Quick Start Guide
Color Block™ PSU 05B
For a full product manual please visit www.chroma q.com

Color Block PSU-05B Quick Start Guide V1.0 Color Block PSU-05B Quick Start Guide V1.0
1. Overview
The Color Block PSU 05B supplies power and data to a maximum of 5 Color Block DB4 or Color Block 2 LED fixtures
through a XLR4 output. It can be controlled in 16 modes via ANSI E1.11 USITT DMX 512 A, or can operate
independently as a standalone system.
For the purpose of clarification, the Color Block DB4 is a fixture that contains 4 Cells, with each Cell comprising of 3
LEDs; the Color Block 2 is a fixture that contains 48 high output LED set into 12 single optic RGBA clusters that are
grouped into 4 cells.
Note: To ensure proper functionality, Date/Time must be set before operation. Look Store will function when
Date/Time are set. Time is reset when battery is replaced or when the PSU 05B is reset.
2. Safety
The PSU 05B must be hung with a safety cable.
3. Cabling
1. Connect power through a fused male IEC connector with input of 100 240V, 50 60 Hz. The standard fuse is a
5x20mm 3A GMA.
2. Connect input data ANSI E1.11 USITT DMX 512 A from an external source or lighting control console through a
male XLR 5. A pass through connection is available on the female XLR 5.
3. Connect power and output data through a single female XLR 4 to the Color Block DB4 or Color Block 2 fixtures.
A maximum of five daisy chained Color Block fixtures can be connected to the XLR4 output. Return lines are
not required but the total length of each chain must not exceed 60m/~200ft.
Note:
: :
: See diagram in full User Manual available at www.chroma q.com.
4. Control Menu
The Color Block PSU 05B menu items are accessed via the LCD display with the following controls:
•Right hand button (red) = Enter (hold for 2 seconds to save)
•Left hand button (blue) = Exit without saving
•Wheel = Adjusts values or scrolls through menu items
Menu Option Function
DMX Addre
To set DMX start address, press Enter, turn wheel to adjust DMX start address, press Enter for 2
seconds to save.
Control Mode There are 10 DMX controlled modes for the Color Block DB4 system (CB1) an
d 16 DMX controlled
modes for the Color Block 2 system (CB2). Go to “System” and select either “CB1” or “CB2”.
There
are 3 grouping options (Cell, Block, All) with 3 control options for each (FX, HSI and RGB):
Mode Ch Group Sy tem: CB1 Sy tem: CB2
1 67 Variable
7FX + 20xHSI 7FX + 20xHSI
2 60 Cell 20xHSI 20xHSI
3 60 Cell 20xRGB(w/ *Magic Amber) 20xRGB(w/ *Magic Amber)
4 21 Block 6FX + 5xHSI 6FX + 5xHSI
5 15 Block 5xHSI 5xHSI
6 15 Block 5xRGB(with *Magic Amber) 5xRGB(w/ *Magic Amber)
7 9 All 6FX + HSI 6FX + HSI
8 3 All HSI HSI
9 3 All RGB (w/ *Magic Amber) RGB (w/ *Magic Amber)
10 80 Cell Not Available 20xRGBA
11 80 Cell Not Available 20xRGBI (w/ *Magic Amber)
12 20 Block Not Available 5xRGBA
13 20 Block Not Available 5xRGBI (with *Magic Amber)
14 4 All Not Available RGBA
15 4 All Not Available RGBI (w/ *Magic Amber)
16 1 Any Look Select Look Select
When DMX i
Lo t
If DMX is not detected press Enter, turn wheel to selection, press Enter for 2 seconds to save. Off –
will snap to off; Hold – will hold last valid DMX state; Trig – will default to Time Trigger operation
;
Look 1 42 – will snap to the Look of your choice.
Look Store There are 31 internal FX Looks (1
9 are preset). To replay a Look, press Enter and scroll through
the Looks. 2 ways to record or edit a Look:
•
Simple, with DMX console: set to Mode 1. Use DMX console to adjust the internal FX engine.
Scroll to Look Store press Enter, scroll to desired Look location and p
ress Enter for 2
seconds to save.
•Advanced, standalone: (To edit or record without a DMX console, please s
ee the full User
Manual available at www.ac et.com)
Time Trigger Press Enter and scroll to Time Trigger –
press Enter. Press Enter to toggle between Day, Hour (24),
Minutes and Look to be triggered adjust settin
g with scroll wheel. Time Triggers will occur on all 7
days unless specified. The triggers will be activated when the mode “When DMX is Lost” is set to
Trig.
Set Day and
Time
Press Enter. Press Enter to toggle between Day, Hour (24) and Minutes, adjusting
the settings with
scroll wheel and press Enter for 2 seconds to save.
Di pl Backlight To set LCD backlight to go off after 5 seconds, press Enter and
scroll wheel to On (permanently) or
Off (after 5 seconds) and press Enter for 2 seconds to save setting.
Re et to Default
Press Enter for 2 seconds to reset all menu items to factory defaults:
DMX address = 001, Control
Mode = 1 (67 channels HSI+FX), DMX Lost = Hold, Looks = default, Display = On, Frequency =
360, System = CB2
Sy tem To set PSU 05B for the
Color Block DB4 (CB1) or the Color Block 2 (CB2) system press Enter, scroll
wheel to select CB1 or CB2, press Enter for 2 seconds to save.
Frequency 360, 600, 1200 and 2400
frequency settings available for the LED scan rate to be synchronised
with the vi
deo camera. Press Enter, scroll wheel to select frequency, press Enter for 2 seconds to
save.
Sync Mode Press Enter and use the scroll wheel to select Master or Slave. Press Enter for 2 seconds to save.
5. Further Information
Please refer to the Chroma Q Color Block PSU 05B manual for more detailed information. A copy of the manual can
be found at the Chroma Q website – www.chroma q.com – under Support.
Variable Cell Block All Cell Block All
Mode 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Ch1 Group H 1
R 1
Speed H 1
R 1
Speed H 1
R 1
R 1 R 1
R 1 R 1
R 1 R 1
Ch2 Speed S 1
G 1
Fan S 1
G 1
Fan S 1
G 1
G 1 G 1
G 1 G 1
G 1 G 1
Ch3 Fan I 1 B 1
Range I 1 B 1
Range I 1 B 1
B 1 B 1
B 1 B 1
B 1 B 1
Ch4 Range H 2
R 2
Step H 2
R 2
Step A 1 I 1 A 1 I 1 A 1 I 1
Ch5 Step S 2
G 2
Int. FX S 2
G 2
Int. FX R 2 R 2
R 2 R 2
Ch6 Int. FX I 2 B 2
Int.Fan I 2 B 2
Int.Fan G 2 G 2
G 2 G 2
Ch7 Int.Fan H 3
R 3
H 1 H 3
R 3
H 1 B 2 B 2
B 2 B 2
Ch8 H 1 S 3
G 3
S 1 S 3
G 3
S 1 A 2 I 2 A 2 I 2
Ch9 S 1 I 3 B 3
I 1 I 3 B 3
I 1 R 3 R 3
R 3 R 3
Ch10 I 1 H 4
R 4
H 2 H 4
R 4
G 3 G 3
G 3 G 3
Ch11 H 2 S 4
G 4
S 2 S 4
G 4
B 3 B 3
B 3 B 3
Ch12 S 2 I 4 B 4
I 2 I 4 B 4
A 3 I 3 A 3 I 3
Ch13 I 2 H 5
R 5
H 3 H 4
R 5
R 4 R 4
R 4 R 4
and so on up to:
Total 67 60 60 21 15 15 9 3 3 80 80 20 20 4 4
