CIRCLE CIM315A User manual
CIM315A – User Manual [email protected]
Version 0.00.03 www.abcircle.com
Page 2 of 10
Driver installation Procedure
* Driver signed by Microsoft and WHQL, user can install the driver with Window Update. In case that
cannot install via Window Update, please process the below steps to Manual installation
Hardware requires:
CIM315A
PC with OS windows 7 or above
Software requires:
CIR315 Driver Package
Steps:
1. Connect CIM315A to PC
2. On PC, open “Control Panel > System”
3. Open “Device Manager”
4. Select and open “Smart card readers”
if it is shown “Microsoft Usbccid ... (WUDF)”, please continue with step 5)
CIM315A – User Manual [email protected]
Version 0.00.03 www.abcircle.com
Page 3 of 10
if it is shown “CIR315 PICC” and “CIR315 SAM”, mean driver install completed
5. Right click then select “Update driver” (one by one)
6. Select “Browse my computer for driver software…”
7. 選擇 “Let me pick from a list …”
CIM315A – User Manual [email protected]
Version 0.00.03 www.abcircle.com
Page 4 of 10
8. Select “Have Disk…”
9. Select “Browse…”
Select “CIR315.inf”, then press “Open” and “OK”
CIM315A – User Manual [email protected]
Version 0.00.03 www.abcircle.com
Page 5 of 10
10. Select “CIR315 PICC” or “CIR315 SAM” then “Next”
11. Waiting until below screen shown, Press “Close” to complete
12. Double click to ensure the device changed to “CIR315 PICC” and “CIR315 SAM”
13. Done
CIM315A – User Manual [email protected]
Version 0.00.03 www.abcircle.com
Page 6 of 10
Operation Example
Hardware requires:
CIM315A
PC with OS windows 7 or above
ISO14443 Test Card
Software requires:
Any PCSC Application (e.g. APDU.exe)
Steps:
1. Plug in the reader into the PC
2. Open “APDU.exe”
3. Click “1. Select reader”, Chose “Circle CIR315 PICC 0”, then click “OK”
CIM315A – User Manual [email protected]
Version 0.00.03 www.abcircle.com
Page 7 of 10
4. Tag ISO14443 Test card on CIM315A
5. Select “T1”, Message = “90 0a 00 00 01 00 00”
CIM315A – User Manual [email protected]
Version 0.00.03 www.abcircle.com
Page 8 of 10
6. Press “2. Connect”
7. Press “3. Transmit”
CIM315A – User Manual [email protected]
Version 0.00.03 www.abcircle.com
Page 9 of 10
8. Result will be shown on the “Answer from the card:”
CIM315A – User Manual [email protected]
Version 0.00.03 www.abcircle.com
Page 10 of 10
Warning:
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help
Caution
Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the
equipment.
Specific operational use conditions
The end product which used the equipment have to full test and apply an original FCC ID. Any changes or modifications not
expressly approved by the grantee of this device could void the user’s authority to operate the equipment.
Limited modular
This equipment applied as Limited single-modular transmitter, the end product which used this equipment have to full test and
apply an original FCC ID.
RF Exposure warning
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. The End user must follow
the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter. The end product which used this equipment have to full test and apply an
original FCC ID.
Antennas
Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the
equipment. The end product which used this equipment have to full test and apply an original FCC ID.
Label and compliance information
The end product which used this equipment have to full test and apply an original FCC ID. Label should be included and
compliance to the FCC rules with end product’s FCCID.
