Cisco Service Control Engine 1000 2xGBE Quick Start Guide,
Release 3.7.x
1Prepare for Installation
2Rack-Mount the SCE 1000
3Connect the Power Supply Units
4Connect the Management Interfaces and Perform Initial System Configuration
5Cable the Line Ports
6Completing the Installation
7Installing a Service Control Application
8Troubleshoot Startup Problems
9Obtaining Documentation and Submitting a Service Request

2
Revised: June 13, 2011, OL-24144-01
Note This document supports all 3.7.x releases.
1 Prepare for Installation
This section contains warnings, information about tools and parts, site preparation information, and information for
workbench or tabletop installation and rack-mount installation.
Warning This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any
equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for
preventing accidents. To see translations of the warnings that appear in this publication, refer to the translated
safety warnings that accompanied this device.
Only trained and qualified personnel should install, replace, or service this equipment.
Read the installation instructions before you connect the system to its power source.
This unit is intended for installation in restricted access areas. A restricted access area is where access can only be gained by
service personnel through the use of a special tool, lock and key, or other means of security, and is controlled by the authority
responsible for the location.
Voltage is present on the backplane when the system is operating. To reduce risk of an electric shock, keep hands and fingers
out of the power supply bays and backplane areas.
Do not work on the system or connect or disconnect cables during periods of lightning activity.
Before beginning the installation of the SCE 1000, read the Regulatory Compliance and Safety Information for the Cisco Service
Control Engines (SCE) document.
Information About Preparing for Installation
•Site Preparation and Unpacking, page 2
•Tools and Parts, page 2
•Prepare for Rack-Mount Installation, page 3
Site Preparation and Unpacking
•Lift the SCE 1000 platform safely out of the packing container.
•Ensure the power service at the site is suitable for the SCE 1000 platform.
•Check the packing slip to ensure that all the proper components are present.
•Locate and have accessible the Site Log for recording information about this installation.
Tools and Parts
Use the following list of tools and parts as a checklist for preparing for installing the SCE 1000 platform:
•Appropriate cables to connect the SCE 1000 to the network and console terminal
•Tape measure (optional)
•Level (optional)
•Number 1 Phillips screwdriver
•Number 2 Phillips screwdriver
•1/4-inch flat-blade screwdriver
•1/4-inch hex wrench

3
•Grounding kit (shipped with the SCE 1000)
•12 AWG or 2.5 mm copper installation wire with hex or loop connectors for DC power leads (DC power only) Ring
terminals must be UL approved and suitable for 12 AWG wire.
•AC power cords (AC power only, shipped with SCE 1000)
•Rack-mounting kit (shipped with SCE 1000)
– Spare screws for changing bracket position
Prepare for Rack-Mount Installation
Before you begin the rack-mounting tasks, determine the type of rack—four-post or two-post—that you will be using.
Workbench or Tabletop Installation
Figure 1 Tabletop Installation of the SCE 1000 Platform
For a workbench or tabletop installation, verify the following before installing the SCE 1000 platform:
•The SCE 1000 platform is off the floor and has adequate ventilation.
•An adequate chassis ground (earth) connection exists for the SCE 1000 platform.
•The SCE 1000 platform has at least 2 inches (5 cm) of clearance at each side and at least 5 inches (12.7 cm) of clearance at
the rear to allow proper air flow.
Step 1 Remove the adhesive strips from the four rubber feet and affix the feet onto the four marked locations on the bottom
panel of the unit.
Step 2 Place the SCE 1000 platform on the tabletop or workbench.
Cisco SCE 1000
Series
2xGBE
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
GBE-1
SUBLINENET
PWRB ST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
AUX
CONSOLE
MNG 2
MNG 1
1
2
92967

4
2 Rack-Mount the SCE 1000
This section provides information for rack-mounting the SCE 1000 platform.
•SCE 1000 Mounting Brackets, page 4
•Attach the Brackets to the SCE 1000, page 5
•Installing the Crossrail Supports (Four-post rack only), page 6
•Mount the System to the Rack, page 7
SCE 1000 Mounting Brackets
There are two standard types of equipment racks, and the appropriate brackets for each are provided in the enclosed kit.
•19” rack with front rack posts — the mounting kit includes two mounting brackets as illustrated below:
Figure 2 Mounting Bracket for 2-post Racks
•19” rack with front and back rack posts — in addition to the mounting brackets illustrated below, the mounting kit includes
two crossrail supports that the unit slides onto.
Figure 3 Mounting Bracket for 4-post Racks
The SCE 1000 mounts to the two front rack posts with brackets that attach to the front of the SCE 1000. The inside width
between the two posts or mounting strips (left and right) must be at least 17.3 inches (44 cm).
Note Remember to leave a two-inch (5 cm) clearance on both sides of the SCE 1000 and at the rear for adequate airflow for
the inlet and exhaust vents.
210429
210430

5
Attach the Brackets to the SCE 1000
Before installing the SCE 1000 in the rack, you must first install an appropriate rack-mount bracket on each side of the front
of the SCE 1000, as illustrated in the following figures.
Figure 4 Attaching the Mounting Brackets (4-post)
Figure 5 Attaching the Mounting Brackets (2-post)
To install the rack-mount brackets on the SCE 1000 chassis, complete the following steps:
Before installing the SCE 1000 in the rack, you must first install a rack-mount bracket on each side of the front of the SCE 1000.
Step 1 Align the rack-mount bracket to the side of the SCE 1000. Choose the proper bracket for your installation (2-post rack
or 4-post rack) as illustrated in Rack-Mount the SCE 1000
Step 2 Insert and tighten three screws.
Step 3 Repeat steps 1 and 2 on the other side of the SCE 1000.
If mounting the SCE 1000 in a rack with only two posts, skip to Mount the System to the Rack.
If mounting the SCE 1000 in a rack with four posts, proceed to the next step, Installing the Crossrail Supports
(Four-post rack only), page 6).
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
PWRBST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
AUX
CONSOLE
MNG2
MNG1
Cisco SCE 1000
Series
2xGBE
GBE-1
SUB LINE NET
1 2
210418
LINK RX TX
RX MM TX
LINK RX TX
RX MM TX
PWR BSTATUS
PWR ABYPASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
AUX
CONSOLE
MNG 2
MNG 1
Cisco SCE 1000
Series
2xGBE
GBE-1
SUB LINE NET
210603
1 2

6
Installing the Crossrail Supports (Four-post rack only)
This section provides information for assembling the crossrail supports and attaching them to the rack.
When mounting in a rack with four posts (front and back) the two crossrail supports are mounted one on each side of the rack.
The SCE 1000 then slides into these crossrails, which support the weight of the unit.
•Assemble the Crossrail Supports, page 6
•Attach the Crossrail Supports to the Rack, page 6
Assemble the Crossrail Supports
Step 1 Assemble the two crossrail supports. Use three screws for each crossrail assembly.
Figure 6 Assembling the Slider Brackets
Step 2 Make sure that they are oriented so that both crossrails will support the SCE 1000 when they are attached to the rack.
Attach the Crossrail Supports to the Rack
Step 1 Align the crossrail supports with the side of the rack, parallel to the floor.
Figure 7 Attaching the Crossrails to the Rack
Step 2 Insert and tighten two screws to the front posts or mounting strips of the rack
Step 3 Insert and tighten two screws to the Back posts of the rack.
Step 4 Repeat steps 2 and 3 on the other side of the rack, keeping the brackets flush against the posts and parallel to the
supporting bracket on first side of the rack.
321
92777
321
92778

7
Mount the System to the Rack
When the appropriate mounting brackets are securely installed, the SCE 1000 can be installed into the rack.
Summary Steps
1. Make sure that the rack brakes are locked or that the rack is otherwise stabilized.
2. Position the SCE 1000 so that the front end is closest to you, and lift it carefully to place it into the rack. To prevent injury,
avoid sudden twists or moves.
3. Slide the SCE 1000 into the rack, pushing it back until the brackets (installed at the front of the SCE 1000) meet the
mounting strips or posts on both sides of the rack.
4. While keeping the brackets flush against the posts or mounting strips, align the holes in the brackets with the holes on the
rack or mounting strip.
5. For each bracket, insert and tighten two appropriate screws to the rack.
Detailed Steps
Step 1 Make sure that the rack brakes are locked or that the rack is otherwise stabilized.
Figure 8 Sliding the SCE Platform into the Rack
Step 2 Position the SCE 1000 so that the front end is closest to you, and lift it carefully to place it into the rack. To prevent
injury, avoid sudden twists or moves.
Step 3 Slide the SCE 1000 into the rack, pushing it back until the brackets (installed at the front of the SCE 1000) meet the
mounting strips or posts on both sides of the rack.
A rack with both front and back posts will have the crossrail supports installed. Slide the SCE 1000 onto these crossrails
and push it all the way back.
LINKRX
CiscoSCE2000
Series
4xGBE
TX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
GBE-1
SUBLINENET
PWRBST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
GBE-2
SUBLINE/CASCADENET
AUX
CONSOLE
MNG2
MNG1
LINKRXTX
RXMMT
X
LINKRXTX
RXMMTX
PWRB ST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
AUX
CONSOLE
MNG2
MNG1
Cisco SCE 1000
Series
2xGBE
GBE-1
SUB LINENET
1 2 3
210419

8
Step 4 While keeping the brackets flush against the posts or mounting strips, align the holes in the brackets with the holes on
the rack or mounting strip.
Figure 9 Securing the SCE Platform to the Rack
Step 5 For each bracket, insert and tighten two appropriate screws to the rack.
Note Since the brackets support the weight of the entire SCE 1000 chassis, be sure to use all four screws to fasten the two
rack-mount brackets to the rack posts.
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
PWRB ST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
AUX
CONSOLE
MNG2
MNG1
Cisco SCE 1000
Series
2xGBE
GBE-1
SUB LINENET
321
210420

9
3 Connect the Power Supply Units
This section provides information for grounding the SCE 1000 platform and connecting the AC or DC power supply units.
•Connect the Chassis Ground, page 9
•Connecting the Power, page 10
Connect the Chassis Ground
Figure 10 Grounding the Unit (AC)
IN POWER B OK IN POWER A OK
BYP
ASS 1
210421
21

10
Figure 11 Grounding the Unit (DC)
A Grounding kit is provided with each SCE 1000. Use this Grounding kit to properly ground the SCE 1000 chassis.
When installing the unit, the chassis ground connection must always be made first and disconnected last.
Step 1 On the rear panel of the SCE 1000, locate the chassis grounding connector (refer to the appropriate figure for an AC-
or DC-powered SCE 1000 above).
Step 2 Attach the grounding cable (green and yellow colored cable), firmly fastening the (enclosed) hex nuts and spring
washers with a #¼” hex wrench (refer to the appropriate figure for an AC- or DC-powered SCE 1000 above).
The other side of the grounding cable must be connected to the site equivalent of the AC earth.
Connecting the Power
The following sections describe how to reconnect the AC or DC power:
•Connect the DC-Input Power Supply Unit, page 11
•Connect the AC-Input Power Supply Unit, page 12
IN POWER B OK IN POWER A OK
BYPASS 1
-48V -48VRTN
Input
48/60Vdc
7A
ON
OFF
-48V -48VRTN
Input
48/60Vdc
7A
ON
OFF
210422
