Circutor CVM-E3-MINI User manual

INSTRUCTION MANUAL
(M170B01-03-22B)
Power analyzer
CVM-E3-MINI

2
CVM-E3-MINI
Instruction Manual

SAFETY PRECAUTIONS
DISCLAIMER
CIRCUTOR S.A.U. reserves the right to make modifications to the device or the unit specifications set
out in this instruction manual without prior notice.
CIRCUTOR S.A.U. on its web site, supplies its customers with the latest versions of the device specifi-
cations and the most updated manuals.
www.circutor.com
CIRCUTOR S.A.U. recommends using the original cables and accessories that are sup-
plied with the device.
DANGER
Warns of a risk, which could result in personal injury or material damage.
ATTENTION
Indicates that special attention should be paid to a specific point.
Follow the warnings described in this manual with the symbols shown below.
If you must handle the unit for its installation, start-up or maintenance, the following should be
taken into consideration:
Incorrect handling or installation of the device may result in injury to personnel as well as damage to
the device. In particular, handling with voltages applied may result in electric shock, which may cause
death or serious injury to personnel. Defective installation or maintenance may also lead to the risk of
fire.
Read the manual carefully prior to connecting the device. Follow all installation and maintenance in-
structions throughout the device’s working life. Pay special attention to the installation standards of
the National Electrical Code.
Refer to the instruction manual before using the device
In this manual, if the instructions marked with this symbol are not respected or carried out correctly, it can result
in injury or damage to the device and/or installations.
CIRCUTOR S.A.U. reserves the right to modify features or the product manual without prior notification.
3
Instruction Manual
CVM-E3-MINI

CONTENTS
SAFETY PRECAUTIONS .........................................................................................................................................................3
DISCLAIMER ..........................................................................................................................................................................3
CONTENTS.............................................................................................................................................................................4
REVISION LOG .......................................................................................................................................................................7
SYMBOLS...............................................................................................................................................................................7
1. VERIFICATION UPON RECEPTION....................................................................................................................................8
2. PRODUCT DESCRIPTION .................................................................................................................................................8
3. DEVICE INSTALLATION.................................................................................................................................................. 10
3.1.- PRIOR RECOMMENDATIONS ..................................................................................................................................10
3.2.- INSTALLATION ........................................................................................................................................................11
3.3.- PANEL MOUNTING ACCESSORY (72 x 72 mm) .......................................................................................................11
3.4.- CVM-E3-MINI-FLEX: ROGOWSKI SENSORS........................................................................................................... 13
3.5.- DEVICE TERMINALS............................................................................................................................................... 14
3.5.1.- MODELS CVME3MINIITF AND CVME3MINIMC ...................................................................................... 14
3.5.2.- MODEL CVME3MINIFLEX............................................................................................................................ 14
3.5.3.- MODELS CVME3MINIITFWiEth AND CVME3MINIMCWiEth ............................................................... 15
3.5.4.- MODEL CVME3MINIFLEXWiEth ................................................................................................................ 15
3.6.- CONNECTION DIAGRAM......................................................................................................................................... 16
3.6.1.- MEASURING THREEPHASE NETWORKS WITH A 4WIRE CONNECTION: CVME3MINIITF AND CVME3
MINIITFWiEth ........................................................................................................................................................... 16
3.6.2.- MEASURING THREEPHASE NETWORKS WITH A 4WIRE CONNECTION: CVME3MINIMC AND CVME3
MINIMCWiEth. ......................................................................................................................................................... 17
3.6.3.- MEASURING THREEPHASE NETWORKS WITH A 4WIRE CONNECTION: CVME3MINIFLEX AND
CVME3MINIFLEXWiEth.........................................................................................................................................18
3.6.4.- MEASURING THREEPHASE NETWORKS WITH A 3WIRE CONNECTION: CVME3MINIITF AND
CVME3MINIITFWiEth............................................................................................................................................ 19
3.6.5.- MEASURING THREEPHASE NETWORKS WITH A 3WIRE CONNECTION: CVME3MINIMC AND
CVME3MINIMCWiEth ........................................................................................................................................... 20
3.6.6.- MEASURING THREEPHASE NETWORKS WITH A 3WIRE CONNECTION: CVME3MINIFLEX AND
CVME3MINIFLEXWiEth ........................................................................................................................................ 21
3.6.7.- MEASURING THREEPHASE NETWORKS WITH A 3WIRE CONNECTION AND TRANSFORMERS WITH AN
ARON CONNECTION: CVME3MINIITF AND CVME3MINIITFWiEth ...................................................................22
3.6.8.- MEASURING THREEPHASE NETWORKS WITH A 3WIRE CONNECTION AND TRANSFORMERS WITH AN
ARON CONNECTION: CVME3MINIMC AND CVME3MINIMCWiEth ...................................................................23
3.6.9.- MEASURING TWOPHASE NETWORKS WITH A 3WIRE CONNECTION: CVME3MINIITF AND CVME3MI
NIITFWiEth ...............................................................................................................................................................24
3.6.10.- MEASURING TWOPHASE NETWORKS WITH A 3WIRE CONNECTION: CVME3MINIMC AND CVME3
MINIMCWiEth...........................................................................................................................................................25
3.6.11.- MEASURING TWOPHASE NETWORKS WITH A 3WIRE CONNECTION: CVME3MINIFLEX AND
CVME3MINIFLEXWiEth.........................................................................................................................................26
3.6.12. MEASURING SINGLEPHASE NETWORKS, PHASE TO PHASE, WITH A 2WIRE CONNECTION:
CVME3MINIITF AND CVME3MINIITFWiEth .....................................................................................................27
3.6.13.- MEASURING SINGLEPHASE NETWORKS, PHASE TO PHASE, WITH A 2WIRE CONNECTION:
CVME3MINIMC AND CVME3MINIMCWiEth .....................................................................................................28
3.6.14.- MEASURING SINGLEPHASE NETWORKS, PHASE TO PHASE, WITH A 2WIRE CONNECTION:
CVME3MINIFLEX AND CVME3MINIFLEXWiEth ...............................................................................................29
3.6.15.- MEASURING SINGLEPHASE NETWORKS, PHASE TO NEUTRAL, WITH A 2WIRE CONNECTION:
CVME3MINIITF AND CVME3MINIITFWiEth .................................................................................................... 30
3.6.16.- MEASURING SINGLEPHASE NETWORKS, PHASE TO NEUTRAL, WITH A 2WIRE CONNECTION:
CVME3MINIMC AND CVME3MINIMCWiEth ..................................................................................................... 31
3.6.17.- MEASURING SINGLEPHASE NETWORKS, PHASE TO NEUTRAL, WITH A 2WIRE CONNECTION:
CVME3MINIFLEX AND CVME3MINIFLEXWiEth ...............................................................................................32
4. OPERATION....................................................................................................................................................................33
4.1.- MEASURING PARAMETERS....................................................................................................................................34
4.2.- KEYBOARD FUNCTIONS .........................................................................................................................................36
4.3.- DISPLAY.................................................................................................................................................................37
4.4.- LED INDICATORS................................................................................................................................................... 38
4.5.- DIGITAL INPUT (Models CVM-E3-MINI-xxx)........................................................................................................ 38
4.6.- DIGITAL OUTPUT (Models CVM-E3-MINI-xxx)......................................................................................................39
4
CVM-E3-MINI
Instruction Manual

5. DISPLAY........................................................................................................................................................................ 40
5.1.- ANALYZER PROFILE .............................................................................................................................................. 40
5.1.1.- MAXIMUM VALUES.........................................................................................................................................43
5.1.2.- MINIMUM VALUES .........................................................................................................................................43
5.1.3.- MAXIMUM DEMAND.......................................................................................................................................43
5.1.4.- HARMONICS ...................................................................................................................................................43
5.1.5.- DETECTION OF INCORRECT CONNECTION AND INCORRECT DIRECTION OF ROTATION ..............................44
5.2.- e3 PROFILE.............................................................................................................................................................45
5.3.- DEVICE INFORMATION SCREENS...........................................................................................................................49
5.4.- DIGITAL INPUT AND OUTPUT STATUS SCREEN (Models CVM-E3-MINI-xxx) .......................................................49
5.5.- ETHERNET - Wi-Fi - Bluetooth® COMMUNICATIONS SCREENS ............................................................................ 50
5.5.1. Ethernet COMMUNICATIONS: dHCP CONFIGURATION .................................................................................... 50
5.5.2. ETHERNET COMMUNICATIONS: IP ADRESS................................................................................................... 50
5.5.3. ETHERNET COMMUNICATIONS: IP MASK....................................................................................................... 51
5.5.4. ETHERNET COMMUNICATIONS: GATEWAY .....................................................................................................52
5.5.5. ETHERNET COMMUNICATIONS: MAC ADDRESS.............................................................................................52
5.5.6. WIFI COMMUNICATIONS: IP ADDRESS..........................................................................................................53
5.5.7. WIFI COMMUNICATIONS: MAC ADDRESS ......................................................................................................53
5.5.8. WIFI COMMUNICATIONS: SIGNAL LEVEL......................................................................................................53
5.5.9. Bluetooth®COMMUNICATIONS: NAME ..........................................................................................................54
6. CONFIGURATION ...........................................................................................................................................................55
6.1.- PRIMARY VOLTAGE.................................................................................................................................................56
6.2.- SECONDARY VOLTAGE ...........................................................................................................................................56
6.3.- PRIMARY CURRENT...............................................................................................................................................57
6.4.- SECONDARY CURRENT (MODEL CVM-E3-MINI-ITF)............................................................................................ 58
6.5.- FLEX SENSOR ........................................................................................................................................................59
6.6.- NUMBER OF QUADRANTS.....................................................................................................................................59
6.7.- MEASUREMENT CONVENTION.............................................................................................................................. 60
6.8.- MEASUREMENT SYSTEM ..................................................................................................................................... 60
6.9.- MAXIMUM DEMAND INTEGRATION PERIOD......................................................................................................... 61
6.10.- DELETING MAXIMUM DEMAND ..........................................................................................................................62
6.11.- DELETING MAXIMUM AND MINIMUM VALUES....................................................................................................63
6.12.- DELETING ENERGY VALUES................................................................................................................................63
6.13.- ENABLE HARMONICS DISPLAY SCREEN. ............................................................................................................64
6.14.- kgC02CARBON EMISSION RATIO OF CONSUMED ENERGY ................................................................................64
6.15.- kgC02CARBON EMISSION RATIO OF GENERATED ENERGY ...............................................................................65
6.16.- COST RATIO OF CONSUMED ENERGY ................................................................................................................ 66
6.17.- COST RATIO OF GENERATED ENERGY.................................................................................................................67
6.18.- PROGRAMMING ALARM : DIGITAL OUTPUT T1.................................................................................................. 68
6.18.1. MAXIMUM VALUE...........................................................................................................................................70
6.18.2. MINIMUM VALUE...........................................................................................................................................70
6.18.3. CONNECTION TIME DELAY ............................................................................................................................ 71
6.18.4. HYSTERESIS VALUE....................................................................................................................................... 71
6.18.5. LATCH ............................................................................................................................................................72
6.18.6. LATCH TIME ...................................................................................................................................................73
6.18.7. DISCONNECTION TIME DELAY ......................................................................................................................73
6.18.8. CONTACT STATUS..........................................................................................................................................74
6.18.9. KILOWATTS PER PULSE ................................................................................................................................74
6.18.10. PULSE WIDTH ..............................................................................................................................................75
6.19.- OPERATING MODE OF DIGITAL INPUT (Models CVM-E3-MINI-xxx)...................................................................76
6.20.- TARIFF SELECTION (Models CVM-E3-MINI-xxx-WiEth).....................................................................................77
6.21.- BACKLIGHT, TURNING ON THE BACKLIT DISPLAY...............................................................................................77
6.22.- RS-485 COMMUNICATIONS (Models CVM-E3-MINI-xxx) ..................................................................................78
6.22.1.- MODBUS PROTOCOL: BAUD RATE................................................................................................................79
6.22.2.- MODBUS PROTOCOL: PERIPHERAL NUMBER .............................................................................................79
6.22.3.- MODBUS PROTOCOL: PARITY ..................................................................................................................... 80
6.22.4.- MODBUS PROTOCOL: DATA BITS .................................................................................................................81
6.22.5.- MODBUS PROTOCOL : STOP BITS ................................................................................................................ 81
6.22.6.- BACnet PROTOCOL : BAUD RATE.................................................................................................................82
6.22.7.- BACnet PROTOCOL : ID.................................................................................................................................82
6.22.8.- BACnet PROTOCOL : MAC ADDRESS........................................................................................................... 83
5
Instruction Manual
CVM-E3-MINI

Note: Devices images are for illustrative purposes only and may differ from the actual device.
6.23.- LOCKING THE PROGRAMMING............................................................................................................................84
6.23.1.- PASSWORD...................................................................................................................................................85
7. CVME3MINIXXX : RS485 COMMUNICATIONS .........................................................................................................86
7.1.- CONNECTIONS ........................................................................................................................................................86
7.2.- MODBUS PROTOCOL..............................................................................................................................................87
7.2.1.- READING EXAMPLE : Funtion 0x04. ..............................................................................................................87
7.2.2.- WRITING EXAMPLE : Funtion 0x05. ..............................................................................................................87
7.3.- MODBUS COMMANDS .......................................................................................................................................... 88
7.3.1. MEASUREMENT VARIABLES ........................................................................................................................... 88
7.3.2. ENERGY VARIABLES ........................................................................................................................................ 91
7.3.3. VOLTAGE AND CURRENT HARMONICS. ...........................................................................................................93
7.3.4. DELETING PARAMETERS................................................................................................................................96
7.3.5. POWER STATUS ..............................................................................................................................................97
7.3.6. DETECTION OF INCORRECT DIRECTION OF ROTATION...................................................................................97
7.3.7. DEVICE SERIAL NUMBER................................................................................................................................97
7.3.8. DIGITAL INPUT: PULSE COUNTER ..................................................................................................................98
7.3.9. DEVICE CONFIGURATION VARIABLES.............................................................................................................98
7.4.- BACnet PROTOCOL...............................................................................................................................................103
7.4.1.- MAPA PICS .................................................................................................................................................... 103
8. CVME3MINIXXXWIETH : COMMUNICATIONS........................................................................................................ 107
8.1.- USAGE ENVIRONMENT AND HEALTH .................................................................................................................. 107
8.2.- Wi-Fi COMMUNICATIONS.................................................................................................................................... 107
8.3.- Bluetooth® COMMUNICATIONS...........................................................................................................................108
8.4.- MOBILE APP ........................................................................................................................................................108
8.5.- CONFIGURATION WEB PAGE ...............................................................................................................................109
9. TECHNICAL FEATURES................................................................................................................................................. 111
10. MAINTENANCE AND TECHNICAL SERVICE.................................................................................................................115
11. GUARANTEE ................................................................................................................................................................115
12. EU DECLARATION OF CONFORMITY...........................................................................................................................116
ANNEX A. CONFIGURATION MENUS.................................................................................................................................119
6
CVM-E3-MINI
Instruction Manual

REVISION LOG
Table 1: Revision log.
Date Revision Description
12/17 M170B01-03-17A Initial Version
02/18 M170B01-03-18A Changes in the following sections:
3.3.- 6.17.- 10.
04/18 M170B01-03-18B Changes in the following sections:
3.2.- 3.5.- 5.1.5 - 7.3.6.
09/18 M170B01-03-18B
Changes in the following sections:
2.- 3.2.- 3.4.- 3.5.- 3.6.- 5.- 5.1.4.- 6.4.- 6.7.- 7.3.1.- 7.3.7.1.- 7.3.7.4.
- 7.4.1.- 8.
12/18 M170B01-03-18D Changes in the following sections:
6.1.- 6.2.- 6.4.- 7.3.7.13.
02/19 M170B01-03-19A Changes in the following sections:
7.3.1.- 8.
03/19 M170B01-03-19B Changes in the following sections:
3.6.2.- 3.6.5.
03/19 M170B01-03-19C Changes in the following sections:
3.6.3.- 3.6.6.- 3.6.11.- 3.6.14.- 3.6.17.
08/19 M170B01-03-19D Logo modification and corporate colors.
10/19 M170B01-03-19E
Changes in the following sections:
2.- 3.5.- 3.6.- 4.2.- 4.5.- 4.6.- 5.4.- 5.5.- 6.3.- 6.4.- 6.5.- 6.7.- 6.8.
- 6.17.- 6.19.- 6.20.- 6.22.- 7.- 7.3.7.1.- 7.3.7.4.- 7.3.7.10.- 7.3.7.11 -
7.3.7.12.- 7.3.7.13.- 7.3.7.14.- 8.- 9.
05/20 M170B01-03-20A Changes in the following sections:
9.
06/20 M170B01-03-20B Changes in the following sections:
7.3.1.- 7.3.2.
10/20 M170B01-03-20C Changes in the following sections:
5.5.6.- 8.4.- 9.
12/20 M170B01-03-20D Changes in the following sections:
3.5.1.- 3.5.2.- 7.3.1.- 9.
06/21 M170B01-03-21A Changes in the following sections:
9.
03/22 M170B01-03-22A Changes in the following sections:
6.22.1.- 6.22.6.- 7.3.7.- 7.3.8.15.- 9.-Annex A
12/22 M170B01-03-22B
Changes in the following sections:
2.- 4.1.- 4.5.- 6.18.6.- 6.19.- 6.22.1.- 6.22.6.- 7.3.1.- 7.3.2.- 7.3.4.-
7.3.8.- 7.3.9.8.- 7.3.9.11.- 7.3.9.12.- 7.3.9.15.- 9.- Annex A
SYMBOLS
Table 2: Symbols
Symbol Description
In compliance with the relevant European directive.
Wireless communications using the Bluetooth®protocol.
Device covered by European directive 2012/19/EC. At the end of its useful life, do not
leave the unit in a household waste container. Follow local regulations on electronic
equipment recycling.
DC current
~AC current
7
Instruction Manual
CVM-E3-MINI

1. VERIFICATION UPON RECEPTION
Check the following points when you receive the device:
a) The device meets the specifications described in your order.
b) The device has not suffered any damage during transport.
c) Perform an external visual inspection of the device prior to switching it on.
d) Check that it has been delivered with the following:
- An installation guide,
- 1 retainer to secure the device to the DIN rail,
- 4 connectors.
- 2 terminal covers.
If any problem is noticed upon reception, immediately contact the transport com-
pany and/or CIRCUTOR's after-sales service.
2. PRODUCT DESCRIPTION
The CVM-E3-MINI device measures, calculates and displays the main electrical parameters of the
following networks: single-phase, two-phase, with and without neutral, balanced three-phase, with
ARON measurements or unbalanced.The measurement will be taken in RMS with the three AC voltage
inputs and three current inputs.
There are 6 versions of the device, in accordance with current input:
CVM-E3-MINI-ITF and CVM-E3-MINI-ITF-WiEth, indirect current measurement with/5A or
/1A transformers.
CVM-E3-MINI-MC and CVM-E3-MINI-MC-WiEth, indirect current measurement with effi-
cient MC1 and MC3 series transformers.
CVM-E3-MINI-FLEX and CVM-E3-MINI-FLEX-WiEth, current measurement through Ro-
gowski sensors.
Table 3: Models.
Models Pulse
outputs
Digital
input
Communications
RS-485 Ethernet Wi-Fi Bluetooth®
CVM-E3-MINI-ITF   
CVM-E3-MINI-ITF-WiEth   
CVM-E3-MINI-MC   
CVM-E3-MINI-MC-WiEth   
CVM-E3-MINI-FLEX   
CVM-E3-MINI-FLEX-WiEth   
8
CVM-E3-MINI
Instruction Manual

The device features:
- 3 keys that allow you to browse between the various screens and program the device.
- 2 indicator LEDs: CPU and ALARM.
- LCD display, displays all parameters.
Note: Devices with software version v1.xx cannot be upgraded to version v2.xx and vice versa.
9
Instruction Manual
CVM-E3-MINI

3. DEVICE INSTALLATION
3.1.- PRIOR RECOMMENDATIONS
In order to use the device safely, it is critical that individuals who handle it follow the
safety measures set out in the standards of the country where it is being used, use the
necessary personal protective equipment, and pay attention to the various warnings
indicated in this instruction manual.
The CVM-E3-MINI device must be installed by authorised and qualified staff.
The power supply plug must be disconnected and measuring systems switched off before handling, al-
tering the connections or replacing the device. It is dangerous to handle the device while it is powered.
Also, it is critical to keep the cables in perfect condition in order to avoid accidents, personal injury and
damage to installations.
The manufacturer of the device is not responsible for any damage resulting from failure by the user
or installer to heed the warnings and/or recommendations set out in this manual, nor for damage
resulting from the use of non-original products or accessories or those made by other manufacturers.
If an anomaly or malfunction is detected in the device, do not use it to take any measurements.
Inspect the work area before taking any measurements. Do not take measurements in dangerous ar-
eas or where there is a risk of explosion.
Disconnect the device from the power supply (device and measuring system power
supply) before maintaining, repairing or handling the device's connections.
Please contact the after-sales service if you suspect that there is an operational fault
in the device.
10
CVM-E3-MINI
Instruction Manual

3.2.- INSTALLATION
The device must be installed on an electric panel or enclosure, attached to a DIN rail (IEC 60715).
The minimum recommended distance between rails for installing the CVM-E3-MINI device is 150 mm.
Terminals, opening covers or removing elements can expose parts that are hazardous
to the touch while the device is powered. Do not use the device until it is fully installed.
The device must be connected to a power circuit that is protected with gl (IEC 269) or M type fuses with
a rating of 0.5 to 2 A. It must be fitted with a circuit breaker or equivalent device, in order to be able to
disconnect the device from the power supply network.
The power and voltage measuring circuit must be connected with cables that have a minimum
cross-section of 1mm2.
The secondary line of the current transformer will have a minimum cross-section of 2.5 mm2.
The temperature rating of insulation of wires connected to the device will be at minimum 62ºC.
3.3.- PANEL MOUNTING ACCESSORY (72 x 72 mm)
Note: The 72 x 72 mm panel mounting accessory is an accessory that is sold separately.
CIRCUTOR has a panel mounting accessory of the CVM-E3-MINI equipment so that it can be installed
on 72 x 72 mm panels.
Figure 1: CVM-E3-MINI with panel mounting accessory.
Figure 2 shows the installation of the panel mounting accessory to the CVM-E3-MINI.
Disconnect all power supplies and measuring equipment from the device before carry-
ing out the installation of the panel mounting accessory.
11
Instruction Manual
CVM-E3-MINI

Figure 2: Installation of the panel mounting accessory.
Table 4: Technical features.
Technical features
Protection degree IP40
Enclosure Self-extinguishing V0 plastic
68 mm
68 mm
Figure 3: Panel cut-out.

12
CVM-E3-MINI
Instruction Manual

3.4.- CVM-E3-MINI-FLEX: ROGOWSKI SENSORS
The CVM-E3-MINI-FLEX model measures currents using flexible sensors, based on the Rogowski coil
principle.
The flexibility of the sensor allows it to measure an alternating current irrespective of the position of
the conductor.
CIRCUTOR has 1 Rogowski sensor model that can be used with the CVM-E3-MINI-FLEX: FLEX-MAG.
Table 6 shows the connection of the sensors and Table 5 the maximum position error.
Note: For more information, consult the corresponding sensor guide.
Table 5: Position error.
Position Error
A
B
A± 1%
BA ± 3%
Table 6: Probe cable terminal connections
Probe cable terminal connections
FLEX-MAG
Canal de medida / Measuring channel
Común / Common
Shield
Black : Shield (SHLD)
Blue: Common (C)
Green: Measuring channel (L1, L2, L3, N)
13
Instruction Manual
CVM-E3-MINI

3.5.- DEVICE TERMINALS
3.5.1.- MODELS CVME3MINIITF AND CVME3MINIMC
A1
A2
10
11
12
13
10
11
12
13
1
2
S
9
8
7
3
4
5
6
A
B
2
3
4
5
6
A
B
S
9
8
7
1
Figure 4: CVM-E3-MINI-ITF/-MC /-FLEX terminals: Up - Down
Table 7: Device terminals: CVM-E3-MINI-ITF and CVM-E3-MINI-MC
Device terminals
A1: ~+, Power supply 4: S2, current input L2
A2: ~ -, Power supply 5: S1, current input L3
10: VL1, voltage input L1 6: S2, current input L3
11: VL2, voltage input L2 A: A+, RS-485
12: VL3, voltage input L3 B: B-, RS-485
13: N, Neutral voltage input S: S, GND for RS-485 and digital inputs
1: S1, current input L1 9: I1, Digital input 1 or selection rate
2: S2, current input L1 8: O1, Digital output 1
3: S1, current input L2 7: CO, Common digital outputs
3.5.2.- MODEL CVME3MINIFLEX
Table 8: Device terminals: CVM-E3-MINI-FLEX
Device terminals
A1: ~+, Power supply 4: Without connecting
A2: ~ -, Power supply 5: C, Common current input
10: VL1, voltage input L1 6: SHLD,GND for current inputs
11: VL2, voltage input L2 A: A+, RS-485
12: VL3, voltage input L3 B: B-, RS-485
13: N, Neutral voltage input S: S, GND for RS-485 and digital inputs
1: L1, current input L1 9: I1, Digital input 1 or selection rate
2: L2, current input L2 8: O1, Digital output 1
3: L3, current input L3 7: CO, Common digital outputs
14
CVM-E3-MINI
Instruction Manual

3.5.3.- MODELS CVME3MINIITFWiEth AND CVME3MINIMCWiEth
A1
A2
10
11
12
13
10
11
12
13
1
2
3
4
5
6
Ethernet
Figure 5: CVM-E3-MINI-ITF/-MC/-FLEX-WiEth terminals: Up - Down.
Table 9: Device terminals: CVM-E3-MINI-ITF-WiEth and CVM-E3-MINI-MC-WiEth
Device terminals
A1: ~+, Power supply 2: S2, current input L1
A2: ~-, Power supply 3: S1,current input L2
10: VL1, voltage input L1 4: S2,current input L2
11: VL2, voltage input L2 5: S1,current input L3
12: VL3, voltage input L3 6: S2,current input L3
13: N,Neutral voltage input Ethernet: Ethernet connection
1: S1,current input L1
3.5.4.- MODEL CVME3MINIFLEXWiEth
Table 10: Device terminals: CVM-E3-MINI-FLEX-WiEth
Device terminals
A1: ~+, Power supply 2: L2,current input L2
A2: ~-, Power supply 3: L3,current input L3
10: VL1, voltage input L1 4: Without connecting
11: VL2, voltage input L2 5: C,Common current input
12: VL3, voltage input L3 6: SHLD,GND for current inputs
13: N,Neutral voltage input Ethernet: Ethernet connection
1: L1,current input L1
15
Instruction Manual
CVM-E3-MINI

3.6.- CONNECTION DIAGRAM
3.6.1.- MEASURING THREEPHASE NETWORKS WITH A 4WIRE CONNECTION: CVME3MINIITF
AND CVME3MINIITFWiEth
Measurement system: 4-3Ph
VL1 VL2 VL3 N
L1
L2
L3
N
N
V
L3
L2
V
L1 V
VL1 VL2 VL3
ab
A B
ab
A B
CARGA / LOAD
13
12
11
10
Alimentación Auxiliar
Power Supply
S1
S2
S1
S2
S1
S2
S1 S2
P1 P2 S1 S2
P1 P2 S1 S2
P1 P2
1
2
3
4
5
6
Figure 6: Three-Phase measuring with a 4-wire connection: CVM-E3-MINI-ITF and CVM-E3-MINI-ITF-WiEth.
To guarantee the insulation of the device and its category, it is necessary
to earth the S2 terminals of the transformers.
16
CVM-E3-MINI
Instruction Manual

3.6.2.- MEASURING THREEPHASE NETWORKS WITH A 4WIRE CONNECTION: CVME3MINIMC
AND CVME3MINIMCWiEth.
Measurement system: 4-3Ph
VL1 VL2 VL3 N
L1
L2
L3
N
N
V
L3
L2
V
L1 V
VL1 VL2 VL3
ab
A B
ab
A B
CARGA / LOAD
13
12
11
10
Alimentación Auxiliar
Power Supply
S1
S2
S1
S2
S1
S2
1
2
3
4
5
6
3P1 2P1 1P1
3P2 2P2 1P2
Brown/Green
Grey/Pink
Green/White
Red/Blue
Figure 7: Three-Phase measuring with a 4-wire connection:CVM-E3-MINI-MC and CVM-E3-MINI-MC-WiEth.
Note: Do not connect MC current transformers to ground.
The MC transformer secondary value is set to 0.250 A (fixed value).
17
Instruction Manual
CVM-E3-MINI

3.6.3.- MEASURING THREEPHASE NETWORKS WITH A 4WIRE CONNECTION: CVME3MINIFLEX
AND CVME3MINIFLEXWiEth
Measurement system: 4-3Ph
VL1 VL2 VL3 N
L1
L2
L3
N
N
V
L3
L2
V
L1 V
VL1 VL2 VL3
ab
A B
ab
A B
CARGA / LOAD
13
12
11
10
Alimentación Auxiliar
Power Supply
L1
L2
L3
SHLD
C
1
2
3
4
5
6
L1
C
SHLD
L2 L3
Figure 8: Three-Phase measuring with a 4-wire connection: CVM-E3-MINI-FLEX and CVM-E3-MINI-FLEX-WiEth.
It is mandatory connect the SHLD terminal of the probe.
18
CVM-E3-MINI
Instruction Manual

3.6.4.- MEASURING THREEPHASE NETWORKS WITH A 3WIRE CONNECTION: CVME3MINIITF
AND CVME3MINIITFWiEth
Measurement system: 3-3Ph
VL1 VL2 VL3
L1
L2
L3
V L3
L2
V
L1 V
VL1 VL2 VL3
ab
AB
ab
A B
CARGA / LOAD
12
11
10
S1
S2
S1
S2
S1
S2
S1 S2
P1 P2 S1 S2
P1 P2 S1 S2
P1 P2
1
2
3
4
5
6
Alimentación Auxiliar
Power Supply
Figure 9: Three-Phase measuring with a 3-wire connection: CVM-E3-MINI-ITF and CVM-E3-MINI-ITF-WiEth.
To guarantee the insulation of the device and its category, it is necessary
to earth the S2 terminals of the transformers.
19
Instruction Manual
CVM-E3-MINI

3.6.5.- MEASURING THREEPHASE NETWORKS WITH A 3WIRE CONNECTION: CVME3MINIMC
AND CVME3MINIMCWiEth
Measurement system: 3-3Ph
VL1 VL2 VL3
L1
L2
L3
V L3
L2
V
L1 V
VL1 VL2 VL3
ab
AB
ab
A B
CARGA / LOAD
12
11
10
Alimentación Auxiliar
Power Supply
S1
S2
S1
S2
S1
S2
1
2
3
4
5
6
3P1 2P1 1P1
3P2 2P2 1P2
Brown/Green
Grey/Pink
Green/White
Red/Blue
Figure 10: Three-Phase measuring with a 3-wire connection: CVM-E3-MINI-MC and CVM-E3-MINI-MC-WiEth.
Note: Do not connect MC current transformers to ground.
The MC transformer secondary value is set to 0.250 A (fixed value).
20
CVM-E3-MINI
Instruction Manual
