RPMSP-D120U 1.75:1 Projector Addendum Page 1 of 3
020-100169-01 Rev. 1 (03/08)
ADDENDUM
RPMSP-D120U 1.75:1 Projector
Refer to this addendum along with the RPMX/RPMSP-D120U User’s Manual (020-100043-xx) for
updated installation and setup information. It is recommended you keep this document with your manuals for
future reference.
Installation & Setup – Modifying Project Configuration
The following illustration depicts an updated ISO view of the light engine. For details, refer to the
RPMX/RPMSP-D120U User’s Manual (020-100043-xx).
Figure 1.1 Secure Light Engine to Configuration Bracket
Applies to the Following Projectors
RPSMP-D120U 1.75:1

Page 2 of 3 RPMSP-D120U 1.75:1 Projector Addendum
020-100169-01 Rev. 1 (03/08)
Throw Distance Formula
The following illustrations depict the updated horizontal and vertical throw distance for the RPMSP-D120U
1:75.1 projector. For details, refer the RPMX/RPMSP-D120U User’s Manual (020-100043-xx).
**light shield not shown for clarity
Figure 1.2 Throw-distance formula for Lens-horizontal Configuration
Adjust the Projection Lens
The following illustrations depict the updated projection lens for the RPMSP-D120U 1:75.1 projector. For
details, refer to the RPMX/RPMSP-D120U User’s Manual (020-100043-xx).
Figure 1.3 SXGA Lens Adjustments

RPMSP-D120U 1.75:1 Projector Addendum Page 3 of 3
020-100169-01 Rev. 1 (03/08)
Projector Dimensions & Mounting Information
Horizontal Configuration (dimensions shown in millimeters)
**light shield not shown for clarity
Figure 1.4 RPMSP-D120U 1.75:1 Horizontal Configuration
