Christie DS Series User manual

DS Series
LWU900-DS, LHD878-DS, LWU755-DS
Service Manual
020-001586-01

SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT.
Multimedia LCD Projector
SERVICE MANUAL
LWU900-DS
LHD878-DS
LWU755-DS
Warning
The technical information and parts shown in this
manual are not to be used for: the development,
design, production, storage or use of nuclear, chemical,
biological or missile weapons or other weapons of
mass destruction; or military purposes; or purposes that
endanger global safety and peace. Moreover, do not
sell, give, or export these items, or grant permission for
use to parties with such objectives. Forward all inquiries
to the supplier.
Be sure to read this manual before servicing. To assure safety from re, electric shock, injury, harmful
radiation and materials, various measures are provided in this Multimedia Projector.
Be sure to read cautionary items described in the manual to maintain safety before servicing.
Caution
1. This projector is provided with a high voltage circuit. Do not touch the electric parts of power unit (circuit),
after turn on the projector.
2. Do not touch the exhaust fan, during operation.
3. If replacing to the LCD PRISM assembly, do not hold the FPC of the LCD module assembly.
4. Use the cables which are included with the projector or specied.
Service Warning
1. Features------------------------------------------------------3
2. Specications -----------------------------------------------4
3. Names of each part---------------------------------------- 6
4. Install/Maintenance----------------------------------------7
5. Troubleshooting ------------------------------------------ 10
6. Diagnosis--------------------------------------------------- 19
7. Internal System------------------------------------------- 27
8. Replacement Parts list---------------------------------- 32
9. Disassemble/Assemble--------------------------------- 37
10.Adjustment------------------------------------------------- 97
11. Technical Information ----------------------------------108
Contents
1. Cross-head screwdriver (Size #1, #2)
2. Hexagonal nut driver (opposite side distance: 5mm)
3. Torque driver
4. Antistatic mat
5. Antistatic strap
Required tools
1
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual 020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
2
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
CAUTION FOR SAFETY
Please read this page before the repair work. This page explains the indications of the following
items to keep safety and prevent an accident.
Entries with graphical symbol explanation
WARNING This entry warns of a risk of personal serious injury or even death.
CAUTION
This entry warns of a risk of personal injury, physical or property damage.
Typical graphical symbols explanation
This symbol indicates
warnings and cautions. This symbol indicates hazard of high voltage. This symbol indicates mandatory actions.
This symbol indicates
hazard of explosion. This symbol indicates hazard of hand crush. This symbol indicates coercing to unplug.
This symbol indicates
hazard of high temperature.
This symbol indicates
prohibited actions.
WARNING
Follow the instructions.
The warning labels or markings are on the parts which need special attention.
Follow those notes and the User's Manual - Safety Guide.
Never disassemble the laser light source unit.
Avoid electric shock.
Be careful and unplug the power cord as far as possible during the work. Be sure to
unplug when disassembling or assembling.
The projector has high voltage portion and possibly charged portion. If you touch such a
place or other live part, it cause electric shock and may lead to death.
Use specied or recommended components.
Use the components which have same characteristic especially about incombustibility
and voltage proof as previous for keeping safety and reliability. Be particularly sure to
use the components marked with in the replacement parts list and circuit diagram.
Using un-specied or non-recommended components may cause electric shock or re.
Keep same style of wiring and components.
This product uses insulating tapes or tubes, and has some components assembled
keeping distance from particular portion to keep safety and reliability. Also the cables
are wired so that they keep away from high temperature or voltage part.
Be sure to restore them to prevent an electric shock and a re after you have changed them.
Do safety inspection after repair work.
Check if the all is restored (removed parts and wiring are same condition as previous)
after repair work. Also check if any damage are around the repaired or replaced part.
Measure the insulation resistance with megohmmeter after visual inspection. If the
resistance is less than 4M ohm, it may cause electric shock and re.
CAUTION
Take care of LCD panels.
Hold by the frame when disassembling the component including LCD panel. If you hold
it by the FPC cable or the surface of the panel, it may get damaged.
Do not touch the fan motor while it is rotating.
Do not touch the fan motors when you have turned on the projector with the UPPER
CASE removed. It may injure you.
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
3
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
1. Features
> Advanced Network Functions
Not only can you control and monitor the projectors via LAN connection, but also project still or
moving images from one or more networked computers.
> Wireless Network Capability
You can use the wireless network by connecting the projector to a PC using the optional USB
wireless adapter.
> Instant Stack
Two projectors of same model can project an image on the same screen using the Instant Stack
feature. They can be operated simultaneously to make the image brighter, moreover, can work
alternately by themselves, and once one projector has an accident the other voluntarily starts to
work to keep your presentation going.
> LENS MEMORY
The projector is capable of storing the lens shift position.
> Flexible installation
It is possible to install the projector for any vertical direction(*) with specied mounting
accessories.
*: The side planes of the projector should be kept vertical.
> Picture by Picture, Picture in Picture
You can project two images from different input ports on one screen at the same time. With the
remote control, it is easy to turn on/off this function and select the input source for the main and
sub areas.
> eClarity
eClarity is a function to improve the legibility so that it helps to read small letters.
> HDCR
Advanced feature which is the image stabilizer for a clearer image.
> HDBaseT™ covered
Gives one more digital interface to get clearer pictures on a screen.
> PJLink™
This projector's network supports the PJLink™ standard. PJLink™ is a unied standard for
operating and controlling data projectors. For specications of PJLink™, see the web site of the
PJLink™.
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
4
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
2. Specications
Liquid crystal
panel
Drive system TFT active matrix
Panel size LWU900-DS/LWU755-DS: 1.9cm (0.76" type)
LHD878-DS: 1.9cm (0.74" type)
Number of pixels LWU900-DS/LWU755-DS: 1920(H) x 1200(V)
LHD878-DS: 1920(H) x 1080(V)
Light Source Laser Diode
Digital
audio/video
signal
HDMI 1Type: T.M.D.S Signal level: DC 3.3V±5%, AC 0.15-1.56Vp-p
Audio signal: Linear PCM format, Sampling frequency 48kHz, 44.1kHz, 32kHz
2
DisplayPort Data Rate: 2.7Gbps or 1.62Gbps per lane Lane Count: 4-, 2-, or 1-lane
Audio Signal: Linear PCM format, Sampling frequency 48kHz, 44.1kHz, 32kHz
3G-SDI
(LWU900-DS, LHD878-DS only) SD-SDI, Single link HD-SDI, 3G-SDI Level-A
Computer signal COMPUTER IN (Dsub) Video: Analog 0.7Vp-p (75Ω termination)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
MONITOR OUT Video:Analog 0.7Vp-p, 75Ω output impedance (positive) H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
Video signal VIDEO 1.0Vp-p (75Ω termination)
HDBaseT* (RJ45) Signal type: PAM16
Differential signal level: 1.9~2.1V
Audio signal AUDIO IN 1Input impedance 47kΩ or more (max. 2Vrms) 2 (L/R)
AUDIO OUT (L/R) Output impedance 1kΩ (max. 2Vrms)
RS-232C Input: Hi: Max. 20V, Min. 2.6V Lo: Typ. –20.0V, Max. 0.8V
Output: Hi: Typ. 8.0V, Min. 5.0V Lo: Typ. –7.0V, Max. –5.0V
USB
TYPE A
(wireless LAN ***)
I/O Level
Amplitude of
differential signal (D+)-(D-)>0.2V and D+>2.0V or (D-)-(D+)>0.2V and D->2.0V
I/O Level
Amplitude of
signal INPUT: “L” 0.8V or less, “H” 2.0V or more
OUTPUT: “L” 0.3V or less, “H” 2.8V~3.6V
USB Mini B **
(Service port)
I/O Level
Amplitude of
differential signal (D+)-(D-)>0.2V and D+>2.0V or (D-)-(D+)>0.2V and D->2.0V
I/O Level
Amplitude of signal
INPUT: “L” 0.8V or less, “H” 2.0V or more
OUTPUT: “L” 0.3V or less, “H” 2.8V~3.6V
Wired LAN HDBaseT* (RJ45) System: 100Base-T
Differential signal level: 1.9~2.1V (100Ω termination)
LAN* (RJ45) System: 100Base-TX / 10Base-T
Differential signal level: 1.9~2.1V (100Ω termination)
Wireless LAN *** IEEE802.11a/b/g/n/ac See the user's manual of the optional USB wireless adapter.
Power supply LWU755-DS
: AC100V-120V/5.2A, AC220V-240V/2.5A
LWU900-DS/LHD878-DS : AC100V-120V/5.9A, AC220V-240V/2.9A
Power consumption LWU755-DS
: AC100V-120V/510W, AC220V-240V/500W
LWU900-DS/LHD878-DS : AC100V-120V/580W, AC220V-240V/560W
Dimensions 585 (W) x 232 (H) x 444 (D) mm
582 (W) x 205 (H) x 431 (D) mm (Not including protruding parts)
Weight approx. 18.2 kg
Temperature
range
Operating
Operating Temperature range :
0~Under 5,249ft
Normal mode 0~45°
35~45°(The brightness of the light source is reduced automatically.)
Quietmode 0~45°
5,249~Under 10,000ft
Normal mode 0~40°
30~40°(The brightness of the light source is reduced automatically.)
Quietmode 0~40°
Operating Humidity range : 10% to 80% (non-condensing)
Operating altitude range : 0 to 10,000ft
Non-Operating Storage Temperature range : -15 to +60°C Storage Humidity range : 5% to 85% (non-condensing)
Storage altitude range : 0 to 10,000ft
Accessories Remote control x1 User’s manual x 1 Computer cable x 1
Security label x 1 Power cord x 1 or 3 Terminal cover x 1
Adapter cover x 1 HDMI-DVI cable x 1 HDMI cable holder x 2
Cable tie x 2
* DC power cannot be provided from these ports.
** The service mini USB port is hidden behind the rear panel (mini USB COVER).
*** Wireless network function requires the optional USB wireless adapter. The communication speed (and standard) is restricted depending on
circumstances like encryption, communication mode and so on.
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
5
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
Laser precautions
“No direct exposure to the beam shall be permitted”
As with any bright source, do not stare into the direct beam,
RG2 IEC 62471-5:2015.
Hazard distance (for non-US installs)
Refer to the table T-1 in Supplement (at the back of this manual). The table
shows the hazard distance in which the beam strength described in IEC 62471 - 5
(Photobiological safety of lamps and lamp systems – Part 5: Image projectors) is
categorized as RG3.
For the combination of the lens and projector for which a value is shown in the
table, when the projection distance is the value or shorter the beam strength is
categorized as RG3, and is a hazard.
When applying the combination shown in the table, “operators shall control
access to the beam within the hazard distance or install the product at the height
that will prevent exposures of spectators’ eyes within the hazard distance”.
Refer to the F-9 in Supplement (at the back of this manual).
Laser aperture and Laser caution label
The positions of the laser aperture ( ) and the laser caution label are shown in
gure.
Laser evaluation standard
IEC60825-1: 2007, IEC60825-1: 2014, EN60825-1: 2014
Internal Laser Specications
This product is equipped with 2 Laser Diodes.
1. LWU900-DS/LHD878-DS
Internal Laser 1 : 71W, Wave Length: 449 - 461nm
Internal Laser 2 : 95W, Wave Length: 449 - 461nm
2. LWU755-DS
Internal Laser 1 : 71W, Wave Length: 449 - 461nm
Internal Laser 2 : 71W, Wave Length: 449 - 461nm
LASER ENERGY - EXPOSURE NEARAPERTURE MAY CAUSE BURNS
Laser aperture
• This projector is classied as a class 1 laser product (for non-US installs) that
complies with IEC60825-1:2014 and JIS C 6802:2014, and as a class 3R laser
product (for US installs) that complies with IEC60825-1:2007.
Improper handling may cause injury. Be careful of the following.
• If an abnormality occurs in the projector, turn it off immediately, unplug the
power cord from the outlet, and consult your dealer or service company. If you
continue to use it, it may cause not only electric shock or re but also vision
disorder.
• Do not disassemble or modify the projector. The projector has a high-power
laser device inside. It may cause serious injury.
• Do not look into the beam while projecting an image. Do not look into the lens
through optical devices such as magniers or telescopes. It may cause vision
disorder.
• Make sure that nobody is looking into the lens when you turn on the projector
by remote control away from the projector.
• Do not let children operate the projector. If children could possibly operate the
projector, they must be accompanied by an adult.
• Do not expose optical devices such as magniers or reection mirrors to a
projected image. It may cause bad effects on the human body if you continue
to use it. It may also cause re or accidents.
• Do not disassemble the projector when you dispose of it. Dispose of it
according to laws and regulations of each country or region.
CAUTION
► Use of controls or adjustments or performance of procedures other than those
specied herein may result in hazardous radiation exposure.
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
6
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
3. Names of each part
Part names
Projector
►Do not open or remove any portion of the projector, unless the
manuals direct it.
►Do not subject the projector to unstable conditions.
►Do not apply a shock or pressure to this projector. Remove all the attachments
including the power cord and cables, from the projector when carrying the
projector.
►Do not look into the lens and the openings on the projector while the light
source is on as the projection ray may cause a trouble on your eyes.
►Keep any object away from concentrated projection light beam. Blocking the
beam causes high temperature and could result in  re or smoke.
WARNING
►Do not touch around the exhaust vents during use or
just after use, since it is too hot.
►Do not attach anything onto the lens except the lens cover of this
projector because it could damage the lens, such as melting the lens.
CAUTION
(1)
(3)
(2)
(4)
(5)
(12)
(8)
(11)
(14)
(7)
(6)
(2)
(9) (10)
(9)
(6)
(6)
(6) (13)
(1) Filter cover
The air fi lter and intake vent
are inside.
(2) Elevator feet (x2)
(3) Remote sensors (x2)
(4) Lens hole cover
(5) Indicators
(6) Intake vents
(7) Control panel
(8) AC (AC inlet)
(9) Exhaust vents
(10) Ports
(11) Security bar
(12) Security slot
(13) Safety bar
(14) Battery cover
Control panel and Indicators
(3)
(2)
(7)
(1)
(8) (9) (10) (11) (12) (13)
(6)
(5)
(4)
(1) STANDBY/ON button
(2) INPUT button
(3) MENU button
(4) LENS SHIFT button
(5) ZOOM button
(6) FOCUS button
(7) SHUTTER button
(8) SERVICE indicator
(9) STATUS indicator
(10) FILTER indicator
(11) LIGHT indicator
(12) TEMP indicator
(13) POWER indicator
(1) COMPUTER IN port
(2) HDBaseT port
(3) LAN port
(4) WIRELESS port
(5) HDMI 1 port
(6) HDMI 2 port
(7) DisplayPort port
(8) VIDEO port
(9) 3G-SDI port (LWU900-DS/LHD878-DS)
(10) AUDIO IN1 port
(11) AUDIO IN2 (L, R) ports
(12) AUDIO OUT port
(13) MONITOR OUT port
(14) REMOTE CONTROL IN port
(15) REMOTE CONTROL OUT port
(16) CONTROL port
(17) HDMI OUT port
Ports
LWU755-DS
LWU900-DS/LHD878-DS
(1)
(2)
(3)
(15) (13)
(8)
(16)
(5) (6)
(7)
(10)
(11) (12) (14)
AC
MONITOR OUT AUDIO OUT
AUDIO IN 1
AUDIO IN 2
VIDEO
L
R
COMPUTER IN
DISPLAY PORT
WIRELESS
DC5V 0.5A
LAN
CONTROL
IN OUT
REMOTE CONTROL
HDMI OUT HDMI 1 HDMI 2
HDBaseT
(4) (17)
(1)
(2)
(3)
(15) (13)
(8)
(16)
(5) (6)
(7)
(10)
(11) (12) (14)
(9)
AC
MONITOR OUT AUDIO OUT
AUDIO IN 1
AUDIO IN 2
VIDEO
L
R
COMPUTER IN
3G-SDI DISPLAY PORT
WIRELESS
DC5V 0.5A
LAN
CONTROL
IN OUT
REMOTE CONTROL
HDMI OUT HDMI 1 HDMI 2
HDBaseT
(4) (17)
• When you press the button marked with *1, the input signal selection
menu is displayed.
• Any button marked with *2 is not supported on this projector.
• Each time you press any button (except ID buttons), the ID button of current
selected ID number lights.
NOTE
Remote control
(15) DIGITAL button *1
(16) FOCUS + / - buttons
(17) ZOOM + / - buttons
(18) AV MUTE button
(19) LENS MEMORY LOAD / SAVE buttons
(20) SHIFT button
(21) OSD MSG button
(22) ▲/▼/◄/►cursor buttons
(23) ENTER button
(24) RESET button
(25) MENU button
(26) GEOMETRY button
(27) PICTURE button
(28) NETWORK button
(29) INTERACTIVE button *2
(30) FREEZE button
(31) PbyP button
(32) MAGNIFY ON / OFF buttons
(33) VOLUME + / - buttons
(34) INFO button (35) ASPECT button
(36) MY BUTTON - 1 / 2 / 3 / 4 buttons
(37) Battery cover (38) Wired remote control port
Back of
the remote control
(1)
(3)
(4)
(7)
(8)
(10)
(13)
(14)
(16)
(20)
(18)
(23)
(24)
(26)
(30)
(34)
(36)
(2)
(5)
(6)
(9)
(11)
(12)
(15)
(17)
(19)
(21)
(22)
(25)
(29)
(33)
(37)
INFO
NETWORK
INTERACTIVE
(27) (28)
(38)
(31) (32)
(35)
(1) STANDBY button
(2) ON button
(3) ID - 1 / 2/ 3/ 4buttons
(4) COMPUTER 1 button
(5) COMPUTER 2 button *1
(6) VIDEO button
(7) LAN button
(8) USB TYPE A button *1
(9) USB TYPE B button *1
(10) HDMI 1 button
(11) HDMI 2 button
(12) DisplayPort button
(13)
HDBaseT button
(14)
SDI button
(Supported only for LWU900-DS/LHD878-DS)
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
7
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
■Installing the Batteries
WARNING
Always handle the batteries with care and use them only as directed. Improper use may result
in battery explosion, cracking or leakage, which could result in re, injury and/or pollution of the
surrounding environment.
• Be sure to use only the batteries specied. Do not use batteries of different types at the same
time. Do not mix a new battery with used one.
• Make sure the plus and minus terminals are correctly aligned when loading a battery.
• Keep a battery away from children and pets.
• Do not recharge, short circuit, solder or disassemble a battery.
• Do not place a battery in a re or water. Keep batteries in a dark, cool and dry place.
• If you observe battery leakage, wipe out the leakage and then replace a battery. If the leakage
adheres to your body or clothes, rinse well with water immediately.
• Obey the local laws on disposing the battery.
Insert the batteries into the remote control before using it. If the remote control starts to malfunction,
replace the batteries. If not using the remote control for long period, remove the batteries from the
remote control and store them in a safe place.
1. Holding the hook part of the battery cover, remove it.
2. Align and insert the twoAA batteries according to their plus and minus terminals as indicated in
the remote control. (Use the appropriate AA carbon-zinc or alkaline batteries (non-rechargeable)
according to laws and regulations.)
3. Replace the battery cover in the direction of the arrow and snap it back into place.
21 3
Replace a battery according to the following procedure.
1. Turn the projector off, and unplug the power cord. Allow the projector to cool
sufciently.
2. After making sure that the projector has cooled adequately, slowly turn over
the projector, so that the bottom is facing up.
3. Turn the battery cover fully in the direction indicated “OPEN” using a coin,
and pick the cover up to remove it.
4. Pry up the battery using a athead screwdriver to take it out. While prying it
up, put a nger lightly on the battery as it may pop out of the holder.
5. Replace the battery with a new MAXELL, Part No.CR2032 or CR2032H.
Slide the battery in under the plastic claw, and push it into the holder until it
clicks.
6. Replace the battery cover in place, then turn it in the direction indicated
“CLOSE” using a coin.
■Replacing the internal clock battery
4. Install/Maintenance
90°
90°
Bottom side
Battery Cover
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
8
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
■Air lter
Cleaning and replacing the air lter
Check and clean the air lter periodically. When the
indicators or a message prompts you to clean the
air lter, comply with it as soon as possible.
1.
Turn the projector o󰀨, and unplug the power
cord. Allow the projector to su󰀩ciently cool
down.
2.
Use a vacuum cleaner on and around the lter
cover.
3.
Pick and pull up the lter cover knobs to take it
o󰀨.
4.
Press up slightly the bottom side knobs to
unlock the bottom side of the air lter, and take
it o󰀨.
5.The air lter consists of two parts. Press down around the interlocking parts to unlock,
then separate the two parts.
Use a vacuum cleaner for both sides of the air lter.
If the air lter is damaged or heavily soiled, replace it with
the new one. Request for an air lter with the following
type number from your dealer when purchasing a new
one.
Type number:
003-006607-01
6.
Use a vacuum cleaner for the lter vent of the projector.
7.
Put back the air lter and lter cover into their place.
8.
Turn the projector on and reset the lter hours using
the FILTER HOURS item in the EASY MENU.
(1) Press the MENU button to display a menu.
(2) Point at the FILTER HOURS using the ▲/▼ buttons,
then press the ► button. A dialog will appear.
(3) Press the ► button to select “OK” on the dialog.
It performs resetting the lter hours.
5
Filter vent
Air lter knobs
4Air lter
6
Interlocking
Parts
2
Filter cover
Filter cover knobs
3
Extra
air lter
► Before taking care of the air lter, make sure the power cable
is not plugged in, then allow the projector to cool su󰀩ciently.
►Use only the air lter of the specied type. Do not use the projector without the
air lter or the lter cover. It could result in a re or malfunction to the projector.
►Clean the air lter periodically. If the air lter becomes clogged by dust or the
like, internal temperatures rise and could cause a re, a burn or malfunction to
the projector.
WARNING
• Replace the air lter when it is damaged or heavily soiled.
• Reset the lter hours only when you have cleaned or replaced the air lter, for
a suitable indication about the air lter.
• The projector may display the message such as the “CHECK THE AIR FLOW”
or turn o󰀨 the projector, to prevent the internal heat level rising.
NOTE
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
9
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
■Other care
WARNING
Before caring, make sure the power cable is not plugged in, and then allow the projector to cool
sufciently. The care in a high temperature state of the projector could cause a burn and/or
malfunction to the projector.
Avoid wetting the projector or inserting liquids in the projector. It could result in a re, an electric
shock, and/or malfunction to the projector.
• Don’t put a container containing water, cleaner or chemicals near the projector.
• Don’t use aerosols or sprays.
CAUTION
Please take right care of the projector according to the following. Incorrect care could cause not
only an injury but adverse inuence such as discoloration, peeling paint, etc.
• Do not use cleaner or chemicals other than those listed below.
• Do not polish or wipe with hard objects.
Inside of the projector
In order to ensure the safe use of the projector, it needs to clean and inspect the projector about
once a year.
Caring for the lens
If the lens is awed, soiled or fogged, it could cause deterioration of display quality. Please take
care of the lens, being cautions of the handling.
1. Turn the projector off, and unplug the power cord. Allow the projector to cool sufciently.
2. After making sure that the projector is cool adequately, lightly wipe the lens with a commercially
available lens-cleaning wipe. Do not touch the lens directly with your hand.
• Use commercially available lens tissue to clean the lens (used to clean cameras, eyeglasses, etc.).
• If the lens is heavily soiled, wipe it with a cloth moistened with little water.
• Never use polishing agents, detergents, chemicals, or solvents such as benzine or thinner.
• Excepting for lens, use a soft cloth to clean. When excessively soiled, dilute a neutral detergent in
water, wet and wring out the soft cloth.
Caring for the cabinet and remote control
Incorrect care could have adverse inuence such as discoloration, peeling paint, etc.
1. Turn the projector off, and unplug the power cord. Allow the projector to cool sufciently.
2. After making sure that the projector is cool adequately, lightly wipe with gauze or a soft cloth. If
soiling is severe, dip soft cloth in water or a neutral cleaner dilute in water, and wipe lightly after
wringing well. Then, wipe lightly with a soft, dry cloth.
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
10
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
5-1 Notice of AUTO adjustment
Use of AUTO adjustment with the image through analog RGB input optimizes V_POSI, H_POSI,
and H_PHASE automatically.
In case that display image has dark tone around its peripheral, AUTO operation sometimes makes
artifacts in the image, shifts capture area and so on. Those failures are caused by period of image
data is not exactly distinguished to period of blanking on signal processing.
To avoid such phenomena, AUTO function should be used with the full size picture that has bright
tone on its peripheral.
NOTE:
• The phenomenon of the failure ofAUTO adjustment depends on resolution of input source, scene
of picture etc.
• There is no above failure ofAUTO with video source through VIDEO port. The reason is
recognition of input signal’s standard does not need to search the capture range from input signal
itself.
Image when AUTO operates correctly Image when AUTO fails.
• Noting image of top or bottom lines.
• Shift of the image to East or West.
• Artifacts on image. Etc.
AA
5. Troubleshooting
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
11
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
5-2 Regarding the indicator lamps
The indicators may differ from the usual, check and deal with it according to the following table.
Indicator Status Description
The projector is in a standby state.
Refer to the section “Power on/o󰀨”.
The projector is warming up.
Wait for the projector to warm up.
The projector is in an on state.
Ordinary operations may be performed.
The projector is cooling down.
Wait for the projector to cool down.
(continued on next page)
The indicators are described as below.
Lit
Steady light Blinking O󰀨
Orange
Green
Orange
Green
Indicator Status Description
At least 1 "Power ON" schedule is saved to the
projector.
Please refer to Schedule Settings section of User’s
Manual - Network Guide.
STANDBY MODE is set to QUICK START.
Refer to STANDBY MODE.
Blank(black) or AV Mute(black) is on.
Press any button on the remote control or on the
control panel to disable Blank or AV Mute.
The temporarily shading the screen is
enabled.
Press the SHUTTER button on the remote control
or on the control panel to disable temporarily
shading the screen.
The projector received the remote control
signal when ALL is selected for REMOTE
CONTROL in KEY LOCK.
CONTROL PANEL was operated when ALL is
selected for CONTROL PANEL in KEY LOCK.
(continued on next page)
Blinking In Green 1 time
Normally lighting in Orange.
Blinking In Green 2 times for
approx. 3 seconds.
Blinking In Green 2 times
Green
Blinking In Green 3 times
GreenGreen
Green
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
12
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
Red
Indicator Status Description
PIN LOCK or TRANSITION DETECTOR
function is active.
Please refer to the section How to inactivate the
security functions and PIN LOCK System, or the
chapter SECURITY menu in the User's Manual.
It is time to clean the air lter.
Turn the power o󰀨 immediately, and clean or change
the air lter referring to the section Cleaning and
replacing the air lter. After cleaning or changing
the air lter, reset the lter hours.
After the remedy, restart the projector.
The air filter is clogged or dirty.
Check and clean the air filter.
Make sure the power cable is not plugged in, then
allow the projector to cool sufficiently.
See the section "The interior portion has become
heated".
NOTE • The FILTER indicator might light up
in red when something blocks the intake vents
even though the air lter is clean.
• The FILTER indicator might light up
di󰀨erently from other indicators or display
messages related to cleaning the air lter.
Follow the prompt that is displayed earlier.
The internal temperature is rising.
Turn the power o󰀨, and allow the projector to cool
down at least 20 minutes. After having conrmed the
following items, please turn the power on again.
• Is there blockage of the air passage aperture?
• Is the air lter dirty?
• Does the peripheral temperature exceed 45°C?
(continued on next page)
Blinking In Green 1 time
Blinking In Red 1 time
Green
Red
Blinking In Red 2 ～3 times
Green
Red
Blinking In Red 1 time Green
Orange
Indicator Status Description
The interior portion has become heated.
down at least 20 minutes. After the projector has
and then turn the power on again.
• Is there blockage of the air passage aperture?
• Is the air filter dirty?
• Does the peripheral temperature exceed 45°C?
• Is the setting for ALTITUDE appropriate?
• Is the exhaust air (hot/cold) from peripheral
equipment blowing against the ventilation opening of
projector?
For details on ALTITUDE, refer to ALTITUDE of
SERVICE in the OPTION menu. If the projector is
used with a wrong setting, it may cause damage to
the projector itself or the parts inside.
All or part of light sources are not lighting.
Turn off the projector and unplug the power cord,
and then turn on the projector again.
Lens unit is not installed.
Make sure that the lens unit is installed correctly, and
turn on the projector again.
(continued on next page)
Red
Blinking In Red 2 ～6 times
Red
Red
Blinking In Red 1 ～5 times
Red or
Green
Red
Blinking In Red 1 time
Red
The upper case is not attached correctly.
Make sure the upper case is attached.
Red
Blinking In Red 4 times
Red
The illuminance sensor measures irregular
value.
Make sure the connection of illuminance sensor and
illuminance sensor (Duration) calibration is executed.
Please refer to the section LD MENU in chapter
Adjustment.
Red
Blinking In Red 6 or 8 times
Green
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
13
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
Indicator Status Description
The cooling fan is not operating.
Turn the power off, and allow the projector to cool
down at least 20 minutes. After the projector has
sufficiently cooled down, confirm that no foreign
matter has become caught in the fan, and so on
and then turn the power on again.
Red
Blinking In Red 1 ～11 times
Red or
Green
Lens shift does not work correctly.
Turn off the projector and install the lens unit
correctly.
Remove obstacles if they are around the lens.
Blinking In Orange 1 time
Orange or Green
Green
Blinking In Orange 2 ～6 times
The illuminance sensor is loose.
Check the connection of each illuminance sensor
according to the number of SERVICE blinks.
7: Light sensor R
9: Light sensor B
The temperature sensor is loose.
Check the connection of each temperature sensor
according to the number of SERVICE blinks.
2: Inside temp sensor
3: Outside temp sensor
4: LD1 temp sensor
5: LD2 temp sensor
6: PW temp sensor
Green
Blinking In Orange 7 or 9 times
The phosphor wheel is not operating correctly.
Check the connection of the phosphor wheel cable
or replace the light source unit that includes
phosphor wheel.
Red
Blinking In Red 9 times
Red
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
14
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
5-3 Related Messages
When some messages appear, check and deal with it according to the following table. Although
these messages automatically disappear after several minutes, they reappear when the power is
turned on.
Message Description
There is no input signal.
Conrm the signal input connection, and the status of the
signal source.
Projector is waiting for an image le.
Check the hardware connection, settings on the projector and
network-related settings.
The computer-Projector network connection might be
disconnected. Re-connect them.
The horizontal or vertical frequency of the input signal is
not within the specied range.
Conrm the specs for your projector or the signal source
specs.
An improper signal is input.
Conrm the specs for your projector or the signal source
specs.
The internal temperature is rising.
Turn the power off, and allow the projector to cool down at
least 20 minutes. After having conrmed the following items,
turn the power ON again.
•Is there blockage of the air passage aperture?
•Is the air lter dirty?
• Use the unit within the usage temperature parameters (0°C
to 40°C or 45°C).
• Is the setting for ALTITUDE appropriate?
• Is the exhaust air (hot/cold) from peripheral equipments
blowing against the ventilation opening of projector?
For details of ALTITUDE, refer to ALTITUDE of SERVICE in the
OPTION menu. If the projector is used with a wrong setting, it
may cause damage to the projector itself or the parts inside.
A note of precaution when cleaning the air lter.
Immediately turn the power off, and clean or change the air
lter referring to the Cleaning and replacing the air lter
section of this manual. After you have cleaned or changed the
air lter, reset the lter timer.
The button operation is not available.
Check the button you want to use.
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
15
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
■ Troubleshooting for other Network problems
Problem Likely Cause Things to Check
No image
The projector is not turned on. Is the projector’s light source on?
The projector’s input source isn’t
switched properly.
Is the proper input channel is selected?
LAN: PC screen display via wired/wireless
LAN
Projector does not work
when the network cable
is connected.
The network packet congestion is
occurred.
Check the cable connection diagram making
sure no "ring" or "loop" connection is made
in the network that the projector is connected
to.
Time is not displayed
correctly.
The time has not been congured. Set the Date and Time in the OPTION -
SCHEDULE menu of the projector.
The projector displays "2015/1/1
0:00" as the Date and Time in the
Network Info after the AC power is
cut off because the projector has no
battery for the internal clock.
Set the Date and Time in the OPTION -
SCHEDULE menu of the projector every
time the projector is turned on.
The time is not adjusted by the
Daylight Saving Time correctly. Congure the Daylight Saving Time in the Date/Time Settings with a web browser.
The projector cannot get the time
from SNTP server.
Check the projector is connected to the
network correctly.
Congure the correct SNTP server address
in the Date/Time Settings with a web
browser.
The Time Difference is not
congured correctly.
Congure the Time Difference, and then
do the Date and the Time in the Date/Time
Settings with a web browser.
Connection to the Network
The projector
that you want
to connect to is
nowhere to be
found on the
list of available
projectors.
The PC and/or projector’s network
settings are not congured correctly.
Check the network congurations of the PC
and projector.
If you change the projector’s settings, turn
off the projector’s AC power and then turn it
on again. If you simply put the projector in
STANDBY power mode and then turn it on
again, the new settings might not take effect.
Firewall software other than
Windows Firewall is installed in
your PC.
Refer to the manual for the rewall software
and take one of the following actions:
- Exclude the “LiveViewer” from blocking
item list
- Disable the rewall while using the
“LiveViewer”
Can't communicate
The PC and/or projector's network
settings are not congured correctly.
Check the network congurations of the PC
and projector.
An access point is used, and your
PC is connected to the access point
via wireless LAN.
Use network utilities that may come with
your PC or wireless LAN card to establish
wireless network connection. For detail, refer
to the manual of the PC or the card.
Security software is blocking
network communication. Change the security setting to allow "LiveViewer" to use.
The number of PC connection
exceeds the limit (max. 50).
Try again after one of session is
disconnected. (nish "LiveViewer"
application)
(continued on next page)
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
16
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
Troubleshooting for other Network problems (continued)
Problem Likely Cause Things to Check
Network Presentation
Can't Install
"LiveViewer"
The "LiveViewer" does not work on
Windows Vista without any Service
Pack.
Apply the latest Service Pack to your
PC.
The projected image is
rather slow compared
to that of the PC.
The projector isn’t capable of
relaying dynamic images such as
PowerPoint®animation at full speed.
Switching the priority to ‘Transmission
Speed’ under the options menu may
help to improve speed.
The compression rate being used
for transferring the images is too
low.
Switching the priority to ‘Transmission
Speed’ under the options menu may
help to improve speed.
No Image Using screensaver with password. The "LiveViewer" cannot send PC screen data while using screensaver
with password.
Can't display the
movies correctly.
In some combinations of PC's video
card and application software,
the true image, especially movies
played by media player, might not
be transferred to the projector with
the “LiveViewer”.
If there is a video acceleration level
adjustment function in your application,
please try to adjust it.
Refer your application manual in detail.
The LiveViewer can't transfer movie
when DFMirage driver was installed. Remove DFMirage driver when you need to display movie with LiveViewer.
Network connection
between the PC
and projector is
disconnected when
PC screen resolution
is changed during
Network Presentation.
The PC-Projector network
connection might be disconnected
when PC screen resolution is
changed while displaying picture.
Please re-connect them.
“Connect button” after changing PC
screen resolution, or change display
resolution before connecting with the
“LiveViewer”.
Images contain lots of
interference.
The compression rate being used
for transferring the images is too
high.
Try setting the priority to 'Image Quality'
in the “LiveViewer” Option menu. You
may experience a drop in speed.
Neither transparency
nor translucency
effects (Glass)
Using the “LiveViewer” with
Windows Aero®mode. The “LiveViewer” does not support
these features of Windows Aero.
NOTE:
It is recommended to refer the section “Troubleshooting” in the latest version of User’s Manual - Operating
Guide, Network Guide and the User’s manual of "LiveViewer" from web site.
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
17
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
Cannot communicate via wired network.
NO
Set IP address and Subnet Mask in the
NETWORK - WIRED SETUP menu.
YES
YES
Does the
LED on lower right of
the LAN port light in
green?
NO
YES
Are
both of
IP address and
Subnet mask in the
WIRED INFORMATION set to
“0.0.0.0” after waiting
more than 1
minute?
NO
Is
the DHCP in
the NETWORK - WIRED
SETUP menu set to
“ON”?
NO
Use new LAN cable.
YES
YES
Is
the STANDBY
MODE setting “NORMAL”
or “QUICK START“?
Set the STANDBY MODE
as “NORMAL” or “QUICK
START“ in the SETUP menu.
NO Check the network hardware.
YES
Is the PC
connected with the projector
directly?
NO
Are there
any damage to the LAN
cable?
Replace MAIN PCB.
Replace MAIN PCB.
YES
NO
Are the network
addresses of PC and
projector same?
Use the same network
address on PC and projector.
YES
NO
Make sure those settings of the
projector and PC are correct.
Is
there DHCP
server on the network
which the projector is
connected to?
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
18
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
Cannot communicate via wireless network.
NO
YES
YES
Wait more than 1 minute after the adapter is connected.
Is the USB
wireless adapter connected
properly?
Re-connect the USB wireless adapter properly.
NO
YES
Is LED on
the adapter blinking?
NO
Can SSID
of projector be found from
PC?
Turn off your PC and projector and try again.
If they still cannot be connected, try replacing
the wireless adapter.
Replace MAIN PCB
or
Try replacing the USB wireless adapter.
NO
Can
MAC address
be read from WIRELESS
INFORMATION?
YES
Remove the projector and PC
from the place and try again.
NO Reset the projector’s wireless
settings to default, and try again by
using Passcode.
YES
Is there
another projector
nearby (within 100m) which
use same wireless
setting ?
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series

LWU900-DS / LHD878-DS / LWU755-DS
19
LWU900-DS/LHD878-DS/LWU755-DS
Service Manual
6. Diagnosis
■ Check points
NOTE:
1) The picture above shows the inside of the projector after the UPPER CASE is removed.
To access the components of the INPUT PCB shown in the picture, you need to detach the block
including the MAIN PCB and to separate the I/O PANEL and the I/O METAL from the block.
2) Wiring shown in this picture may differ from mass-products. Refer the chapter of “Wiring
diagram” to check the proper wiring.
3) The component IV01 is located on the reverse side of MAIN PCB.
MAIN PCB
E820:CNMPW2
connect
E800:CNMPW1
connect
EW32:CNFL2
connect
DRIVE PCB
POWER UNIT
(CIRCUIT SUB)
EP05:CNRCR
connect
EZ02:CNUAR
connect
E806:LD2_FAN
connect E301:CNKEY
connect POWER UNIT
(CIRCUIT MAIN)
NTC-IN PCB
EW31:CNFL1
connect
E805:LD1_FAN
connect
E809:SUB POW FAN
connect
E807:LD3_FAN
connect NTC-OUT PCB
EW77:CNOPR
connect
ILLUMINANCE
SENSOR RED PCB
EW76:CNOPR
connect
E302:CNLED
connect EM03:CNSSV connect
EM02:CNLAD
connect
EM04:CNSSH
connect E801:R FAN connect
ILLUMINANCE
SENSOR BLUE PCB
BATTERY PCB
EL50:CNBAT
connect E804:PBS_FAN
connect
E822:CNACR
connect
MAIN P.RELAY PCB
EP03:CNRCF
connect
E803:B_FAN
connect
EM00:Shift Mech.
V motor connect
E802:G_FAN
connect
FRONT REMOTE
CONTROL PCB
REAR REMOTE
CONTROL PCB
INPUT PCB
KEYPAD PCB
LED PCB
LCD LENS PRISM
LCD LENS PRISM
LCD LENS PRISM
LCD LENS PRISM
LCD LENS PRISM
EM00:Shift Mech.
H motor connect
LCD LENS PRISM
EW36:
Connected to Laser
temperature sensor
EW34:Connected to
Laser temperature
sensor
E808:Connected to
LD4 FAN
E810:Connected to
MAIN POWER UNIT FAN
E811: Connected to
Phosphor wheel FAN
EW35: Connected to
Phosphor wheel temperature sensor
EW71: Connected to
Phosphor wheel motor flexible cable
EM05:Connected
to Shift Mech.
P501, P601, P701:Connected to RGB Panel flexible cable
WARNING
Do not light the light source with the upper case opened because this projector is equipped with
a laser light source.
020-001586-01 Rev. 1(02-2021)
LIT MAN SERV DS Series
