CIPTA PERNIKA NUSANTARA SMART VMS Application guide

CIPTA
PERNIKA
NUSANTARA
SMART VMS
Device Installation
Versi Hardware : 1.2
Versi Dokumen 1.0.0
Tanggal Rilis 2021/02/13
:
:

3. 1Pcs
4. 10Kabel Antena SBD Meters
5. 10 Meters
Antena SBD dan GPS
Kabel Antena GPS
No Name Preview Account Unit
1. 1Pcs
2. 2 Meters
Armada DLC
Kabel Power/Data
Figure 2
Figure 1
SMART VMS
DEVICE INSTALLATION DOCUMENT
Before we install the device , make sure devices and tools are complete. The following table,
describe devices in cakrawala armada
1. Device List
Device Installation
1
Figure 3
Figure 4
Figure 5

2. Devices Installation
Connect SBD and GPS antenna (picture 3) with SBD and GPS cable (picture 4
and 5), antenna have to face sky and unobstructed by anything
2.1. SBD and GPS Antenna Installation
Device Installation
2
6. 2 PcsFuse 3 Ampere
7. 1 PcsAntena WiFi
Figure 6
Figure 7
ABOVE
DECK
BELOW
DECK
DC 12/24 V

Device Installation
3
Unobstructed view of sky all direction
8.0 m (26.2 ft.) 8.0 m (26.2 ft.)
MIN 15
MIN 15
d
d
RADAR
ABOVE- OK
BELOW-OK
RADAR
ABOVE- OK
BELOW-OK
3’
d = 2 meters for S-Band up to 50kW
d = 4 meters for X & C-Bands up to 50kW
Keep the safe distance of Barracuda ADU from VHF Antenna radiation
and Electromagnetic Interference
Keep the safe distance of Barracuda ADU from RADAR radiation

Device Installation
3. Turn on Devices
After antenna and cable installed, next is install SBD and GPS antenna(picture 4
and 5) to Armada device (picture 1). Warning: Do not connect it reverse.
2.2. Antenna cable installation on device
3.1. Fuse Installation on the device
Device position (picture 1) that have LED facing the front (if device on table), if it’s
on the wall power and cable must facing down. Make sure device position
avoid water, and SOS button easy to reach.
Insert the fuse (Gambar 3) to the device at the fuse holder, make sure device
already got signal GPS and SBD signal corresponding in the operator manual, if
not get signal check again connection GPS and SBD cable
*Fuse installation will make POWER LED lit orange/amber
2.3. Devices Placement
4
EMI (Electromagnetic Interference) from engine components
EMI
BEST
GOOD
BETTER
NOT OK
Fuse
Fuse

Device Installation
4. [OPTIONAL] Integrasi Automatic Identification System (AIS)
3.3. Position service activation by Superadmin
4.1. Connection AIS Data Cable to Armada Data Cable
4.2. AIS service activation by superadmin
Make sure LED connectivity (middle) lit static green, if not wait it to change
green and not blink.
If vessel already using AIS device, look about it’s specification and check the
output. Find the output cable of AIS device, then connect it to Armada data
cable
Make sure connectivity LED (midle) light static green, if not wait till it’s change to
static green.
* If you buy bundle with AIS Transceiver, we don’t need to connect to AIS devices
that installed on vessel. Just connect AIS device that bundle to Armada data
cable.
*If already green and stable, you can call Superadmin to activate the position
service
*After it’s change to green, you can contact Superadmin to activate position
services.
This process is in another document..
5
3.2. Power cable installation with power supply
Connect red (+) and black (-) cable to 12-24V DC power supplied by vessel, then
connect it to devices
*Power cable installation will make power LED lit to green colour
DC 12-24 V
From Source
DC 12-24 V
From Source
A
B
NMEA OUT +
NMEA OUT -
5. [OPSIONAL] Integrasi Armada Data Acquisition Unit (DAQ)
