Cisco TelePresence ISDN GW MSE 8321 User manual

Cisco TelePresence
ISDN GW MSE 8321
Getting started
61-0020-05

2
Contents
General information ................................................................................................................ 3
About the Cisco TelePresence ISDN GW MSE 8321 ........................................ 3
Port and LED location ................................................................................................ 3
LED behavior ................................................................................................................ 4
Installing the ISDN gateway .................................................................................................. 6
Step one: Install the ISDN gateway into the MSE 8000 chassis .................. 6
Connecting the ISDN gateway ............................................................................................ 9
Your ISDN connection ............................................................................................... 9
Step one: Connect to Ethernet Port A ................................................................. 9
Step two: Connect to the ISDN ports ................................................................... 9
Initial configuration ...............................................................................................................10
Step one: Configure Ethernet Port A settings ................................................10
Step two: Assign an IP address to the ISDN gateway ..................................10
Configuring the ISDN gateway ..........................................................................................11
Step one: Log in to the ISDN gateway ...............................................................11
Step two: Allocate port licences ..........................................................................11
Step three: Set up the ISDN interfaces ..............................................................11
Step four: Configure an H.323 gatekeeper ......................................................12
Step five: Configure the dial plan ........................................................................12
Troubleshooting and technical support information ...............................................15
Calls fail to complete ...............................................................................................15
Using the event log to help solve a problem ..................................................15
Getting more help ....................................................................................................15
Pin outs .......................................................................................................................................16
Disclaimers and notices ........................................................................................................17

General information
3
General information
About the Cisco TelePresence ISDN GW MSE 8321
The Cisco TelePresence ISDN GW MSE 8321 (ISDN GW MSE 8321) is a high
performance video gateway which enables ISDN network connectivity for the Cisco
TelePresence IP-based video infrastructure products as well as IP-based endpoints.
Port and LED location
Figure 1 shows the position of ports on the ISDN gateway.
Figure 1: ISDN GW MSE 8321 front panel
Cisco ISDN GW MSE 8321
Alarm LED
Status LED
Compact Flash
Activity LED
ISDN Ports
Ethernet Port Status LEDs
Ethernet Ports
Power LED
Console Port
ISDN Port Status LEDs

General information
4
LED behavior
Table 1 describes the behavior of the LEDs.
Table 1: ISDN GW MSE 8321 LED behavior
LED Color Indicates
Compact Flash
Activity
Flashing
green
One of:
the ISDN GW MSE 8321 is booting
a configuration change has been made
the configuration is being transferred by FTP
Status Green The ISDN gateway is operating normally
Alarm Red The ISDN gateway is booting or has developed a
fault, for example:
temperature is outside normal limits
battery failure of the internal clock
Refer to the web interface for more information
about the problem (go to Status > Health)
ISDN Port Status, for each ISDN port:
L1 Off There is no connection on this port, or the ISDN
gateway is not receiving framing (also known as
Red Alarm)
Flashing
green
The ISDN gateway is receiving framing, but the far
end is not receiving framing (also known as Yellow
Alarm)
Green The port is connected to the far end
L2 Green Layer 2 connectivity has been achieved with the
ISDN network from this port. This means that
D-channel signaling has been established with the
network
Act Green There is at least one active call using this port.
Data is currently being received on this port

General information
5
Ethernet Port Status, for each Ethernet port:
FDX Green The link has been negotiated as a full-duplex link
Act Green Packets are being transmitted on this port
Link Green The speed of the link from this port, which is
either 10, 100, or 1000 Mbps
Power Blue The ISDN gateway is receiving power from the
MSE 8000 chassis
Table 1: ISDN GW MSE 8321 LED behavior (continued)
LED Color Indicates

Installing the ISDN gateway
6
Installing the ISDN gateway
For information about powering the MSE 8000, refer to the Getting Started Guide on
http://www.tandberg.com/support/video-conferencing-documentation.jsp).
Step one: Install the ISDN gateway into the MSE 8000 chassis
1 Remove the blade or blanking blade from the slot into which you are going to
install the ISDN gateway:
i Using a No.1 Phillips screwdriver, loosen the screws in the retaining latches
with an anti-clockwise quarter turn.
ii Open both retaining latches on the front of the blade or blanking blade.
When open, a retaining latch is at a 90° angle perpendicular to the front of
the blade.
iii Slide out the blade or blanking blade.
2 Open both retaining latches on the front of the ISDN gateway. When open, a
retaining latch is at a 90° angle perpendicular to the front of the blade.
3 Slide the ISDN gateway into the blade slot (as shown in Figure 2) until it stops.
IMPORTANT: Before installing the ISDN GW MSE 8321 into the MSE
8000, and connecting the power supply, you must read the safety
information at
http://www.cisco.com/go/telepresence/safety.
Although blades are hot-swappable parts, you must only remove one
blade at any time. Remove the power from the MSE 8000, if you need to
remove more than one blade at a time.
Before hot-swapping a blade, shut down the blade using the web
interface. Do not shut down a blade during a software upgrade or if the
blade is processing.
You must install either a blade or a blanking blade in each of the ten
positions in the chassis.
The Supervisor blade must be installed into slot 1 of the MSE 8000
chassis.
!
!
!
!

Installing the ISDN gateway
7
4 Simultaneously close both retaining latches on the blade (thereby engaging the
connectors at the rear of the blade) to secure it in the chassis as shown in
Figure 3.
5 Using a No.1 Phillips screwdriver, tighten the screws in the retaining latches
with a clockwise quarter turn.
Figure 2: Inserting a blade into the chassis

Installing the ISDN gateway
8
Figure 3: Closing the retaining latches on the front of a blade

Connecting the ISDN gateway
9
Connecting the ISDN gateway
Your ISDN connection
Outside North America
Check with your network provider to ensure that your incoming ISDN PRI line is
terminated in an NTU/CSU (Network Termination Unit/ Channel Service Unit). If
it is not, then seek their advice regarding the provisioning of such a device. Do not
connect the ISDN gateway directly to an external ISDN line.
Within North America
If your network provider has not terminated all of your incoming ISDN PRI lines
with an NTU/CSU, Cisco recommends that you install a suitably approved CSU to
protect the ISDN gateway from damage by surges on your ISDN PRI lines.
Step one: Connect to Ethernet Port A
Connect an Ethernet cable from Ethernet Port A to an Ethernet switch (rather than a
hub, to minimize interference from other devices on the network). The Ethernet
port is a 10/100/1000 Mbps auto-sensing connection.
Step two: Connect to the ISDN ports
The ISDN gateway uses a standard RJ48C ISDN interface for each PRI port. Use a
single straight-through STP patch cable to connect each PRI port on the ISDN
gateway to your ISDN connection.
For information about the behavior of the ISDN port LEDs, refer to Table 1, ISDN
gateway LED behavior, on page 4.
To reduce the risk of fire, use only 26 AWG or larger telecommunication
line cord.
Only connect to Ethernet Port A, as all initial configuration must be done
on this port. Do not connect anything to Ethernet Port B.
For D-channel signaling to be established, the ISDN gateway must have
found and synchronized with the ISDN network clock. In some
installations, you may have to explicitly request your ISDN provider to
enable the network clock before the link will be established.
i
i

Initial configuration
10
Initial configuration
Step one: Configure Ethernet Port A settings
The default setting for the ISDN gateway Ethernet ports is auto-sensing mode. If the
switch ports to which you connect the ISDN gateway are not also set to auto-sensing
mode, then you need to configure the ISDN gateway Ethernet ports to use the same
speed and duplex mode.
To configure Ethernet Port A, log in to the Supervisor’s web interface and go to
Hardware > Blades. For more information about configuring the port, refer to the
online help accessible from the Supervisor’s web interface.
Step two: Assign an IP address to the ISDN gateway
You can use the Supervisor’s web interface to configure the IP addresses of all blades
installed in the MSE 8000. Note that all blades are supplied with DHCP enabled. You
can either keep this setting or assign static IP addresses to a blade from the
Supervisor’s web interface. To view or configure the IP address of the ISDN gateway,
log in to the Supervisor and go to Hardware > Blades. To access the web interface of
the ISDN gateway, go to Hardware > Blades and click the IP address of that blade.
Only connect to Ethernet Port A, as all initial configuration must be done
on this port. Do not connect anything to Ethernet Port B.
Both ends of the Ethernet connection must be configured in the same
way. For example, either configure both ends of the link to be auto-
sensing or configure both ends to operate at the same speed and duplex.
To establish a 1000Mbps connection, both ends of the link must be
configured as auto-sensing.
i
i
i

Configuring the ISDN gateway
11
Configuring the ISDN gateway
Step one: Log in to the ISDN gateway
All administration of the ISDN gateway is performed via the web interface.
To log in to the ISDN gateway:
1 Log in to the Supervisor’s web interface.
2GotoHardware > Blades and click the IP address of the ISDN gateway.
3Click
Log in and enter the user name admin with no password. The Login
information page is displayed.
Step two: Allocate port licences
Port licenses must be allocated to the ISDN gateway from the Supervisor's Port
licenses page. Refer to the online help for assistance.
Step three: Set up the ISDN interfaces
1 In the web interface, go to Settings > ISDN.
2 Select the ISDN interface type to match that of your installation; E1 is typically
used in the UK and mainland Europe, T1 (USA and Canada) in North America,
and T1(Japan) in Japan.
3 Complete the other settings as required by your network, referring to the online
help for further information.
4Click
Apply changes to save any changes you have made to the configuration.
5 Restart the ISDN gateway (this is only necessary if you changed the ISDN
configuration). To do this:
iGotoSettings > Shutdown, and click Shut down ISDN GW.
ii Confirm that you want to shut down the ISDN gateway.
iii Click Restart ISDN GW.
6 When the ISDN gateway has restarted, log in to the web interface again, and go
to Settings > ISDN ports.
Cisco recommends that you change the admin account to use a password
as soon as possible. To do that, click Change password on the Login
information page or go to Users, click the admin link, and provide the
required user information.
i

Configuring the ISDN gateway
12
7 Complete the settings for ISDN Port 1 as required by your network, referring to
the online help for further information. Note that all ISDN ports on the ISDN
gateway are enabled by default.
8Click
Apply changes to save your configuration changes to the ISDN port.
9 Complete the settings for other ISDN ports as required by your network,
referring to the online help for further information.
Step four: Configure an H.323 gatekeeper
If you have H.323 endpoints, using an H.323 gatekeeper can make it easier for callers
to make their call. You can configure the ISDN gateway to use an external gatekeeper
or its own built-in gatekeeper.
To configure the use of an H.323 gatekeeper, go to Settings > H.323. Typically you
may want to add a Dial plan prefix for voice calls (for example, 9) and another for
video calls (for example, 8).
For more information refer to the online help topic: “Configuring gatekeeper
settings”.
Step five: Configure the dial plan
The default behavior of the ISDN gateway is to reject all calls. You must configure a
dial plan to allow permitted calls to be placed.
Below are some simple configurations for dial plan rules. Refer to the online help for
more information on dial plan rule syntax.
IP to ISDN dial plan setup
This example allows IP codecs to dial (via a gatekeeper) the ‘phone number of the
destination endpoint, using a prefix of 9 for audio calls and 8 for video calls. It
assumes that you require both video and voice calls to be made from your IP network
to ISDN and that you have set up dial plan prefixes 8 and 9 on the ISDN gateway’s
Settings > H.323 page.
1 In the web interface, go to Dial plan > IP to ISDN and click Add rule.
2For
Condition, select Called number matches and enter the correct match for
example 9(D*).
3For
Action, select Call this number and enter $1.
4For
Call type, select Telephone.

Configuring the ISDN gateway
13
5 Leave the other values unchanged. Click Add rule to add the rule to the dial
plan.
6 Repeat steps 1 to 5 to create a second dial plan to accept and forward the video
calls with the correct format in Called number matches, for example 8(D*)
and for Call type, select Video.
ISDN to IP dial plan setup
Options 1 and 2 will automatically handle both voice and video calls.
Option 1 - This example assumes that you have a PRI line that has 100 numbers (00
to 99) associated with it and that all your endpoints are registered to a gatekeeper
with registrations in the range 5900 - 5999.
1GotoDial plan > ISDN to IP, and click Add rule.
2For
Condition, select Called number matches and enter the correct match for
example D*(DD), which will match the last 2 digits of the dialed number. To
match the last 3 digits, use D*(DDD).
3For
Action, select Call this number and enter 59$1.
4For
Call type, select Video.
5 Leave the other values unchanged. Click Add rule to add the rule to the dial
plan.
Option 2 - This example assumes that you have a PRI line which has 1 number
associated with it but you require access to multiple endpoints on the IP side. When
you dial you will be greeted by the ISDN gateway's auto attendant and using TCS-4
or DTMF you can dial the extension of the IP endpoint, if known.
1GotoDial plan > ISDN to IP, and click Add rule.
2For
Condition, select Match any called number.
3For
Action, select Enter the auto attendant + TCS-4.
4For
Call type, select Video.
5 Leave the other values unchanged. Click Add rule to add the rule to the dial
plan.

Configuring the ISDN gateway
14
There are a number of different ways in which you can use the dial plan. For
example, you can use the dial plan to link specific bandwidths to certain prefixes,
thereby enabling users to use the correct bandwidth for an IP to ISDN call. You can
also use the dial plan to enable the ISDN gateway to join incoming ISDN calls to the
correct conference on an MCU. These dial plan configurations — and the dial plan
rule syntax — are explained in greater detail and with supporting examples in the
online help accessible from the web interface.

Troubleshooting and technical support information
15
Troubleshooting and technical support information
Refer to this section if you are experiencing difficulties with the ISDN gateway.
Ensure that you have followed the instructions in this guide when installing and
configuring the ISDN gateway.
Calls fail to complete
If outgoing calls fail to complete, check that you have configured the ISDN gateway
and all other equipment correctly, paying particular attention to the number you are
trying to call. Remember that endpoints may be busy when you call them.
Using the event log to help solve a problem
You can use the event log to produce debugging information to assist technical
support in solving any problems. Event logging capture filter topics are set by default
to Errors, warnings and information. Do not change the capture filter topic level
without the guidance of technical support.
Getting more help
Cisco recommends registering your product at http://www.tandberg.com/
services/video-conferencing-product-registration.jsp in order to receive
notifications about the latest software and security updates. New feature and
maintenance releases are published regularly, and we recommend that the ISDN
gateway’s software is always kept up to date.
If you experience any problems when configuring or using the ISDN gateway, consult
the online help (available within the UI of your ISDN gateway) for an explanation of
how its individual features and settings work. If you cannot find the answer you need,
check on the web site at http://www.tandberg.com/support to make sure that the
ISDN gateway is running the most up-to-date software and for further relevant
documentation.
You or your reseller can get help from our support team by raising a case at http://
www.tandberg.com/support/video-conferencing-online-support.jsp. Make sure
you have the following information ready:
The serial number and product model number of the unit
The software build number which can be found on the product user interface
Your contact email address or telephone number

Pin outs
16
Pin outs
The pin numbering for the PRI ports on the ISDN gateway is shown in Figure 4. The
pin assignments for the PRI ports are shown in Table 2:
Figure 4: Pin numbering for PRI ports
Table 2: Pin assignments for PRI ports
Pin number Signal
1 Receive -
2 Receive +
3 Not connected
4Transmit-
5 Transmit +
6 Not connected
7 Not connected
8 Not connected
8 7 6 5 4 3 2 1

Disclaimers and notices
17
Disclaimers and notices
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL
ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND
RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE
PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE
FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT
ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND
ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE
SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE
FOR A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program
developed by the University of California, Berkeley (UCB) as part of UCB's public domain
version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the
University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND
SOFTWARE OF THESE SUPPLIERS ARE PROVIDED "AS IS" WITH ALL FAULTS. CISCO AND THE
ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF
DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL,
CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST
PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE
THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S.
and other countries. A listing of Cisco's trademarks can be found at
www.cisco.com/go/
trademarks . Third party trademarks mentioned are the property of their respective owners. The
use of the word partner does not imply a partnership relationship between Cisco and any other
company. (1005R)
Any Internet Protocol (IP) addresses and phone numbers used in this document are not
intended to be actual addresses and phone numbers. Any examples, command display output,
network topology diagrams, and other figures included in the document are shown for
illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative
content is unintentional and coincidental.
© November 2010, Cisco Systems, Inc. All rights reserved.
