CIRCUIT DESIGN STD-302N-R User manual

OG_STD-302N-R-458M_v12e
OPERATION GUIDE
UHF Narrow band radio transceiver
STD-302N-R 458MHz
Operation Guide
Version 1.2 (Oct. 2007)
CIRCUIT DESIGN, INC.,
7557-1 Hotaka, Azumino-city,
Nagano 399-8303 JAPAN
Tel: + [phone]
Fax: + [phone]
e-mail: [email protected]
http://www.cdt21.com

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
2
OPERATION GUIDE
CONTENTS
GENERAL DESCRIPTION & FEATURES ...........................3
SPECIFICATIONS STD-302N-R 458 MHz .......................4
PIN DESCRIPTION .............................................................6
BLOCK DIAGRAM...............................................................8
DIMENSIONS......................................................................9
PLL IC CONTROL .............................................................10
PLL IC control ..................................................................10
How to calculate the setting values for the PLL register ........ 11
Method of serial data input to the PLL.................................12
TIMING CHART.................................................................13
PLL FREQUENCY SETTING REFERENCE .....................15
TEST DTA..........................................................................16
REGULATORY COMPLIANCE INFORMATION ................17
CAUTIONS & WARNINGS ................................................18
REVISION HISTORY.........................................................19

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
3
OPERATION GUIDE
GENERAL DESCRIPTION & FEATURES
General Description
The UHF FM narrow band semi-duplex radio data module STD-302N-R 458 MHz is a RoHS
compliant, high performance transceiver designed for use in industrial applications requiring long
range, high performance and reliability.
The module is designed to meet the requirements of the R&TTE Directive and to be used in the
458MHz band allocated for Short Range Devices in the UK. The applicable technical standard is
EN 300 220.
All high frequency circuits are enclosed inside a robust housing to provide superior resistance
against shock and vibration. A narrow band technique enables high interference rejection and
concurrent operation with multiple modules.
STD-302N-R, a narrowband module with 25 kHz channel steps, achieves high TX/RX switching
speed, making it an ideal RF unit for inclusion in feedback systems.
Features
 10 mW RF power, 3.0 V operation
 Programmable RF channel
 Fast TX/RX switching time
 High sensitivity -119 dBm
 Excellent mechanical durability, high vibration & shock resistance
 RoHS compliance
 EN 300 220 / EN 301 489 compliant
Applications
 Teleme try
Water level monitor for rivers, dams, etc.
Monitoring systems for environmental data such as temperature, humidity, etc.
Transmission of measurement data (pressure, revolution, current, etc) to PC
Security alarm monitoring
 Telecontrol
Industrial remote control systems
Remote control systems for factory automation machines
Control of various driving motors
 Data transmission
RS232/RS485 serial data transmission

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
4
OPERATION GUIDE
SPECIFICATIONS
STD-302N-R 458 MHz All ratings at 25°C unless otherwise noted
General characteristics
Item Units MIN TYP MAX Remarks
Applicable standard EN 300 220-3 Ver.1.1.1
Communication method Simplex, Half-duplex
Emission class F1D
Operating frequency range MHz 458.525 459.175
Operation temperature range °C -20 60 No dew condensation
Storage temperature range °C -30 75 No dew condensation
Aging rate ( / year) ppm -1 1 TX freq., RX Lo freq.
Initial frequency tolerance * ppm -1.5 1.5 TX freq., RX Lo freq. At delivery
Dimensions mm 30 x 50 x 9 mm Not including antenna
Weight g 25 g
* Initial frequency tolerance: At delivery
Initial frequency tolerance is defined as frequency drift at delivery within 1 year after the final adjustment
Electrical specification <Common>
Item MIN TYP MAX Remarks
Oscillation type PLL controlled VCO
Frequency stability (-20 to 60°C) ppm -4 4 Reference frequency at 25 °C
TX/RX switching time ms 15 20 DI/DO
Channel step kHz 25
Data rate bps 2400 9600 DO/DI
Max. pulse width ms 15 DO/DI
Min. pulse width us 100 DO/DI
Data polarity Positive DO/DI
PLL reference frequency MHz 21.25 TCXO
PLL response ms 30 60 from PLL setting to LD out
Antenna impedance Ω50 Nominal
Operating voltage V 3.0 5.5
TX consumption current mA 45 50 Vcc = 3.0 V
RX consumption current mA 26 30 Vcc = 3.0 V
Transmitter part
Item MIN TYP MAX Remarks
RF output power mW 10 Conducted 50 Ω
Deviation kHz +/- 2.35 +/- 2.75 +/- 3.15 PN9 9600 bps
DI input level V 0 5.5 L= GND, H = 3 V- Vcc
Residual FM noise kHz 0.17 DI=L, LPF=20 kHz
-54
47-74, 87.5-118, 174-230, 470-862 MHz
-36 Other frequencies below 1000 MHz
Spurious emission dBm
-30 Frequencies above 1000 MHz
Adjacent CH power dBm -37 PN9 9600 bps CH25kHz/BW16kHz

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
5
OPERATION GUIDE
Receiver part
Item MIN TYP MAX Remarks
Receiver type Double superheterodyne
1st IF frequency MHz 21.7
2nd IF frequency kHz 450
Maximum input level dBm 10
BER (0 error/2556 bits) *1 dBm -107 -110 At 458.85MHz PN 9 9600bps
BER (1 % error) *2 dBm -116 At 458.85MHz PN 9 9600bps
Sensitivity 12dB/ SINAD dBm -119 fm1 k/ dev 2.75 kHz CCITT
65 1 st Mix, 2 signal method, 1 % error
Spurious response rejection *3 dB 60 2 nd Mix, 2 signal method, 1 % error
Adjacent CH selectivity *3 dB 50 +/- 25 kHz, 2 signal method, 1 % error
Intermodulation *4 dB 50 2 signal method, 1 % error
DO output level V 0 2.8 L = GND H = 2.8 V
30 50 CH shift of 25 kHz (from PLL setup)
RSSI rising time ms 50 70 When power ON (from PLL setup)
50 100 CH shift of 25 kHz (from PLL setup)
Time until valid Data-out *5 ms 70 120 When power ON (from PLL setup)
-57 Below 1000 MHz
Spurious radiation dBm -47 Above 1000 MHz
RSSI mV 180 230 280 With -113 dBm at 458.85MHz
Specifications are subject to change without prior notice
Notice
 The time required until a stable DO is established may get longer due to the possible frequency drift
caused by operation environment changes, especially when switching from TX to RX, from RX to TX and
changing channels. Please make sure to optimize the timing. The recommended preamble is more than
20 ms.
 Antenna connection is designed as pin connection.
 RF output power, sensitivity, spurious emission and spurious radiation levels may vary with the pattern
used between the RF pin and the coaxial connection. Please make sure to verify those parameters
before use.
 The feet of the shield case should be soldered to the wide GND pattern to avoid any change in
characteristics.
Notes about the specification values
*1 BER: RF level where no error per 2556 bits is confirmed with the signal of PN9 and 9600 bps.
*2 BER (1 % error): RF level where 1% error per 2556 bits is confirmed with the signal of PN9 and 9600 bps.
*3 Spurious response, CH selectivity: Jamming signal used in the measurement is unmodulated.
*4 Intermodulation: Ratio between the receiver input level with BER 1% and the signal level (PN9 9600 bps)
added at the points of 'Receiving frequency - 200 kHz ' + ' Receiving frequency -100kHz' with which BER 1%
is achieved.
*5 Time until valid Data-out: Valid DO is determined at the point where Bit Error Rate meter starts detecting
the signal of 9600bps, 1010 repeated signal.
All specifications are specified based on the data measured in a shield room using the PLL setting controller
board prepared by Circuit Design.
Measuring equipment:
SG=ANRITUS communication analyzer MT2605
Spectrum analyzer = ANRITSU MS2663G
BER measure = ANRITSU MP1201G

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
6
OPERATION GUIDE
PIN DESCRIPTION
Pin name I/O Description Equivalent circuit
RF I/O
RF input terminal
Antenna impedance nominal 50 Ω
GND I
GROUND terminal
The GND pins and the feet of the shield case
shoud be connected to the wide GND
pattern.
VCC I
Power supply terminal
DC 3.0 to 5.5 V
TXSEL I
TX select terminal
GND = TXSEL active
To enable the transmitter circuits, connect
TXSEL to GND and RXSEL to OPEN or 2.8
V.
RXSEL I
RX select terminal
GND= RXSEL active
To enable the receiver circuits, connect
RXSEL to GND and TXSEL to OPEN or 2.8
V.
AF O
Analogue output terminal
There is DC offset of approx. 1 V.
Refer to the specification table for amplitude
level.
CLK I
PLL data setting input terminal
Interface voltage H = 2.8 V, L = 0 V
DATA I
PLL data setting input terminal
Interface voltage H = 2.8 V, L = 0 V
LE I
PLL data setting input terminal
Interface voltage H = 2.8 V, L = 0 V
100nH
47P
RF
GND
SAW FILTER
REG
VCC
47P
10µ
22µ 47P
2.8V
2.8V
10
TXSEL
2.8V 20K
2.8V
10
RXSEL
2.8V 20K
MB15E03
CLK
2K
MB15E03
DATA
2K
MB15E03
LE
2K

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
7
OPERATION GUIDE
LD O
PLL lock/unlock monitor terminal
Lock = H (2.8 V), Unlock = L (0 V)
RSSI O
Received Signal Strength Indicator terminal
DO O
Data output terminal
Interface voltage: H=2.8V, L=0V
DI I
Data input terminal
Interface voltage: H=2.8V to Vcc, L=0V
Input data pulse width Min.100 µs Max. 15
ms
2K
MB15E03
102
2.8V
LD
102
DO
2K
10K
2.8V

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
8
OPERATION GUIDE
BLOCK DIAGRAM <STD-302N-R 458 MHz>

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
9
OPERATION GUIDE
DIMENSIONS

.
OG_STD-302N-R-458M_v12e Circuit Design, Inc.
10
OPERATION GUIDE
PLL IC CONTROL
 PLL IC control
OSCin
OSCout
Vp
VCC
Do
GND
Xf in
Fin
R
PSTD-302
Control pin name
ZC
PS
LE
Data
2kohm
MB15E03SL
Reference Oscillator
LPF
Voltage Controled
Oscillator
VCO
PLL
CLK
DATA
LE
LD
LD/f out
+2.8v
#:Control v oltage = +2.8v
21.25MHz
up to 1200MHz
Figure 1
CLK
2kohm
2kohm
2kohm
STD-302N-R is equipped with an internal PLL frequency synthesizer as shown in Figure 1. The operation of
the PLL circuit enables the VCO to oscillate at a stable frequency. Transmission frequency is set externally by
the controlling IC. STD-302N-R has control terminals (CLK, LE, DATA) for the PLL IC and the setting data is
sent to the internal register serially via the data line. Also STD-302N-R has a Lock Detect (LD) terminal that
shows the lock status of the frequency. These signal lines are connected directly to the PLL IC through a 2 kΩ
resistor.
The interface voltage of STD-302N-R is 2.8 V, so the control voltage must be the same.
STD-302N-R comes equipped with a Fujitsu MB15E03SL PLL IC. Please refer to the manual of the PLL IC.
The following is a supplementary description related to operation with STD-302N-R. In this description, the
same names and terminology as in the PLL IC manual are used, so please read the manual beforehand.

.
OG_STD-302N-R-458M_v12e Circuit Design, Inc.
11
OPERATION GUIDE
 How to calculate the setting values for the PLL register
The PLL IC manual shows that the PLL frequency setting value is obtained with the following equation.
fvco = [(M x N)+A] x fosc / R -- Equation 1
fvco : Output frequency of external VCO
M: Preset divide ratio of the prescaler (64 or 128)
N: Preset divide ratio of binary 11-bit programmable counter (3 to 2,047)
A: Preset divide ratio of binary 7-bit swallow counter (0 ≤A ≤127 A<N))
fosc: Output frequency of the reference frequency oscillator
R: Preset divide ratio of binary 14-bit programmable reference counter (3 to 16,383)
With STD-302N-R, there is an offset frequency (foffset) 21.7 MHz for the transmission RF channel frequency fch.
Therefore the expected value of the frequency generated at VCO (fexpect) is as below.
fvco = fexpect = fch – foffset ---- Equation 2
The PLL internal circuit compares the phase to the oscillation frequency fvco. This phase comparison
frequency (fcomp) must be decided. fcomp is made by dividing the frequency input to the PLL from the reference
frequency oscillator by reference counter R. STD-302N-R uses 21.25 MHz for the reference clock fosc. fcomp is
one of 6.25 kHz, 12.5 kHz or 25 kHz.
The above equation 1 results in the following with n = M x N + A, where “n” is the number for division.
fvco=n*fcomp ---- Equation 3 n = fvco/fcomp ---- Equation 4 note: fcomp = fosc/R
Also, this PLL IC operates with the following R, N, A and M relational expressions.
R=fosc/fcomp ---- Equation 5 N = INT (n / M) ---- Equation 6 A = n - (M x N) ---- Equation 7
INT: integer portion of a division.
As an example, the setting value of RF channel frequency fch 869.725 MHz can be calculated as below.
The constant values depend on the electronic circuits of STD-302N-R.
Conditions: Channel center frequency: fch = 869.725 MHz
Constant: Offset frequency: foffset=21.7 MHz
Constant: Reference frequency: fosc=21.25 MHz
Set 25 kHz for Phase comparison frequency and 64 for Prescaler value M
The frequency of VCO will be
fvco = fexpect = fch - foffset = 869.725 –21.7 = 848.025MHz
Dividing value “n” is derived from Equation 4
n = fvco / fcomp = 848.025MHz/25kHz = 33921
Value “R” of the reference counter is derived from Equation 5.
R = fosc/fcomp = 21.25MHz/25kHz = 850
Value “N” of the programmable counter is derived from Equation 6.
N = INT (n/M) = INT(33921/64) = 530
Value “A“ of the swallow counter is derived from Equation 7.
A = n – (M x N) = 33921 – 64 x 530 = 1
The frequency of STD-302N-R is locked at a center frequency fch by inputting the PLL setting values N, A and
R obtained with the above equations as serial data. The above calculations are the same for the other
frequencies.
Excel sheets that contain automatic calculations for the above equations can be found on our web site
(www.cdt21.com/).
The result of the calculations is arranged as a table in the CPU ROM. The table is read by the channel
change routine each time the channel is changed, and the data is sent to the PLL.

.
OG_STD-302N-R-458M_v12e Circuit Design, Inc.
12
OPERATION GUIDE
 Method of serial data input to the PLL
After the RF channel table plan is decided, the data needs to be allocated to the ROM table and read from
there or calculated with the software.
Together with this setting data, operation bits that decide operation of the PLL must be sent to the PLL.
The operation bits for setting the PLL are as follows. These values are placed at the head of the reference
counter value and are sent to the PLL.
1. CS: Charge pump current select bit
CS = 0 +/-1.5 mA select VCO is optimized to +/-1.5 mA
2. LDS: LD/fout output setting bit
LDS = 0 LD select Hardware is set to LD output
3. FC: Phase control bit for the phase comparator
FC = 1 Hardware operates at this phase
The PLL IC, which operates as shown in the block diagram in the manual, shifts the data to the 19-bit shift
register and then transfers it to the respective latch (counter, register) by judging the CNT control bit value
input at the end.
1. CLK [Clock]: Data is shifted into the shift register on the rising edge of this clock.
2. LE [Load Enable]: Data in the 19-bit shift register is transferred to respective latches on the rising edge of
the clock. The data is transferred to a latch according to the control bit CNT value.
3. Data [Serial Data]: You can perform either reference counter setup or programmable counter setup first.
CS
Inv alid Data
LDS FC SW R14 R13 CNT=1
R1
1st data
2nd data N11 N10 N9 N8 N7 N6 CNT=0A1
1st Data 2nd Data
DATA
CLK
LE
MSB LSB
t6
t5t4
t3t2t1
t0
#: t0,t5 >= 100 ns t1,t2,t6 >= 20 ns t3,t4 >= 30 ns
#: Keep the LE terminal at a low level, w hen w rite the data to the shift resister.
STD-302
terminal name
Figure 2

.
OG_STD-302N-R-458M_v12e Circuit Design, Inc.
13
OPERATION GUIDE
TIMING CHART
Control timing in a typical application is shown in Figure 3.
Initial setting of the port connected to the radio module is performed when power is supplied by the CPU and
reset is completed. MOS-FET for supply voltage control of the radio module, RXSEL and TXSEL are set to
inactive to avoid unwanted emissions. The power supply of the radio module is then turned on. When the
radio module is turned on, the PLL internal resistor is not yet set and the peripheral VCO circuit is unstable.
Therefore data transmission and reception is possible 40 ms after the setting data is sent to the PLL at the
first change of channel, however from the second change of channel, the circuit stabilizes within 20 ms and is
able to handle the data.
Changing channels must be carried out in the receive mode. If switching is performed in transmission mode,
unwanted emission occurs.
If the module is switched to the receive mode when operating in the same channel, (a new PLL setting is not
necessary) it can receive data within 5 ms of switching*1. For data transmission, if the RF channel to be used
for transmission is set while still in receiving mode, data can be sent at 5 ms after the radio module is
switched from reception to transmission*2.
Check that the Lock Detect signal is “high” 20 ms after the channel is changed. In some cases the Lock
Detect signal becomes unstable before the lock is correctly detected, so it is necessary to note if processing
of the signal is interrupted. It is recommended to observe the actual waveform before writing the process
program.
*1 DC offset may occur due to frequency drift caused by ambient temperature change. Under conditions below
-10 °C, 10 to 20 ms delay of DO output is estimated. The customer is urged to verify operation at low
temperature and optimize the timing.
*2 Sending ‘10101…..’ preamble just after switching to transmission mode enables smoother operation of the
binarization circuit of the receiver.
For 9600 bps, a preamble of ‘11001100’ is effective.
Recommended preamble length: -20 °C - +60 °C: 15 ms (Typical)
Remark
For details about PLL control and the sample programs, see our technical document ‘STD-302N-R interface
method’

.
OG_STD-302N-R-458M_v12e Circuit Design, Inc.
14
OPERATION GUIDE
Receiv e mode
RXSEL
STD-302
Po w e r o n
TXSEL
CPU c ontr ol,
CH change
&
Data rec.
Timing
Data transmit
#:6 10 to 20 ms later, the receiver can receive the data after changing the channel.
Data #:6
LD
CH CH Data #:7
5 ms
10 to 20 ms
#:4 RFchannel change must be perf ormed in receiving mode.
#:7 5 ms later, the data can be received if the RF channel is not changed.
5 ms #:4
40 ms
CPU
Po w e r o n
CH Data #:5
5 ms 5 ms
Check LD signal
Check LD signal
Normal statusStatus immediately af ter pow er comes on.
Channel change No channel change
#:4
#:2 Initialize the port connected to the module.
#:3 Supply pow er to the module af ter initializing CPU.
#:1 Reset control CPU
#:1 #:2 #:4
#:3
#:5 40 ms later, the receiver can receive the data after changing the channel..
Figure 3: Timing diagram for STD-302
activ e period
Receiv e mode
active period
Receiv e mode
activ e period
Tran sm it m o de
activ e
Check LD signal
Activ e period
Tran s m it m ode
activ e
Tran sm it m o de
activ e

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
15
OPERATION GUIDE
PLL FREQUENCY SETTING DATA REFERENCE
458 MHz ISM band (458.525 – 459.175 MHz)
Channel Frequency
FCH
Expect
Frequency
FEXPECT
Lock
Frequency
FVCO
No.
(MHz) (MHz) (MHz)
Number of
Division n
Programmable
Counter N
Swallow
Counter A
0 458.5250 436.8250 436.8250 17473 273 1
1 458.5500 436.8500 436.8500 17474 273 2
2 458.5750 436.8750 436.8750 17475 273 3
3 458.6000 436.9000 436.9000 17476 273 4
4 458.6250 436.9250 436.9250 17477 273 5
5 458.6500 436.9500 436.9500 17478 273 6
6 458.6750 436.9750 436.9750 17479 273 7
7 458.7000 437.0000 437.0000 17480 273 8
8 458.7250 437.0250 437.0250 17481 273 9
9 458.7500 437.0500 437.0500 17482 273 10
10 458.7750 437.0750 437.0750 17483 273 11
11 458.8000 437.1000 437.1000 17484 273 12
12 458.8250 437.1250 437.1250 17485 273 13
13 458.8500 437.1500 437.1500 17486 273 14
14 458.8750 437.1750 437.1750 17487 273 15
15 458.9000 437.2000 437.2000 17488 273 16
16 458.9250 437.2250 437.2250 17489 273 17
17 458.9500 437.2500 437.2500 17490 273 18
18 458.9750 437.2750 437.2750 17491 273 19
19 459.0000 437.3000 437.3000 17492 273 20
20 459.0250 437.3250 437.3250 17493 273 21
21 459.0500 437.3500 437.3500 17494 273 22
22 459.0750 437.3750 437.3750 17495 273 23
23 459.1000 437.4000 437.4000 17496 273 24
24 459.1250 437.4250 437.4250 17497 273 25
25 459.1500 437.4500 437.4500 17498 273 26
26 459.1750 437.4750 437.4750 17499 273 27
Parameter name Value
Phase Comparing Frequency Fcomp [kHz] 25
Start Channel Frequency Fch [MHz] 458.5250
Channel Step Frequency [kHz] 25
Number of Channel 27
Prescaler M 64
Parameter name Value
Reference Frequency Fosc [MHz] 21.25
Offset Frequency Foffset [MHz] 21.7
: For data input
: Result of calculation
: Fixed value
Parameter name Value
Reference Counter R 850
Programmable Counter N Min. Value 273
Programmable Counter N Max. Value 273
Swallow Counter A Min. Value 1
Swallow Counter A Max. Value 27

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
16
OPERATION GUIDE
Measurement is done with the PLL setting control
board prepared by Circuit Design.
Purple line shows typical value.
Yellow and black line shows maximum and
minimum of the specification.
TEST DATA
RSSI typical output level characteristic (Purple line)
Measurement frequency: 458MHz / Modulation: unmodulated
25°C +/- 5°C
RSSI vs dBm
0
100
200
300
400
500
600
700
800
-120 -115 -110 -105 -100 -95 -90 -85 -80 -75 -70 -65 -60 -55 -50 -45 -40 -35 -30 -25 -20
dBm
mV
MIN
RSSI(mV)
MAX
Sig (dBm) MIN RSSI (mV) MAX
-120 134 184 234
-115 168 218 268
-110 202 252 302
-105 238 288 338
-100 270 320 370
-95 306 356 406
-90 346 396 446
-85 380 430 480
-80 410 460 510
-75 444 494 544
-70 482 532 582
-65 516 566 616
-60 558 608 658
-55 586 636 686
-50 596 646 696
-45 596 646 696
-40 598 648 698
-35 600 650 700
-30 600 650 700
-25 600 650 700
-20 600 650 700

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
17
OPERATION GUIDE
Regulatory compliance information
Regulatory compliance of the STD-302N-R 458MHz
The STD-302N-R 458MHz is designed to meet the requirements of the R&TTE Directive and to be used in the
458MHz band allocated for Short Range Devices in the UK. The applicable technical standard is EN 300 220.
Cautions related to regulatory compliance when embedding the STD-302N-R 458MHz
1. Antenna
The STD-302N-R 458MHz is supplied without a dedicated antenna and the user is required to provide an
antenna. Circuit Design’s technical verification of the STD-302N-R 458MHz was performed using Circuit
Design’s standard antenna (ANT-LEA-01, 1/4 lambda lead antenna). Please make sure to use an antenna
which can meet the regulatory requirement.
2. Frequency channel
The frequency channel of the STD-302N-R 458MH is programmable between 458.825 MHz to 459.175 MHz,
with 25 kHz spacing. Please make sure to use a frequency plan which can meet the frequency channel
requirements applicable to your application in the relevant regulations.
3. Duty cycle
The STD-302N-R 458MHz continuously emits carrier signals when power is supplied. The user must design the
final product to meet the requirements of the duty cycle as provided in the relevant regulations.
4. Supply voltage
The STD-302N-R 458MHz should be used within the specified voltage range. (3.0 V to 5.5 V).
5. Enclosure
To fulfill the requirements of EMC and safety requirements, the STD-302N-R 458MHz should be mounted on
the circuit boards of the final products and must be enclosed in the cases of the final products. No surface of the
STD-302N-R should be exposed.
Conformity assessment of the final product
The STD-302N-R 458MHz is designed to meet the requirements of the R&TTE Directive, however the conformity
assessment to the applicable standards has not been performed .
The manufacturer of the final product is responsible for the conformity assessment procedures of the final product
in accordance with the R&TTE Directive and the UK regulation.
Notification of the final product
The notification required by R&TTE Directive Article 6 (4) is not necessary if the final product is used in the
harmonized frequency band and is classified as Class-1 equipment. If the final product is not used in the
harmonized frequency band and is classified as Class-2 equipment, the manufacturer of the final product has a
duty to notify the relevant radio regulatory authorities in the countries where the final product is sold.
* A list of Class-1 equipment is available at http://www.ero.dk/.
Exemption clause
Circuit Design, Inc does not guarantee the accuracy of the above mentioned information about the conformity
assessment and notification of the final product. Directives, technical standards, principles of operation and the like
may be interpreted differently by the authorities in each country. Also the national laws and restrictions vary with the
country. In case of doubt or uncertainty, we recommend that you check with the authorities or official certification
organizations of the relevant countries.

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
18
OPERATION GUIDE
Cautions
•As the radio module communicates using electronic radio waves, there are cases where transmission will be
temporarily cut off due to the surrounding environment and method of usage. The manufacturer is exempt from
all responsibility relating to resulting harm to personnel or equipment and other secondary damage.
•Do not use the equipment within the vicinity of devices that may malfunction as a result of electronic radio waves
from the radio module.
•The manufacturer is exempt from all responsibility relating to secondary damage resulting from the operation,
performance and reliability of equipment connected to the radio module.
•Communication performance will be affected by the surrounding environment, so communication tests should be
carried out before actual use.
•Ensure that the power supply for the radio module is within the specified rating. Short circuits and reverse
connections may result in overheating and damage and must be avoided at all costs.
•Ensure that the power supply has been switched off before attempting any wiring work.
•The case is connected to the GND terminal of the internal circuit, so do not make contact between the '+' side of
the power supply terminal and the case.
•When batteries are used as the power source, avoid short circuits, recharging, dismantling, and pressure.
Failure to observe this caution may result in the outbreak of fire, overheating and damage to the equipment.
Remove the batteries when the equipment is not to be used for a long period of time. Failure to observe this
caution may result in battery leaks and damage to the equipment.
•Do not use this equipment in vehicles with the windows closed, in locations where it is subject to direct sunlight,
or in locations with extremely high humidity.
•The radio module is neither waterproof nor splash proof. Ensure that it is not splashed with soot or water. Do not
use the equipment if water or other foreign matter has entered the case.
•Do not drop the radio module or otherwise subject it to strong shocks.
•Do not subject the equipment to condensation (including moving it from cold locations to locations with a
significant increase in temperature.)
•Do not use the equipment in locations where it is likely to be affected by acid, alkalis, organic agents or corrosive
gas.
•Do not bend or break the antenna. Metallic objects placed in the vicinity of the antenna will have a great effect
on communication performance. As far as possible, ensure that the equipment is placed well away from metallic
objects.
•The GND for the radio module will also affect communication performance. If possible, ensure that the case
GND and the circuit GND are connected to a large GND pattern.
Warnings
•Do not take a part or modify the equipment.
•Do not remove the product label (the label attached to the upper surface of the module.) Using a module from
which the label has been removed is prohibited.
Circuit Design, Inc. All right reserved
No part of this document may be copied or distributed in part or in whole without the prior written consent o
f
Circuit Design, Inc.
Customers are advised to consult with Circuit Design sales representatives before ordering.
Circuit Design, Inc. believes the furnished information is accurate and reliable. However, Circuit Design, Inc.
reserves the right to make changes to this product without notice.

OG_STD-302N-R-458M_v12e Circuit Design, Inc.
19
OPERATION GUIDE
Revision history
Version Date Description Remark
1.0 Jul. 2006 STD-302N-R 458MHz The first issue
1.1 Feb. 2007 Correction Page 6 AF IO status “I” -> “O”
1.2 Oct. 2007 Replace drawing of product Page 9
