Christie CA20-AC Assembly instructions

Installation and Setup Guide
020-103456-02
CounterAct

NOTICES and SOFTWARE LICENSING AGREEMENT
COPYRIGHT AND TRADEMARKS
Copyright © 2021 Christie Digital Systems USA Inc. All rights reserved.
All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
GENERAL
Every effort has been made to ensure accuracy, however in some cases changes in the products or availability could occur which may not be reflected in this
document. Christie reserves the right to make changes to specifications at any time without notice. Performance specifications are typical, but may vary
depending on conditions beyond Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on
information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied
warranties of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or consequential damages in connection
with the performance or use of this material. Manufacturing facilities in Canada and China are ISO 9001 certified.
For the most current technical documentation and office contact information, visit http://www.christiedigital.com.
Warranty
Products are warranted under Christie’s standard limited warranty, the details of which are available at https://www.christiedigital.com/help-center/
warranties/ or by contacting your Christie dealer or Christie.
PREVENTATIVE MAINTENANCE
Preventative maintenance is an important part of the continued and proper operation of your product. Failure to perform maintenance as required, and in
accordance with the maintenance schedule specified by Christie, will void the warranty.
ENVIRONMENTAL
The product is designed and manufactured with high-quality materials and components that can be recycled and reused. This symbol means that electrical
and electronic equipment, at their end-of-life, should be disposed of separately from regular waste. Please dispose of the product appropriately and according
to local regulations. In the European Union, there are separate collection systems for used electrical and electronic products. Please help us to conserve the
environment we live in!
SOFTWARE LICENSING AGREEMENT
1. Agreement: This Software License Agreement (the “Agreement”) is a legal agreement between the end user, either an individual or business entity,
(“Licensee”) and Christie Digital Systems USA, Inc. (“Christie”) for the software and firmware that accompanies this Agreement and/or is installed in Christie
CounterAct™ products that Licensee has purchased along with related software components, which may include associated media, printed materials and online
or electronic documentation that may be provided by or for Christie to Licensee (all such software and materials are referred to herein, collectively, as
“Software”). If Licensee does not accept the terms of this Agreement, Licensee will return the Christie CounterAct™ products and Software to Christie in
accordance with Christie’s standard return policy in place from time to time. BY DOWNLOADING, INSTALLING, ACTIVATING OR USING THE SOFTWARE, THE
LICENSEE IS AGREEING TO BE BOUND BY THE TERMS OF THIS AGREEMENT.
2. Third-Party Software: The Software may contain third party software programs which require notices and/or additional terms and conditions. Such
required third party notices and/or additional terms and conditions are located in the Software settings screen under “About” – “License”. By accepting this
Agreement and using the Software, you are also accepting any such additional terms and conditions applicable to the third-party software programs. To the
extent any license for third party software programs requires an offer to provide source code for those third-party software programs, this Agreement
constitutes such an offer. You may request more information or a copy of such source code by contacting Christie at [email protected]. In
conjunction with such request, provide the Christie Product Number, the Software version and the Product Serial Number (if applicable). If applicable, a
nominal cost to cover shipping and media charges will be charged.
License and Restrictions
3. Ownership of Software: Christie retains title and ownership of all rights, including copyright and all other intellectual property rights, in and to the
Software and all copies thereof, regardless of form or media. This license is not a sale of any rights in or to the Software or any copy thereof. Licensee
acquires no right whatsoever to the Software except the right to use the Software in accordance with the terms of this License.
4. Grant of License: Christie grants to Licensee a license providing a nonexclusive and non-transferable right to use, for personal or internal business
purposes, the executable version of the Software, as long as Licensee complies with the terms and conditions of this License. Christie reserves all rights not
expressly granted to Licensee.
5. Copy Restrictions: Where the Software is provided for download onto a personal computer, server or other device, Licensee may make as many copies of
the Software as is reasonably required for Licensee’s own use with such personal computer, server or other device. Licensee may also make a backup copy of
the Software which may be used only for reinstallation of the Software. Where the Software is pre-installed in a Christie CounterAct™ product, Licensee may
keep one copy of the Software solely for backup or archival purposes. Unauthorized copying or distribution of the Software is expressly prohibited unless
agreed to in writing by Christie. Licensee must reproduce and include the copyright notice on any backup copy of the Software. Licensee may not remove or
alter any proprietary rights or copyright notice or identification which indicates the ownership of the Software.
6. Use Restrictions Licensee will not (a) modify, adapt, decompile, disassemble, reverse engineer, or otherwise attempt to derive the source code for the
Software, or create derivative works based on the Software; (b) assign this Agreement or redistribute, encumber, sell, transfer, lease, or grant a sublicense of
the Software or the license granted herein or otherwise transfer rights to the Software to any person or entity except as and when expressly permitted by this
Agreement; (c) directly or indirectly, export or transmit the Software, either alone or bundled with other software, to any country to which such export or
transmission is restricted by any applicable laws without the appropriate prior written consent of the applicable government entity or department; and (d)
publish or otherwise disclose the Software for others to copy. Licensee will make reasonable efforts to prevent any unauthorized use of the Software by third
parties and will advise Licensee’s employees of the restrictions upon use restrictions herein.
7. Upgrades and Updates: This Agreement covers any upgrades or updates to the Software that Christie, or one of its authorized vendors, may elect to
provide to Licensee, unless the upgrade or update comes with its own license agreement. If Licensee decides not to download or install an upgrade or update
provided by Christie, Licensee understands that this could put the Software at risk to serious security threats or cause the Software to become unstable. To
the extent needed for security, safety or legal reasons, Christie may, at its option, cause an upgrade or update to apply automatically.

Maintenance and Support
8. This Agreement does not provide for support and maintenance of the Software. Support and maintenance (if any) would be governed by a separate
contract between Christie and Licensee. Any supplemental software code provided to Licensee as part of the Support Services will be considered part of the
Software and subject to the terms and conditions of this Agreement.
Warranties; Limitation of Liability
9. Warranties:
a. Christie warrants that it owns or has the right to license the Software.
b. Christie warrants that its documentation (if any) provided with its Software accurately describes such Software. Licensee’s sole remedy for breach of the
foregoing representation shall be Christie’s commercially reasonable efforts to redeliver the documentation and/or the affected Software to address any
inconsistency.
c. Christie warrants that the media on which the Software is distributed will be free from defects in materials and workmanship under normal use for a
period of ninety (90) days from the date of delivery. Christie will replace any defective media returned to Christie within the ninety (90) day period.
d. The foregoing is Licensee’s sole and exclusive remedy for breach of the warranties given pursuant to this Section.
10. Limitations of Liability: Christie will not be liable for errors contained in the Software or in connection with the performance or use of the Software.
Christie does not warrant that the Software is free from any defects or that it will operate uninterrupted.
IN NO EVENT WILL CHRISTIE BE LIABLE TO ANY PARTY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, INCLUDING LOST
PROFITS, LOST REVENUES AND LOST DATA ARISING OUT OF THE USE OF THIS SOFTWARE AND ITS DOCUMENTATION, EVEN IF CHRISTIE HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
EXCEPT AS PROVIDED IN SECTION 9 OF THIS AGREEMENT, CHRISTIE SPECIFICALLY DISCLAIMS ANY WARRANTIES OR CONDITIONS, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, TITLE AND NON-
INFRINGEMENT. THE SOFTWARE AND ACCOMPANYING DOCUMENTATION, IF ANY, PROVIDED HEREUNDER IS PROVIDED “AS IS”. CHRISTIE HAS NO
OBLIGATION TO PROVIDE MAINTENANCE, SUPPORT, UPDATES, ENHANCEMENTS, OR MODIFICATIONS.
CHRISTIE FURTHER DISCLAIMS ANY AND ALL REPRESENTATIONS, WARRANTIES, OBLIGATIONS AND LIABILITIES RELATING TO THIRD-PARTY SOFTWARE
WHICH IS EMBEDDED IN THE SOFTWARE.
Some jurisdictions do not allow exclusions or limitations of certain conditions or warranties. Only those exclusions or limitations that are lawful in Licensee’s
jurisdiction will apply to Licensee and, in such instances, Christie’s liability will be limited only to the maximum extent permitted by law.
CHRISTIE SPECIFICALLY DISCLAIMS ANY WARRANTIES OR CONDITIONS, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE SOFTWARE AND ACCOMPANYING DOCUMENTATION, IF ANY, PROVIDED HEREUNDER IS
PROVIDED “AS IS”. CHRISTIE HAS NO OBLIGATION TO PROVIDE MAINTENANCE, SUPPORT, UPDATES, ENHANCEMENTS, OR MODIFICATIONS.
CHRISTIE FURTHER DISCLAIMS ANY AND ALL REPRESENTATIONS RELATING TO THIRD PARTY SOFTWARE WHICH IS EMBEDDED IN THE SOFTWARE. Some
jurisdictions do not allow exclusions or limitations of certain conditions or warranties. Only those exclusions or limitations that are lawful in Licensee’s
jurisdiction will apply to Licensee and, in such instances, Christie’s liability will be limited only to the maximum extent permitted by law.
Termination
11. Christie may terminate this Agreement at any time and for any reason. Christie may also terminate this Agreement if the Licensee breaches or is in
default of any obligation of Licensee under this Agreement. Upon termination of this Agreement, the Licensee will immediately (i) cease using the Software
and (ii) uninstall the Software from any personal computers, servers, tablets, or other devices (to the extent it is installed thereon). The Licensee's obligation
under this provision will survive the termination of this Agreement.
General
12. Notices: Unless otherwise set forth in this Agreement, all notices, or other communications hereunder will be deemed to have been duly given when
made in writing and delivered in person, by courier or deposited in the mail, postage prepaid, and registered mail, return receipt requested, and addressed to
Licensee at the billing address supplied to Christie by Licensee or such other address as Licensee may provide to Christie, and addressed to Christie at Christie
Digital Systems USA, Inc., c/o Christie Digital Systems Canada Inc. at 809 Wellington Street North, Kitchener, Ontario, Canada N2G 4Y7, Attention: Vice
President, Global Engineering, with a copy (which will not constitute notice) to Christie's Legal Department at the same address.
13. Severability and Waiver: Any provision of this Agreement which is held by any court to be unenforceable or invalid will be deemed severed from this
Agreement, without affecting any other provision of this Agreement. No waiver by Christie of any particular default or omission committed by Licensee will
affect or impair the right of Christie in respect of any subsequent default or omission of the same or a different kind. No delay or failure by Christie to exercise
any rights in connection with any default or omission committed by Licensee will affect or impair Christie's rights in respect of that particular default or
omission or any subsequent default or omission of the same or different kind. In any event, time will continue to be of the essence without the necessity of
specific reinstatement.
14. Language: This Agreement has been prepared in the English language and if a translation of this agreement is provided in any other language, such
translation is for convenience only and will not bind the parties so that only the English language version of this Agreement will be binding on the parties.
15. Governing Law: This Agreement is governed by the laws of the State of California, without regard to its conflict of law principles. Any suit or action
arising out of or in connection with this Agreement will be brought in the federal or state courts located in Orange County, State of California. Each of Licensor
and Licensee hereby irrevocably submit to the jurisdiction of such courts for the purpose of such suit or action and expressly and irrevocably waive, to the
fullest extent permitted by law, any objection it may now or hereafter have to the venue of any such suit or action in any such court and any such claim that
any suit or action has been brought in an inconvenient forum.

Content
Introduction...................................................... 6
Model names......................................................6
Product documentation................................................6
Related documentation..............................................6
Important safeguards.................................................7
Disclaimer......................................................7
Safety and warning guidelines......................................... 7
Patented Care222 UV lamp safety precautions............................... 8
Service and maintenance guidelines......................................9
Low-power radio frequency warnings.....................................9
Product labels...................................................10
CounterAct overview................................................ 12
Key features......................................................12
Technical support...................................................12
Installation and setup..............................................14
Site requirements.................................................. 14
Power requirements...............................................14
Tools and components required..........................................15
Optional accessories...............................................15
Tablet recommendations for CounterAct Configure..............................16
Getting to know your device............................................16
Product components...............................................16
Inserting the disinfecting module in the receiver box.......................... 17
Removing the disinfecting module from the receiver box........................18
Workflow: Installing and setting up CounterAct................................20
Planning the layout and power of the site....................................21
Planning the installation height........................................21
Setting the lamp mode.............................................22
Installing CounterAct Configure™.........................................23
Logging into CounterAct Configure........................................23
Logging off the CounterAct Configure application.............................24
Connecting to power................................................ 24
Removing the metal casing............................................ 26
CounterAct Installation and Setup Guide 4
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Mounting options...................................................27
Mounting requirements.............................................28
Recommended torque for screws.......................................28
Mounting receiver boxes on the ceiling surface.............................. 28
Mounting receiver boxes recessed in the ceiling with a block and hanger..............31
Mounting receiver boxes with the pendant option.............................35
Powering on the CounterAct fixture....................................... 39
LED status indicators..............................................39
Switching fixture modes............................................ 39
Setting up fixtures in CounterAct Configure.................................. 40
Creating a room................................................. 40
Adding fixtures to a room........................................... 40
Registering CounterAct.............................................42
Creating a schedule.................................................43
Verifying the optical power output ........................................43
Maintenance and service........................................... 45
Replacing the lamps.................................................45
Replacing a fixture..................................................48
Regulatory...................................................... 50
Safety......................................................... 50
Electro-magnetic compatibility.......................................... 50
Emissions..................................................... 50
Immunity..................................................... 50
Environmental.................................................... 50
Radio frequency (RF) wireless communication.................................51
Content
CounterAct Installation and Setup Guide 5
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Introduction
This manual is intended for professional UV installers. Read, follow, and save these instructions.
Model names
CounterAct consists of the following models:
• CounterAct CA20-AC
• CounterAct CA20-AU
• CounterAct CA20-D
Product documentation
For installation, setup, and user information, see the product documentation available on the Christie
website. Read all instructions before using this product.
1. Access the documentation from the Christie website:
• Go to this URL: https://bit.ly/3nuRiMG or
https://www.christiedigital.com/products/uvc-disinfection/counteract/.
• Scan the QR code using a QR code reader app on a smartphone or tablet.
2. On the product page, select the model and switch to the Downloads tab.
Related documentation
Additional information on this product is available in the following documents.
With the exception of lamp replacements, this product is not serviceable in the field and must be sent
back to Christie if servicing is required.
•CounterAct Product Safety Guide (P/N: 020-103455-XX)
•CounterAct User Guide (P/N: 020-103457-XX)
CounterAct Installation and Setup Guide 6
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Important safeguards
To prevent personal injury and to protect the device from damage, read and follow these safety
precautions.
Disclaimer
Product effectiveness and safety of UV radiation (even within the range specified by the American
Conference of Governmental Industrial Hygienists (ACGIH) or any other standard) are not guaranteed.
Christie will have no liability for the following:
• Discomfort on the skin, eyes, hair, and any other part of the human body arising from or
relating to the product
• Degradation, fading, damage, or any other changes to, or impact on, personal property
including, without limitation, surfaces, finishes, and fabrics, arising from or relating to the
product.
TO THE FULLEST EXTENT PERMITTED BY APPLICABLE LAW, CHRISTIE WILL HAVE NO LIABILITY FOR
ANY CONSEQUENTIAL, INCIDENTAL, SPECIAL, EXEMPLARY OR PUNITIVE DAMAGES, WHETHER OR
NOT CHRISTIE HAS BEEN ADVISED THAT ANY SUCH DAMAGES MAY OCCUR AND WHETHER SUCH
DAMAGES ARE CLAIMED BASED ON BREACH OF CONTRACT, BREACH OF WARRANTY, NEGLIGENCE,
STRICT LIABILITY IN TORT, OR ANY OTHER LEGAL OR EQUITABLE THEORY.
Safety and warning guidelines
Read all safety and warning guidelines before installing or operating the device.
This product must be operated in an environment that meets the operating range specification. Use
only the attachments and/or accessories recommended by Christie. Use of others may result in the
risk of fire, shock, excessive UV exposure, or personal injury.
CounterAct is a regulated pesticide device. The United States Environmental Protection Agency (EPA)
regulates pesticide devices under the Federal Insecticide, Fungicide, and Rodenticide Act (FIFRA). EPA
Establishment Numbers are noted on the label.
Any references to disinfection and disinfecting are referring generally to the reduction of pathogenic
bioburden and are not intended to refer to any specific definition of the term as may be used for other
purposes by the U.S. Food and Drug Administration or the U.S. Environmental Protection Agency.
The CounterAct device can produce small amounts of ozone during regular operation. When designing
the system, local regulations must be reviewed to ensure system compliance given the volume of the
space, characteristics of ventilation, access, and other factors.
The device may be used when humans are present but it is not intended to be used on humans, to
treat human disease, or otherwise be used as a medical device. Do not use the device for other than
the intended use.
Warning! If not avoided, the following could result in death or serious injury.
• The pathogen-reducing efficacy of Christie CounterAct products with patented Care222
technology and their use in occupied spaces is dependent on proper installation and operational
specifications, in accordance with American Conference of Governmental Industrial Hygienists
(ACGIH) guidelines.
• UV-C HAZARD! UV-C emitted from this product. Avoid eye and skin exposure to the unshielded
product. Follow all installation and operation instructions.
• Christie CounterAct products with patented Care222 technology are not for use as or for medical
devices.
Introduction
CounterAct Installation and Setup Guide 7
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Caution! If not avoided, the following could result in minor or moderate injury.
• UV RADIATION HAZARD! This equipment is designed for use with germicidal lamps or UV
sources and must be installed in compliance with competent technical directions and
manufacturer's site planning recommendations to prevent the user's eyes and bare skin from
exposure to harmful UV or optical radiation. Recommendations include the relative location of
each UV-generating device, the minimum distances between the devices and other objects or
surfaces, and protection from line-of-sight exposure to UV radiation in occupied spaces located
above the equipment mounting area (for example, upper floor balconies, open staircases, and so
on).
• UV-C OR OPTICAL RADIATION HAZARD! The installer must conduct an assessment of irradiance
or illuminance levels in the surrounding occupied space prior to occupancy to ensure people will
not be exposed to excessive UV or optical radiation during operation of the device.
• UV-C OR OPTICAL RADIATION HAZARD! Follow the manufacturer’s recommendations for
selecting appropriate ceiling and wall finishes as UV and optical radiation can be reflected by
surrounding surfaces such as ceilings and walls and reflective properties of surfaces can vary
widely.
• Mount the product in locations and at heights not readily subjected to tampering by
unauthorized personnel.
• Do not install this product in a dwelling.
Notice. If not avoided, the following could result in property damage.
• This telecommunication equipment complies with international standards or technical
requirements—NBTC.
• This equipment is not entitled to protection against harmful interference and may not cause
interference in properly authorized systems. For more information, see ANATEL's website
www.anatel.gov.br.
Patented Care222 UV lamp safety precautions
Read all safety and warning guidelines before handling the patented Care222 UV lamp.
Warning! If not avoided, the following could result in death or serious injury.
• PERSONAL INJURY HAZARD! Eye damage may result from directly viewing the light produced by
the lamp in this product. Always turn off the lamp before performing maintenance or service.
Introduction
CounterAct Installation and Setup Guide 8
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Caution! If not avoided, the following could result in minor or moderate injury.
• HOT SURFACE HAZARD! Do not touch the lamp module during operation.
• HOT SURFACE HAZARD! Allow lamp sufficient time to cool before handling.
• SHOCK HAZARD! Always turn off power before performing lamp module maintenance.
• FIRE HAZARD! Keep all flammable items, such as paper or cloth, away from the lamp module.
• Use protective eye wear and gloves when handling the lamp module.
• Do not drop, hit, use force, or scratch the lamp module.
• Do not disassemble or modify the lamp module.
• Use only mercury-free, excimer lamps (UXFL70-222B4-UIA) sold by Christie (P/N: 174-006107-
XX/003-121997-XX).
Service and maintenance guidelines
Read all safety and warning guidelines before maintaining or servicing the device.
Warning! If not avoided, the following could result in death or serious injury.
• SHOCK HAZARD! Disconnect the product from AC before installing, moving, servicing, cleaning,
removing components, or opening any enclosure.
• PERSONAL INJURY HAZARD! Eye damage may result from directly viewing the light produced by
the lamp in this product. Always turn off the lamp before performing maintenance or service.
• ELECTRICAL and BURN HAZARD! Use caution when accessing internal components.
• PERSONAL INJURY HAZARD! Use caution when servicing the lamp to avoid the risk of personal
injury.
Caution! If not avoided, the following could result in minor or moderate injury.
• Always connect the ground or earth first to reduce shock hazard.
• This Christie product must be serviced by Christie qualified technicians.
Low-power radio frequency warnings
The following warnings refers to radio communication operated according to the provisions of the
Telecommunications Administration law for Taiwan only. Low power radio frequency devices must
endure the interference of legal communications or industrial, scientific, and medical wave radiation
electrical devices.
Technical characteristics of Bluetooth radio access equipment (fixed luminaire (UV-C Fixture (BLE)):
• Frequency range: 2400-2483.5 MHz
• Maximum output power of the transmitter: dBm: 10.0
Caution! If not avoided, the following could result in minor or moderate injury.
• For certified low-power radio frequency devices, do not change the frequency, increase the
power, or change the characteristics and functions of the original design without approval.
• Using low-power radio frequency devices must not affect flight safety or interfere with legal
communications. If interference is found, stop using the device immediately and before
continuing use, modify so no interference occurs.
Introduction
CounterAct Installation and Setup Guide 9
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Product labels
Learn about the labels that may be used on the product. Labels on your product may be yellow or
black and white.
General hazards
Hazard warnings also apply to accessories once they are installed in a Christie product that is
connected to power.
Fire and Shock Hazard
To prevent fire or shock hazards, do not expose this product to rain or moisture.
Do not alter the power plug, overload the power outlet, or use it with extension cords.
Do not remove the product enclosure.
Only Christie qualified technicians are authorized to service the product.
Electrical Hazard
Risk of electric shock.
Do not remove the product enclosure.
Only Christie qualified technicians are authorized to service the product.
Warning! If not avoided, the following could result in death or serious injury.
Electric shock hazard. To avoid personal injury, disconnect all power sources before
performing maintenance or service.
Electrocution hazard. To avoid personal injury, always disconnect all power sources
before performing maintenance or service procedures.
Harmful ozone hazard. To avoid personal injury, follow installation and operating
instructions.
UV-C hazard. To avoid eye or skin exposure to unshielded product, follow installation
and operating instructions.
Caution! If not avoided, the following could result in minor or moderate injury.
Hot surface hazard. To avoid personal injury, allow the product to cool for the
recommended cool down time before touching or handling for maintenance or
service.
Notice. If not avoided, the following could result in property damage.
General hazard.
Introduction
CounterAct Installation and Setup Guide 10
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Mandatory action
SHOCK HAZARD! Disconnect all power sources before performing maintenance or service
procedures.
Consult the service manual.
Electrical labels
Indicates the presence of an earth ground.
Additional safety hazards
Caution - Risk of Personal Injury
Personal injury may result if the equipment is installed in a
dwelling. Do not install the equipment in a dwelling.
Warning - Risk of Personal Injury
Eye damage may result from directly viewing the light produced by
the lamp in this equipment. Always turn off the lamp before
performing service.
Warning - Risk of Shock
Shock hazard may result if a connection is made or broken while
under load.
This equipment is designed for use with germicidal lamps or UV
sources and must be installed in compliance with competent
technical directions to prevent the user's eyes and bare skin from
exposure to harmful UV or optical radiation.
Requirements for safe installation and operation of the product are
the following:
• Single-lamp mode: 6.7 m (22 feet) to 8.5 m (28 feet) above
the floor
• Dual-lamp mode: 8.5 m (28 feet) or greater above the floor
• Suitable for operation in ambient temperatures not exceeding
40°C (104°F)
• Suitable for dry locations IP20
• Use only mercury-free, excimer lamps (UXFL70-222B4-UIA)
sold by Christie (P/N: 174-006107-XX/003-121997-XX).
LAMP (RISK GROUP 3) UV-C HAZARD! To avoid eye or skin
exposure to the unshielded lamp, follow installation and operating
instructions. Once the lamp is integrated into CounterAct and
installed according to this guide, CounterAct performs according to
Risk Group Exempt levels.
Introduction
CounterAct Installation and Setup Guide 11
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

CounterAct overview
CounterAct is a commercial UV disinfection fixture containing Ushio Inc.’s patented Care222® lamps
that emit far-UVC 222nm light, shown to significantly reduce surface pathogens in occupied and
unoccupied indoor spaces. Care222® is based on far-UVC germicidal technology that may also be used
around people and it is the only product with a proprietary filter that prevents longer UVC wavelengths
from being emitted.
The CounterAct fixtures are installed in the ceiling throughout a space. The light spreads out in a fixed
cone size. Therefore as the ceiling height increases or decreases the output power must be adjusted
up or down respectively. The lamps cannot be dimmed and are only capable of being in the fully on or
off state. Operating modes for CounterAct comply with the UV Threshold Limit Values (TLV) outlined
by the American Conference of Governmental Industrial Hygienists (ACGIH). The TLV is measured as a
time-weighted average for a conventional eight-hour workday.
Key features
Understand the important features of CounterAct.
• Ushio Care222® B1 lamp module
• BLE Mesh communication technology
• Android control application
• Central power coupler for easy servicing
• Three-finger hold design for single-handed service
• Flexible power input options
• LED status indicator
Technical support
Technical support for Christie Cinema products is available at:
•[email protected]
• [phone]
• Christie Professional Services: [phone] or [email protected]
Technical support for Christie Enterprise products is available at:
• North and South America: [phone] or [email protected]
• Europe, Middle East, and Africa: [phone] or [email protected]
• Asia Pacific ([email protected])
• Australia: [phone] or [email protected]
• China: [phone] or [email protected]
• India: [phone] or [email protected]
• Japan: 81-3-3599-7481
• Singapore: [phone] or [email protected]
Introduction
CounterAct Installation and Setup Guide 12
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

• South Korea: [phone] or [email protected]
•Christie Professional Services: [phone] or [email protected]
Introduction
CounterAct Installation and Setup Guide 13
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Installation and setup
Learn how to plan, install, and setup CounterAct.
Site requirements
To safely install and operate CounterAct, the installation location must meet these minimum
requirements.
Physical operating environment
Item Requirement
Operating environment
Ambient temperature 0°C to 40°C (32°F to 104°F)
Ambient humidity 10 to 85% relative humidity (non-condensing)
Altitude 0 to 2000 meters (6550 feet)
Non-operating environment
Ambient temperature -10 to 60°C (14 to 140°F)
Ambient humidity 10 to 90% relative humidity
Power requirements
Learn the power requirements for CounterAct.
Parameter Requirement
AC input—UL version
Rated voltage Input 1: 120 VAC, single-phase
Input 2: 100-120 VAC, single-phase
Frequency Input 1: 60Hz
Input 2: 50/60 Hz
Rated current Input 1: 0.5 A maximum
Input 2: 0.5 A maximum
Maximum power draw Input 1: 45 W
Input 2: 45 W
AC input—CE version
Rated voltage 220-240 VAC, single-phase
Frequency 50/60 Hz
CounterAct Installation and Setup Guide 14
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Parameter Requirement
Rated current 0.23 A maximum
Maximum power draw 45 W
Tools and components required
The following tools are required to install CounterAct.
Tools required
• Phillips screwdriver
• Magnetic screwdriver (provided with the product)
• 2.5 hex key
• T20 Torx tamper-proof screwdriver
• Drill
• Hammer
• Level
• Tape measure
• Ceiling and ceiling tile cutter
• Pencil
• UIT240 light meter for 222NM
Components required
• Load wires
• Self-drilling screws ST4.2X25 (ISO 15481-1999)
• 12.7 mm (1/2 inch) flexible metal conduit and fitting or cable gland
Safe access to the ceiling is required.
Optional accessories
The following accessories are available for the CounterAct:
• Receiver box with IEC plug—black (P/N: 174-102104-XX)
The IEC receiver box assists with setup prior to installing the unit in the ceiling, bench top testings,
and troubleshooting.
Use only the attachments and/or accessories recommended by Christie. Use of others may result in
the risk of fire, shock, excessive UV exposure, or personal injury.
Installation and setup
CounterAct Installation and Setup Guide 15
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Tablet recommendations for CounterAct
Configure
The CounterAct application must be configured using at least one of the following tablets: Samsung
Galaxy™ Tab A 8” or Galaxy™ Tab A 10.1".
Getting to know your device
Understand the main components of CounterAct and how to insert and remove the disinfecting
module. before you begin your installation
Product components
Identify the main components of CounterAct.
ID Component Description
A Receiver box Provides electrical power and a quick mounting interface to the
disinfecting module.
B LED status indicator Indicates the status of the fixture (on page 39).
C Disinfecting module Contains the ultraviolet lamps modules.
D Locking pin access Secures the disinfecting module to the receiver box.
E Ultraviolet lamp module Emits far-UVC 222nm light to reduce pathogens.
F Locking/unlocking indicator Indicates the locking and unlocking rotation direction for the
disinfecting module.
G Multi-function button Provides three functions:
Installation and setup
CounterAct Installation and Setup Guide 16
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

ID Component Description
• Switches to Standby mode from current operational mode if
pressed less than 5 seconds.
•Turns on the LED status indicator (blinking green three times)
if pressed for more than 5 seconds and less than 10 seconds.
This functionality is the same as the Identify device function,
even though the fixture is in Stealth mode.
• Performs a factory reset and pairing if pressed for longer than
10 seconds within five minutes after start up.
H Three-finger hold holes Provides hand holds to mount the disinfecting module to the
receiver box.
Inserting the disinfecting module in the receiver box
Insert the disinfecting module in the receiver box and lock the fixture in position.
1. Place the disinfecting module in the receiver box by aligning the slots on the side of the
receiver box and the disinfecting module.
2. Hold the disinfecting module and turn the disinfecting module clockwise to engage.
A Lock
B Align line
C Start line
D Lock line
E Unlock
Installation and setup
CounterAct Installation and Setup Guide 17
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

3. Insert the magnetic driver in the locking hole and rotate the locking pin clockwise to set in the
locked position.
4. Once the locking pin is engaged, check to ensure you cannot rotate the disinfecting module
counterclockwise and remove it.
Removing the disinfecting module from the receiver box
Remove the disinfecting module from the receiver box to replace lamps.
1. Disable power to the system.
2. Insert the magnetic driver in the locking hole and turn the locking pin counterclockwise to
release it.
Installation and setup
CounterAct Installation and Setup Guide 18
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

3. Hold the disinfecting module and turn the disinfecting module counterclockwise (20° rotation)
to disengage it from the receiver box.
4. Remove the disinfecting module from the receiver box by pulling the module straight down
(assuming the receiver box is mounted flush with the ceiling).
Installation and setup
CounterAct Installation and Setup Guide 19
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.

Workflow: Installing and setting up CounterAct
Identify the recommended order for installing and setting up the components of the CounterAct
system.
1. Plan the layout and power for the site (on page 21).
2. Download and install the CounterAct application (on page 23) on a tablet.
3. Log into the CounterAct application (on page 23).
When the application is first installed, it prompts you to create three accounts (installer,
administrator, and user).
4. Determine if you want to add the fixtures to the room before or after installation.
•Before mounting in ceiling—Configure each fixture at ground level (on page 40) prior
to physically mounting the fixture in the ceiling. Adding one fixture at a time avoids
confusion between fixtures.
•After mounting in the ceiling—Configure each fixture after physically mounting the
receiver boxes and modules in the ceiling. (later in step 8c).
5. Ensure the power is turned off at the source breaker.
6. Install the CounterAct receiver boxes.
a) Connect to power (on page 24).
b) For pendant and ceiling surface mounting, remove the metal casing (on page 26).
c) Mount the receiver boxes in the ceiling and install the disinfecting modules in the receiver
boxes (on page 27).
Installation and setup
CounterAct Installation and Setup Guide 20
020-103456-02 Rev. 1 (12-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.
