Chroma PS08 User manual

Chroma-Q™
PS08
User Manual
Version 1.3 December 2006
PN: 139-0025

PS08 User Manual 1 V1.3 December 2006
Disclaimer
The information contained herein is offered in good faith and is believed to be accurate.
However, because conditions and methods of use of our products are beyond our control, this
information should not be used in substitution for customer's tests to ensure that Chroma-Q
products are safe, effective, and fully satisfactory for the intended end use. Suggestions of use
shall not be taken as inducements to infringe any patent. Chroma-Q sole warranty is that the
product will meet the sales specifications in effect at the time of shipment. Your exclusive
remedy for breach of such warranty is limited to refund of purchase price or replacement of any
product shown to be other than as warranted.
Chroma-Q reserves the right to change or make alteration to devices and their functionality
without notice due to our on going research and development.
The Chroma-Q PS08 has been designed specifically for the professional entertainment lighting
industry. Regular maintenance should be performed to ensure that the products perform well in
the entertainment environment.
If you experience any difficulties with any Chroma-Q products please contact your selling
dealer. If your selling dealer is unable to help please contact [e-mail]. If the
selling dealer is unable to satisfy your servicing needs, please contact the following, for full
factory service:
Outside North America: North America:
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
[email protected] supp[email protected]
For further information please visit the Chroma-Q website at www.chroma-q.com.
Chroma-Q is a trademark, for more information on this visit www.chroma-q.com/trademarks.
The rights and ownership of all trademarks are recognised.
Approvals

PS08 User Manual 2 V1.3 December 2006
Table of Contents
1. Product Overview ……………………..………………………….………................ 3
2. Operation……………...…………………………………………………….…………. 3
Power
Data
Termination
Indicators
System Diagram
Load
Power Units
Installation
Compatibility
Control and Power Cables

PS08 User Manual 3 V1.3 December 2006
1. Product overview
The Chroma-Q PS08 supplies power and data to the Chroma-Q range of colour changers and
compatible products (see below). A maximum capacity of 8PU (Power Units), it can be
controlled remotely via ANSI E1.1 USITT DMX 512-A and delivers power and data via 2 XLR-4
outputs.
2. Operation
Power
Connect power through a fused male IEC chassis connector with input power of 100-240V, 50-
60 Hz. The standard fuse is a 5x20mm 3A GMA. It provides 2 circuits of combined 24VDC.
Data
Data input ANSI E1.1 USITT DMX 512-A from an external source or lighting control console
connects through a male XLR-5. A pass through connection is available on the female XLR-5.
Connect power and data from the female XLR-4 outputs of the PS08 to the colour changer
units.
Termination
Data termination is built in at the input.
Indicators
The red LED indicates mains power is present and the green LED indicates a DMX signal is
present.
System Diagram
The PS-08 has been designed for cable loops of up to 60m/200ft per output. Closing the loop
with a return cable will enhance the stability of the power delivered and connected to your data
line.
Load
To simplify the choice of power supply we use the "PU" (Power Unit) to calculate the load
requirements of the Chroma-Q system. The PS08 will supply up to 8 PU's, so you can plug-in 8
Chroma-Q Plus (8 x 1PU = 8PU).
Power Units
Chroma-Q Product Power Unit
Plus 1 PU
Broadway 1 PU
Cascade 1.5 PU
Universal 1.5 PU
M5 1.5 PU
M8 1.5 PU
Moving Mirror 1 PU
DMX Gobo Rotator 0.6 PU

PS08 User Manual 4 V1.3 December 2006
Installation
The Chroma-Q PS08 is designed to be screwed on to set or hung from truss. The L-shaped
bracket has multiple fixing slots to accept standard hook clamps or half couplers. Ensure
adequate ventilation around the holes on the enclosures. Inadequate ventilation may result to
premature failure of the unit.
Compatibility
The Chroma-Q PS08 is compatible with all Chroma-Q Colour Changers - Chroma-Q Plus,
Original, Broadway, Universal, Cascade, M5, M8, Moving Mirror, Twin Gobo Rotator, Twin
Effects Gobo Rotator, Twin DMX Gobo Rotator.
Control and Power Cables
The Chroma-Q utilises an XLR-4 pin cable system. This is used to supply power and data
transfer. Pins 1 and 4 supply 24VDC power and pins 2 and 3 supply ANSI E1.11 USITT
DMX512-A control protocol with a ground drain wire to the connector shell.
Only genuine Tourflex Datasafe Cable is recommended for use of the Chroma-Q colour
changing system.
Damage will occur if the power connections short circuit to the data or ground/shield
connections. When assembling XLR4-pin cables, heat shrink sleeves should be used on each
individual data pin and the drain wire to prevent short circuits.
The XLR-4 cable is wired pin to pin, in the following format:
Pin # Function
1 0V DC
2 Control data minus
3 Control data plus
4 +24V DC
Chassis Ground bonding
The XLR-5 cable is wired pin to pin, in the following format:
Pin # Function
1 Ground (screen)
2 Data minus
3 Data plus
4 Spare data minus
5 Spare data plus
