Chroma 63200 Series Owner's manual

High Power
DC Electronic Load
63200 Series
Operation & Programming
Manual
Version 2.9
September 2015
P/N A11 000599

ii
Legal Notices
The information in this document is subject to change without notice.
Chroma ATE INC. makes no warranty of any kind with regard to this manual, including, but
not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Chroma ATE INC. shall not be held liable for errors contained herein or direct, indirect, special,
incidental or consequential damages in connection with the furnishing, performance, or use of
this material.
CHROMA ATE INC.
66 Huaya 1st Road, Guishan, Taoyuan 33383, Taiwan
Copyright Notices. Copyright 2003 Chroma ATE INC., all rights reserved. Reproduction,
adaptation, or translation of this document without prior written permission is prohibited,
except as allowed under the copyright laws.

iii
Warranty
All of Chroma’s instruments are warranted against defects in material and workmanship for a
period of one year from date of shipment. Chroma agrees to repair or replace any assembly
or component found to be defective, under normal use during this period. Chroma’s obligation
under this warranty is limited solely to repairing any such instrument, which in Chroma’s sole
opinion proves to be defective within the scope of the warranty when returned to the factory or
to an authorized service center. Purchaser is responsible for the shipping and cost of the
service item to Chroma factory or service center. Shipment should not be made without prior
authorization by Chroma.
This warranty does not apply to any products repaired or altered by persons not authorized by
Chroma, or not in accordance with instructions furnished by Chroma. If the instrument is
defective as a result of misuse, improper repair, or abnormal conditions or operations, repairs
will be billed at cost.
Chroma assumes no responsibility for its product being used in a hazardous or dangerous
manner either alone or in conjunction with other equipment. High voltage used in some
instruments may be dangerous if misused. Special disclaimers apply to these instruments.
Chroma assumes no liability for secondary charges or consequential damages and in any
event, Chroma’s liability for breach of warranty under any contract or otherwise, shall not
exceed the purchase price of the specific instrument shipped and against which a claim is
made.
Any recommendations made by Chroma regarding the use of its products are based upon
tests believed to be reliable; Chroma makes no warranty of the results to be obtained. This
warranty is in lieu of all other warranties, expressed or implied, and no representative or
person is authorized to represent or assume for Chroma any liability in connection with the
sale of our products other than set forth herein.
CHROMA ATE INC.
66 Huaya 1st Road, Guishan,
Taoyuan 33383, Taiwan
Tel: [phone]
Fax: [phone]
e-mail: [email protected]
http://www.chromaate.com

iv
Material Contents Declaration
The recycling label shown on the product indicates the Hazardous Substances contained in
the product as the table listed below.
: See <Table 1>.
: See <Table 2>.
<Table 1>
Part Name
Hazardous Substances
Lead
Mercury
Cadmium
Hexavalent
Chromium
Polybrominated
Biphenyls
Polybromodiphenyl
Ethers
Pb
Hg
Cd
Cr6+
PBB
PBDE
PCBA O O O O O O
CHASSIS O O O O O O
ACCESSORY O O O O O O
PACKAGE O O O O O O
“O” indicates that the level of the specified chemical substance is less than the threshold level
specified in
the standards of SJ/T-11363-2006 and EU 2005/618/EC.
“
” indicates that the level of the specified chemical substance exceeds the threshold level
specified in
the standards of SJ/T-11363-2006 and EU 2005/618/EC.
Disposal
Do not dispose of electrical appliances as unsorted municipal waste; use separate collection
facilities. Contact your local government for information regarding the collection systems
available. If electrical appliances are disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain, damaging your health and
well-being. When replacing old appliances with a new one, the retailer is legally obligated to
take back your old appliances for disposal free of charge.

v
<Table 2>
Part Name
Hazardous Substances
Lead
Mercury
Cadmium
Hexavalent
Chromium
Polybrominated
Biphenyls
Polybromodiphenyl
Ethers
Pb
Hg
Cd
Cr6+
PBB
PBDE
PCBA O O O O O
CHASSIS O O O O O
ACCESSORY 
O O O O O
PACKAGE O O O O O O
“O” indicates that the level of the specified chemical substance is less than the threshold level
specified in the
standards of SJ/T-11363-2006 and EU 2005/618/EC.
“
” indicates that the level of the specified chemical substance exceeds the threshold level
specified in the standards of SJ/T
-11363-2006 and EU 2005/618/EC.
1.
Chroma is not fully transitioned to lead-free solder assembly at this moment; however,
most of the components used are RoHS compliant.
2.
The environment-friendly usage period of the product is assumed under the operating
environment specified in each product’s specification.
Disposal
Do not dispose of electrical appliances as unsorted municipal waste; use separate collection
facilities. Contact your local government for information regarding the collection systems
available. If electrical appliances are disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain, damaging your health and
well-being. When replacing old appliances with a new one, the retailer is legally obligated to
take back your old appliances for disposal free of charge.

vi

vii

viii
Safety Summary
The following general safety precautions must be observed during all phases of operation,
service, and repair of this instrument. Failure to comply with these precautions or specific
WARNINGS given elsewhere in this manual will violate safety standards of design,
manufacture, and intended use of the instrument. Chroma assumes no liability for the
customer’s failure to comply with these requirements.
BEFORE APPLYING POWER
Verify that the power is set to match the rated input of this power supply.
PROTECTIVE GROUNDING
Make sure to connect the protective grounding to prevent an electric
shock before turning on the power.
NECESSITY OF PROTECTIVE GROUNDING
Never cut off the internal or external protective grounding wire, or
disconnect the wiring of protective grounding terminal. Doing so will
cause a potential shock hazard that may bring injury to a person.
FUSES
Only fuses with the required rated current, voltage, and specified type
(normal blow, time delay, etc.) should be used. Do not use repaired
fuses or short-circuited fuse holders. To do so could cause a shock or
fire hazard.
DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE
Do not operate the instrument in the presence of flammable gases or
fumes. The instrument should be used in an environment of good
ventilation.
DO NOT REMOVE THE COVER OF THE INSTRUMENT
Operating personnel must not remove the cover of the instrument.
Component replacement and internal adjustment can be done only by
qualified service personnel.

ix
Safety Symbols
DANGER – High voltage.
Explanation: To avoid injury, death of personnel, or damage to the
instrument, the operator must refer to the
explanation in the instruction
manual.
High temperature: This symbol indicates the temperature is
hazardous to human beings. Do not touch it to avoid any personal
injury.
Protective grounding terminal: This symbol indicates that the
terminal must be connected to ground before operation of the
equipment to protect against electrical shock in case of a fault.
Functional grounding: To identify an earth (ground) terminal in
cases where the protective ground is not explicitly stated. This
symbol indicates the power connector does not provide grounding.
Frame or chassis: To identify a frame or chassis terminal.
Alternating Current (AC)
Direct Current (DC) / Alternating Current (AC)
Direct Current (DC)
Push-on/Push-off power switch
The WARNING sign highlights an essential operating or maintenance
procedure, practice, condition, statement, etc., which if not strictly
observed, could result in injury to, or death of, personnel or long term
health hazards.
The CAUTION sign highlights an essential operating or maintenance
procedure, practice, condition, statement, etc., which if not strictly
observed, could result in damage to, or destruction of, equipment.
The Notice sign highlights an essential operating or maintenance
procedure, condition, or statement.
WARNING
CAUTION

x
Revision History
The following lists the additions, deletions and modifications in this manual at each revision.
Date
Version
Revised Sections
Mar. 2003
1.3
Update “CE Conformity Declaration” to add model 63205/63207/63209
Update “Specifications” for changes and addition of model
63205/63207/ 63209
Add the rear panel of Model 63205/630206/63207/63208/63209 in
“Rear Panel Description”
May 2003
1.4
Add a note to the “Specifications” for the fuse of 63205
Jan. 2004
1.5
Modify the “Specifications” in Chapter 1 for power rating changes for all
models.
Add a section of “Dimension Outline for 63200 Series” in Chapter 1.
Jan. 2005
1.6
Add the following sections:
–“Diagram of RS485 Parallel Connections” in Chapter 2.
–“Load Surge Capability” in Chapter 3.
–“Timer Function for Battery Discharge Testing” in Chapter 3.
Modify the following sections:
–“Specifications” in Chapter 1.
–“Protection Features” in Chapter 3.
Jun. 2005
1.7
Change the address of Chroma in CE-Conformity Declaration
Nov. 2005
1.8
Modify the “Specifications” in Chapter 1.
Jun. 2006
1.9
Modify the followings:
–“Specifications” to add a new model 63210.
–Description in the section of “Parallel Connections”.
–“Load Connections” in the section of “Application Connection”.
–Commands in the chapter of “Language Dictionary”.
–“Questionable Status” in the chapter of “Status Reporting”.
–“Command Summary” in the chapter of “Index”.
Add “Installing the 63200 Protective Cover” in the section of
“Dimension Outline for 63200 Series”.
Dec. 2006
2.0
Add the following:
–“Von Protection”, “CR Offset Error Compensation” and the GPIB
related commands in the chapters of “Operation Overview”, “Local
Operation” and “Language Dictionary”.
–“Battery Discharge” and the GPIB related commands in the
chapters of “Local Operation” and “Language Dictionary”.
Modify the contents of “Voltage & Current Monitor” in the chapter of
“Operation Overview”.
Mar. 2007
2.1
Add “Material Contents Declaration”.
Mar. 2008
2.2
Delete GPIB cable from the section of “Inspection” in the chapter of
“Installation.”
Modify the contents of “Load Connections” in the chapter of
“Installation.”
Modify the figure of “Timer Function for Battery Discharge Testing” in
the chapter of “Operation Overview.”
July 2009
2.3
Add Battery commands to the section of “Command Summary.”
Update the detail specifications and descriptions in the table of
“Specification” section.

xi
Feb. 2012
2.4
Add the following:
−“Parallel Setting” in the chapter of “Installation”
−“External LOAD ON/OFF Control” in the chapter of ”Operation
Overview”
−“Troubleshooting” and “Precautions for Loading 63200 Battery”
two chapters
Update the following:
−Detail specifications and descriptions in “Specification” section
−Front and rear panel descriptions
−Standard accessories
Oct. 2012
2.5
Add the following:
−Timeout setting to Battery
−Recall Default function
−SHORT KEY: ENABLE/DISABLE function
Modify the following:
−Minimum setting to 0V in CV Mode
−External ON/OFF to support all Modes and Programs
−63202 specifications to upgrade to 600V
−Copyright text from “CHROMA ATE Inc.” to “Chroma ATE Inc.”
−List of accessories
Jun. 2013
2.6
Add the following:
−63211 CE Declaration of Conformity
−Specification for 63211
−Accessory for 63211
−Dimension for 63211
−“Maintenance & Cleaning” & “Calibration & Verification”
sections in
the chapter of “Installation”
−63211 parallel usage
−63211 has no surge capability
−“Verification” chapter
Modify the following:
−63200 Series Verification
−63201~63210 CE Declaration of Conformity
Feb. 2014
2.7
Add a new model 63212.
Jun. 2014
2.8
Add the following in the chapter of “Operation Overview”:
−Notice of Von time delay specification in the section of “Von
Protection.”
−Note in the section of “CR Offset Error Compensation.”
Modify the CURSOR EDIT description in the section of “
Online Change
Level” under the chapter of “Local Operation.”
Add TIMEOUT function for Firmware version 2.50 or above for all
models in the entire series.
Update the appendix of “List of Functions & Mapped F/W Versions.”
Sep. 2015
2.9
Modify CR mode specification.
Update “Hardware Requirements” in the chapter of “Verification.”

High Power DC Electronic Load 63200 Series Operation & Programming Manual
xiii
Table of Contents
1. General Information..............................................................................................1-1
1.1 Introduction.....................................................................................................1-1
1.2 Description......................................................................................................1-1
1.3 Overview of Key Features...............................................................................1-2
1.4 Specifications..................................................................................................1-2
1.5 Dimension Outline for 63200 Series..............................................................1-11
2. Installation ............................................................................................................2-1
2.1 Introduction.....................................................................................................2-1
2.2 Inspection .......................................................................................................2-1
2.2.1 Maintenance & Cleaning .........................................................................2-3
2.2.2 Calibration & Verification.........................................................................2-3
2.3 Installing .........................................................................................................2-3
2.3.1 Changing Line Voltage............................................................................2-3
2.3.2 Turn-On Self-Test ...................................................................................2-4
2.4 Application Connection ...................................................................................2-5
2.4.1 Load Connections ...................................................................................2-5
2.4.2Remote Sensing Connections.................................................................2-6
2.4.3 Parallel Connections ...............................................................................2-7
2.4.4 RS-485 Parallel Connection Diagram......................................................2-8
2.4.5 Parallel Setting........................................................................................2-9
2.5 Remote Control Connection..........................................................................2-11
3. Operation Overview..............................................................................................3-1
3.1 Introduction.....................................................................................................3-1
3.2 Front Panel Description...................................................................................3-1
3.3 Rear Panel Description...................................................................................3-1
3.4 Local/Remote Control .....................................................................................3-6
3.5Modes of Operation ........................................................................................3-6
3.5.1 Constant Current Mode...........................................................................3-6
3.5.2 Constant Resistance Mode .....................................................................3-8
3.5.3 Constant Voltage Mode...........................................................................3-9
3.5.4 Constant Power Mode...........................................................................3-10
3.5.5 Load Surge Capability...........................................................................3-10
3.5.6 Timer Function for Battery Discharge Testing........................................3-12
3.6 Measurements..............................................................................................3-12
3.7 Slew Rate & Minimum Transient Time..........................................................3-13
3.8 Start/Stop Current Loading ...........................................................................3-13
3.9 Short On/Off..................................................................................................3-14
3.10 Load On/Off ..................................................................................................3-15
3.11 Protection Features.......................................................................................3-15
3.12 Save/Recall Setting.......................................................................................3-16
3.13 Program........................................................................................................3-17
3.14 External Waveform Control...........................................................................3-17
3.15 Voltage & Current Monitor.............................................................................3-17
3.16 Von Protection ..............................................................................................3-17
3.17 CR Offset Error Compensation .....................................................................3-20
3.18 External LOAD ON/OFF Control...................................................................3-21
3.19 SHORT KEY：ENABLE/DISABLE Function.................................................3-22
4. Local Operation....................................................................................................4-1
4.1 Introduction.....................................................................................................4-1
4.2 Local Operation...............................................................................................4-1

High Power DC Electronic Load 63200 Series Operation & Programming Manual
xiv
4.2.1 Setting the Operation Mode.....................................................................4-3
4.2.2 Setting the Program ................................................................................4-9
4.2.3 Running the Program............................................................................4-12
4.2.4 Setting the Specification........................................................................4-12
4.2.5 Setting the Configuration.......................................................................4-13
4.2.6 Recalling Files.......................................................................................4-17
4.2.7 Saving File/Default/Program..................................................................4-17
4.2.8 Going To Local......................................................................................4-18
4.2.9 Setting System & RS-232 Connection...................................................4-18
4.2.10 Online Change Level.............................................................................4-19
5. Basic Information for Programming....................................................................5-1
5.1 Introduction.....................................................................................................5-1
5.1.1 Setting the GPIB Address and RS-232 Parameters.................................5-1
5.1.2 Wire Connection of RS-232.....................................................................5-1
5.2 GPIB Capability of the Electronic Load ...........................................................5-2
5.3 RS-232 in Remote Control..............................................................................5-3
6. Introduction to Programming ..............................................................................6-1
6.1 Basic Definition...............................................................................................6-1
6.2 Numerical Data Formats.................................................................................6-2
6.3 Character Data Formats..................................................................................6-2
6.4 Separators and Terminators............................................................................6-3
7. Language Dictionary............................................................................................7-1
7.1.1 Common Commands ..............................................................................7-1
7.1.2 Common Command Dictionary ...............................................................7-1
7.2 Specific Commands........................................................................................7-4
7.2.1 CONFigure Sub-system..........................................................................7-5
7.2.2 COMMunicate Sub-system....................................................................7-10
7.2.3 CURRENT Sub-system.........................................................................7-12
7.2.4 FETCh Sub-system...............................................................................7-15
7.2.5 LOAD Sub-system.................................................................................7-16
7.2.6MEASure Sub-system...........................................................................7-18
7.2.7 MODE Sub-system................................................................................7-20
7.2.8 POWer Sub-system...............................................................................7-21
7.2.9 PROGram Sub-system..........................................................................7-22
7.2.10 RESistance Sub-system........................................................................7-25
7.2.11 SPECification Sub-system.....................................................................7-26
7.2.12 STATus Sub-system .............................................................................7-28
7.2.13 VOLTage Sub-system...........................................................................7-30
7.2.14 SYSTem Sub-system............................................................................7-32
8. Status Reporting...................................................................................................8-1
8.1 Introduction.....................................................................................................8-1
8.2 Register Information in Common.....................................................................8-1
8.3 Questionable Status........................................................................................8-2
8.4 Output Queue .................................................................................................8-3
8.5 Standard Event Status....................................................................................8-4
8.6 Status Byte Register.......................................................................................8-4
8.7 Service Request Enable Register ...................................................................8-5
9. Command Index....................................................................................................9-1
9.1 Command Summary.......................................................................................9-1
9.2 Parallel Operation...........................................................................................9-4
10. Troubleshooting .............................................................................................10-1

High Power DC Electronic Load 63200 Series Operation & Programming Manual
xv
10.1 Overview.......................................................................................................10-1
10.2 Troubleshooting............................................................................................10-1
11. Precautions for Battery Loading....................................................................11-1
11.1 Measures for Improvement ...........................................................................11-3
11.1.1 Additional Protection Switch..................................................................11-3
11.1.2 Operation..............................................................................................11-3
12. Verification......................................................................................................12-1
12.1 Introduction...................................................................................................12-1
12.2 Hardware Requirements...............................................................................12-1
12.3 Performance Test .........................................................................................12-1
12.3.1 CC Mode Verification ............................................................................12-1
12.3.2 CR Mode Verification ............................................................................12-5
12.3.3 CV Mode Verification.............................................................................12-7
12.3.4 CP Mode Verification...........................................................................12-11
12.3.5 Dynamic & Slew Rate Circuit Testing..................................................12-13
Appendix A List of Functions & Mapped F/W Versions......................................... A-1

General Information
1-1
1. General Information
1.1 Introduction
This manual contains specifications, installation, operation, and programming instructions of
63200 series high power electronic loads. All the machines are tested according to safety
standard EN61010-1: TYPE POLLUTION II and INSTALLTION CATEGORY II.
1.2 Description
The functions of the 63200 series loads are the same except the variations on input voltage,
load current, and power ratings. They can be operated independently in constant current
(CC) mode, constant resistance (CR) mode, constant voltage (CV) mode or constant power
(CP) mode.
Figure 1-1 Front Panel of the Electronic Load
There are three groups of keypads on the electronic load front panel shown in Figure 1-1.
They are System keypad, Function keypad and Entry keypad from left to right.
5.2KW

High Power DC Electronic Load 63200 Series Operation & Programming Manual
1-2
1.3 Overview of Key Features
Local operation on front panel keypad
Remote control via GPIB, RS-232 interface or remote controller (optional)
Photo-couple isolation supplies true floating Load
Automatic fan speed control to reduce audio noise
Constant current (CC), constant resistance (CR), constant voltage (CV) and constant
power (CP) operation modes
Programmable slew rate, load level, load period and conduct voltage (Von)
Programmable dynamic loading with speed up to 20kHz
Minimum input resistance allows load to sink high current even with low input voltage
Selective voltage and current ranges
Remote sensing capability
100 sets of memories to save/recall user-definable setups
10 sets of programs to link files for automatic test
15-bit A/D converter with precision measurement
Short circuit simulation
Automatic GO/NG inspection to confirm the UUT is within spec.
Isolated voltage and current monitoring waveforms output
Isolated external Vdc reference input to control the load current
1.4 Specifications
AC input: 115/230 interchangeable Vac line
Fuse: 3.15A, 250V *
Amplitude: ±10%
Frequency: 47 to 63 Hz
Maximum VA: Please refer to the detail specifications listed below
Note *
The fuses in 63201, 63202 are specified as 2A, 250V. The fuses in 63203,
63204, 63205, 63208, 63209 and 63210 are specified as 2.5A, 250V. The fuse
in 63211 and 63212 is specified as 5A, 250V.
1. The equipment is for indoor use only.
2. The altitude up to 2000 meters is allowed to use the equipment.
3. All specifications are tested under 20°C ∼30°C except stated
otherwise.
4. The range of operation temperature is 0°C ∼40°C.
5. The range of storage temperature is -5°C ∼60°C.
6. The relative operating humidity is 30% to 90%.
7. The relative storage humidity is 10% to 90%.
8. The specifications of DC current accuracy are tested after the input is
applied for 30 seconds.
9. The typical temperature coefficient is 100ppm.
10. The accuracy specification of CR mode: S (Siemens) means 1/Ω.
This equipment is not intended for performing measurements on CAT I,
II, III or IV.
CAT IV – is for measurements performed at the source of the low-voltage
installation.
CAT III – is for measurements performed in the building installation.
CAUTION
