springing Auger may cause personal
injury.
Support Information
The Chore-Time Adult Turkey Feeding System, MODEL ATF™, has been designed to feed poultry. Using this
equipment for any other purpose or in a way not within the operating recommendations specified in this manual
will void the warranty and may cause personal injury.
This manual is designed to provide comprehensive planning and installation information. The Table of Contents
provides a convenient overview of the information in this manual.
Safety Instructions
General
Manboot 3/98

General Adult Turkey Feeder, MODEL ATF™
8MF232Q
Model ATF Recommendations & Guidelines
The Chore-Time Adult Turkey Feeder is recommended for birds 5 to 6 weeks old and over. See “Manufacturer’s
Recommendations: Birds per Pan” on page 9 for feeder space recommendations.
Adult Tom Turkeys: 40 to 50 birds per pan.
Hen Turkeys: 60 birds per pan.
Operate the equipment, if possible, before birds are housed to check installation, switch operation and to fill the
feeder lines with feed.
The oil coating on new auger will cause the auger to deliver feed at a slower rate. To reduce the load on the motor
while the equipment is being broken in, auger 50 pound (20 kg) increments of feed out to the pans. Allow
the system to run for approximately 30 seconds, then add another 50 pounds (20 kg) of feed. Repeat this
procedure until feed has been supplied to all the pans. Do not feed grit with the Adult Turkey Feeder.
Birds avoid dark or cold areas. Do not locate a Control Unit or Intermediate Control in such an area. Also, do not
locate the Control Unit close to the end of the building. Allow a minimum of 10 feet (3 m) between the
Control Unit and the building wall. If these problems are anticipated, they can be corrected during
installation. Otherwise, artificial lighting can partially correct the problem.
During the break-in period, check the feed level in the pans. Normally, 1" to 1-1/2" (25 to 38 mm) of feed in the
pan controls feed waste. When birds are housed, monitor the feed leave in the pans and adjust as needed.
Note: When birds are debeaked, a deeper feed level is required. Adjust the feed level by raising or
lowering the Feed Level Ring.
The height of the feeder line can be adjusted easily and it should be raised periodically as birds grow. Keep the lip
of the pan approximately at the point where the bird’s neck joins the breast so the birds must reach slightly.
For the average 20 pound (9.1 kg) turkey, this will put the lip of the pan about 16 to 18 inches (405 to 455
mm) above the floor. Keeping the pans high results in less feed waste, less litter in pans and easier bird
movement.

Adult Turkey Feeder, MODEL ATF™
MF232Q 9
Manufacturer’s Recommendations: Birds per Pan
*Notice: Please be advised that the maximum number of birds that may be successfully produced per feed pan
may vary based upon such factors as climate, housing type or style, bird breeds, genetic factors of the birds at
issue, grower management practices, etc. All other environmental and management circumstances, such as proper
bird density per house, access to adequate nutrients in feed, access to adequate water supply, proper ventilation,
adequate health care for the birds, and other similar factors, must meet industry standards and recommendations,
if any, of applicable bird breeder companies.
* NOTICE: The above Manufacturer’s recommendations do not constitute a product warranty and are in no
way to be considered as a guarantee of performance for poultry production. In addition, the above information in
no way alters or revises the terms and conditions of any applicable Chore-Time manufacturer’s warranty.
Type Max weight and/or
weeks of age
Feeders Number of birds/pan
Broiler 4.5lbs/2kg. Revolution 12, Models
C2 Plus, C2Plus S, C,
H2, H2 Plus
60 - 90
Broiler 7lbs/3.1kg Revolution 8, C2 Plus,
C2 Plus S, G Plus, G Plus
S, C, H2, H2 Plus
55 - 75
Broiler 9lbs/4.0kg Revolution 8, G Plus, G
Plus S
45 – 65
Broiler Breeder Pullet –
rearing
0 – 18 weeks C2 Plus (Breeder),
C2 Plus S (Breeder)
14 - 15
Broiler Breeder Pullet –
rearing
0 – 18 weeks
Hi-Yield
C2 Plus (Breeder),
C2 Plus S (Breeder)
12-14
Broiler Breeder Male –
rearing
0 -- 18 weeks C2 Plus (Breeder), C2
Plus S (Breeder), G Plus
(Breeder), G Plus s
(Breeder)
11-13
Broiler Breeder Layer 17 + weeks C2 Plus (Breeder),
C2 Plus S (Breeder)
13 - 14
Broiler Breeder Layer 17 + weeks
Hi-Yield
C2 Plus (Breeder),
C2 Plus S (Breeder)
12 - 13
Broiler Breeder Male 17 + weeks G Plus (Breeder), G Plus
S (Breeder)
8-10
Commercial Layer Pullet
– rearing
0 – 20 weeks Revolution 12, C2Plus,
H2, H2 Plus
40-60
Commercial Layer 18 + weeks Revolution 12, C2 Plus,
C, H2, H2 Plus
30 - 40
Turkey Poult 0 – 5 weeks Revolution 8, H2 Plus,
H2, G Plus, G Plus S
60 - 65
Turkey Poult 0 – 10 weeks Revolution 8, G Plus, H2
Plus, H2
40 - 50
Turkey Female 5 + weeks ATF, ATF Plus 60
Turkey Male 5 + weeks ATF Plus 40 - 50
Ducks 0 – 3 weeks G Plus, G Plus S 60 - 70
Ducks 4 – 8 weeks G Plus, G Plus S 50 - 60

Glossary of Terms Adult Turkey Feeder, MODEL ATF™
10 MF232Q
Intermediate control: End control:
Clamp: Anti-Roost Bracket:
Adjustment Leveler: Drop Line:
Throw-back:
A cable/pulley arrangement that allows cable to be routed to a
desired location.
Double-back:
A cable/pulley arrangement that reduces the load on the Power
Winch.
Power Lift:
Red, cast iron winch used to raise and lower the feeder line(s).
Operated by a hand crank or electric drill. Referred to as Power
Winch.
Electro-Guard:
A high voltage, low current shocking device used to keep birds
from setting on the feeder line.
Glossary of Terms
A feeder, equipped
with a switch,
(located near the
center of thefeeder
line) used to
control the feeding
system when
partial house
brooding.
A feeder, equipped with a
switch, (located at the
power unit) used to control
the feeding system.
A two-piece, riveted strap used to
secure auger tubes together. An insulator and bracket assembly mounted on
every fourth or fifth clamp to support shocker
wire.
A cable locking devise used to conveniently
adjust the feeder to a level position. Asection of cable fastened
to the main cable, routed
through a pulley, down to
the feeder line.

Adult Turkey Feeder, MODEL ATF™ Planning the Floor Feeding System
MF232Q 11
1. Select the House Layout.
Figure 1.Component location diagram for systems up to 400 feet [122 m]. (Top View).
A. Systems with line lengths over 400’ [122 m] should be split in the center, as shown in Figure 2. This will
reduce auger running time and eliminate the need for Mid-Line Controls for partial house brooding.
Figure 2. Component location diagram for systems over 400 feet [122 m]. (Top View).
2. Determine the Feed Bin location.
3. Determine the Brood Curtain location.
4. Determine the location for the End Control Pans. The Feeder Control Pans should be at least 10’ [3 m]
from the Wall or Brood Curtain.
5. Determine the distance to the Feeder Line from the Side Wall.
6. Determine the distance from the Feed Hoppers to the End Wall for a Straight Line Feeding System.
Planning the Floor Feeding System
1255-68 1/2001
6) Feed Bin
3) Feed Hopper 4) Mid Line Control
2) Brood Curtain
5) End Control
& Power Unit
1) Control Tube
1) Control Tube
1) Control Tube
1) Control Tube
10' [3 m]
Minimum
10' [3 m]
Minimum
10' [3 m]
Minimum
10' [3 m]
Minimum
1255-69 1/2001
5) Feed Bin
3) Feed Hoppers
2) Brood Curtain
4) End Control
& Power Unit
4) End Control
& Power Unit
1) Control Tube
1) Control Tube
1) Control Tube
1) Control Tube

Suspension System Adult Turkey Feeder, MODEL ATF™
12 MF232Q
The feeder line suspension system is a vital part of your feeding system. Proper planning and installation is
necessary to insure proper operation of the system. Use the chart below as a reference guide for determining
support load requirements for your system.
The type of installation required depends on feeder line length. Figure 3shows the suspension system for feeder
line lengths to 350’ (107 m). Figure 4 shows the suspension system for feeder lines over 350’ (107 m).
IMPORTANT: Notice that the feeder line MUST BE SUPPORTED WITHIN 3 FEET (1 M) OF
THE MOTOR ON THE CONTROL UNIT. When Steel Hoppers with center
suspension are installed the feeder line MUST BE SUPPORTED WITHIN 1
FOOT (300MM) OF THE HOPPER. If the Control Unit does not come out
directly under a truss, fasten a pulley to a 2x8 (50x200 mm) board or other fixture
that will span 2 trusses supporting the Control Unit. See “Hopper Assembly
Procedure” on page 17. for special plastic hopper suspension.
After determining the type of suspension system required, decide where the feeder line is to be installed. Mark a
straight line on the ceiling or rafters the full length of the feeder line. Use a string, chalk line, or the winch cable,
temporarily attached with staples, to mark the line. Center the line directly over where the feeder is to be
installed.
The recommended distance between the drops is 8’ (2.4 m) on center. Do not exceed 10’ (3 m) spacing on drop
lines.
If the distance raised is greater than the distance between the drop spacings, offset the hooks 3" (75 mm) to each
side of the line to prevent the cable clamps from catching the pulleys, see figure 5.
For installations using wood trusses, standard screw hook or the optional Ceiling Hook may be used to hold the
pulley assemblies.
For installations using steel trusses, the Ceiling Hooks are available to hold the pulley assemblies.
Suspension System
Component Weigh in pounds (kg)
Tube, Auger, Feeders, & Feed 7 lbs./ft (10.5 kg./m)
Power Unit & Control Unit Assembly 50 lbs. (22.6 kg)
150 lb. Feed Hopper & Feed 180 lbs. (81.6 kg)
Power Winch 40 lbs. (18.1 kg)

Adult Turkey Feeder, MODEL ATF™ Suspension System
MF232Q 13
Figure 3. For Systems over 350’ (107 m)
Figure 4. For Systems up to 350’ (107 m)

Suspension System Adult Turkey Feeder, MODEL ATF™
14 MF232Q
Figure 5. Suspension System with Offsets
Screw Hook Installation
Screw the hook into the truss the full length of the threads to prevent bending. The openings of the screw hooks
must be pointed away from the direction of travel when the Power Winch raises the feeder line, see figure 6.
Figure 6. Screw Hook Installation

Adult Turkey Feeder, MODEL ATF™ Suspension System
MF232Q 15
Ceiling Hook Installation
Figure 8. Swivel Pulley Installation
Item Description Part No.
1 Ceiling Hook 28550
2 Steel Truss --
3 Wood Truss
4 1/4-20 Lag Screw --
5 Cable Travel Direction --
6Weld --
4
22
5 5
5
5
4
63
4
2
1111
Figure 7. Pulley Installation

Suspension System Adult Turkey Feeder, MODEL ATF™
16 MF232Q
Power Winch Installation
1. Bolt the Power Winch, fully assembled, to a 2 x 8" (50 x 200 mm) board or other fixture that will span at
least 3 rafters. The brake mechanism will protrude on one side.
For feeder lines over 350 feet (106 m), install a 2985 Cable Hook between the mounting bolt and Power Winch
frame, as shown in Figure 9.
2. Attach the 2 x 8" (50 x 200 mm) board, with the Power Winch secured, to the ceiling at the center of the
feeder line. The 2 x 8" (50 x 200 mm) or other fixture must be parallel to the line and must span at least 3
rafters or other fixture.
If the hopper is located at the center of the feeder line, locate the Power Winch a few feet offset from the center
of the feeder line.
3. Extend the 3/16" (5 mm) cable the full length of the feeder line. Attach the cable temporarily to the ceiling
with nails, staples, or some type of fastener.
Figure 9. Power Winch Installation
4. Wrap the cable through the winch drum relief located near the bottom of the drum. Tighten the set screw to
anchor the cable to the drum, see figure 10.
5. Turn the winch drum one full revolution. Guide the cable against the flange at the bottom of the winch drum.
The cable must not wrap over itself on the drum, but should be wrapped as close as possible to each previous
wrap, see figure 10.
Figure 10. Cable Installation & Wrap
Drop Installation
1. Attach a 3004 Pulley to each hook.
2. Thread the end of the 3/32" cable through the pulley toward the winch. Clamp this end to the 3/16" winch
cable about 6" (150 mm) from the pulley, using a 3/16" cable clamp, see figure 6.
3. Cut the cable long enough to allow for installation to the feeder line and to the Adjustment Leveler.
Sufficient cable is included to provide "throwbacks" on drops located beneath and near the winch. See
Figure 3 (on page 13), Detail D shows a "throwback" cable arrangement.
4. Begin installing suspension drops at the winch and proceed to the ends of the feeder line.
Keep the main cable tight between drops. It may be necessary to hang a weight on the end of the main cable
to maintain tension.
Direction of Drum
Rotation

Adult Turkey Feeder, MODEL ATF™ Hopper Assembly Procedure
MF232Q 17
The 150 lb. Hopper Assembly is NOT designed for single-point suspension. The upper cross brace is designed
for supporting the drop tube ONLY. This Hopper Assembly is to have Two-point suspension as stated.
Assembly
1. Assemble the 1/4-20 x 1-1/2" bolt to the brace with two
1/4-20 nuts. One nut should be assembled under the
brace with the other on top. This bolt is to provide a
place for the tube support assembly chain to be hooked,
see figure 11.
2. Assemble the 150 lb. hopper halves and brace as shown
in Figure 11, using #14 x 5/8" screws (supplied in
hardware package).
3. Assemble suspension angles and suspension braces
around feeder line boot (single or twin), using 1/4-20 x
1/2" Hex bolts and nuts (supplied in hardware package),
see figure 12.
Note: The larger holes on the ends of the suspension
angles need to be on the upper side of the
assembly.
4. Assemble the twist lock collar to the top of the
feeder line boot (single or twin) using 1/4-20 x
1/2" bolts and lock nuts (supplied in hardware
package), see figure 12.
5. Assemble the adjustment brackets to the
suspension angles with 5/16-18 x 3/4" bolts and
nuts (supplied in hardware package).
6. Two cable assemblies (cable with a sleeve clamp
and a 5/32 thimble) are supplied with the
suspension kit to support the hopper. Attach the
cable assemblies to the adjustment brackets
using the top holes of the adjustment brackets,
see figure 12.
7. Install two pulleys to either a 2" x
8" [50x200 mm] board that will
span at least 3 rafters or a 3/8" [9.5
mm] thick steel plate welded to two
pieces of angle iron that are long
enough to span at least 2 rafters.
Install the pulleys directly above
the feeder line where the hopper is
to be located. The pulleys should
be spaced 22" apart (11" from the
center of the hopper in both
directions), see figure 13.
Suspend the Hopper
1. Attach the boot to the feeder line.
2. Route the two cable assemblies up and around the pulleys.
3. Level the boot with the feed line and clamp the cables to the main cable using 1 cable clamp per cable
assembly.
4. Place the hopper on top of the twist lock collar and rotate the hopper 90 degrees into position.
Make sure the cables lay in the channels on the sides of the hopper for support.
Hopper Assembly Procedure
Figure 11.
Figure 12.
Figure 13.

Feeder Assembly Adult Turkey Feeder, MODEL ATF™
18 MF232Q
MODEL ATF™ Feeding System
1. Attach one Swing Down Pan Support and three regular Pan Supports to the Pan Shield using rivets supplied.
Always attach the Swing Down Pan Support at the sam location on all pan shields. It will be necessary to
support the Pan Shield while installing the rivets. Use a hammer to drive rivets as shown in Figure 14.
Figure 14. Pan Shield Assembly
2. Determine which Feeder Pan (Adult Turkey or Stage II) is to be installed, see figure 15. Refer to appropriate
assembly section.
The basic assembly and installation of the Stage II Feeder is the same as the Adult Turkey Feeder. The two
primary differences being; 1) the feeder pan design, and 2) installation of the Feed Level Tube.
Figure 15. Feeder Pans
Stage II Feeder Assembly
Assemble the Feed level Tube & Ring with
the arrow pointing DOWN, when the
Stage II Pan is used, see figure 16.
The Feed Level Ring Should be positioned
in the second hole from the top fro Stage II
Feeder Pans. Note the direction of the
arrow.
Feeder Assembly
Figure 16. Stage II Feed Level Ring

Adult Turkey Feeder, MODEL ATF™ Feeder Assembly
MF232Q 19
Adult Turkey Feeder Assembly
• Assemble the Feed Level Tube and Feed
Level Ring as shown in Figure 17.
• Note the direction of the arrow on the side of
the Feed Level Tube.
• Position the Feed Level Ring in the third
hole from the bottom for the Plastic Adult
Turkey Feeder Pan.
• Position the Feed Level Ring in the fourth
hole from the top for the steel Adult Turkey
Feeder Pan, see figure 17.
3. If the Feed Level Tubes are to be winch
adjustable, install the Cable Assemblies at
this point. If the Feed Level Tubes are not to
be winchable proceed to step 4.
Before installing the cable assemblies a 90
degree bend needs to be put in the cable
to keep all the feed level tube assemblies at a uniform height. To do this take a pair of needle nose pliers
and grab the cable behind the cable stop. Now bend the cable over the pliers back onto itself, see figure 18.
Figure 18. Cable
Install two cables at each feed level tube, as shown in Figure 19. The cable stop should be located on the inside
of the Feed Level Tube and pulled up tight against the inside.
NOTE: After the feeder operates, re-adjustment of the Feed Level Tubes may be desired to achieve the
desired feed level.
Figure 19. Cable Installation
4. Place the Feed Level Tube Assembly in the Feeder Pan.
Figure 17. Adult Turkey Feeder Feed Level Ring

Feeder Assembly Adult Turkey Feeder, MODEL ATF™
20 MF232Q
5. Insert the Drop Tube into the Feed Level Tube Assembly, see figure
20. Install the pan shield supports in the slots in the drop tube.
6. With the bottom of the pan up, hook the swing down pan support.
Then rotate the pan down to hook the remaining pan supports over
the lip of the pan.
Do not bend the Pan Supports during assembly.
Feeder Tube Assembly
1. Slide one Pan Assembly onto the Feeder Tube for each outlet hole. Lift the Drop Tube through the Pan
Shield so the Feeder Tube can slide through the holes in the sides of the Droop Tube. Install the Pan
Assemblies so all the Swing Down Supports are on the same side to the feeder line.
2. Rotate the feeder tube so the tab at the outlet hole will pass throughout the notch in the Drop Tube. Rotate the
tube 180 degrees to lock the pans in place, see figure 22. Make sure outlet holes are down.
3. Position the tubes with pans attached end to end in the approximate location where they will be suspended.
The belled ends of the tubes must point towards the hopper.
Figure 22. Install Feeders on Tubes
Figure 20. Drop Tube Installation
Figure 21. Swing Down Pan Support
