MircroTiles LED status
system
This guide contains information about the values and fault conditions that can be reported by the
status system for the wall controllers on MircroTiles LED devices.
The wall controller status system is accessible through both the web user interface and the Christie
serial protocol Ethernet port 3002. The Octroller status system is not accessible through the serial
protocol. Therefore, the wall controller status system contains status items specific to the wall
controller as well as entire system status entries.
For example, if an Octroller has a temperature warning, it sets its temperature status to a warning
state and the Octroller LED blinks yellow. The wall controller monitors the overall temperature status
of all devices in the system and when it sees this warning, it sets a system temperature warning (SST
+SYST 176). From the wall controller web user interface the status of the Octrollers can be viewed to
find the one with an issue.
The status system provides an overview of the device at the current point in time. It contains a
number of groups, which contain a set of status items. Each status item represents a component or
sub-component of the system. Obtain specific details regarding a warning or error for a status item
using the log system.
The numbers next to the status items in this guide correspond directly to the status item index within
each group.
Product documentation
For installation, setup, and user information, see the product documentation available on the Christie
website. Read all instructions before using or servicing this product.
1. Access the documentation from the Christie website:
• Go to this URL: http://bit.ly/2DE9cnu or
https://www.christiedigital.com/en-us/digital-signage/products/led-tiles/microtiles-led.
• Scan the QR code using a QR code reader app on a smartphone or tablet.
2. On the product page, select the model and switch to the Downloads tab.
MicroTiles LED Technical Reference–Status System 4
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Related documentation
Additional information on this product is available in the following documents.
•MicroTiles LED Product Safety Guide (P/N: 020-102824-XX)
•MicroTiles LED Installation and Setup Guide (P/N: 020-102825-XX)
•MicroTiles LED User Guide (P/N: 020-102835-XX)
•MicroTiles LED Specifications Guide (P/N: 020-102836-XX)
•MicroTiles LED Serial Commands Guide (P/N: 020-103050-XX)
•Replacing LED modules in a MicroTiles LED array (P/N: 020-103059-XX)
•Removing the MicroTiles LED chassis (P/N: 020-102670-XX)
•
Status system states
The status system has three states to indicate the health of the device.
OK No known issue
Warning A problem with this item should be addressed.
Error A problem with this item prevents the system from properly
displaying video or turning on the system.
Wall controller status system items
The following sections provide the status system items for the wall controllers.
Configuration Group (SST+CONF?)
The Configuration group provides values and fault conditions for configuration-related items for the
wall controller.
# Status State Value Description
0 Device Model <model> Displays the device specific model information.
Unknown Cannot read the device model.
Not Specified Indicates no device model information is
available.
1 Device S/N <serial number> Displays the serial number of the device.
Unknown Invalid or no serial number information is
available.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 5
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
3 Device Build Date <YYYY>/<MM>/<DD> Displays the build date of the device.
Unknown Invalid or no build date information is
available.
System Group (SST+SYST?)
The System group provides values and fault conditions relating to the system and its health for the
wall controller.
# Status State Value Description
9 Built-In Self Test N/A The built-in self test has not been
executed yet.
PASS The built-in self test completed
successfully.
FAILED The built-in self-test did not complete
successfully.
10 System ID Board OK Properly detected and initialized the
board.
Communication Fault Cannot communicate with the board.
Invalid Data The information on the board is
missing or corrupted.
12 Keypad Display Auto Detect The system is attempting to detect
the presence of the keypad display.
Programming Programming the keypad display with
the correct firmware.
OK Properly detected and initialized the
keypad display.
Detection Fault Cannot detect the keypad display.
Unexpected Behavior The keypad display is not responding
correctly.
30 Main Control Board OK The main control board has been
initialized at least once and is known
to be OK.
Initialization Fault Cannot successfully initialize the
main control board.
118
119
QSFP+0
QSFP+1
OK (Active) The QSFP connection for port 0 is
present.
OK (Copper) The Copper QSFP connection for port
0 is present.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 6
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
OK (Unknown) An unknown type of QSFP connection
for port 0 is present.
Not Present Cannot detect the QSFP connection
for port 0.
Link Down Cannot detect a device on the other
end of the QSFP connection on port
0.
Device Error The QSFP connection on port 0
experienced a device error with an
active signal.
Disabled The QSFP connection was manually
disabled.
Auto Disabled The QSFP connection was disabled
due to generic communication errors.
Auto Disabled (Link
Toggle)
The QSFP connection was disabled
due to the link toggle communication
errors.
Auto Disabled (Error
Toggle)
The QSFP connection was disabled
due to error toggle communication
errors.
Auto Disabled (Bad Cable) The QSFP connection was disabled
due to a bad cable.
120 Network Topology Closed Indicates the system array is in a
closed loop configuration.
Open Indicates the system array is in an
open loop configuration.
121 Showing Secondary Wall
Controller
N/A Cannot detect any Octrollers in the
system.
No The system is not showing the video
from the secondary wall controller.
Yes An Octroller in the system is showing
the video from the secondary wall
controller.
122 Primary Wall Controller OK Indicates the current configuration
has only one primary LED wall
controller.
Missing Cannot detect a primary LED wall
controller in the current
configuration.
Two Primary Detects more than one primary LED
wall controller in the current
configuration.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 7
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
123 Wall Controller Count <number> Displays the number of LED wall
controllers connected in the current
configuration.
124 Octroller Count <number> Displays the number of Otrollers
connected in the current
configuration.
125 Tile Count <number> Displays the number of tiles
connected in the current
configuration.
142 Wall Power On All connected tiles are powered on.
Off All connected tiles are powered off.
143 Pixel Pitch <value> value = Pixel pitch of the system
Indicates the pixel pitch is OK and
matches across the system.
Unknown Cannot determine the pixel pitch
information.
Mismatch Indicates the pixel pitch is
mismatched in the system and the
system is not designed to operate
like this.
146 SDVOE IP Address <IP address> Displays the SDVOE IP address.
Unknown Cannot determine the SDVOE IP
address.
175 Power Consumption <power>W Displays the system power
consumption in Watts.
N/A The power consumption of the
system is currently not available.
176 System Temperature OK Indicates all device temperatures are
OK.
Warning Indicates some device temperatures
are in a warning state.
Critical Fault Indicates some device temperatures
are at a critical fault.
The device may automatically shut
down if a critical fault occurs. To
return to regular operation, the
device must be manually restarted.
201 LED Series <series> Displays the LED series name.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 8
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
Unknown Cannot identify any LED modules.
Mismatch Detects more than one LED series in
the system.
203 Ambient Brightness <value> Displays the value in lux from the
ambient light sensor or N/A when not
connected.
Multiple ambient light
sensors found
Indicates more than one ambient
light sensor is connected to the
system.
Error reading from ambient
light sensor
Indicates an error reading from the
ambient light sensor
.
205 Calibration Data OK All LED modules have calibration.
Mixed (v1.1/v1.2) All LED modules have calibration data
but multiple compatible versions
have been found.
Missing Calibration Data Some LED modules do not have
calibration data.
Sensor Not Connected Indicates no sensor is present.
Signal Group (SST+SIGN?)
The Signal group provides values and fault conditions relating to the video signal status for the wall
controller.
# Status State Value Description
1
2
3
4
5
6
7
8
9
DP 1
DP 2
HDMI 1
HDMI 2
SDI 1
SDI 2
SDI 3
SDI 4
SDVOE
<signal> Displays the signal specific information for the
signal.
Unavailable The signal is not available.
No Signal There is no signal.
52 3D Sync Valid 3D Sync Indicates a valid external 3D sync signal.
Internal 3D Sync Indicates 3D mode where no external sync is
required.
N/A Indicates no input signal or not a 3D mode.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 9
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
Invalid 3D Sync An external 3D sync signal exists but it is not
correct.
No 3D Sync The 3D sync is missing.
54 Showing Redundant
Input
No The wall controller is not showing the redundant
input.
Yes The wall controller is showing the redundant
input.
Version Group (SST+VERS?)
The Version Group provides values and fault conditions related to software and hardware versions for
the wall controller.
# Status State Value Description
0 Main Control Board SW Version <version> Displays the software version running on the
main control board.
Unknown Cannot determine the software version
information.
1 Main Control Board HW Version <version> Displays the hardware version for the main
control board.
19 Keypad Display HW Version <version> Displays the hardware version for the keypad
display.
Unknown Cannot retrieve the hardware version as the
board is not ready.
65 Wall Controller Software
Versions
<version> Displays the software version for all the wall
controllers.
N/A The software version for all the wall controllers
is not available.
Mismatch A software version mismatch exists in the
connected system wall controllers.
66 Octroller Software Versions <version> Displays the software version for all the
Octrollers.
N/A The software version for all the Octrollers is not
available.
Mismatch A software version mismatch exists in the
connected system Octrollers.
67 Tiles Software Versions <version> Displays the software version for specified tiles.
N/A The software version for the specified tiles is
not available.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 10
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
Mismatch A software version mismatch exists in the
connected system.
70 System Level Versions <version> Displays the software version for all system
components.
N/A The software version for the system level
software is not available.
Mismatch A software version mismatch exists in the
connected components (wall controllers and
Octrollers).
Temperature Group (SST+TEMP?)
The Temperature Group provides values and fault conditions for temperature-related items for the wall
controller.
# Status State Value Description
4 Main Control Board Temperature OK Indicates the temperature of the main
control board is OK.
Unknown Cannot determine the temperature of
the main control board.
Warning The temperature of the main control
board has reached warning values.
Critical Fault The temperature of the main control
board has encountered a critical fault.
129
130
QSFP+0
QSFP+1
<value> Indicates the temperature of the
installed QSFP+ module.
Unknown The installed module does not support
temperature readings.
N/A No module is installed.
Warning The QSFP+ temperature has reached
warning values (v1.3.4 or higher).
Critical Fault The QSFP+ temperature has
encountered a critical fault (v1.3.4 or
higher).
Cooling Group (SST+COOL?)
The Cooling Group provides values and fault conditions related to fans for the wall controller.
# Status State Value Description
0 Intake (Fan 3) <tach> RPM Display the RPM of the intake fan.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 11
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
Unknown Cannot determine the RPM of the intake fan.
0 RPM Indicates the fan speed is too low.
51 Main Control Board Blower <tach> RPM Display the RPM of the main control board
blower
.
Unknown Cannot determine the RPM of the main control
board blower
.
0 RPM Indicates the blower speed is too low.
Serial Group (SST+SERI?)
The Serial Group provides values and fault conditions related to hardware serial numbers for the wall
controller.
# Status State Value Description
0 Main Control Board S/N <serial number> Displays the electronic serial number
of the main control board.
Missing Serial Number Cannot retrieve the value because the
serial number of the board is missing.
Octroller status system items
The following sections provide the status system items for the Octroller.
Octroller status items cannot be retrieved through the serial port or Ethernet port 3002. However, they
can be viewed in the wall controller web user interface. Only the wall controller status system is
accessible through the Christie serial protocol.
System Group (SST+SYST?)
The System group provides values and fault conditions relating to the system and its health for the
Octroller.
# Status State Value Description
9 Built-In Self Test N/A The built-in self test has not been
executed yet.
PASS The built-in self test completed
successfully.
FAILED The built-in self-test did not complete
successfully.
10 System ID Board OK Properly detected and initialized the
Octroller board.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 12
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
Communication Fault Cannot communicate with the
Octroller board.
Unknown The information on the Octroller
board is unknown.
30 Main Control Board OK The main control board has been
initialized at least once and is known
to be OK.
Bad PoE Power Source
Device (PSE)
The main control board has a bad
PoE (Power over Ethernet) power
source device.
PoE Power Source Device
Too Hot
The main control board PoE (Power
over Ethernet) power source device
is too hot
Bad PoE Supply Voltage xV The main control board PoE (Power
over Ethernet) has a bad supply
voltage.
Initialization Fault Cannot successfully initialize the
main control board.
97
98
99
100
101
102
103
104
Port0
Port1
Port2
Port3
Port4
Port5
Port6
Port7
OK The tile in port is OK.
Not detected The tile in port is not detected.
Communication Fault The tile in port encountered a
communication fault.
105
106
107
108
109
110
111
112
Port 0 Link Speed
Port 1 Link Speed
Port 2 Link Speed
Port 3 Link Speed
Port 4 Link Speed
Port 5 Link Speed
Port 6 Link Speed
Port 7 Link Speed
Full Speed The port is operating at full speed.
Down The port is down (the tile is not
connected).
Full Speed not reached;
check connection
The port is working but not at full
speed.
118
119
QSFP+0
QSFP+1
OK The QSFP connection for the port is
present.
Not Present The QSFP connection for the port is
not present.
Link Down The QSFP connection on the port has
no device at the other end.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 13
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
Device Error The QSFP connection on the port ran
into a device error with an active
signal.
Auto Disabled The QSFP connection was disabled
due to link/error toggle
communication errors.
126
127
128
129
130
131
132
133
MOSFET on port 0
MOSFET on port 1
MOSFET on port 2
MOSFET on port 3
MOSFET on port 4
MOSFET on port 5
MOSFET on port 6
MOSFET on port 7
OK The MOSFET is operating as
expected.
Error The MOSFET has experienced an
error
.
134
135
136
137
138
139
140
141
Port 0 current threshold
Port 1 current threshold
Port 2 current threshold
Port 3 current threshold
Port 4 current threshold
Port 5 current threshold
Port 6 current threshold
Port 7 current threshold
OK The current threshold for the port is
OK.
Error The current threshold for the port
has been exceeded.
143 Pixel Pitch <value>mm-Pixel Pitch The pixel pitch is OK and matches
across the Octroller
.
Unknown The pixel pitch information is
unknown.
Mismatch The pixel pitch is mismatched in the
system.
147
148
149
150
151
152
153
154
155
156
157
158
159
Port 0 Module 0
Port 0 Module 1
Port 0 Module 2
Port 1 Module 0
Port 1 Module 1
Port 1 Module 2
Port 2 Module 0
Port 2 Module 1
Port 2 Module 2
Port 3 Module 0
Port 3 Module 1
Port 3 Module 2
Port 4 Module 0
OK The module has been detected with
no errors.
Not Detected Cannot detect the module.
Pixel Data Missing The module is missing the pixel data.
Colour Data Missing The module is missing the color data.
Pixel and Colour Data
Missing
The module is missing the color and
pixel data.
Manufacturer Missing The module is missing the
manufacturer information.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 14
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
160
161
162
163
164
165
166
167
168
169
170
Port 4 Module 1
Port 4 Module 2
Port 5 Module 0
Port 5 Module 1
Port 5 Module 2
Port 6 Module 0
Port 6 Module 1
Port 6 Module 2
Port 7 Module 0
Port 7 Module 1
Port 7 Module 2
Type Missing The module is missing the type
information.
Serial Missing The module is missing its serial
number
.
171 Octroller Tile Count <number of Tiles
connected>
Indicates the number of tiles
connected to the Octroller
.
Unknown The number of tiles connected to the
Octroller is unknown.
172 Octroller Module Count <number of LED modules
connected>
Indicates the number of LED modules
connected to the Octroller
.
Unknown The number of LED modules
connected to the Octroller is
unknown.
173 Octroller Supply Voltage <supply voltage>V Indicates the Octrollers supply
voltage in Volts.
N/A The Octrollers supply voltage is
currently not available.
174 Power Consumption <number consumption>W Indicates the total Octroller power
consumption in Watts.
N/A The total power consumption is
currently not available.
177
178
179
180
181
182
183
184
185
186
187
188
189
Port 0 Module 0 Run Time
Port 0 Module 1 Run Time
Port 0 Module 2 Run Time
Port 1 Module 0 Run Time
Port 1 Module 1 Run Time
Port 1 Module 2 Run Time
Port 2 Module 0 Run Time
Port 2 Module 1 Run Time
Port 2 Module 2 Run Time
Port 3 Module 0 Run Time
Port 3 Module 1 Run Time
Port 3 Module 2 Run Time
Port 4 Module 0 Run Time
<number> mins Indicates the run time in minutes.
N/A The run time is not available.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 15
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
190
191
192
193
194
195
196
197
198
199
200
Port 4 Module 1 Run Time
Port 4 Module 2 Run Time
Port 5 Module 0 Run Time
Port 5 Module 1 Run Time
Port 5 Module 2 Run Time
Port 6 Module 0 Run Time
Port 6 Module 1 Run Time
Port 6 Module 2 Run Time
Port 7 Module 0 Run Time
Port 7 Module 1 Run Time
Port 7 Module 2 Run Time
201 LED Series <series> Indicates the LED series, where
series = the LED series name
S60(P3)/S40(NTSC).
Unknown Did not identify any LED modules.
Mismatch More than one LED series are
detected on the Octroller
.
213 Custom Configuration Files OK All module configuration files are not
corrupted.
Corrupted Files At least one of the module
configuration files is corrupted.
Signal Group (SST+SIGN?)
The Signal group provides values and fault conditions relating to the video signal status for the
Octroller.
# Status State Value Description
54 Showing Secondary
Wall Controller
No The Octroller is not displaying the video signal
from the secondary wall controller.
N/A The array detects only one wall controller.
Yes the Octroller is showing the video signal from the
secondary wall controller .
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 16
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Temperature Group (SST+TEMP?)
The Temperature Group provides values and fault conditions for temperature-related items in the
Octroller .
# Status State Value Description
4 Main Control Board Temperature OK Indicates the temperature of the main
control board is OK.
Unknown Cannot determine the temperature of
the main control board.
Warning The temperature of the main control
board has reached warning values.
Critical Fault The temperature of the main control
board has encountered a critical fault.
82 Port 0 FPGA die Temperature OK Indicates the temperature of the port
FPGA is OK.
Unknown Cannot determine the temperature of
the port FPGA.
Warning The temperature of the port FPGA has
reached warning values.
Critical Fault The temperature of the port FPGA has
encountered a critical fault.
83
84
85
Port 0 LED Module 0 Temperature
Port 0 LED Module 1 Temperature
Port 0 LED Module 2 Temperature
OK Indicates the module temperature is
OK.
Unknown Cannot determine the temperature of
the module.
Warning The temperature of the module has
reached warning values.
Critical Fault The temperature of the module has
encountered a critical fault.
86 Port 1 FPGA die Temperature OK Indicates the temperature of the port
FPGA is OK.
Unknown Cannot determine the temperature of
the port FPGA.
Warning The temperature of the port FPGA has
reached warning values.
Critical Fault The temperature of the port FPGA has
encountered a critical fault.
87
88
89
Port 1 LED Module 0 Temperature
Port 1 LED Module 1 Temperature
Port 1 LED Module 2 Temperature
OK Indicates the module temperature is
OK.
Unknown Cannot determine the temperature of
the module.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 17
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
Warning The temperature of the module has
reached warning values.
Critical Fault The temperature of the module has
encountered a critical fault.
90 Port 2 FPGA die Temperature OK Indicates the temperature of the port
FPGA is OK.
Unknown Cannot determine the temperature of
the port FPGA.
Warning The temperature of the port FPGA has
reached warning values.
Critical Fault The temperature of the port FPGA has
encountered a critical fault.
91
92
93
Port 2 LED Module 0 Temperature
Port 2 LED Module 1 Temperature
Port 2 LED Module 2 Temperature
OK Indicates the module temperature is
OK.
Unknown Cannot determine the temperature of
the module.
Warning The temperature of the module has
reached warning values.
Critical Fault The temperature of the module has
encountered a critical fault.
94 Port 3 FPGA die Temperature OK Indicates the temperature of the port
FPGA is OK.
Unknown Cannot determine the temperature of
the port FPGA.
Warning The temperature of the port FPGA has
reached warning values.
Critical Fault The temperature of the port FPGA has
encountered a critical fault.
95
96
97
Port 3 LED Module 0 Temperature
Port 3 LED Module 1 Temperature
Port 3 LED Module 2 Temperature
OK Indicates the module temperature is
OK.
Unknown Cannot determine the temperature of
the module.
Warning The temperature of the module has
reached warning values.
Critical Fault The temperature of the module has
encountered a critical fault.
98 Port 4 FPGA die Temperature OK Indicates the temperature of the port
FPGA is OK.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 18
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
Unknown Cannot determine the temperature of
the port FPGA.
Warning The temperature of the port FPGA has
reached warning values.
Critical Fault The temperature of the port FPGA has
encountered a critical fault.
99
100
101
Port 4 LED Module 0 Temperature
Port 4 LED Module 1 Temperature
Port 4 LED Module 2 Temperature
OK Indicates the module temperature is
OK.
Unknown Cannot determine the temperature of
the module.
Warning The temperature of the module has
reached warning values.
Critical Fault The temperature of the module has
encountered a critical fault.
102 Port 5 FPGA die Temperature OK Indicates the temperature of the port
FPGA is OK.
Unknown Cannot determine the temperature of
the port FPGA.
Warning The temperature of the port FPGA has
reached warning values.
Critical Fault The temperature of the port FPGA has
encountered a critical fault.
103
104
105
Port 5 LED Module 0 Temperature
Port 5 LED Module 1 Temperature
Port 5 LED Module 2 Temperature
OK Indicates the module temperature is
OK.
Unknown Cannot determine the temperature of
the module.
Warning The temperature of the module has
reached warning values.
Critical Fault The temperature of the module has
encountered a critical fault.
106 Port 6 FPGA die Temperature OK Indicates the temperature of the port
FPGA is OK.
Unknown Cannot determine the temperature of
the port FPGA.
Warning The temperature of the port FPGA has
reached warning values.
Critical Fault The temperature of the port FPGA has
encountered a critical fault.
107
108
Port 6 LED Module 0 Temperature
Port 6 LED Module 1 Temperature
OK Indicates the module temperature is
OK.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 19
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

# Status State Value Description
109 Port 6 LED Module 2 Temperature Unknown Cannot determine the temperature of
the module.
Warning The temperature of the module has
reached warning values.
Critical Fault The temperature of the module has
encountered a critical fault.
110 Port 7 FPGA die Temperature OK Indicates the temperature of the port
FPGA is OK.
Unknown Cannot determine the temperature of
the port FPGA.
Warning The temperature of the port FPGA has
reached warning values.
Critical Fault The temperature of the port FPGA has
encountered a critical fault.
111
112
113
Port 7 LED Module 0 Temperature
Port 7 LED Module 1 Temperature
Port 5 LED Module 2 Temperature
OK Indicates the module temperature is
OK.
Unknown Cannot determine the temperature of
the module.
Warning The temperature of the module has
reached warning values.
Critical Fault The temperature of the module has
encountered a critical fault.
129
130
QSFP+0 Temperature
QSFP+1 Temperature
<value> Indicates the temperature of the
installed QSFP module.
Unknown The installed QSFP+ module does not
support temperature readings.
N/A Indicates no module is installed.
Warning The QSFP+ temperature has reached
warning values for version 1.3.4 and
higher.
Critical Fault The QSFP+ temperature has
encountered a critical fault for version
1.3.4 and higher.
MircroTiles LED status system
MicroTiles LED Technical Reference–Status System 20
020-103556-01 Rev. 1 (07-2022)
Copyright © 2022 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
