Chore-Time Chore-Tronics 2 User manual

Chore-Tronics®2 Breeder Edition
Override Box
MT2309BNovember 2007

CTB Inc. Warranty Override Box
2MT2309B
CTB Inc. warrants each new product manufactured by it to be free from defects in material or workmanship
for one year from and after the date of initial installation by or for the original purchaser. If such a defect is
found by the Manufacturer to exist within the one-year period, the Manufacturer will, at its option, (a) repair
or replace such product free of charge, F.O.B. the factory of manufacture, or (b) refund to the original
purchaser the original purchase price, in lieu of such repair or replacement. Labor costs associated with the
replacement or repair of the product are not covered by the Manufacturer.
Conditions and Limitations
1. The product must be installed by and operated in accordance with the instructions published by the
Manufacturer or Warranty will be void.
2. Warranty is void if all components of the system are not original equipment supplied by the Manufacturer.
3. This product must be purchased from and installed by an authorized distributor or certified representative
thereof or the Warranty will be void.
4. Malfunctions or failure resulting from misuse, abuse, negligence, alteration, accident, or lack of proper
maintenance shall not be considered defects under the Warranty.
5. This Warranty applies only to systems for the care of poultry and livestock. Other applications in industry
or commerce are not covered by this Warranty.
The Manufacturer shall not be liable for any Consequential or Special Damage which any purchaser may
suffer or claim to suffer as a result of any defect in the product. “Consequential” or “Special Damages” as
used herein include, but are not limited to, lost or damaged products or goods, costs of transportation, lost
sales, lost orders, lost income, increased overhead, labor and incidental costs and operational inefficiencies.
THIS WARRANTY CONSTITUTES THE MANUFACTURER’S ENTIRE AND SOLE WARRANTY
AND THIS MANUFACTURER EXPRESSLY DISCLAIMS ANY AND ALL OTHER WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, EXPRESS AND IMPLIED WARRANTIES AS TO
MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSES SOLD AND DESCRIPTION OR
QUALITY OF THE PRODUCT FURNISHED HEREUNDER.
CTB Inc. product Distributors are not authorized to modify or extend the terms and conditions of this
Warranty in any manner or to offer or grant any other warranties for CTB Inc. products in addition to those
terms expressly stated above. An officer of CTB, Inc. must authorize any exceptions to this Warranty in
writing. The Manufacturer reserves the right to change models and specifications at any time without notice
or obligation to improve previous models.
Effective: December 2007
CTB Inc.
P.O. Box 2000 • Milford, Indiana 46542-2000 • U.S.A.
Phone [phone] • Fax [phone]
Email: [email protected] • Internet: http//www.ctbinc.com
Thank You
The employees of CTB Inc. would like to thank your for your recent purchase. If a problem should arise, your
CTB distributor can supply the necessary information to help you.
CTB Inc. Warranty

Override Box Overview
MT2309B 3
The Chore-Tronics 2 Breeder Override Box is used to connect the Chore-Tronics 2 Breeder Edition Control
to a Weighmatic®scale system. During normal operation, the Breeder Override Box provides feedback to the
Chore-Tronics Control to inform the Control the current status of the Weighmatic®scale system. The Breeder
Override Box can also temporarily operate both the Weighmatic®scale system and feeding system if
necessary. If itisdesiredto connecttwo Weighmatic®scale systems to the Chore-Tronics®2 then two Breeder
Override boxes will be required.
The Breeder Override Box front panel consists of three toggles switches: One for the lower switch and
push button of the scale, one for the upper switch of the scale and one for manually running the feed
lines.
Normal Operation
Under normal operating conditions, all toggle switches should be in the automatic position. This will allow
the Chore-Tronics 2 Breeder Edition control to operate the Weigh Fill, Feeder Fill, and Feed Line outputs.
Please refer to the Chore-Tronics 2 Breeder Control manual for normal operation details.
Overview
Introduction to the Control
Item Description
1 Lower Switch and Push
Button Toggle Switch
2 Upper Switch Toggle
Switch
3 Feed Lines (Manual)
Figure 1. Introduction to Control
13 2
Control Operation
Toggle switches in the
Automatic Position
Figure 2. Normal Operation

Control Operation Override Box
4MT2309B
Manual Operation
Lower Switch and Push Button (Filling the weigh Bin)
To temporarily override the Chore-Tronics®control and fill the weigh bin manually, first place the Lower
Switch and Push Button toggle switch (Item 1, Figure 3) into the manual position. Set the slide bar (Item 2)
on the scale to the desired amount of feed and press the push button on the Weigh Scale Beam (Item 3) to
begin filling the weigh bin. When all the feed is in the bin, Return the switch to the automatic position. This
will return Control of the weigh system back to the Chore-Tronics®Control.
Figure 3. Manual Operation
Return Toggle Switch to the Auto position when feed is delivered
1
Step 1. Set Toggle Switch to the Manual Position
Step 2. Set Slide Bar to desired feed amount and
Step 3. Set the Toggle Switch back to Auto when feed is all in the Weigh Bin
2
Item Description
1 Lower Switch and Push
Button Toggle Switch
2 Slide Bar
3 Push Button on Weigh
Scale Beam
1Set "Lower Switch and Push Button
Toggle Switch" to the Manual position.
press the Push Button
3

Override Box Control Operation
MT2309B 5
Upper Switch (Delivering Feed to House)
To temporarily override the Chore-Tronics®Control to deliver feed into the house, first set the slide bar (Item
1, Figure 4) to the amount of feed desired to be delivered to the house. Then move the Upper Switch Toggle
switch (Item 2) to the manual position. When all of the feed has been delivered to the house return the switch
to the automatic position. This will return control of the Feeder fill system backto the Chore-Tronics®Control.
Feed Line (Operate Feed Lines)
To temporarily operate the feed lines from the Breeder Override Box, press and hold the Feeder line toggle
switch (Item 1, Figure 5) in the manual position. When the toggle switch is released the feed lines will turn
off..
1
Figure 4. Upper Switch Operation
Step 2. Set Toggle Switch to the Manual Position
2
Step 1. Set Slide Bar to desired feed amount
Step 3. Set the Toggle Switch back to Auto when feed is delivered
Item Description
1 Upper Switch Toggle Switch
2 Slide Bar
2
1
Item Description
1 Feedline Toggle Switch
Figure 5. Feeline Operation

Wiring Override Box 6MT2309B
Wiring to Chore-Tronics Control and Weighmatic Scale
The three digital input terminals must be connected to the Chore-Tronics®2 Controls using twisted pair wire (part no. 42208). Failure to do so could result
in improper operation of the feeding system.
Wiring
DI1 12V DI2 DI3 DI412V
DI5 12V DI6 DI7 DI812V
CT 2 DIGITAL IN
FEED
CLOCK
RELAY
M. SCALE FILL RELAY (WEIGH FILL)
FILL CLOCK RELAY (FEEDER FILL
)
GROUND
Figure 6. Wiring to Chore-Tronics Control
EXTERNAL WIRING TERMINAL 1
1L1Supply
2L2Supply
3 Upper Switch Out
Scale Wiring
4 Upper Switch Return
5 Lower Switch Return
6 Push Button Return
7L1Common
8 To Control (Feeder Fill Relay)
9 From Control (Feeder Fill Relay)
10 To Weigh Fill Relay
11 From Weigh Fill Relay
EXTERNAL WIRING TERMINAL 2
1 To Control Feeder Line Relay
2 From Control Feeder Line Relay
3
4
5
6
7 Upper Switch
8 Upper Switch C-Tronics
D1 Wiring
9 Lower Switch
10 Lower Switch
11 Push Button
12 Push Button

Override Box Wiring MT2309B 7
Wiring to Weigh Bin, Fill System, and Feed Line Motors
M1
WEIGH BIN FILL MOTOR
3/4 HP, 230V, 1 PHASE
25697 SAFETY SWITCH
(SL)
ADDITIONAL CONTACTOR FOR
FEEDER LINE POWER UNITS
REQUIRED IF TOTAL HP IS
GREATER THAN 2 HP. (NOT SUPPLIED)
L1
L2
25694 JUNCTION BOX
ASSEMBLY
123456
M2
L1
L2 HOPPER
FILL MOTOR
1 HP, 230 V
1 PHASE
UPPER HOPPER
LEVEL CONTROL
(S5)
6500 CONTROL UNIT
L1
L2
L1
L2
L1
L2 F. FILL
RELAY FEED LINE RELAY
W. FILL
RELAY
123456789101112
JUMPER TO BE
INSTALLED IN
FIELD
123456789101112
240vac
SUPPLY
GROUND
Figure 7. Wiring to Weigh Bin

Wiring Override Box 8MT2309B
Breeder Override Box Internal Wiring
8
75 611
910 12 4
123
5
6
8
7
2
4
3
1
9
12
11
10
LID SWITCHES
Figure 7. Internal Wiring
EXTERNAL WIRING TERMINAL 2
1 To Control Feeder Line Relay
2 From Control Feeder Line Relay
3
4
5
6
7 Upper Switch
8 Upper Switch C-Tronics
D1 Wiring
9 Lower Switch
10 Lower Switch
11 Push Button
12 Push Button

Override Box Part Numbers
MT2309B 9
Part Numbers
Item Description Part No.
1 Toggle Switch 6014
2 Control Box Latch 30862
3 Control Box Latch Pivot 30863
4 SPDT 220 VAC Relay 34702
5 Neoprene Seal 34767
6 12 Pole Terminal Strip 34925
7 DPDT Toggle Switch 50699
8 Breeder Overide Box Lid 51064
9 Control Box 30860-3
10 Breeder Override Base Plate 51043
11 DPST 200/400V Coil Relay 34654
Figure 8. Part Numbers
7
1
2
3
5
8
9
10
11
6
4

Part Numbers Override Box
10 MT2309B
Note: The original, authoritative version of this manual is the [English] version produced by
CTB, Inc. or any of its subsidiaries or divisions, (hereafter collectively referred to as "CTB").
Subsequent changes to any manual made by any third party have not been reviewed nor
authenticated by CTB. Such changes may include, but are not limited to, translation into
languages other than [English], and additions to or deletions from the original content. CTB
disclaims responsibility for any and all damages, injuries, warranty claims and/or any other
claims associated with such changes, inasmuch as such changes result in content that is different
from the authoritative CTB-published [English] version of the manual. For current product
installation and operation information, please contact the customer service and/or technical
service departments of the appropriate CTB subsidiary or division. Should you observe any
questionable content in any manual, please notify CTB immediately in writing to: CTB Legal
Department, P.O. Box 2000, Milford, IN 46542-2000 USA.
Revisions to this Manual
Page No. Description of Change
6 Corrected Relay Info.
