Christie DWX600-G User manual

Christie G Series
Boardrooms
Conference rooms
Education
Government
Houses of worship
Museums
Training rooms

1
Three models available Christie
DWX600-G, Christie DHD600-G
and Christie DWU600-G

2
Unsurpassed
value,versatility
and long-life
performance
What does value mean to you? We think it’s the fine
balance between quality, performance, support and
cost. The Christie®G Series offers you unsurpassed
value – with energy saving features, low maintenance
costs, numerous standard features, and the best
warranty and support in the industry.
Built with proven DLP®technology, the Christie
G Series gives you excellent image quality and
reliability. At 6000 lumens, this is the brightest
platform in its category. High brightness combined
with powerful features, including wireless connectivity,
makes the Christie G Series a perfect fit for a variety
of applications.
Ideal for 24/7 operation, the filter-free, dust-sealed
design prevents dust and dirt from affecting the
projector – ensuring that image quality is preserved
and maintenance costs are minimal. Shipping with
standard zoom lens (1.22-1.53:1), the Christie G
Series is packed with ProAV features, including three
resolution options, WXGA, HD and WUXGA, built-in
color matching for a more uniform image in a multi-
projector configuration, and blending and warping
capabilities to handle curved surfaces.
If you need a projector that is easy to install and
configure, and offers unsurpassed value, the
Christie G Series is right for you.

3
EXCELLENT IMAGE QUALITY
High brightness
The brightest in its class, the G Series delivers
exceptional images.
Christie DWX600-G – 5950 ANSI lumens (6500 center lumens)
Christie DHD600-G – 6050 ANSI lumens (6600 center lumens)
Christie DWU600-G – 6150 ANSI lumens (6750 center lumens)
Six-segment color wheel
Comes with high brightness color wheel for standard
applications and uses.
Show your audience
amazing images
People tend to associate great image quality with high cost. That
doesn’t have to be the case. You can enjoy stunning images with
the Christie®G Series at a low total cost of ownership.
The Dynamic Contrast feature further enhances the image quality
of the Christie G Series by increasing the contrast ratio to 4800:1.
This series ships standard with a high brightness, six-segment
color wheel for maximum brightness and excellent color range.
WUXGA HD XGA WXGA
Three resolution options
WXGA model Amazing performance value
Native HD model Maintain and maximize your brightness
WUXGA model Ideal for graphic intensive applications

4
Whites
Blacks
No Dynamic black –
standard contrast ratio.
Dynamic black – this feature
dramatically increases the
on/off contrast ratio of the
system. A fast-acting dynamic
iris optically minimizes the
black levels in the image
while electronically increasing
the gain in the image which
enhances the overall detail
in the blacks.
CR= Whites
Blacks
Intensity
1250 2000 4800 3000
Dynamic Contrast
With the Dynamic Contrast
enabled, up to 4800:1 contrast
can be achieved. Ideal for video
applications, the Dynamic Contrast
automatically adjusts an internal iris
to extend the range of blacks and
provide richer details during dark
content for true image reproduction.
Without
Dynamic
Contrast
With
Dynamic
Contrast
EXCELLENT IMAGE QUALITY
Color matching
When used with multiple projectors, this feature ensures
accurate color matching and uniformity across the
entire image.
Constant intensity mode
For tiled arrays, the constant intensity mode automatically
increases brightness as the lamps wear out over time in order
to maintain the overall brightness and image consistency
across the display.
With constant intensity mode
Without constant intensity mode
Time
Constant regulated brightness
Natural lamp brightness
Lamp power
Brightness
R
G
B
Color matching Edge blending
No color matching With color matching

5
VERSATILE DESIGN
Picture-in-picture/picture-by-picture functions offer different layout options
A30H PIP/POP Matrix Main
HDMI VGA Component S-video CVBS RJ45 USB type B
(mini)
USB type A DisplayPort DVI-D
HDMI – – – – – • • • • •
VGA – – – – – • • • • •
Component – – – – – • • • • •
S-video – – – – – • • • • •
CVBS – – – – – • • • • •
RJ45 • • • • • – – – – –
USB type B (mini) • • • • • – – – – –
USB type A • • • • • – – – – –
DisplayPort • • • • • – – – – –
DVI-D • • • • • – – – – –
• = PIP/POP combinations are enabled –= PIP/POP combinations are disabled
Christie G Series cable cover
We understand the unique
needs of your application
No application requirements are the same. We strive to pack all the features
crucial to the success of your display into one compact chassis minimizing the
expense of purchasing additional “out of projector’’ technologies. The Christie®
G Series is the full package. Its single lamp design lowers your cost of ownership
without compromising image quality. Wireless connectivity opens the door for easy
connection and clean presentation space. Three lens choices, input options and 360
degree projection are all designed to give you the flexibility to pick whatever you
need to capture the attention of your audience.
24/7 use capability
The G Series offers sealed, dust-free housing and heat-pipe
cooling system that enables the projector to run 24 hours
a day, 7 days a week in continuous operation.
White-colored cable cover (optional)
White chassis color and an optional cable cover gives you
a crisp, clean, uncluttered look ultimately maximizing
environment aesthetics and architectural design features.
Security lock
Multi-purpose security lock bar plus Kensington security
slot provide options for anti-theft.

6
VERSATILE DESIGN
Projector control
Control the projector through a web user interface.
SNMP (simple network management protocol)
lets you remotely monitor a Christie projector and
get status changes on various parameters.
Wireless capability
Input options
Wireless (optional)
One HDMI
One DisplayPort
Analog
Network
USB and network input
One DVI-D
Video (Component, S-Video and Composite)
Interchangeable lenses with 100% offset
Lenses with 100% offset helps make installation and
configuration easy, even in the most demanding installation
situations. It also makes it possible to take advantage of
existing mounting and hardware assets and reduces costs.
1
9 J K L M N O P
2 3 4 5 6 7 8
1Remote in
2Remote out
3 Red/Pr
4Blue/Pb
5Green/Y
6CVBS
7S-video
8RS-232
9Ethernet
JMini USB
KUSB
LDisplayPort
MHDMI
NVGA-IN
OVGA-OUT
PDVI
Wireless projection
Easy connectivity
Less cluttered meeting space
Cable-free management
Digital projector
Computers/laptops
Christie Presenter
The Christie Presenter application allows up to four remote
desktops from host PC’s to be displayed on the network
through Ethernet, USB, or wireless transports. It can adapt
to different network settings (DHCP, fixed IP, and direct link
by USB/Ethernet cable).
Christie G Series
wireless dongle

7
VERSATILE DESIGN
Projection surface
Curved screens
Tilted screen
Warping capabilities
1 Reference User Manual for combination compatibility of warp modes.
Blending and warping capabilities (optional)
Coupled with the internal color matching functions, blend and
warp capabilities enable the projector to be used in high-end
applications where large images are needed. An optional dual
processor warp module is required to blend and warp displays.
Warp modes: Keystone, 4-Corner, Curve, Pincushion, Barrel
and Rotation1
Dual processor warp module360 degree projection
360 degree
projection
The Christie®G Series can project
on a table top, be ceiling mounted,
straight down or straight up.
However you spin it, the Christie
G Series will fit your needs.
Motorized zoom, focus and lens shifts
For easy installation and configuration, the Christie G Series
comes with motorized zoom, focus and lens shift to ensure your
image is aligned tight within the desired viewing area for every
presentation. The mechanical shutter allows for quick pauses
in your display when the need arises to shutter the image.

8
ACCESSORIES AND OPTIONS
A suite of
lens options
to choose from
Our suite of lenses for HD and WUXGA
resolutions increases installation flexibility.
Christie G Series ships with standard
1.22-1.52:1 zoom lens.
Full suite of lenses
Accessories and options
Description Part Number
Lenses 0.95-1.22 zoom 140-101103-01
1.22-1.52 zoom 140-100102-01
1.52-2.89 zoom 140-102104-01
Ceiling mount 140-105107-01
Ceiling mount extension 104-101001-XX
Dual processor warp module 133-111104-01
Wireless dongle 133-113106-01
Cable cover 140-103105-01
Lamp 003-004808-01

9
CHRISTIE CARES
1Projector shown with optional cable cover.
Going above and beyond
In addition to high-quality products, what makes Christie
different from everyone else?
We go above and beyond to take care of our customers.
Customers keep coming back to us because they can’t
get the same level of support anywhere else.
We care about our customers. Your satisfaction is our ultimate
goal. We stand behind our products and support you with
our second-to-none warranty and service programs.
Top view1
Front view
Underneath view1
Side view1
22.00 [.87] MIN
27.7 [1.09] MAX
171.50±20.00 [6.75±.79]
160.00±20.00
[6.30±.79]
VARIES WITH PROJECTION LENS
239.50 [9.43]35.50 [1.40]
20°20°
19.76 [.78]
15.83 [.62]
41.60
493.76 [19.44]
383.76 [15.11]
CENTER OF GRAVITY
CENTER OF GRAVITY
ROLL (+/- 20 DEGREES)
206.80 [8.14]20 2.8 6 [7.99 ]
4 35 .0 0 [17.13]
35.50 [1.40]
108.50
[4.27]
124.50
[4.90]
56.40 [2.22]
100.60 [3.96]
125.60
[4.94] 95.00 [3.74] 72.40 [2.85]
90.60
[3.57] 160.00 [6.30] 42.40 [1.67]
66.40 [2.61]
25.00 [.98]
4 X M6 X 1.0
71.76 [2.83]
115.6 0 [4.55]
22.00 [.87] MIN
27.7 [1.09] MAX
171.50±20.00 [6.75±.79]
160.00±20.00
[6.30±.79]
VARIES WITH PROJECTION LENS
239.50 [9.43]35.50 [1.40]
20°20°
19.76 [.78]
15.83 [.62]
41.60
493.76 [19.44]
383.76 [15.11]
CENTER OF GRAVITY
CENTER OF GRAVITY
ROLL (+/- 20 DEGREES)
206.80 [8.14]20 2.8 6 [7.99 ]
4 35 .0 0 [17.13]
35.50 [1.40]
108.50
[4.27]
124.50
[4.90]
56.40 [2.22]
100.60 [3.96]
125.60
[4.94] 95.00 [3.74] 72.40 [2.85]
90.60
[3.57] 160.00 [6.30] 42.40 [1.67]
66.40 [2.61]
25.00 [.98]
4 X M6 X 1.0
71.76 [2.83]
115.6 0 [4.55]
22.00 [.87] MIN
27.7 [1.09] MAX
171.50±20.00 [6.75±.79]
160.00±20.00
[6.30±.79]
VARIES WITH PROJECTION LENS
239.50 [9.43]35.50 [1.40]
20°20°
19.76 [.78]
15.83 [.62]
41.60
493.76 [19.44]
383.76 [15.11]
CENTER OF GRAVITY
CENTER OF GRAVITY
ROLL (+/- 20 DEGREES)
206.80 [8.14]20 2.8 6 [7.99 ]
4 35 .0 0 [17.13]
35.50 [1.40]
108.50
[4.27]
124.50
[4.90]
56.40 [2.22]
100.60 [3.96]
125.60
[4.94] 95.00 [3.74] 72.40 [2.85]
90.60
[3.57] 160.00 [6.30] 42.40 [1.67]
66.40 [2.61]
25.00 [.98]
4 X M6 X 1.0
71.76 [2.83]
115.6 0 [4.55]
22.00 [.87] MIN
27.7 [1.09] MAX
171.50±20.00 [6.75±.79]
160.00±20.00
[6.30±.79]
VARIES WITH PROJECTION LENS
239.50 [9.43]35.50 [1.40]
20°20°
19.76 [.78]
15.83 [.62]
41.60
493.76 [19.44]
383.76 [15.11]
CENTER OF GRAVITY
CENTER OF GRAVITY
ROLL (+/- 20 DEGREES)
206.80 [8.14]20 2.8 6 [7.99 ]
4 35 .0 0 [17.13]
35.50 [1.40]
108.50
[4.27]
124.50
[4.90]
56.40 [2.22]
100.60 [3.96]
125.60
[4.94] 95.00 [3.74] 72.40 [2.85]
90.60
[3.57] 160.00 [6.30] 42.40 [1.67]
66.40 [2.61]
25.00 [.98]
4 X M6 X 1.0
71.76 [2.83]
115.6 0 [4.55]
Environmental
At Christie we recognize our responsibility to control the
impact of our business on the environment. We take pride
in offering eco-friendly features in our products that are
not only good for the environment, but also lower total
cost of ownership for our customers.
Christie G Series includes features that support our
commitment to being eco-friendly.
Eco mode
0.5W standby mode
Auto shut down
Sleep timer: save energy by controlling
when the projector goes to sleep
Christie support and service
All Christie products are backed by industry-leading warranties,
renowned service and support. We ensure our customers are
well supported with training, service and technical support
through our extensive distribution and support network.
Christie has local support on five continents offering support
for international installations and global deployments.
We offer customer-centric service with years of extensive
experience in varieties of applications.

10
TECHNICAL SPECIFICATIONS
Christie DWX600-G Christie DHD600-G Christie DWU600-G
Image brightness • 5950 ANSI lumens
• WXGA (6500 center lumens)
• 6050 ANSI lumens
• HD (6600 center lumens)
• 6150 ANSI lumens
• WUXGA (6750 center lumens)
color wheel • 6 Segment (RGBCYW)
contrast • 4000:1 (Dynamic Contrast Enabled);
1000:1 (full on/off); 250:1 ANSI
• 4800:1 (Dynamic Contrast Enabled); 1200:1 (full on/off); 250:1 ANSI
Display type • 1-chip 0.65" DMD • 1-chip 0.67” DMD
native resolution • 1280 x 800 (1,024,000 pixels) 16:10 • 1920 x 1080 (2,073,600 pixels) 16:9 • 1920 x 1200 (2,304,000 pixels) 16:10
Lamp type • 465W NSH
typical lifetime • 2000 hrs minimum @ 370W •2500 hrs typical @ 360W
Inputs standard • HDMI x 1 •DVI-D x 1 (Digital only) •DisplayPort x 1 •HD15 x 1 •Composite video x 1 (RCA) •S-Video x 1 (mini DIN)
• Component video (RCA) •USB x 1 (type B mini) - Display over USB •USB x 1 (type A) - Image viewer or WiFi dongle (optional) •RJ45 x1
signals • HDTV formats VGA through to WUXGA (1920 x 1200) •Horizontal and vertical scaling while maintaining aspect ratio, all inputs
pixel clock • 162 MHz
scan rates • Horizontal: 15-100kHz •Vertical: 24-85Hz
Outputs monitor out • HD15 x 1
Control and networking • RS-232 in •Ethernet (10/100) RJ45 with ChristieNET™ connectivity •Built-in backlit keypad •Wired remote control (3.5mm stereo)
Accessories standard • IR Remote with wired remote jack (wire not included) •AC Line cord for projector head •User manual
optional • 1DWUSB-BGN (wireless dongle for video and control) •Warp module •Cable cover •Ceiling mount •Ceiling mount extension
Lens mount type • Tool-free lens insertion system •Boresight adjustable •Motorized horizontal and vertical lens offset •Motorized zoom and focus adjustment
Lenses zoom • 1.22-1.52:1 HD (included) •0.95-1.22:1 HD (optional) •1.52-2.89:1 HD (optional)
offsets • Vertical: ± 100% of ½ image height
(± 400 pixels) optical range
• Horizontal: ± 20% of ½ image width
(± 128 pixels)
• Vertical: ± 120% (± 648 pixels)
• Horizontal: ± 20% (± 192 pixels)
• Vertical: ± 100% (± 600 pixels)
• Horizontal: ± 20% (±192 pixels)
Power
requirements
operating voltage • 100-240 VAC 50/60Hz
consumption • 510W maximum •405W eco mode
operating current • 6.5A maximum
dissipation • 1979 BTU/hr maximum •1535 BTU/hr eco mode
Physical specs size • (LxWxH) 15.28 x 17.13 x 8.15" (388 x 435 x 207mm) without feet
shipping size • (LxWxH) 23.27 x 23.03 x 17.44" (591 x 501 x 443mm) without feet
weight • 33.7lbs (15.3kg)
shipping weight • 45.2lbs (20.5kg)
Operating environment • Temperature: 40-95°F (5-35°C) •Humidity: 0-90% non-condensing
Regulatory2• UL/CSA/IEC 60950-1 •FCC Class A, CE, CCC, KC, EAC, PSE, CU, SABS, BIS, and RCM
• This product conforms to all relevant European directives, standards, safety, health and environmental concerns
• This product is designed to comply to the rules and regulations required for the product to be sold in various regional markets,
including USA/Canada, EU, Norway, Australia/New Zealand, Kuwait, China, Korea, Japan, Mexico, Ukraine, India, Russia,
South Africa and Saudi Arabia
• RoHS, REACH, WEEE
Limited warranty • Three years parts and labor (including light engine)
• Contact an authorized Christie representative for full details of our limited warranty
24 7
Operational
Reliability
Operation
24 7
Operational
Reliability
24 7
Operational
Reliability
24 7
CHRISTIE LCD,
1-CHIP AND 3-CHIP DLP®
FOR
2Some certifications are pending. Please contact Christie for currently approved certifications.

Corporate offices Worldwide offices
Christie Digital Systems USA, Inc.
USA – Cypress
ph: 714 236 8610
Christie Digital Systems Canada Inc.
Canada – Kitchener
ph: 519 744 8005
Independent sales
consultant offices
Italy
ph: [phone]
Australia
ph: [phone]
Brazil
ph: [phone]
China (Beijing)
ph: [phone]
China (Shanghai)
ph: [phone]
Eastern Europe and
Russian Federation
ph: [phone]
France
ph: [phone]
Germany
ph: [phone]
India
ph: [phone]
Japan (Tokyo)
ph: 81 3 3599 7481
Korea (Seoul)
ph: [phone]
Republic of South Africa
ph: [phone]
Singapore
ph: [phone]
Spain
ph: [phone]
United Arab Emirates
ph: [phone]
United Kingdom
ph: [phone]
For the most current specification information, please visit www.christiedigital.com
Copyright 2014 Christie Digital Systems USA, Inc. All rights reserved. All brand names and product names are trademarks, registered trademarks
or tradenames of their respective holders. Christie Digital Systems Canada Inc.’s management system is registered to ISO 9001 and ISO 14001.
Performance specifications are typical. Due to constant research, specifications are subject to change without notice.
Printed in Canada on recycled paper. 3729 Jan 14
