Chronomite Instant-Flow SR-15L/120 User manual

â
â
â
â
â
â
â
Unlimited hot water
Saves water and energy - 99% energy efficient
Meets all CAL GREEN low flow requirements
Vandal resistant rugged cast aluminum housing
Space saving compact size:
6-1/4" (H) x 9-5/8" x 2-3/4"
Meets applicable building codes
including ADA, UL, IAPMO, UPC, CSA.
Environmentally friendly
PRODUCT FEATURES
®
INSTANT-FLOW SR - LOW FLOW
IFSR-LF 07/28/16
®
Chronomite Instant-Flow SR - Low Flow models are
manufactured to provide reliable point-of-use hot water.
There is no pressure and temperature relief valve
needed (unless required by code), saving time and
money on installation.
Housing is fabricated from
Element assembly is fabricated from Celcon plastic.
Heating coils are nichrome.
Faucet flow controls are supplied with each unit. 3/8”
compression fittings are supplied (standard). Optional
1/2” male NPT water connections available.
rugged cast aluminum alloy.
Member of
U.S.Green
Building Council
Water
Conserving
Product
®
Instant-Flow SR - Low Flow
GUIDE SPECIFICATION
SR - _______ L / _______
AMPS VOLTS
Tankless Water Heater shall be a Chronomite
Laboratories Model
with Amps and Volts
To heat 0.4 gpm at a temperature rise of
°F
Unit shall be provided with Celcon waterways, and
Nichrome heating coils.
OPTIONS
PA 765 ABS Housing (P)
Satin Finish Stainless Stee Housing (SS)
High Polish Finish Stainless Steel (SSP)
Pressure & Temp Relief Valve Assembly (TP)
1/2” Male NPT (NPT08)
Disconnect Switch, Rotary 40A - Lockable
Nema 4X (2095-1)
m
m
m
m
m
m
For the model being selected, please place the
corresponding amps, volts and temperature rise values
in the Guide Specifications to the right.
APPLICATION: commercial, industrial,
residential, public lavatories, kitchen/bar sink
17451 Hurley St. :: City of Industry, CA 91744
Phone [phone] :: 626-937-4270
Fax [phone] :: www.chronomite.com
Complies
with
Standards
for:
OPTIONS
_____
SR-15L / 120 15 120 1800 0.35 31 - -
SR-15L / 277 15 277 4150 0.35 71 38 28
SR-20L / 120 20 120 2400 0.35 41 22 -
SR-20L / 208 20 208 4160 0.35 71 38 28
SR-20L / 240 20 240 4800 0.35 82 44 33
SR-20L / 277 20 277 5540 0.35 95 50 38
SR-30L / 120 30 120 3600 0.35 61 33 25
TEMP RISE @
0.75 GPM
TEMP RISE @
1.00 GPM
MODEL AMPS VOLTS WATTS TEMP RISE @
0.40 GPM
ACTIVATION
GPM
Federal
Public Law
111-380
(No Lead)
LISTED TO:
UL STD 499
CERTIFIED TO:
CAN/CSA STD C22.2 NO. 88

TECHNICAL DIMENSIONS
®
INSTANT-FLOW SR - LOW FLOW
Dimensions: 6-1/4" (H) x 9-5/8" x 2-3/4"
Weight: 5 lbs.
Materials: Rugged cast aluminum housing
Celcon plastic element assembly
with nichrome coils
Housing Color: White
Minimum Operating Flow Rate: 0.35 GPM
Minimum Operating Pressure: 25 PSI
Maximum Operating Pressure 80 PSI
Maximum Pressure: 150 PSI
Maximum Operating Temperature: 160°F
Listing: UL, IAPMO, UPC, ADA, ETL
GENERAL NOTES:
¥240V models when operated at 220V will have approximately a 15%
temperature decrease.
¥120V models when operated 110V will have approximately a 15%
temperature decrease.
1/4"
9-5/8"
5-3/4"
ø 3/16", 4 Mounting Holes
2-3/4"
2"
3-5/16"
Rear Electrical Knock-Out
ø 1" Access Hole
1-1/8"
2-3/4"
10-1/8"
1-1/8"
1-5/16"
HOT
COLD
6-1/4"
1/4"
Front Service Panel
Chronomite Laboratories, Inc.
City of Industry, CA 91744 U.S.A.
®
INSTANT-FLOW SR - LOW FLOW
IFSR-LF 07/28/16
INSTALLATION DIAGRAM
WIRING CONNECTION
"GRD" is
earth
ground.
Conduit
Refer to local
code for wire size
Hot
Hot or
Neutral
ATTENTION:
Unit must be hard wired.
NOTE: Heaters are single phase.
All tests are measured at
the output of the heater.
HOT
COLD
3/8" Hot Water Outlet
Compression
Fittings (2)
Instant-Flow
Heater
J-Box
Mounting Flanges (4)
3/8"
Cold Water
Faucet Feed
5/8" x 3/8" x 3/8"
Three Way Angle
Stop Valve
3/8" Cold Water Inlet
Chronomite Laboratories assumes no responsibility for use of void or suspended data. © Copyright Chronomite Laboratories, Inc.
Member of Morris Group International, City of Industry, CA Please visit www.chronomite.com for most current specifications.
SELECTION SUMMARY
& APPROVAL FOR
MANUFACTURING
Model Number & Options_____________________________________________________________________Quantity_______________
Company_______________________________________________________________________________________________________
Contact_________________________________________________Title____________________________________________________
Signature
(Approval for
Manufacturing)__________________________________________________________________Date ____________________________
PH. 800-447-4962
626-937-4270
FAX [phone]
www.chronomite.com
Notes:
1. Heater to be installed below
the level of all hot water
outlets serviced by the heater
2. Diagram shown with standard
3/8” compression fitting.
Optional 1/2” male NPT water
connections available.
