Cine Gears Ghost-Eye 150M User manual

© 2016 Cine Gears INC. All Rights Reserved
GHOSTEYE M-SERIES
GHOSTEYETM
www.ghosteye.com
WIRELESS HDMI/SDI
VIDEO TRANSMISSION SUITE
MANUAL BOOK

© 2016 Cine Gears INC. All Rights Reserved
Cautions
Warning
Electrical Considerations
This instructional user manual and all the related documents are subject to change at the sole
discretion of SFAIMO (Guangzhou SunFieldAimo Electron Technology Co., Ltd.). SFAIMO inc.
reserves the right to make changes and improvements to any of the products described
without prior notice. Under no circumstances shall SFAIMO be responsible for any loss of
income or any special, incidental, consequential, or indirect damages howsoever caused. For
up-to-date product information, visit https://www.ghosteye.com and navigate to the support
page.
Please read this user introduction manual to become familiar with the features of the Ghost-Eye
series products before operation. Failure to operate the product correctly can result in damage
to the product, or interference with other devices. This is a sophisticated product which must
be operated with caution and common sense. Failure to operate this product properly might
children without direct adult supervision. Do not use with incompatible components, or alter
this product in any way outside of the documents provided by Ghost-Eye. These safety
guidelines contain instructions for installation, operation, and maintenance. It is essential to
read and follow all of the instruction in the manual, and all the notices and warnings regarding
Ghost-Eye series products prior to assembly, setup, or use to prevent any damage or
interference.
1. Do not use this product in extreme heat, cold, dusty, or humid environments.
2. Prevent friction against hard objects.
3. Prevent jarring, such as from falling from high places, or from improper packaging during
transportation.
4. These products are not waterproof; prevent moisture from getting in, on, or around the
unit(s).
5. Do not dismantle, assemble, or otherwise alter the product(s) arbitrarily.
1. When this device is sharing a power supply or battery with other equipment, please make
sure all signal and power cables are well connected before turning on the Ghost-Eye unit
power.
2. When this device is sharing a power supply or battery with other equipment, please make
cables from the Ghost-Eye unit.
3. When this device is sharing a power supply or battery with other equipment, please check the
polarity of the power connectors of all equipment to ensure the inside conductor is positive.
If the polarity of the power connector is unknown, please check the user manual to make sure
the outer conductor of the SDI or HDMI connector is connected to the negative of the power
supply. Otherwise, the equipment will not be able to share the same power supply with the
Ghost-Eye unit.

© 2016 Cine Gears INC. All Rights Reserved
About Cine Gears Inc.
Cine Gears Inc. was originally founded in 2010, specializing in designing and
are custom designed in Canada and China.
With years of development preceding Cinegears opening up for business, we hit the
ground running with our custom designed wireless follow focus systems. Now, we not
only continue to innovate our wireless follow focus systems, but also adopt and
video transmission systems which provide HD video broadcast with virtually no
new technologies, but to improve on our existing designs. At Cinegears we are not
allowing us to expand to our current size, with 3 branches; our original Canadian
branch, a branch in the USA, a branch in China, and service centers around the globe.
You don't need to send your Ghost-Eye products across the globe, just to your
nearest service center! To ensure that you receive world-class service, we have service
centers worldwide. We guarantee that your units are fully functional upon receipt, or
else we will exchange it for a brand new unit within two weeks of purchase. After that,
we will service any issue arising from manufacturing defect for up to 1-year.
Reach us at 1-800-693-8883, or check out our website Cinegears.com.
Cine Gears Inc. Service Guarantee

© 2016 Cine Gears INC. All Rights Reserved
Ghost-Eye HD Wireless Video Transmission Systems
Here at Cine Gears Inc., we supply some of the best wireless HD video transmitters
and receivers available. During the development of Ghost-Eye units, we subjected our
feedback and suggestions in to serious consideration. After careful consideration,
Ghost-Eye products have integrated all the in-demand wireless video transmission
in the form of our unique Ghost-Eye Wireless Video Transmission kits, across the
transmission needs. The most powerful video transmitters and receivers will satisfy
4:4:4 video, support both HD and SD, and can broadcast with less than 1ms latency.

© 2016 Cine Gears INC. All Rights Reserved
GHOSTEYE 150M KIT
GHOSTEYETM
www.ghosteye.com
WIRELESS HDMI/SDI
VIDEO TRANSMISSION SUITE

About the 150M
■
© 2016 Cine Gears INC. All Rights Reserved
Product description
The Ghost-Eye 150M Wireless HDMI/SDI Transmission Suite
utilizes today's most advanced wireless video transmission
technology, broadcasting uncompressed 3G SDI/HDMI HD
video signals with zero delay. The suite includes one transmitter
and one receiver; where the transmitter provides a 3G
SDI/HDMI HD input, the receiver provides 3G SDI//HDMI output.
The Ghost-Eye 150M suite has 2 external stick antennas on the
receiver and 5 internal antennas inside the transmitter. The
transmission suite functions in the 5.1-5.9GHz frequency band
and can be flexibly configured to licensed or ISM band
frequencies around the globe. The side panel of the transmitter
and receiver units have a frequency selection knob that provides
a maximum of 10 workable frequency channels, and supports a
maximum of 4 simultaneous receiver units per transmitter unit.
The wireless suite can accommodate a wide range of DC power
input, including many kinds of camera battery models. The suite
can also sustain ~8kV ESD (HBM, contact discharge), the industry
class metal case and professional heatsink design guarantees
robust reliability.

About the 150M







© 2016 Cine Gears INC. All Rights Reserved
Waterproof custom-fit hard case (310mm*190mm*93mm)
What is included
■

About the 150M
■Features
© 2016 Cine Gears INC. All Rights Reserved
• Uses License-Free 5GHz ISM frequency band, maximum 10 frequency
channels manual selection, coexist with WIFI.
• Highest resolution 10bits color depth 4:4:4, 1080p 60FPS HDMI and
SD/HD/3G SDI input and output, HDMI SDI cross conversion is supported.
• Supports wireless 10 bit HD video with no compression and no delay up to
150m (500ft).
• Uncompromised picture quality with very low latency, <30ms
• Supports point to point, and point to multi points network topology, multiple
receiver is supported with up to 4 receivers .
• Cross compatibility between Cinegears Ghost-eye 100M, 300M, and 400M
transmitter and receivers.
• Support professional audio formats include Dolby True HD, DTS-master, etc.
• AES-128 encryption with air interface HD video data stream.
• Time Code, tally is supported for broadcast or live event streaming
production.
• Wide range power voltage input, compatible with most kinds of camera
batteries, optional Standard V-mount, Anton Bauer, or ¼ bolt Mount battery
plate can be installed.
• Sony F970 battery buckle, convenient for field battery install and replacement.
• All input and output ports have ±8 kV ESD protection level (HBM, contact
discharge).
• Plug & Play - no software is required.
• Professional standard 2-pin LEMO power plugs.
• Each RX (receiver) paired to the unique TX(transmitter) in factory Industrial
metal case, stable and reliable.
• RX built-in directional antenna.
• Signal indicators for wireless power status, Video status and receiver RSSI.
• Water and mist proof, shock proof production case with form insert ready for
traveling .
• CE, FCC, RoHS certified product, safe to use worldwide.

About the 150M
■Diagram - Transmitter
1
1
2
3
4
5
6
7
8
9
Transmitter
1) 1/4-20 Screw Hole
2) RP-SMA male antenna connector
3) Video input indicator, 1 yellow LED
4) Power indicator, 1 green LED
5) Frequency selection knob,0-9
6) SD/HD/3G SDI input
7) HDMI Input
8) DC power switch
9) DC input, LEMO 4-pin B series connector
Video
Power
SDI in
HDMI in
On/O
DC in
0
1
2
4
6
7
8
9
5
3
© 2016 Cine Gears INC. All Rights Reserved

About the 150M
■Diagram - Receiver
1
2
3
4
5
6
7
Receiver
1) 1/4-20 Screw Hole
2) LED status indication(4 blue LED for RSSI &1 LED yellow
for POWER/VIDEO)
3) Frequency selection knob,0-9
4) SD/HD/3G SDI output
5) HDMI output
6) DC power switch
7) DC input, LEMO 4-pin B series connector
1
SDI Out
HDMI Out
On/O
DC In
0
1
2
3
4
6
7
8
9
5
© 2016 Cine Gears INC. All Rights Reserved

About the 150M
■Specifications:
© 2016 Cine Gears INC. All Rights Reserved
Transmitter Receiver
Interface
Supply voltage range
Power consumption < 6.5 W < 6 W
Size
Mass Weight
Input Video Format
Output Video Format /
Input Audio Format SDI embedded 2 channel 24 bit/48KHz /
Output Audio /SDI embedded 2 channel 24 bit/48KHz
Signal Indicator POWER-Green; VIDEO-Yellow POWER-Green; Wireless RSSI-Blue (4
LEDs); POWER/VIDEO-Yellow
Frequency Band 5.1-5.9GHz,configurable with China,
North American, Europe,etc
5.1-5.9GHz,configurable with China,
North American, Europe,etc
Modulation Mode OFDM 16QAM OFDM 16QAM
Transmission Power <18dBm /
Receiver Sensitivity /-75dBm
Occupied Bandwidth 40MHz 40MHz
Temperature Range 0~40°C(operating condition);
-20~60°C(Storage)
0 ~ 40°C (operating condition);
-20~60°C(Storage)
Compliance FCC; CE; RoHS FCC; CE; RoHS
270g 355g
6.5-16.8V DC 6.5-16.8V DC
(L x W x H):115 x 67 x 23mm
excluding antennas (L x W x H): 160 x 110 x 25mm
SDI:3G,HD SD-SDI(Auto/Manual-Selected):
525i, 625i, 720p 50/59.94/60, 1080i 50/59.
94/60, 1080p23.98/24/25/29.9/30/50/59.94/60;
HDMI Type A: 525i, 625i, 720p 50/59.94/60,
1080i 50/59.94/60, 1080p23.98/24/25/29.9
/30/50/59.94/60;
SMPTE 259/274/292/296/372/424/425;
SDI:3G,HD SD-SDI(Auto/Manual-Selected):
525i, 625i, 720p 50/59.94/60, 1080i 50/59.94
/60, 1080p23.98/24/25/29.9/30/50/59.94/60;
HDMI Type A: 525i, 625i, 720p 50/59.94/60,
1080i 50/59.94/60, 1080p23.98/24/25/29.9
/30/50/59.94/60;
SMPTE 259/274/292/296/372/424/425;
SDI Input(BNC Female); HDMI Input
(Type A female); 2 Antenna port(PR-
SMA male); DC input
SDI Output(BNC Female); HDMI Output
(Type A female); DC input
>150 Meter(500 feet) >150 Meter(500 feet)
Video Processing Color
Depth 8bit;10 bit;(4:0:0);(4:2:2);(4:4:4) 8bit;10 bit;(4:0:0);(4:2:2);(4:4:4)
Transmission Cross
Compatibility Ghost-Eye 100M;150M;300M;400M Ghost-Eye 100M;150M;300M;400M
Time Code Every 10 Seconds Every 10 Seconds
Transmission Range
/

150M Installation
Getting started
Transmitter
© 2016 Cine Gears INC. All Rights Reserved
1) Ensure the video source output of the camera is OK, and the HD
monitor is powered on and switched to connected video input port.
2) Ensure 2 TX antennas are installed, preferably with an orthogonal
angle to each other for best RF performance, as in figure below.
3) Ensure all input, output SDI or HDMI cables are connected.
4) Ensure both the transmitter and receiver are powered via battery or
DC input. Then turn power switch of the transmitter and receiver,
respectively, to ‘ON’. The ‘Power’ indicator will then light.
5) Ensure the frequency knobs of transmitter and receiver are set with the
same number, this will make sure the transmitter and receiver work with
same RF frequency.
6) If the camera is on and video input is OK, TX side 'video' indicator will
light

150M Installation
© 2016 Cine Gears INC. All Rights Reserved
5) Ensure the frequency knobs of transmitter and receiver are set with the
same number, this will make sure the transmitter and receiver work with
6) If the camera is on and video input is OK, TX side 'video' indicator will light
7) Before RX finished wireless link with TX, 4 “RSSI” indicators and “Video”
indicators are off; when wireless link is OK, “RSSI” indicators will light first,
and “RSSI” will indicate the received RF signal strength. If the receiver
detects wireless video normal internally from air interface, “Video” indicator
will light. Before that, if SDI or HDMI video out port of the receiver has HD
monitor connected, it will display an OSD of “Link Connecting……” as in the
figure below.
8) The system will spend 20-30 seconds constructing the link, depending on
link strength and the signal channel condition. When wireless link is
established the “RSSI” light will illuminate, indicating the current wireless
signal strength, “Video” indicators will light, and the connected HD monitor
will be playing the real-time video and audio.

150M Installation
© 2016 Cine Gears INC. All Rights Reserved
Frequency selection
■
The wireless suite works in the 5.1-5.9GHz frequency band and can be flexibly
configured to other licensed or ISM bands to accommodate different global
regions. The side panel of the transmitter features a frequency selection knob
(see below illustration), which provides a maximum of 10 workable frequency
channels, and supports a maximum of 4 simultaneous receiver units.
Video
Power
SDI in
HDMI in
On/O
DC in
0
1
2
4
6
7
8
9
5
3
Side panel

© 2016 Cine Gears INC. All Rights Reserved
GHOSTEYE 300M KIT
GHOSTEYETM
www.ghosteye.com
WIRELESS HDMI/SDI
VIDEO TRANSMISSION SUITE

About the 300M
■
© 2016 Cine Gears INC. All Rights Reserved
Product description
The Ghost-Eye 300M Wireless HDMI/SDI Transmission Suite
utilizes today's most advanced wireless video transmission
technology, broadcasting uncompressed 3G SDI/HDMI HD video
signals with zero delay up to 300 meters (line of sight). The suite
includes one transmitter and one receiver; where the transmitter
provides a 3G SDI/HDMI HD input, the receiver provides 3G
SDI//HDMI output. The Ghost-Eye 300M suite has 5 external stick
antennas on the receiver and 2 external stick antennas on the
transmitter. The transmission suite functions in the 5.1-5.9GHz
frequency band and can be flexibly configured to licensed or ISM
band frequencies around the globe. The side panel of the
transmitter and receiver units have a frequency selection knob
that provides a maximum of 10 workable frequency channels,
and supports a maximum of 4 receiver units per transmitter unit.
The wireless suite can accommodate a wide range of DC power
input, including many kinds of camera battery models. The suite
can also sustain ~8kV ESD (HBM, contact discharge), the industry
class metal case and professional heatsink design guarantees
robust reliability.

About the 300M







© 2016 Cine Gears INC. All Rights Reserved
Waterproof custom-fit hard case
What is included
■

About the 300M
■Features
© 2016 Cine Gears INC. All Rights Reserved
• 5GHz ISM Band wireless HD video transmission up to 300m (980ft)
depending on line of sight
• HDMI and SD/HD/3G SDI input and output
• Highest resolution 10bits color depth 4:4:4, 1080p 60FPS HDMI and
SD/HD/3G SDI input and output, HDMI SDI cross conversion is supported.
• Signal status indicators for power, video, and receiver RSSI
• AES-128/256 encryption with air interface HD video data stream
• Supports point to point, and point to multi points network topology, multiple
receiver is supported with up to 4 receivers .
• Cross compatibility between Cinegears Ghost-eye 100M, 300M, and 400M
transmitter and receivers.
• HDMI 1.4 with EDID support
• Uncompromised picture quality with very low latency <30ms
• Wide range power voltage input, suitable for most kinds of camera batteries
• Plug & Play - no software is required
• Standard V-mount, Anton Bauer, or 1/4″ bolt
• All input and output ports with ±8 kV ESD protection level (HBM, contact
discharge)

About the 300M
■Specifications:
© 2016 Cine Gears INC. All Rights Reserved
Transmitter Receiver
Interface
Supply voltage range
Power consumption < 6.5 W < 6W
Size
Mass Weight
Input Video Format
Output Video Format /
Input Audio Format SDI embedded 4channel 24 bit/48KHz /
Output Audio /SDI embedded 4 channel 24 bit/48KHz
Signal Indicator POWER-Green; VIDEO-Yellow POWER-Green; Wireless RSSI-Blue (4
LEDs); POWER/VIDEO-Yellow
Frequency Band 5.1-5.9GHz,configurable with China,
North American, Europe,etc
5.1-5.9GHz,configurable with China,
North American, Europe,etc
Modulation Mode OFDM 16QAM OFDM 16QAM
Transmission Power <21dBm /
Receiver Sensitivity /-75dBm
Occupied Bandwidth 20/40MHz 20/40MHz
Temperature Range 0~40°C(operating condition);
-20~60°C(Storage)
0 ~ 40°C (operating condition);
-20~60°C(Storage)
Compliance FCC; CE; RoHS FCC; CE; RoHS
380g540g
6.5-16.8V DC 6.5-16.8V DC
(L x W x H):120 x 70 x 25mm
excluding antennas (L x W x H): 160 x 110 x 25mm
SDI:3G,HD SD-SDI(Auto/Manual-Selected):
525i, 625i, 720p 50/59.94/60, 1080i 50/59.
94/60, 1080p23.98/24/25/29.9/30/50/59.94/60;
HDMI Type A: 525i, 625i, 720p 50/59.94/60,
1080i 50/59.94/60, 1080p23.98/24/25/29.9
/30/50/59.94/60;
SMPTE 259/274/292/296/372/424/425;
SDI:3G,HD SD-SDI(Auto/Manual-Selected):
525i, 625i, 720p 50/59.94/60, 1080i 50/59.94
/60, 1080p23.98/24/25/29.9/30/50/59.94/60;
HDMI Type A: 525i, 625i, 720p 50/59.94/60,
1080i 50/59.94/60, 1080p23.98/24/25/29.9
/30/50/59.94/60;
SMPTE 259/274/292/296/372/424/425;
SDI Input(BNC Female); HDMI Input
(Type A female); 2 Antenna port(PR-
SMA male); DC input (4 Pin Lemo
Female)
SDI Output(BNC Female); HDMI Output
(Type A female); DC input (4 Pin Lemo
Female)
>150 Meter(500 feet) >150 Meter(500 feet)
Video Processing Color
Depth 8bit;10 bit;(4:0:0);(4:2:2);(4:4:4) 8bit;10 bit;(4:0:0);(4:2:2);(4:4:4)
Transmission Cross
Compatibility Ghost-Eye 100M;150M;300M;400M Ghost-Eye 100M;150M;300M;400M
Time Code Every 10 Seconds Every 10 Seconds
Transmission Range
/

300M Installation
Getting started
© 2016 Cine Gears INC. All Rights Reserved
1) Ensure the video source output of the camera is OK, and the HD
monitor is powered on and switched to connected video input port.
2) Ensure all 7 RX and all 2 TX antennas are installed, preferably with
an orthogonal angle to each other for best RF performance, as in figure
below.
3) Ensure all input, output SDI or HDMI cables are connected.
4) Ensure both the transmitter and receiver are powered via battery or DC
input. Then turn power switch of the transmitter and receiver, respectively,
to ‘ON’.
5) Select the broadcasting channel via the "CH" button on both RX and TX,
ensuring that both are set to the same channel. Press "OK" to confirm
channel selection. When the network connection is established, the LCD
display will display "LINK". When the video begins transmission the LCD
screen will display "VIDEO". At this point the connected monitors will display
the live feed from your camera via the TX to RX connection.
